Product Type	Security Camera
Brand	Setti+
Model	SC930
Power Supply	12V DC, 1.0A
Power Adapter Input	100-240V~, 0.5A, 50/60Hz
Power Adapter Output	12V --- 1A, 12W
Protection Rating	IP65 (dustproof and water resistant)
Video Resolution	2304 x 1296 pixels
Monitoring Angle	200° horizontal
Motion Detection Range	15 m
Night Vision	IR LEDs for low-light monitoring
Operating Temperature	-10°C to +55°C
Ethernet Connector	RJ45
Wi-Fi Frequency	2.4 GHz (2412-2472 MHz)
Max Transmission Power	<10 dBm
Memory Card Support	Micro SD up to 128 GB
System Requirements	Android, iOS
Accessories Included	Camera with cables, power adapter, mounting kit
Audio	Built-in microphone and loudspeaker (two-way audio)
Installation	Wall mount with rawlplugs; Ethernet cable waterproofing; PoE support
App Control	Setti+ app for remote monitoring
Cleaning	Soft damp cloth; do not use chemicals
Storage	Disconnect power; store in dry place
Warranty	24 months from date of delivery (conditions apply)

Frequently Asked Questions - SC930 Setti+

How do I reset the camera to factory settings?

Open the memory card slot cover, press and hold the RESET button for 5 seconds. The camera will emit an audible signal and enter configuration mode.

What is the maximum microSD card capacity supported?

The camera supports microSD cards up to 128 GB. Insert the card gently into the slot and lock it.

Is the camera suitable for outdoor use?

Yes, it has an IP65 protection rating, meaning it is dustproof and water resistant. However, it is recommended to install the camera under a roof and avoid direct sunlight.

How do I connect the camera to Wi-Fi?

Download the Setti+ app, create an account, and log in. After powering the camera and entering configuration mode, press '+' in the app, select Security > SC930 Camera. Follow the prompts to select your 2.4 GHz Wi-Fi network, enter the password, and scan the QR code displayed on your phone with the camera lens.

Can I use Power over Ethernet (PoE)?

Yes, you can power the camera via Ethernet using the supplied PoE adapters. Connect the output adapter to the camera's Ethernet and power inputs, then connect the input adapter to the router and power supply. Use an Ethernet cable with RJ45 connectors to link the adapters.

What should I do if the camera does not connect to Wi-Fi?

Ensure your router operates on 2.4 GHz (not 5 GHz) and that the network names for 2.4 GHz and 5 GHz are different. Check Wi-Fi signal strength near the camera. If the issue persists, reset the camera and reconfigure.

How do I clean the camera?

Use a softly damp cloth to wipe the camera. Do not use chemicals or abrasives, as they may damage the device.

What is the warranty period?

The warranty is 24 months from the date of delivery. It covers manufacturing defects but excludes damage from improper use, mechanical damage, or unauthorized repairs.

Can I view the camera remotely?

Yes, after successful configuration via the Setti+ app, you can remotely monitor the camera from your smartphone or tablet anywhere with internet access.

Does the camera have audio capabilities?

Yes, the camera features a built-in microphone and loudspeaker, enabling two-way audio communication through the app.

USER MANUAL SC930 Setti+

WARUNKI BEZPIECZEŃSTWA I ZAGROŻENIA

UWAGA! ZALECANY JEST MONTAŻ KAMERY POD ZADASZENIEM I UNIKANIE MOCNO NASŁONECZNIONYCH MIEJSC.

INSTALACJA I OBSŁUGA APLIKACJI

CZYSZCZENIE

SAFETY AND HAZARD CONDITIONS

1. Do not start the device if it is damaged, if it is so the device must be repaired by the service or a person authorized to do so.
2. Due to safety concerns, only the manufacturer, a service authorized by the manufacturer or a person with appropriate qualifications can perform any repairs of the device.
3. Do not attempt to repair or interfere with the inside of the device.
4. This product may only be operated by children 8 or more years old, mentally and/or physically deficient persons and persons without knowledge of or experience in operation of this appliance type if supervised or instructed in safe operation, with clear understanding of all related risks. Children should not play with the device. Unsupervised children should not carry out maintenance and cleaning of the device.

5. The product has IP65 protection rating, i.e. it is dustproof and water resistant.

6. Do not immerse the device in water nor in other liquids.

7. The device is not designed to protect property. For this purpose one should seek a professional alarm system.
8. Ensure that local laws do not prohibit recording, storing, and editing video without the consent of the people being recorded.
9. Do not use the power adapter if its cable or housing is damaged.

INTRODUCTION

Thank you for the trust you have placed in us when you purchased your Setti+ device.

We are convinced that this high quality device will provide you with a lot of joy and satisfaction during its use

PLEASE CAREFULLY READ AND FOLLOW THE OPERATING MANUAL!

This device is intended for domestic or similar, non-commercial use. The manufacturer will not be held liable for damages resulting from improper or non-compliant use.

TECHNICAL DATA

Model SC930
Power supply 12.0V	---1.0A
Monitoring angle adjustment range	200° Horizontal
Protection rating IP65
Video recording resolution 2304 x 1296
Operating temperature range -10 do	+55°C
Ethernet connector RJ45
Accessories Camera with connectors, power adapter, installation elements
Motion detection range 15 m
System requirements Android, IOS
Supported memory cards Micro SD, up to 128 GB
Frequency of transmission 2.4 GHz
Frequency range 2412 – 2472 MHz
Maximum transmission power <10 dBm
Power supply unit
Model		SC930
Input voltage		100-240V~
Input current		0.5A
Input AC frequency		50/60Hz
Output voltage and current		12V ---1A, 12W
Average efficiency		83.02%
Low load efficiency (10%) 80.59%
No-load power consumption		0.065

DEVICE DESCRIPTION

WALL INSTALLATION

The bracket with the camera can be fixed on the concrete wall with use of rawlplugs.

1. Place the bracket against the wall and mark the locations of the holes to be drilled. You can also use the auxiliary template from the equipment.
2. Drill holes matching the diameter of the mounting plug, put the plugs in the holes.
3. Place the mounting bracket against the wall, insert the screws into the bracket holes and screw into the plugs, securing the bracket to the wall.

ATTENTION! IF THE BRACKET IS NOT SECURELY FIXED, REMOVE IT AND RE-INSTALL IN ACCORDANCE WITH THE INSTALLATION INSTRUCTIONS.

CAUTION! WE RECOMEND TO INSTALL THE CAMERA UNDER A ROOF AND AVOID SUNNY SPOTS.

INSTALLATION OF THE ETHERNET CABLE WITH INSULATION

1. Put the rubber cover on the Ethernet plug.

1. Route the Ethernet cable through the components in the following order:

1. Twist and connect the elements together:

1. Insert the A plug into the camera's Ethernet socket, rotate the mounting nut to attach it to the waterproof housing.

2. To connect the camera to the local Internet network, first configure the camera according to the „Instalation and operation of the application” section, then connect the LAN cable plug to the Ethernet input on the camera.

ATTENTION! REQUIRES A NETWORK CONNECTION WITHIN THE SAME ROUTER.

POWER OVER ETHERNET CABLE (POE)

To power the camera with a network cable, use the supplied adapters (PoE).

1. Connect the output adapter to the Ethernet input and the power input of the camera.
2. Connect the power adapter plug and the LAN connector to the input adapter.
3. Connect both adapters with an Ethernet cable with RJ45 connectors.

INSTALLING THE MEMORY CARD

To install a microSD memory card (max. 128 GB):

1. Gently lift the cover of the memory card slot and open it.
2. Slide the card into the slot as marked, press and lock.

INSTALLATION AND OPERATION OF THE APPLICATION

1. Download the Setti+ app from the website by scanning the QR code below:

1. Open the installed application.
2. As a new user, create a new account. Once you have an account, log in using your own access data.
3. Start the device by connecting the power adapter to the electrical outlet, and the cable plug to the power input in the camera. The camera will perform a test movement and emit audible signals.
4. Open the slot cover, press and hold the reset button for 5 seconds. The camera will emit an audible signal and enter the configuration mode.
5. In the upper right corner of the application, press the „+” button and select the appropriate device: Security, SC930 Camera.

6. Make sure that the camera is plugged into the power supply and makes audible signals, informing about the configuration mode.

7. Select the Wi-Fi network (2.4GHz), enter the password and confirm it with the „Next” button.

8. A QR code will be displayed on the phone screen. Point the camera lens towards the phone screen to scan the code. After hearing a beep, confirm with the button "I heard a sound.
9. After successfully connecting the device, you can fully enjoy its remote operation.
10. To connect the camera to the local network, connect the LAN cable plug to the Ethernet port on the camera.

ATTENTION! A NETWORK CONNECTION IS REQUIRED WITHIN THE SAME ROUTER WITH WHICH CONFIGURATION WITH THE CONTROL APPLICATION WAS MADE.

A detailed operating manual for the control application is available at:

or after scanning this QR code:

CLEANING

The appliance should be inspected and cleaned regularly.

1. If the device works surrounded by high vegetation, it should be cleaned of possible dust and dirt.
2. Use a softly damp cloth for cleaning.

CAUTION! DO NOT USE CHEMICALS OR ABRASIVES FOR CLEANING.

STORAGE

1. Disconnect the power supply from the power socket if the appliance is not in use.
2. Store the appliance in a dry, safe place away from children.

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSE SOLUTION
An acoustic signal was triggered.	The camera has not been properly configured with the network or has been disconnected.	Set up the home network station according to section "Installation and operation of the application".
It is not possible to setup Wi-Fi network in camera.	The router operates at 5GHz.	Change the router operating frequency from 5GHz to 2.4GHz. The names of the 2.4GHz and 5GHz networks should be different.
	There was a problem with Wi-Fi connection.	Check that the Wi-Fi signal of the router is of correct strength.
The camera does not respond to changes in the application.	There was a problem with Wi-Fi connection.	Check that the Wi-Fi signal of the router is of correct strength.
	The camera is too far away from the Wi-Fi signal source.	Boost the Wi-Fi signal of the router or reduce the distance between the camera and the router.
	The router configuration has been changed.	Re-configure the camera with the home network, according to the "Installation and operation of the application" section.

DECLARATION

ART-DOM Sp. z o.o. hereby declares that the SC930 camera complies with the relevant requirements of the Union harmonisation legislation: Directive 2014/53/EU and other Union harmonisation legislation. The full text of the EU declaration of conformity is available at the following address: www.artdom.net.pl/deklaracja/SC930/

ECO-FRIENDLY AND ENVIRONMENTALLY FRIENDLY DISPOSAL

This device is marked, in accordance with Directive 2012/19/EU of the European Parliament and of the Council of 4 July 2012 on waste electrical and electronic equipment (WEEE), with the symbol of a crossed-out waste container:

Do not dispose of the device marked with this symbol together with household waste.

For disposal return the device to your local waste treatment and disposal facility or contact your local authorities.

YOU CAN HELP PROTECT THE ENVIRONMENT!

Proper handling of waste electrical and electronic equipment contributes to avoiding harmful consequences for human health and the environment resulting from the presence of hazardous components and improper storage and processing of such equipment.

WARRANTY CONDITIONS FOR THE EXTERNAL CAMERA

1. ART-DOM Sp. z o.o. with its registered office in Łódź (92-402) at ul. Zakładowa 90/92 National Court Register Number 0000354059 (Guarantor) guarantees that the purchased device is free from physical defects. The warranty covers only defects resulting from the causes inherent in the item sold (manufacturing defects).
2. A disclosed defect will be removed at the Guarantor's expense within 14 days from the date of reporting the damage to the authorized service or point of sale.
3. In exceptional cases, e.g. the need to import spare parts from their manufacturer, the repair period may be extended up to 30 days.
4. The warranty period for the user is 24 months from the date of delivery of the goods.

5. The goods are intended for use only in the conditions of an individual household.

6. The present warranty does not cover:

a. damage caused by using the device in a manner inconsistent with the user manual,
b. mechanical, chemical or thermal damage,
c. repairs and modifications made by companies or persons that were not authorized to do so by the manufacturer,
d. parts that are easily worn or consumables such as: batteries, bulbs, fuses, filters, knobs, shelves, accessories,
e. installation, maintenance, inspection, cleaning, unlocking, removal of contaminants and instruction.

1. The Guarantor will select the mode of defect removal at its own discretion. Removal of a confirmed defect of the device will take place through warranty repair or replacement of the device. The Guarantor may perform repairs when the Buyer requests replacement or the Guarantor may perform replacements when the Buyer requests repair, if bringing the goods (device) into conformity in accordance with the granted warranty in the manner selected by the buyer proves impossible or would require excessive costs at the part of Guarantor. In particularly justified cases, if both repair and replacement are impossible or would require excessive costs for the Guarantor, the Guarantor may refuse to bring the goods into compliance with the granted warranty and propose another way to settle the warranty claim.

2. The exchange of goods is made at the point of sale at which the goods were purchased (replacement or refund) or an authorized service point, if it offers such service (replacement). The returned device must be complete, without mechanical damage. Failure to comply with these conditions may result in failure to accept the warranty claim.

3. In the event of non-compliance of the goods with the sales contract, the buyer is entitled by law to legal protection measures on the part and at the expense of the seller, and the warranty does not affect these legal protection measures.

4. The warranty is valid in Poland.

5. The condition for the warranty repair or replacement of the device is the presentation of proof of purchase and the use of the goods in accordance with the information contained in the user manual.

CAUTION!

Damage or removal of the rating plate from the device may result in warranty being deemed void.

We are constantly improving our products, so they may differ slightly from the images presented on the packaging and in the user manual. Please read the user manual before operating the appliance.

ART-DOM Sp. z o.o., ul. Zakładowa 90/92, 92-402 Łódź. National Court Register number 0000354059.

v.2
