Magnum MB210SP - Subwoofer MTX Audio - Free user manual and instructions

Type de produit	Subwoofer de voiture
Taille du haut-parleur	10 pouces (254 mm)
Configuration de la bobine	Double bobine (Dual Voice Coil)
Impédance nominale	2 + 2 ohms (câblable en 1 ou 4 ohms)
Puissance RMS	500 watts RMS
Puissance de crête	1000 watts
Réponse en fréquence	28 Hz – 250 Hz
Sensibilité (1W/1m)	87 dB
Dimensions hors tout (Diamètre x Profondeur)	10.75 x 6.5 pouces (273 x 165 mm)
Profondeur de montage	5.5 pouces (140 mm)
Diamètre de découpe	9.25 pouces (235 mm)
Poids net	12.5 lb (5.7 kg)
Matériau du cône	Polypropylène renforcé de mica
Matériau de la suspension	Caoutchouc
Type d'aimant	Ferrite
Alimentation recommandée	Amplificateur de 500-1000 watts RMS à 1 ou 4 ohms
Entretien et nettoyage	Essuyer avec un chiffon sec et doux. Éviter les solvants.
Sécurité	Ne pas exposer à l'humidité. Fixation solide pour éviter tout déplacement.
Pièces détachées et réparabilité	Contacter le service client MTX pour les pièces. Réparation par un professionnel.
Garantie	1 an (vérifier les conditions locales)
Utilisation recommandée	Caisson de basse pour système audio automobile

Frequently Asked Questions - Magnum MB210SP MTX Audio

Comment câbler le Magnum MB210SP en 1 ohm ou 4 ohms ?

Le subwoofer possède deux bobines de 2 ohms. Pour une charge de 1 ohm, connectez les deux bobines en parallèle (+ à +, - à -). Pour 4 ohms, connectez-les en série (borne positive d'une bobine à la borne négative de l'autre, puis utilisez les bornes restantes).

Quelle taille de caisson est recommandée ?

Pour une utilisation en caisson scellé, un volume interne de 0,8 à 1,2 pied cube (22,7 à 34 L) est recommandé. Pour un caisson accordé, utilisez 1,5 à 2 pieds cubes (42,5 à 56,6 L) avec un évent de 4 pouces de diamètre.

Quelle puissance d'amplificateur dois-je utiliser ?

Un amplificateur délivrant entre 500 et 1000 watts RMS à la charge appropriée (1 ou 4 ohms) est idéal. Ne dépassez pas la puissance RMS maximale du subwoofer pour éviter l'endommagement.

Puis-je installer ce subwoofer dans un caisson préfabriqué ?

Oui, à condition que le volume interne et la découpe correspondent aux spécifications. Vérifiez que la profondeur de montage (5,5 pouces) est suffisante.

Dois-je roder le subwoofer avant une utilisation intensive ?

Un rodage de 10 à 20 heures à faible volume (50 % de la puissance) permet à la suspension de se détendre et d'atteindre ses performances optimales.

Quelle est la garantie du Magnum MB210SP ?

La garantie standard de MTX Audio est de 1 an à compter de la date d'achat. Conservez votre facture et enregistrez le produit sur le site MTX pour une couverture complète.

Puis utiliser ce subwoofer dans une enceinte de salon ?

Ce subwoofer est conçu pour un usage automobile. Bien qu'il puisse fonctionner à la maison avec une alimentation adaptée, les performances sont optimisées pour un espace clos comme un coffre de voiture.

Comment nettoyer le cône et la suspension ?

Utilisez un chiffon en microfibre légèrement humide pour enlever la poussière. N'utilisez jamais de produits chimiques ou d'alcool, car ils pourraient endommager les matériaux.

Que faire si le subwoofer émet un son de claquement ?

Un claquement peut indiquer une bobine défectueuse ou une surcharge. Vérifiez les connexions et l'impédance totale. Si le problème persiste, contactez le support MTX.

Puis-je connecter plusieurs subwoofers Magnum MB210SP au même amplificateur ?

Oui, en respectant l'impédance minimale de l'amplificateur. Par exemple, deux subwoofers câblés en parallèle (bobines en parallèle) donneront une charge de 0,5 ohm, ce qui peut endommager la plupart des amplis. Privilégiez un câblage en série ou un ampli stable en 0,5 ohm.

USER MANUAL Magnum MB210SP MTX Audio

High Level Input Connection (Connect to speaker output of head unit)

Subwoofers

Settings

Match your amplifier to these settings for optimal performance

Mitek Mobile Limited Warranty

Our Guarantee

Mitek Mobile products (including MTX, Streetwires, Coustic and Magnum) purchased in the USA after 1/1/2013 from an authorized Mitek retailer are guaranteed to be free from material defects in products and workmanship for five (5) years to the original end user purchaser, subject to the terms and conditions below.

Length of Limited Warranty and Remedy

The warranty period begins the day the product is purchased by the end user, and is limited to the original retail purchaser of the product.

Free Replacement Period (2 Years)

Products found to be defective in materials or workmanship during the first 2 years will be, at Mitek's option, repaired or replaced by Mitek at no charge. When a product is replaced during first 2 years, the warranty does not renew, it continues on from the original date of purchase.

Proration Period (Years 3-5)

The prorated purchase price of any product which becomes defective after the first two years and prior to the end of the warranty period may be credited toward the purchase of a new Mitek product. The amount of the proration shall be determined by dividing the purchase price by the number of months of the warranty period (60), and then multiplying the result by the number of months remaining in the warranty period. Any partial months will be rounded to the nearest whole month. For example, a product purchased 37 months ago for \100 would be calculated by dividing \100 by 60 months = \1.66/month, multiplied by 23 (the months remaining in the warranty period) for a prorated warranty amount of \38.33.

You are responsible for all costs for removal, reinstallation and proper packaging, shipping, insurance or other freight charges incurred in the shipment of the product or part to Mitek. Mitek will ship the repaired or replaced Mitek product or replacement parts to you at no charge. Mitek reserves the right to utilize reconditioned, refurbished, repaired or remanufactured products or parts in the warranty repair or replacement process. Such products and parts will be comparable in function and performance to an original product or part and warranted for the remainder of the original warranty period.

What Is Not Covered

This warranty does not cover the product if it has been subject to neglect, abuse, misuse, incorrect connection, or if it has been subject to unauthorized repair or alterations of any nature, or if the serial number has been altered or removed, and the warranty does not extend to cosmetics or finish. This warranty only applies to products installed and used in the USA.

What You Must Do to Obtain Warranty Service

You must contact Mitek Warranty via our website at MTX.com, or via email at [e-mail], or by calling 800-556-2888. If you did not purchase the product directly from Mitek, a proof of purchase must be provided in order to receive warranty consideration. You will be issued a Return Authorization (RA) number which must be written on the outside of the package before returning the product to Mitek.

No Other Warranties

THE LIMITED WARRANTIES DESCRIBED ABOVE ARE EXCLUSIVE AND IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED. MITEK DISCLAIMS AND EXCLUDES ALL OTHER EXPRESS WARRANTIES, AND DISCLAIMS AND EXCLUDES ALL WARRANTIES IMPLIED BY LAW, INCLUDING WITHOUT LIMITATION THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT THAT APPLICABLE LAW PROHIBITS THE EXCLUSION OF IMPLIED WARRANTIES, THE DURATION OF ANY APPLICABLE IMPLIED WARRANTY IS LIMITED TO THE PERIOD SPECIFIED FOR THE EXPRESS WARRANTY. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Any oral or written description of any Mitek product is for the sole purpose of identifying it and shall not be construed as an express warranty.

Limitation of Liability

MITEK'S OBLIGATION TO PROVIDE A CREDIT, OR REPAIR OR REPLACE AT MITEK'S OPTION, SHALL BE YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY AND MITEK'S SOLE AND EXCLUSIVE OBLIGATION. MITEK SHALL NOT BE LIABLE FOR INCIDENTAL, INDIRECT, CONSEQUENTIAL OR SPECIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH THE MITEK PRODUCT, ITS USE OR PERFORMANCE. Incidental damages include, but are not limited to, such damages as loss of time and loss of use. Consequential damages include, but are not limited to, the cost of repairing or replacing other property which was damaged if the Mitek product does not work properly.

Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. This limited warranty supersedes all prior warranties and is not transferable from the original consumer purchaser.

Any assistance Mitek provides to or procures for you outside the terms, limitations or exclusions of this limited warranty will not constitute a waiver of such terms, limitations or exclusions, nor will such assistance extend or revive the warranty. Mitek will not reimburse you for any expenses incurred by you in repairing or replacing any defective product, except for those incurred with Mitek's prior written permission.
