Product Type	Subwoofer
Brand	MTX Audio
Model	WET124-W
Size (Diameter)	12 inches
Impedance	4 ohms
RMS Power Handling	300 Watts
Peak Power Handling	600 Watts
Frequency Response	20 Hz - 200 Hz
Sensitivity (1W/1m)	90 dB
Mounting Depth	6.5 inches
Mounting Hole Diameter	11 inches
Recommended Sealed Enclosure Volume	1.25 cubic feet
Recommended Ported Enclosure Volume	2.0 cubic feet
Weight	12 lbs (5.4 kg)
Cone Material	Polypropylene with UV protection
Surround Material	Rubber
Voice Coil	2.5" Dual 4-ohm (wired to 4 ohms)
Recommended Amplifier Power	150-600 Watts per channel
Use	Marine / Outdoor
Certifications	Marine grade (salt, UV, moisture resistant)
Maintenance	Wipe with damp cloth; do not use solvents
Safety	Use in properly constructed enclosure; secure mounting; avoid distortion
Spare Parts	Contact MTX Audio for grille, terminals, cone replacement

Frequently Asked Questions - WET124-W MTX Audio

What is the recommended enclosure for the MTX WET124-W?

The WET124-W performs well in both sealed and ported enclosures. For a sealed box, use 1.25 cubic feet; for ported, use 2.0 cubic feet tuned to 35 Hz.

How do I wire the WET124-W to a 4-ohm load?

The subwoofer features dual 4-ohm voice coils. To achieve a 4-ohm load, wire the coils in series: connect the positive terminal of one coil to the negative of the other, and use the remaining terminals as positive and negative.

What is the RMS power rating of this subwoofer?

The RMS power handling is 300 Watts, with a peak rating of 600 Watts. For best sound quality and longevity, use an amplifier delivering 150-600 Watts RMS.

Can I use the WET124-W in a boat or outdoor environment?

Yes, the WET124-W is specifically designed for marine use. It features UV-resistant cone, rubber surround, and corrosion-resistant terminals, making it suitable for boats, Jeeps, and outdoor installations.

What is the mounting depth and hole size?

The mounting depth is 6.5 inches (165 mm) and the hole diameter required is 11 inches (279 mm). Ensure your enclosure has sufficient depth and clearance.

What is the sensitivity of this subwoofer?

The sensitivity is 90 dB at 1 watt/1 meter. This means it produces a moderate sound level with low power, but works best with adequate amplification.

How should I clean and maintain the subwoofer?

Clean the cone and surround with a soft damp cloth. Do not use harsh chemicals or abrasive cleaners. Keep the terminals dry and inspect mounting bolts periodically.

Is there a break-in period for the WET124-W?

It is recommended to play the subwoofer at moderate levels for 10-20 hours to loosen the suspension. This can improve low-frequency response and longevity.

What type of amplifier should I pair with this subwoofer?

Use a monoblock or subwoofer amplifier that can deliver 300-600 Watts RMS at 4 ohms. Ensure the amplifier is stable at 4 ohms and has a subsonic filter to protect the sub.

Where can I find the user manual or specifications?

The user manual is available for free download on notice-facile.com. You can also visit the MTX Audio website for official specifications and support.

USER MANUAL WET124-W MTX Audio

This box contains a highly sophisticated, performance machine.

The enclosed subwoofer is designed to produce extreme bass and high SPL levels that will bring your music to life.

This device should only be used by someone that is looking to take their in-boat listening experience to a level others have only dreamed about.

If you are one of these people, congratulations! Use caution when listening to and sharing your system, prolonged exposure to a high performance stereo system may cause jealousy and stereo envy among your friends.

You have been warned.

Now install it, get in, and turn it up.

MTX Audio - Feel the Thunder

Silhouette of a person sitting on a boat with a skis, rendered in grayscale (no text or symbols)

© 2014 Mino Corp. All rights reserved. MTX is a customer of Mtx Corp. Due to consistent practice development, all special statements subject to change without notice. MTX: Audio, 6581 East Balance Fleet, Phoenix, Arizona 0003 U.S.A. MTX:0003 Rev A 1/11

Rec. 1:00

This paper sent to passing monthly and will remechable

② CEA

DESIGNED AND ENGINEERED IN MONROF, WI U.S.A. MADE IN CHINA

WET124-W 500W Peak Power Subwoofer

SPECIFICATIONS

Diameter: 12" (30,48cm)

Mounting Depth: 5-3/16" (13.1cm)

RMS Power: 250W

Peak Power 500W

SPL1W/1m-86.5dB

SPL2.63V/1m:89.9dB

Impedance:40

Frequency Response: 30Hz - 130Hz

Cutoff Diameter: 11" (28cm)

Overall Diameter: 12-7/8" (32.7cm)

ESPECIFICACIONES

WARRANTY:

This Warranty Statement applies to products purchased in the United States of America only. Products purchased outside the United States of America are subject to the warranty offered by the authorized distributor/retailer in the respective country/area where the product is sold and purchased.

Mitek Mobile products (including MTX, Streetwires, Coustic and Magnum) purchased in the USA from an authorized Mitek retailer are guaranteed to be free from material defects in products and workmanship for five (5) years to the original end user purchaser, subject to the terms and conditions below.

The warranty period begins the day the product is purchased by the end user, and is limited to the original retail purchaser of the product. Products found to be defective in materials or workmanship during the first 2 years will be, at Mitek's option, repaired or replaced by Mitek at no charge. When a product is replaced during first 2 years, the warranty does not renew, it continues on from the original date of purchase. The prorated purchase price of any product which becomes defective after the first two years and prior to the end of the warranty period may be credited toward the purchase of a new Mitek product. The amount of the proration shall be determined by dividing the purchase price by the number of months of the warranty period (60), and then multiplying the result by the number of months remaining in the warranty period. Any partial months will be rounded to the nearest whole month. For example, a product purchased 37 months ago for \100 would be calculated by dividing \100 by 60 months = \1.66/month, multiplied by 23 (the months remaining in warranty period) for a prorated warranty amount of \38.33.

You are responsible for all costs for removal, re-installation and proper packaging, shipping, insurance or other freight charges incurred in the shipment of the product or part to Mitek. Mitek will ship the repaired or replaced Mitek product or replacement parts to you at no charge. Mitek reserves the right to utilize reconditioned, refurbished, repaired or re-manufactured products or parts in the warranty repair or replacement process. Such products and parts will be comparable in function and performance to an original product or part and warranted for the remainder of the original warranty period.

This warranty does not cover the product if it has been subject to neglect, abuse, misuse, incorrect connection, or if it has been subject to unauthorized repair or alterations of any nature, or if the serial number has been altered or removed, and the warranty does not extend to cosmetics or finish. This warranty only applies to products installed and used in the USA.

Customers in the USA must contact Mitek Warranty via our website at MTX.com, or via email at [e-mail], or by calling 800-556-2888. If you did not purchase the product directly from Mitek, a proof of purchase must be provided in order to receive warranty consideration. You will be issued a Return Authorization (RA) number which must be written on the outside of the package before returning the product to Mitek.

For more information visit mtx.com.
