Product Type	Online UPS Three Phase
Model	UPS-TRI30K
Capacity	30KVA / 27KW
Input Voltage Range	277-485 Vac (no derating), 190-277 Vac (linear derating 50%-100% load)
Input Power Factor	≥0.99
Output Voltage	360/380/400/415 Vac (settable via LCD)
Output Voltage Regulation	±1%
Output Frequency	50/60 Hz ±0.1 Hz (battery mode)
Efficiency	≥93% (normal mode), 96% (ECO mode)
Battery DC Voltage	240 Vdc (standard), 192 Vdc (long time model)
Battery Recharge Time	4 hours typical
Transfer Time	0 ms (mains to battery, inverter to bypass)
Overload Protection	Inverter: 102%-125% load for 10 min; >150% for 0.5 s
Display	LCD + LED indicators
Communication Ports	USB, RS485, dry contacts; optional SNMP/AS400/RS485
Dimensions (WxDxH)	350 x 785 x 1078 mm
Net Weight	235 kg
Operating Humidity	20-90% RH @ 0-40°C
Noise Level	≤65 dB @ 1 meter
Safety Features	EPO (Emergency Power Off), maintenance bypass, short circuit protection

Frequently Asked Questions - UPS-TRI30K Mach Power

How do I perform a cold start on the UPS-TRI30K?

To cold start, press and hold the power button on the front panel while no utility power is connected. The UPS will start on battery power. Ensure the batteries are charged before use.

What is ECO mode and how does it save energy?

ECO mode bypasses the inverter when utility power is within acceptable range, routing power directly to the load. This increases efficiency to 96% compared to the normal 93%, reducing energy consumption.

Can I set the output voltage myself?

Yes, you can select the output voltage (360, 380, 400, or 415 Vac) via the LCD menu. Refer to the manual for navigation instructions.

How do I connect an external battery cabinet?

Use the optional external battery cabinet model UPS-BCTRI or UPS-BCTRI-38A. Connect via the DC input breaker terminals with provided battery cables. Ensure the battery DC voltage matches (240Vdc or 192Vdc for long time model).

What communication options are available for monitoring?

Standard ports include USB, RS485, and dry contacts. Optional cards (SNMP, AS400, RS485) can be installed in the intelligent slots for network management.

How do I use the maintenance bypass?

The maintenance bypass allows you to isolate the UPS for servicing while still powering the load. Turn the maintenance bypass breaker to the bypass position after ensuring the UPS is switched off. Always follow safety procedures.

What do the alarm indicators mean?

Common alarms include: battery mode (on battery), low battery (battery capacity low), fan fault, overload. The LCD and LED provide visual and audible alerts. Refer to the manual for alarm codes.

Can I parallel multiple UPS units?

Yes, up to 6 units can be paralleled using an optional parallel card for N+X redundancy. This increases capacity or provides redundancy. Consult the manual for configuration details.

What type of batteries does the UPS use?

The UPS-TRI30K is designed for 7Ah or 9Ah batteries (60 units in space). For external batteries, use cabinets with 7/9Ah or 38Ah batteries. Batteries are not included with the UPS.

How do I adjust the battery shutdown voltage?

The battery shutdown voltage (EOD) is selectable via the LCD menu. Navigate to the battery settings and choose the desired voltage level to prevent deep discharge.

USER MANUAL UPS-TRI30K Mach Power

Black industrial temperature control unit with ventilation slots and digital display (no visible text or symbols)

FEATURES

• High frequency and true online double-conversion
- DSP digitai contrai technology
- Input power factor correction (PFC)
- Wide input voltage range (190V - 485V)
• Output power factor 0.9
- Excellent load-carrying capability, linear derating between 50% and 100% load at 190 - 277 Vac
- Optimized battery configuration: 192V / 240V
- Cold start
• Auto sensing frequency
• ECO mode operation for energy saving
- 50 / 60Hz frequency conversion mode
- Selectable output voltage via LCD
- Selectable battery shutdown voltage (EOD) via LCD
- Power-on self test
- Advanced battery management (ABM)
- Short circuit and overload protection
• Automatic charging in OFF mode
- Auto control fan speed when loads varies
- Dual input
- Advanced quick charge technology, charging speed is increased double
- Configurable transfer time from battery to mains power, reducing the impact on grid or generator
- Automatic startup/shutdown function (optional), automatic transfer to bypass at light load, automatic restart at acting load; energy-saving and environment-friendly
- Standard USB communication port
- Standard emergency power off (EPO)
- Standard maintenance bypass
- Optional extension battery bank
- Optional RS465 I SNMP I AS400 communication port
- Optional N+X redundancy parallel up to 6 units
- Optional battery temperature compensation

SPECIFICATION

MODEL	UPS-TRI10K	UPS-TRI20K	UPS-TRI30K
Capacity	10KVA / 9KW	20KVA / 18KW	30KVA / 27KW
INPUT
Rated voltage	360 V /380V /400 V/ 415 Vac
Voltage range	277 - 485 Vac (no derating)
	190 - 277Vac (linear derating between 50% and 100% load)
Rated frequency	50 / 60 Hz (auto-sense)
Frequency range	40 ~ 70 Hz
Power factor	≥ 0.99
Total harmonic distortion THDI	≤5%
Bypass voltage range	-40% - + 15% (settable)
OUTPUT
Voltage	360 V/ 360 V/ 400 V/ 415 Vac (settable)
Voltage regulation	±1%
Frequency	Synchronized with utility in mains mode; 50 / 60 ± 0.1Hz in battery mode
Waveform	Sinusoidal
Crest factor	3:1
Total harmonic distortion THDV	≤ 2% (linear load); ≤ 5% (non-linear load)
Transfer time	Mains mode to battery mode: 0ms; Inverter mode to bypass mode: 0ms
Inverter overload capability	102% - 125%: transfer to bypass in 10 mins;
Bypass overload capability	125% - 150%: transfer to bypass in 1 min;
	> 150%: transfer to bypass in 0.5 s
BATTERIES
DC voltage	240 Vdc; Long time model: 192 Vdc
Inbuilt battery space *	40 x 9Ah	40 x 7/9Ah	60 x 7/9Ah
Typical recharge time	4 Hours
SYSTEM
Efficiency	≥ 93%, ECO mode 96%
Display	LCD+ LED
Alarm	Battery mode, low battery, fans fault etc.

* battery not included

MODEL	UPS-TRI10K	UPS-TRI20K	UPS-TRI30K
Max. parallel numbers	6
EMI	IEC I EN62040-2
EMS	IEC61000-4-2 (ESD)
	IEC61000-4-3 (RS)
	IEC61000-4-4 (EFT)
	IEC61000-4-5 (surge)
COMMUNICATIONS
RS485 / USB I dry contacts	Supports Windows 98 / 2000 / 2003 /XP /Vista/ 2008 / 7 / 8 / 10
SNMP (optional)	Power management from SNMP manager and web browser
OTHERS
Humidity	20 - 90% RH@ O ~ 40°C (non-condensing)
Noise level	≤ 60 dB (1m)	≤ 65 dB (1m)	≤ 65 dB (1m)
Dimensions (WxDxH)	350 x 785 x 868 mm	350 x 785 x 1078 mm	350 x 785 x 1078 mm
Packaged dimensions (WxDxH)	472 x 910 x 1050 mm	472 x 910 x 1260 mm	472 x 910 x 1260mm
Net weight (kg)	115	175	235
Gross weight (kg)	125	190	250

• Derate capacity to 90% when the output voltage is adjusted to 208Vac.

ACCESSORY

External Battery Cabinet for Long Backup (with battery cable and battery breaker)

Technical line drawing of a symmetrical mechanical or architectural component with horizontal slats and a central vertical gap (no text or symbols)

MODEL	UPS-BCTRI	UPS-BCTRI-38A
Dimension (WxDxH)	350 x 785 x 1078mm	950 x 450 x 610mm
Battery Capacity	7groups of 20pcs 7/9Ah	16/20pcs 38Ah
