Product Type	Citrus Fruit Squeezer (Electric Juicer)
Brand	Arendo
Model	304556
Power Supply	220-240 V ~ 50/60 Hz
Power Consumption	40 W
Protection Class	II
Capacity (Jug)	1200 ml
Cable Length	Approximately 1 m
Noise Level	Approximately 45 dBA
Operation Cycle	15 seconds on / 15 seconds off per cycle; max 10 cycles before 30-minute cooldown
Direction of Rotation	Automatic, reversible by double-tapping the pressing cone
Dishwasher Safe Parts	Juice container, filter, pressing cone, pressing cone cover
Cleaning (Base Unit)	Wipe with a slightly damp cloth; never immerse in water
Safety Features	Auto-stop if too much pressure; overheat protection via cooldown cycle
Spare Parts / Accessories	Only original spare accessories recommended
Warranty	Subject to terms; repairs by unauthorized persons void warranty
Included Accessories	Base unit, jug, shaft extender, juice container, filter, pressing cone, pressing cone cover, lid

Frequently Asked Questions - 304556 Arendo

How do I assemble the citrus squeezer?

Push the transmission shaft (2) into the base unit (1). Place the jug (3) on the base. If using a separate juice container, attach the shaft extender (5) and then mount the juice container (6). Finally, place the filter (7) and pressing cone (8) onto the appliance.

How do I change the direction of rotation?

Press the built-in pressing cone twice in quick succession. The direction will reverse. Note: It may also change automatically if the cone is blocked.

Can I wash the parts in the dishwasher?

Yes, the juice container (6), filter (7), pressing cone (8), and pressing cone cover (9) are dishwasher safe. Use a mild cleaning agent and allow parts to dry completely before reassembly.

What is the proper operation cycle?

Turn the appliance on for 15 seconds, then off for 15 seconds (one cycle). After 10 cycles, let the appliance cool down for at least 30 minutes to prevent overheating.

How do I clean the base unit?

Wipe the base unit with a slightly damp cloth. Never immerse it in water, as it contains the motor and is not waterproof.

What should I do if the appliance stops during use?

The appliance automatically stops if too much pressure is applied to the pressing cone. Release pressure, wait a few seconds, and continue with lighter pressure. If it stops due to overheating, wait 30 minutes before resuming.

Can I use an extension cord?

No, never connect the appliance to an extension cable or power strip. Plug it directly into a properly installed socket.

How should I store the juicer?

Clean and dry all parts, then assemble with the lid on to protect from dust. For long-term storage, use the original packaging.

Is the appliance safe to use near water?

No. Do not use the citrus squeezer near bathtubs, washbasins, swimming pools, or any place where it could be splashed or immersed. Electric shock hazard.

What is the warranty and repair policy?

Any repairs or modifications by unauthorized persons void the warranty. Contact the manufacturer (WD Plus GmbH) for inspection, repair, or replacement if the appliance is damaged.

USER MANUAL 304556 Arendo

Citrus Fruit Squeezer

User Manual

Line drawing of a simple line drawing of a coffee maker with lid and handle (no text or symbols)

Table of contents

1. Deutsch .... 3
2. English 14

ENG: Latest information, drivers, user manuals and data sheets can be found at www.ganzeinfach.de in our download area.

⚠️ Usage and safety instructions

• Read the user manual completely before using this product! Keep it for future reference.
• Before using the appliance, check whether the voltage indicated on the rating plate matches that of your mains supply!
• Do not pull the cable if you want to disconnect the plug from the power source. Always pull the plug itself!
• Disconnect the plug from the power source if the appliance is not being used! Do not leave the product unattended!
• This appliance is intended for personal use only!
• Cleaning and maintenance should not be carried out by children.
• This appliance can be operated by children from 8 years of age and above, as well as by people with reduced physical,

sensory or mental capacities or who lack knowledge or experience, if they have been supervised or instructed regarding safe use of the appliance, and they understand the resultant dangers.

• Never immerse it in water for cleaning. Wipe the body with a dry cloth.
• Use the product only on a flat surface.
• Disconnect the appliance from the mains when it is not being used or during cleaning.
• Ensure that the cable does not come into contact with any hot or moist surfaces.
• Do not turn on the appliance if you find a defect in the power cord. Contact the manufacturer of the product in such cases.
• Never move the appliance during operation.
• The product should be opened or re-

(arendo)

paired only by qualified technicians!

• Remove the packaging material and check if the appliance is in proper working condition before using it.
• Ensure that children do not play with the appliance or the packaging material!
• In the interest of child safety, do not leave any packaging components (plastic bags, cardboard, polystyrene, etc.) lying around.
  • This product is not a toy!
• Close supervision is required if the product is used by or near children or frail persons.
• Do not use the appliance after a malfunction, if it has been dropped, or appears to be damaged in any way. Return the complete product to the manufacturer for inspection, repair or replacement.

- Ensure that the appliance is switched off before disconnecting the mains cable. If you touch it, make sure that your hands are dry to avoid electric shock.

- This product should not be used near water, such as a bathtub, washbasin, swimming pool, etc., where there is a risk of immersion or splashing.

- Never connect the appliance to an extension cable or power strip!

- Do not use the citrus fruit squeezer outdoors!

- Use the product as described in this manual. Using the appliance for any other purpose which is not recommended by the manufacturer may cause fire, electric shock or physical injury and void the guarantee.

- Never operate the appliance unsupervised. Always switch off the appliance if you leave the room.

(arendo)

Disconnect the plug from the mains socket.

• Only use original spare accessories.
• Warning! Please do not allow small children to play with the foil. Danger of suffocation!
• Operating period: Turn on the appliance for 15s, then turn it off for 15s as one cycle of operation. After operating the product for 10 cycles, you should stop the operation and turn off the appliance for 30min to cool it down.
• Devices may be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge, provided that they have received proper supervision or detailed instructions for using the device in a safe manner and that they understand the hazards involved.

Thank you for choosing an Arendo product. Please read the following user manual carefully so that you can enjoy the purchased product for a long time.

1. Scope of delivery

• Citrus fruit squeezer
- User manual

2. Technical data

Power supply 220-240 V	~50/60Hz
Power consumption 40 W
Protection class II
Capacity 1200 ml
Noise emission approximately 45 dBA
Cable length ~ 1m

3. Product details

Number Description
1 Base (motor unit)
2 Transmission shaft
3 Jug
4 Spout opening
5 Shaft extender
6 Juice container
7 Filter
8 Pressing cone
9 Pressing cone cover
10 Lid

4. Assembly

1. Push the motor shaft (2) as far as it goes into the base unit.

2. Place the jar (3) on the base unit (1). Now you have the option of using the existing jug (3) as a juice container or to use a separate container. If you want to use a separate juice container, you need to attach the shaft extender (5) and then mount the juice container (6). If you do not want to use a separate juice container but want to use the jug (3), skip parts 5 and 6.

3. Then place the filter (7) and the pressing cone (8) on the appliance.

5. Usage

Take the appliance out of the package and remove all the packaging material. Place it on a flat and firm surface.

• Connect the plug to a properly installed socket.
• Remove the pressing cone cover (9) and the lid (10).
• Cut the desired citrus fruit into two halves before squeezing them.
• Hold the citrus fruit with one hand and the squeezer with the other hand while pushing down on the pressing cone with half the citrus fruit.

Note: The pressing cone starts to turn automatically. Do not press too hard on the cone because the appliance stops if the pressure is too much.

After usage, remove the power cord from the socket and then clean the appliance.

Note: Ensure that you refrigerate the juice after extraction. Remember that the juice should not be stored for more than one day. Do not keep the juice in metal containers because the acid in the juice may affect the surface and impair the taste.

6. Cleaning and Care

Disconnect the plug of the appliance from the mains socket before cleaning. Never immerse the base unit along with the motor in water!

Never use scouring or aggressive cleaning agents to clean the appliance. We recommend that you clean the citrus squeezer after each use.

• Clean the base unit with a slightly dampened cloth.
• The other components of the appliance can be cleaned with water and a mild cleaning agent.
• The juice container (6), the filter (7), the pressing cone (8) and the pressing cone cover (9) are dishwasher safe. Ensure that you do not use too much cleaning agent.
• Allow the parts to dry adequately before assembling the appliance again.

Store the citrus squeezer with the lid in place to protect the components from dust. Store the appliance in the original packaging, if you do not want to use it for a long period.

7. Changing the direction of rotation

Please press the built-in pressing cone twice in quick succession, to change the direction of rotation.

Note: The direction of rotation may change if the pressing cone is blocked.

8. Safety instructions and disclaimer

Never try to open the appliance to repair or make modifications. Avoid contact with the mains voltage. Do not short-circuit the product. The appliance is not waterproof, therefore please use it only in dry surroundings. Protect it from high humidity, water and snow. Do not expose the appliance to high temperatures. Do not expose the appliance to sudden changes in temperature or strong vibrations, as this could damage the electronic components. Check the appliance for damage before using it.

The appliance should not be used if it has been subject to impact or has been damaged in any other manner. Please comply with the local regulations and res-

trictions. Do not use the appliance for purposes other than those described in the user manual. This product is not a toy. Keep it out of the reach of children or mentally disabled persons. Any repairs or modifications to the appliance not carried out by the original supplier will void any warranty and guarantee claims. The appliance should only be used by those who have read and understood this user manual. The specifications of the appliance may be changed without any special prior notification.

9. Disposal instructions

In line with the European WEEE directive, electrical and electronic appliances should not be disposed of along with domestic waste. Their components have to be separately sent for recycling or disposal, because improper disposal of toxic and dangerous components may permanently damage the environment.

According to the electrical and electronic equipment act (ElektroG), you are obliged (as a consumer) to return (free of charge) electrical and electronic appliances to the manufacturer, the point of sale or public collection points at the end of their service life. The relevant local laws regulate the details in this regard. The symbol displayed on the product, in the user manual or/and on the packaging refers to these regulations. With this manner of sorting, recycling and disposal of used appliances, you make an important contribution towards protecting our environment.

WEEE directive 2012/19/EU WEEE Register no.: DE 67896761

The company WD Plus GmbH hereby certifies that the appliance 304556/20200428NB141 complies with the fundamental requirements and all other relevant stipulations. A complete conformity statement can be obtained from: WD Plus GmbH, Wohlenbergstraße 16, 30179 Hannover

WD Plus GmbH

Wohlenbergstraße 16

D 30179 Hannover
