CM4612D - Coffee maker Atag - Free user manual and instructions

Product type	Programmable coffee maker
Brand	Atag
Model	CM4612D
Dimensions (W x H x D)	25 cm x 35 cm x 30 cm
Weight	3.5 kg
Power supply	230 V ~ 50 Hz, 1050 W
Carafe capacity	1.25 L (10 cups)
Coffee type	Ground coffee
Filter	Permanent filter or paper filter #4
Delay programming	Yes, up to 24 hours
Automatic shut-off	Yes, after 2 hours
Keep warm	Yes, heating plate
Water level indicator	Yes, graduated
Anti-drip system	Yes
Power cord	Length 0.8 m
Color	Black / Stainless steel
Maintenance and cleaning	Regular descaling recommended with vinegar or descaling product
Safety	Automatic shut-off in case of overheating
Spare parts	Carafe, permanent filter, water tank available
Repairability	Repairability index estimated at 8.2/10

Frequently Asked Questions - CM4612D Atag

How to program the Atag CM4612D coffee maker to start in the morning?

Make sure you have filled the water tank and added ground coffee in the filter. Press the PROG button, set the start time with the arrows, then confirm with OK.

Why does my coffee maker turn off after 2 hours?

The automatic shut-off function is enabled by default for safety reasons. You can disable it by holding down the ON/OFF button for 5 seconds.

What type of coffee can I use with the CM4612D?

This coffee maker is designed for ground coffee. Use a medium grind (filter type). Do not use coffee beans.

How to clean the permanent filter?

Rinse the filter under running water after each use. For deep cleaning, use a soft brush and soap. Do not put it in the dishwasher.

What to do if coffee does not flow or flows slowly?

This may be due to a clogged filter or necessary descaling. Clean the filter and descale the machine with a water-vinegar mixture (1/3 vinegar, 2/3 water).

How to descale the Atag CM4612D coffee maker?

Pour a mixture of white vinegar and water (ratio 1:2) into the tank. Run a cycle without coffee. Repeat with clean water to rinse. Descale every 2-3 months.

Is the carafe glass or metal?

The provided carafe is glass with an ergonomic handle. It is compatible with the heating plate.

Can I use paper filters?

Yes, you can use paper filters of size #4. Place them in the filter holder as an alternative to the permanent filter.

How to turn off the coffee maker completely?

Press the ON/OFF button to turn off the appliance. Unplug it if not using for an extended period.

Where to find spare parts for the CM4612D?

You can order parts like the carafe, permanent filter, or water tank on the official Atag website or from authorized dealers. Search for reference CM4612D.
