Product type	40-inch LED TV
Brand	Blaupunkt
Model	40/133I-WB-11B2-FHBKUP-EU
Screen size	40 inches (102 cm)
Resolution	1920 x 1080 (Full HD)
Aspect ratio	16:9
Backlight	LED
Connectivity	2x HDMI, 1x USB, 1x VGA, antenna input
Power supply	220-240 V ~ 50/60 Hz
Power consumption (typical)	70 W
Standby consumption	< 0.5 W
Dimensions without stand	904 x 522 x 80 mm
Dimensions with stand	904 x 570 x 200 mm
Net weight	7.5 kg
Main features	Integrated DTT, stereo sound, parental control, sleep timer
Maintenance and cleaning	Clean with a soft, dry cloth. Do not use chemical products.
Safety	Do not expose to water. Use a grounded wall outlet.
Spare parts	Remote control included. Wall mount optional.
Repairability	Repairability index not provided by the manufacturer.

Frequently Asked Questions - 40/133I-WB-11B2-FHBKUP-EU BLAUPUNKT

How to turn on the TV?

Press the Power button located on the side or bottom of the screen, or use the Power button on the remote control.

What to do if the screen displays 'No signal'?

Check that the input source is correctly selected (HDMI, USB, antenna). Make sure the cable is properly connected and the connected device is turned on.

How to reset to factory settings?

Go to Settings > System > Reset and confirm. All personal settings will be erased.

Can I connect headphones?

Yes, use the headphone output jack (3.5 mm) located on the back of the TV.

How to reduce power consumption?

Enable Eco mode in the picture settings and reduce brightness. The automatic standby can also be programmed.

The remote control does not work, what to do?

Check the batteries and their polarity. Point the remote towards the TV's infrared sensor. If the problem persists, replace the batteries.

How to clean the screen?

Turn off the TV and use a slightly damp microfiber cloth. Wipe gently without pressing. Never use abrasive cleaners.

Can I mount the TV on the wall?

Yes, use a VESA 200x200 wall mount (not included). Make sure the wall can support the weight and follow the mounting instructions.

How to search for DTT channels?

Go to Channels > Auto search and select DTT. The device will search and store all available channels.

What to do if the sound is low or distorted?

Check the audio settings: increase the volume, disable night mode, and check the audio connections. If using an external device, test with another source.

USER MANUAL 40/133I-WB-11B2-FHBKUP-EU BLAUPUNKT

Line drawing of a flat-screen TV with a diagonal screen on the left (no text or symbols)

User guide

Enjoy it.

Bedienungsanleitung

USB Multimedia Player

Important safety instructions

CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN

Please, read these safety instructions and respect the following warnings before the appliance is operated:

In order to prevent fi re spread, always keep candles and other open fl ames away from this product.

• TV with the weight of more than 20 kg must be lifted and carried by at least two people.
• Be careful! This TV does not contain any parts which could be repaired by the user. In case of a fault, contact the producer or the authorized service. The contact with certain parts inside the appliance might endanger your life. The guarantee is not provided for the faults caused by non-professional interactions!
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
• Do not remove the rear part of the appliance.
• This appliance is designed for receiving and reproduction of video and sound signals. Any other use is strictly forbidden.
• The ideal distance to watch TV is approximately five times longer of the diagonal of the screen. The light striking upon the screen from other light sources can cause reflections and make the quality of the picture worse.
• Please, ensure the sufficient ventilation and appropriate distance of the appliance from other pieces of furniture.
  • Install the product at least 5 cm from the wall for ventilation.
• The apparatus shall be used in moderate climates only.
• The TV set is designed exclusively for the operation in a dry place. When using the appliance outside, please, make sure it is protected against moisture (rain, splashing water). Never expose the appliance to moisture.
• Do not place any containers with water on the appliance, such as vases, etc. These containers might get pushed over, which would endanger electric safety. Place the appliance exclusively on fl at and stable surfaces. Do not place any objects such as newspaper or blankets, etc. on or under the appliance.
• Make sure the appliance does not stand on any power cables as they might get damaged. Mobile phones and other devices such as WLAN adapters, monitoring cameras with wireless signal transmission, etc. might cause electromagnetic interference and they should not be placed near the appliance.
• Do not place the appliance near heating elements or in a place with direct sunshine as it has a negative effect on cooling of the appliance. Heat storage is dangerous and it can seriously reduce the lifetime of the appliance. In order to ensure the safety, ask the qualified person to remove the dirt from the appliance.
• Try to prevent the mains cable or (if it is part of delivery) mains adapter damage. The appliance can only be connected with a supplied mains cable/adapter.
• Storms are dangerous for all electric appliances. If the mains or aerial wiring is struck by the lightening, the appliance might get damaged, even if it is turned off. Thus you should disconnect all the cables and connectors of the appliance before the storm.
• To clean the screen of the appliance use only a damp and soft cloth. Use only clean water, never detergents or in no case dissolvents.
• Position the TV close to the wall to avoid the possibility of it falling when pushed.

The instructions shown below are a safer way to set up the TV, by fixing

it to the wall, avoiding the possibility of it falling forwards if pulled. This will prevent the TV from falling forward and causing injury. This will also prevent the TV from damage.

This method is used if the TV is placed on a glass surface or you do not wish to screw anything into your furniture.

Ensure that children do not climb or hang onto the TV.

For this type of installation you will need a fastening chord

A) Using one/both of the top wall-mounting holes and screws (the screws are already supplied in the wall mounting holes) fasten one end of the fastening chord/s to the TV.
B) Secure the other end of the fastening chord/s to your wall.

• To use this model TV as a PC/laptop monitor it will need to be connected via the VGA input, it cannot be used as a PC/laptop monitor via the HDMI input. The HDMI Input is provided to view digital content with compatible external devices.
• The software on your TV and the OSD layout can be changed without notice.

Warning:

• Never connect any external devices to a live appliance. Switch off not only the TV but also the devices which are being connected! Plug the appliance plug into the wall outlet after connecting the external devices and the aerial!
• Always make sure there is free access to the appliance main switch and to its mains plug.
• The appliance is not designed for a use in a workplace fitted with monitors.
• The systematic use of headphones at high volume might lead to irreversible hearing damage.
• Ensure environmental disposal of this appliance and any components including batteries. When in doubt, please, contact your local authority for details of recycling.
• While installing the appliance, do not forget that furniture surfaces are treated with various varnishes, plastics, etc. or they might be polished. The additions contained in these products might cause destruction of base material of appliance stand. This will result in the holdovers of this material stuck to the furniture surface, which are difficult to remove, if not even impossible.
• The screen of your TV responds to the top quality requirements and it was checked in details for accidental faulty pixels several times. Due to the technological properties of the manufacturing process, it is not possible to eliminate the existence of a small number of faulty points on the screen for 100% (even with maximum care while production provided). These faulty pixels are not considered faults in terms of guarantee conditions, if their extent is not greater than the boundaries defined by DIN norm.

Important information regarding use of video games, computers, captions and other fixed image displays.

• The extended use of fixed image program material can cause a permanent "shadow image" on LCD screen (this is sometimes incorrectly referred to as "burnout to the screen"). This shadow image is then permanently visible on the screen in the background. It is a partly irreversible damage. You can avoid such a damage by respecting the following instructions:
• Reduce the brightness/contrast setting to a minimum viewing level.
• Do not display the fixed image for a long period of time. Avoid displaying of:

» Teletext time and charts,
» TV/DVD menu, e.g. DVD contents,
» In the „Pause“ mode (hold): Do not use this mode for a long time, e.g. while watching a DVD or a video.
» Turn off the appliance if you are not using it.

Batteries

• Observe the correct polarity when inserting the batteries.
• Do not expose batteries to high temperatures and do not place them on locations where the temperature might increase quickly, e.g. near the fire or on the direct sunshine.
• Do not expose batteries to excessive radiant heat, do not throw them into the fire, do not disassemble them and do not try to recharge unrecoverable batteries. They could leak out or explode.

» Never use different batteries together or mix

new and old ones.

» Dispose of batteries in an environmentally friendly way.
» Most of the EU countries regulate the disposal of batteries by law.

Cd

Disposal

- Do not dispose of this appliance as unsorted municipal waste. Return it to a designated collection point for the recycling of WEEE. By doing so, you will help to converse resources and protect the environment. Contact your retailer or local authorities for more information.

3D Safety Information\*

• If you watch the 3D imaging too closely or for a long period of time, it may harm your eyesight.
• Watching the TV or playing video games that incorporate 3D imaging with the 3D glasses for a long period of time can cause drowsiness, headaches or fatigue to you and/or your eyes. If you have a headache, or otherwise feel fatigued or drowsy, stop watching the TV and take a rest.
• Pregnant woman, seniors, persons with heart problems or persons who experience frequent drowsiness should refrain from watching 3D TV.
• Some 3D imaging may cause you to duck or dodge the image displayed in the video. Therefore, it is best if you do not watch 3D TV near fragile objects or near any objects that can be knocked over easily.
• Please prevent children under the age of 5 from watching 3D TV as it may affect their vision development.

Warning for photosensitization seizure:\*

- Some viewers may experience a seizure or epilepsy when exposed to certain factors, including flashing lights or images in TV or video games. If you or anybody from your family has a history of epilepsy or seizure, please consult with your doctor before watching 3D TV. Also certain symptoms can occur in unspecified conditions without any previous history. If you experience any of the following symptoms, immediately stop watching the 3D imaging and consult a doctor: dizziness or light headedness, visual transition or altered vision, visual or facial instability, such as eye or muscle twitching, unconscious action, convulsion, loss of conscience, confusion or disorientation, loss of directional sense, cramps, or nausea. Parents should monitor their children, including teenagers, for these symptoms as they may be more sensitive to the effects of watching 3D TV.

Risk of photosensitization seizure can be reduced with the following actions.\*

• Take frequent breaks from watching 3D TV.
- For those who have vision that is different in each eye, they should watch the TV after taking vision correction measures.
- Watch the TV so that your eyes are on the same level as the 3D screen and refrain from sitting too closely to the TV.
- Do not watch the 3D imaging when tired or sick, and avoid watching the 3D imaging for a long period of time.
- Do not wear the 3D glasses for any other purpose than viewing 3D imaging on a 3D TV.
- Some viewers may feel disoriented after watching 3D TV. Therefore, after you watch 3D TV, take a moment to regain awareness of your situation before moving.
* - only for TVs with 3D function

What is included in the box

Supply of this TV includes following parts:

• 1x TV
• 1x Remote control
• 2x AAA batteries
• 1x User guide
• 1x Stand
• 1x Stand neck
• 1x RF cable
  • 1x TV stand installation packet
  • 3D glasses (Only for models with 3D function)

Attaching the Stand

Please follow the instructions in the Stand installation leaflet, located in the accessories bag.

Getting started - initial set up

1. Using the RF cable supplied, connect the TV to the TV Aerial wall socket. Connect the power cable to the Electrical outlet.
2. Turn on the device with marked ON/OFF switch
3. Insert the batteries supplied into the Remote control and press the Standby button to power on the TV.

4. You will now be welcomed with the initial set-up screen. If it does not appear, on the remote control, please press [MENU] then 8-8-8-8 and the menu will appear. If you wish to make changes to any of the default settings, use the scroll ▲/▼/◄/► buttons. To exit this menu at anytime, press [EXIT] button.

5. Please select desired language, country and environment.

Set LCN to ON if you want to arrange found channels by cable provider preferences (only applies to DVB-C channels).

To confirm settings press [OK] button.

1. In the next step select the type of digital broadcasting. You can choose between DVB-T (terrestrial), DVB-C (cable) or DVB-S2(satellite)*. The analog channel will be searched automatically, as most of the cable network includes analog channels.

Press [OK] button to start the tuning process.

1. Optional channel presets DVB-C: Select DVB-C if your TV is connected to a cable TV network. Keep all default settings as it is recommended.

Press [OK] button to start the tuning process.

If DVB-C channels are not found, contact your network provider for the valid "Network ID". Then perform a new search. Press the [MENU], select "Network ID" and enter the network ID.

1. Optional channel presets DVB-S2*: Select "Satellite" in the "Digital-type" in the menu for the optional channel presets. Here you can choose between the various satellites. Since selection completed, then the channel list of the exact satellite will be available to be imported into your TV system. This take several seconds.

Confir rm with [OK] button on the remote control, to start scanning.

TIP: If you are missing channels, the reason for this is likely to be signal strength, you should consider connecting signal booster and re-tuning the TV. TIP: As part of our continuing efforts to reduce energy consumption, we added a new Home Mode feature (appears on the first installation screen). This function helps reduce energy consumption up 15% compared to other modes. The image brightness is reduced using Home Mode. If this setting does not suit your environment, you can choose from other modes (Note: the Store mode is the optimal default mode, but consumes 15% more than the Home Mode).

* - Available only for TVs with DVB-S function

Remote control

STANDBY – Switch on TV when in standby or vice versa.

MUTE - Mute the sound or vice versa.

DTV- Switch to digital TV source.

RADIO - TV/RADIO - Switch to Digital and switch between TV and radio in Digital mode.

USB - Switch to USB source.

ATV- Switch to analog TV source.

DVD ^1 - Switch to DVD mode

0 - 9 - to select a TV channel directly.

TV GUIDE – Opens the 7 Day TV Guide (Digital mode).

- To return to the previous channel viewed.

VOL ▲/▼ - To increase / decrease the sound level.

S.MODE - Scrolls through sound mode options

P.MODE - Scrolls through picture mode options

FAV – To display favourites menu.

CH ▲/▼ – To increase or decrease the channel being watched.

(▲/▼/◄/►/OK) – Allows you to navigate the on-screen menus and adjust the system settings to your preference.

MENU – To display OSD menu.

EXIT – To exit all menus.

SOURCE – To display the input/source menu.

INFO – Press once for now/next channel information. Press twice for programme information about current programme.

ASPECT – To switch the screen between the different picture formats.

SLEEP – Press repeatedly to cycle through the sleep options.

AUDIO - To change the audio language (if available).

SUBTITLE – To switch the dialogue at the bottom of the screen (on/off).

TEXT - Teletext mode - To enter Teletext

TEXT HOLD - HOLD - Teletext mode - Hold current page which is displayed

TEXT/ DVD ZOOM - DVD mode - Teletext Mode - To zoom in

ZOOM - DVD mode - Teletext Mode - To zoom in -

DISPLAY – To switch off the screen when listening to radio

DVD MENU ^1 – DVD mode - To display the DVD disc menu

Rec ^2 - PVR mode - PVR Record

DVD SETUP ^1 – DVD mode - To display the DVD setup menu

Rec List ^2 – PVR mode - Opens the list of recordings.

To restart the current chapter

▶ To advance forward to the next chapter

■/▲- To stop the playback / To EJECT the disc press/hold the button for 4 seconds.

◀ To play in fast rewind mode.

▶▶- To play in fast forward mode.

▶ – To play/pause

GOTO ^1 – DVD mode - To go to a specific chapter

A-B ^1 – DVD mode - Press once to set point, press a second time to return to point

ANGLE ^1 – DVD mode - Select different angle of DVD (if available)

REPEAT - DVD mode ^1 - USB mode - To repeat playback

REVEAL - Teletext mode - To reveal or hide the hidden words

SIZE - Teletext mode - To change the display size in Teletext mode

TITLE ^1 – To display the DVD disc menu

D. DIS ^1 – To display the current disc information

INDEX - Teletext mode - To display the index page

Red Green Yellow Blue button- Additional teletext and OSD functions

3D button ^3 - Switches between 3D type settings

1 - available only for TVs with DVD players

2 - available only with PVR function

3 - Available only for TVs with 3D function

TV buttons & Source menu

▲ Eject*

Play / Pause *

Vol+ Volume up and menu right

Vol- Volume down and menu left

CH+ Programme/Channel up and menu up

CH- Programme/Channel down and menu down

MENU Displays Menu/OSD

SOURCE Displays the input source menu

STANDBY Standby Power On/Off

* - Only for models with DVD-Player

Choosing Mode Input/Source

To switch between the different input/connections.

a) Using the buttons on the remote control:

1. Press [SOURCE/ AV] - The source menu will appear.

2. Press [▼] or [▲] to select the input you require.

3. Press [OK].

b) Using the buttons on the Television:

1. Press [SOURCE].

2. Scroll up / down using CH+/CH- buttons to the input/source you require.

3. PressVol+ to change input/source to the one selected.

Connections

USB

USB-Input

HDMI 1, 2*, 3*, 4* in

HDMI-Input 1, 2*, 3*, 4*

VGA(PC) *

VGA PC-Input

VGA (PC) Audio In *

3.5mm PC audio input

R/L - Video & YPbPr audio In *

Component / Video audio input

Mini AV*

Component / Video audio input

Video (CVBS) *

VIDEO Input

Mini YPbPr*

Mini Component HD Input

YPbPr*

Component HD Input

SCART*

SCART-Input

CI Card IN

SCART input

RF In

RF / TV Aerial Input

Sat In *

Satellite Input

COAX Audio Out *

Digital Coax output

HEADPHONES

3.5mm Headphone output

* - Only on supported devices

TV Menu navigation

To access this menu, press [MENU] button on the remote control. To enter a menu press [OK]. If you wish to make changes to any of the default settings, use the scroll (▲/▼/◄/►) buttons. To confirm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.

Channel

Auto Tuning - Allows you to retune the television for all digital channels, digital radio stations and analogue channels.

Analogue Manual Tuning - Allows you to manually tune your analogue signal.

Digital Manual Tuning - Allows you to manually tune your digital signal.

Programme Edit - Allows you to delete, skip and add favourite channels.

Schedule List - Lists your programme reminders.

Signal Information - Information about DVB signal.

CI Information - Pay per view services require a "smartcard" to be inserted into the TV. If you subscribe to a pay per view service the provider will issue you with a 'CAM' and a "smartcard". The CAM can then be inserted into the COMMON INTERFACE PORT (CI Card In).

Dish Setup ^* - This menu is only available in DVB-S2 mode. You can select the type of satellite, your transponder and your LNB type, etc.

* - Only for models with DVB-S tuner


Picture Mode - Choose from the following presets.

- Standard - Default settings

• Dynamic - Recommended settings for fast moving pictures
• Mild - Set to be lighter in colour and less bright
• Personal - Lets you manually alter all the settings
• Economy - Consume 15% less energy.

Contrast - Switch the balance between black and white.

Brightness - Increase or decrease the brightness of the picture.

Colour - Increases the colour from black and white.

Tint - Lets you increase or decrease the level of tint within the picture.

Sharpness - Increase or decrease the sharpness of the picture.

Colour Temperature - Choose from the following presets.

- Normal - Default settings

• Warm - Increases red within the picture
• Cold - Increases blue within the picture

Noise Reduction - Choose from the following presets.

• Off - Turns noise reduction off
• Low- Minor system adjustment
  – Middle- Medium system adjustments
  – High - Maximum system adjustments
• Default - Default settings

3D Settings \*

TIP: For the best 3D picture effect, watch your TV from vertical angle +/- 10°.

3D Type - 3D Type- When connecting a 3D product sometimes the picture maybe displayed incorrectly; choose from the following settings to correct this. You can toggle these settings by pressing the '3D' button on your remote.

• 3D off - Turns 3D off
• Side by Side 3D Format - 3D format is commonly used in 3D broadcasting, works by halving the horizontal resolution of videos to store left and right eye images in each frame. It eff ectively displays up to 960 × 1080 -pixel pictures to each eye, enabling TV stations to

telecast 3D content at a much lower bandwidth compared with 3D Blu-ray discs. Typical supported resolutions are limited to 720p and 1080i for 3D TV programs. Users will need to manually select the correct 3D format to properly display side-by-side 3D content on a 3D TV.

- Top Bottom 3D Format - 3D format is alternative for 3D broadcast, which is pretty similar to side-by-side 3D except that it halves the vertical resolution instead. Available primarily up to 720p resolution, top-and-bottom 3D offers 1,280 pixels horizontally. The higher pixel count is generally considered more suitable for displaying panning motion in sports programs.

• Frame Alternative - As its name suggests, this format stacks the left and right eye images in each frame to retain the content's original resolution for the best 3D pictures. Most, if not all, 1080p 3D Blu-ray movie discs and 720p PS3 3D games are produced utilizing this technique. Another key differentiator is that all 3D TVs should be able to automatically detect frame-packing 3D signals and correctly display the content without user intervention.
• Line by Line - The picture signals for left and right eyes are interleaved in alternate lines. The left clip's resolution is halved then placed in the odd lines of the video stream. Correspondingly, the right clip's resolution is halved then placed in the even lines of the video stream. When combined the video stream totals 1920 × 1080 .

Exchange 3D L/R- change picture sequence for different viewing
2D to 3D- Changes the picture from regular 2 dimensions to 3 (3D). Please note as content is being changed by the TV the effects are limited
3D to 2D- Changes the picture from 3D to regular 2 dimensions (2D).
2D to 3D Depth - Depth of pictures converted from 2D to 3D.
* - Only for models with 3D function

Sound

Sound Mode - Choose from the following presets

• Standard - Default settings
• Music - Emphasises music over voices
• Movie - Provides live and full sound for movies
• Personal - Selects your personal sound settings
• Sports - Emphasises sound for sports

Tip: Treble and bass levels can only be adjusted when the sound mode 'Personal' is selected.

Treble - To adjust the level of high frequency within the sound.

Bass-To adjust the level of low frequency within the sound.

Balance - To switch the sound between the left and right speakers.

Auto Volume Level (AVL) - When 'on' is selected, the volume will stay at a constant level regardless of input/source.

Digital Output - This is the digital COAX Audio output. Choose from the following options:

• Off - Off
• Auto - Selects the best settings automatically

- PCM- Select this option if you are connecting to a Stereo Hi-fi via coax cable (Pulse-code modulation (PCM) is a digital representation of an analogue signal)

Audio Description - Additional sound track for visually impaired.

Available only on selected DTV shows.

Time

Clock - Set the date and time. Date and time is set up automatically in DVB mode.

Off Time - Allows you to set a specific time for your TV to turn off.

On Time - Allows you to set a specific time for your TV to turn on, the channel it will then display, the source it will be on and also the volume. This function can then be toggled to repeat every day or a certain day.

Time Zone - Change your current time zone.

Sleep Timer - Lets you set the sleep timer so the television automatically switches off after a set amount of time. Off -> 10min -> 20min -> 30min -> 60min -> 90min -> 120min -> 180min -> 240min.

Auto standby - Adjustment for the auto standby in hourly increments: Off -> 3h -> 4h -> 5h.

OSD Timer - Lets you adjust the amount of time the On Screen Menu stays on the screen before disappearing.

Lock

System Lock - Allows you to lock or unlock the menu. You will be asked to enter a 4 digit password. Use the ◀ button to quit the password input. Use the ▶ button to clear. Default password is 0000.

Set Password - Change the default password.

Channel lock - Lock specifi c TV channels.

Parental Guidance - Lock TV channels based on age restriction.

Key Lock - Lock the TV buttons.

Hotel mode

For access to Hotel mode press buttons „MENU 7 9 0 6“. In hotel mode you may preset and lock some TV functions.

Setup

Language - Allows you to change the language of the menu.

TT Language - Encoding settings for the proper display of teletext characters.

Audio Languages - Allows you to change audio language on selected DVB channels.

Subtitle Language - Allows you to change subtitles language on selected DVB channels.

Hearing Impaired - If signal provides support for the hearing impaired, the subtitles can be played by pressing the "Subtitle". If you set Hearing Impaired ON and switch to a channel with supports for hearing impaired subtitles will be activated automatically.

Aspect Ratio - Within the EU the picture form varies depending on the channel/broadcast. There are a number of different options to best meet your needs.

- Auto-Automatically displays the best picture format. So the picture is in the correct position. May have black lines at the top/bottom and/or sides.

- 4:3 - Displays the 4:3 picture in its original size. Side bars are shown to fill the 16:9 screen.

- 16:9 - Fills the screen with a regular 16:9 signal.

- Zoom 1/2 - The picture is the correct proportion but zoomed in to fill the screen.

Full Screen - Stretch signal to fill the screen.

Blue Screen - Changes the background when there is no input between transparent and a blue background (Only available on some sources).

First Time Installation - Starts the first time installation.

Reset - This resets the menus to factory settings.

Software Update (USB) - From time to time we may release new fi rmware to improve the operation of the television (available to download). This menu lets you install the new software/ fi rmware onto the television. Further details of how to do this will be issued with the fi rmware. Contact the helpline or refer to the 'www.umc-slovakia.sk/products-support/' website.

HDMI CEC* - Allows you to operate devices connected via HDMI with TV remote control.

- Auto power* - Automatically turn on/off connected devices via HDMI CEC

- Device menu* - Allows you to access devices menu and operate the menu using TV remote control.

- HDMI ARC* - Sends audio signal from terrestrial/satellite broadcast via HDMI to the AV receiver without using any additional audio cables, this functions is available only on HDMI 2 output.

* - HDMI CEC must be supported by connected device.

PC Settings \*

Auto Adjust - Lets you automatically configure the television to be used as a computer monitor.

H Off set - Changes the horizontal position of the picture.

V Off set - Changes the vertical position of the picture.

Size - increase picture size.

Phase - To adjust delay time of phase in order to reduce the noise of picture Position Reset - Changes back to the original settings

Tip: If the computer is left in-active for a period of time, the television will switch into a 'sleep' state (the screen will power off to save power). To switch back on press the standby button.

Tip: If you do not press any buttons for 10 seconds, the menu will automatically exit. You can change the length of time before the menu exits automatically - see 'OSD Timer' section.

* only for devices with VGA connector

7 Day TV Guide

TV Guide is available in Digital TV mode. It provides information about forthcoming programmes (where supported by the Digital channel). You can view the start and end time of all programmes and on all channels for the next 7 days and set reminders.

1. Press [TV GUIDE]. The following 7 Day TV Guide will appear.

2. Navigate through the menu using ▲/▼/◄/►.

You can now:

Record selected TV channel and TV show by pressing the RED button.* only for models with recording function

Set a reminder by pressing GREEN.

View a previous day by pressing YELLOW.

View the next day by pressing BLUE.[INFO] shows detailed information about the selected post

1. Press [EXIT] to exit the 7 day TV Guide.

USB mode / Media player

USB mode offers playback of various different types of content that you have saved on your USB Memory Stick. On switching to USB source the USB mode menu screen will appear. The content will be divided into Photo, Music, Movie and Text based on file type.

1. You can navigate through the menus using the scroll ▲/▼/◄/► buttons. To confirm the item you wish to play/view press[OK] button.

2. Select the drive you require. (If your drive only has 1 partition you will only see 1 item).

3. You can now access the item. Press OK to view.

4. While viewing you may control the item playback modes by using the remote control buttons or by invoking playback navigation menu and selecting on-screen buttons ▲/▼/◄/► and [OK]

USB Record - Digital mode\*

Built into this television is a USB record facility. This function is available in Digital mode when used in conjunction with a compatible USB memory stick or USB Hard drive. The benefits of this are as follows:

- Pause live TV and then playback, fast forward and rewind (up to live TV).

• One button record, if you decide you want to record the current programme.
• Easy programmable recording from the 7 day TV Guide
• Record TV and watch back on your computer/laptop.
  Due to the nature of the product, it is necessary to use a high speed USB memory stick (as the TV reads from and writes to the memory stick at the same time, some memory sticks may not be suitable).
  Minimum Specification - USB Memory Stick
• Read Speed - 20 MB/s (Mega Byte Per Second)
• Write Speed - 6 MB/s (Mega Byte Per Second)

Pause Live TV (Time Shift) \*

Pausing Live TV is very simple.

- Press the play/pause button and the television will pause and the live content will be recorded. To resume watching press play/pause again.

- Press fast forward to go forward in a recording (i.e. to skip adverts).

- Press fast rewind to go back in a recording (i.e. if you fast forwarded too far).

TIP: When you switch the TV to standby or change channel the Time Shift memory is wiped. To restart time shift you must press play/pause button.

One Button Record

At any point in time you may decide to record the current channel that you are watching. To do this you need to press the [REC] button.

TIP: This television contains one TV tuner, therefore it can only record the channel you are watching or record one channel while the television is in standby mode.

Note: USB record function is only available in Digital TV mode. Due to copyright laws and illegal copying/recording it is not possible to record to/from any other input/output source.

* - only for devices with built in PVR function

DVD Menu\*

To access this menu, press [D. MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll ▲/▼/◄/► buttons. To confirm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.

General Setup Page

TV Display - Choose from the following options 4:3

- PanScan - PS Traditional picture format, often used on old film

- 4:3 LetterBox - LB Traditional picture which has been adapted for widescreen

- Wide - Widescreen picture format

OSD Language - Select desired language

Audio Setup Page

Speaker Setup - Choose from the following options

- LT/RT - Set LT/RT Downmix

- Stereo - Set Stereo Downmix

Dolby Digital Page

Dual Mono

- Stereo - Outputs 2 channels of sound both left and right

- Mono L - Outputs left side sound

- Mono R - Outputs right side sound

- Mix Mono - Outputs a single channel of sound but mix between right and left

Dynamic Range - This is the difference between the quietest and loudest sounds. This setting works only with DVD discs recorded in Dolby digital.

Preference Page

TV Type - Choose from the following options

• NTSC - Normally used for discs from North America, Japan etc
• PAL - The standard for discs from UK/Europe, most of Asia, Australia etc
• Multi - For both NTSC and PAL
  Default - This option allows you reset all DVD settings to factory settings.
  * - only for devices equipped with built in DVD Player

-G./D.-Lt/Rt downmix

- Stéréo - Stereo downmix

Réglage Dolby D

Dual Mono -

• Lt/Rt - Lt/Rt downmix
• Stereo - Stereo downmix

▶ I – Odtwarzanie/pauza

USB mode / Media player

USB nudi prikazivanje raznih tipova sadržaja koje ste pospremiliu na USB memoriji. Prelaskom na USB izvor USB meni će se pojaviti. Sadržaj će biti podijeljen na Photo (fotografi je),

Music (muzika), Movie (fi lm) and Text (tekst) u zavisnosti od vrste dokumenta.

1. Možete se kretati kroz meni koristeći ▲ /▼ /◀/▶ tipke Kako biste potvrdili Vaš izbor pritisnuti tipku [OK].
2. Izaberite željeni prenosnik. (ako prenosnik sadrži 1 podjelu vidjećete samo 1 predmet).
3. Možete pristupiti pritiskom na OK.
4. Dok gledate možete kontrolisati gledanje koristeći daljinski upravljači ili pozivanjem navigacijskog menija i izborom tipaka ▲ /▼ / ◀/► a zatim [OK]

USB snimanje - Digitalni mode\*

U Vaš televizor ugrađen je USB zapis. Ova funkcija je dostupna u digitalnom modu kada se koristi zajedno sa odgovarajućom USB memorijom ili USB hard disk.Prednosti ovoga su:

• Pauziranje TV uživo a zatim gledanja, premotavanja.
• Snimanje jednim dugmetom, ako želite možete snimati trenutne programe.
• Lako programiranje snimanja sa 7 dnevnog TV programa.
• Snimanje TV i gledanje na kompjuteru/laptopu. Zbog prirode proizvoda potrebno je koristiti USB memoriju visoke brzine (pošto TV čita i zapisuje na memoriju u istom trenutku, neke USB memorije nisu prihvatljive).

Minialne specifi kacije - USB Memorija

- Brzina čitanja - 20 MB/s (Mega Byte Po Sekundi)

- Brzina zapisivanja - 6 MB/s (Mega Byte Po Sekundi)

Pause Live TV (Time Shift) \*

ATV–Switch to analog TV source.

DVD ^1 – preklopite na DVD.

Mod USB / Media player

MENU – For at vise OSD menu

SOURCE – For at vise input/source menu

TEXT – Teletext mode: For at gå til Teletext

TEXT HOLD - HOLD – Teletext mode: Hold nuværende side som vises

TEXT / DVD ZOOM – Teletext mode: DVD mode: For at zoome ind på teksten

DISPLAY – Sluk for LCD panelet

DVD MENU ^1 – DVD mode: For at vise DVD disc menu

SIZE – Teletext mode: For at skifte display størrelsen i Teletext mode

TITLE ^1 – DVD mode: For at vise DVD disc menu

D. DIS ^1 – Hvis information om DVD playback

	CI Card INSCART input
	RF InRF / TV Aerial Input
	Sat In *Satellite Input
	COAX Audio Out *Digital Coax output
	HEADPHONES3.5mm Headphone output

b) Using the buttons on the Television:

WAARSCHUWING RISICO VAN ELEKTRISCHE SCHOK NIET OPENEN

DTV – Switch to digital TV source.

RADIO – Prepnutie na Digital a prepínanie medzi TV a rádio v režime Digital

USB – Prepnutie na USB zdroj

DVD¹ – Prepnutie na DVD zdroj

0 – 9 – priama volba TV kanálu.

Uzbek Prices in the United States is a serious problem that is not to be affected by the U.S.

التخلص من الجهاز

Solid blue square with rounded corners (no text or symbols)
