Björn Axén Flow Travel 5188 - Hair Dryers OBH NORDICA - Free user manual and instructions

Product Type	Hair Dryer
Brand	OBH Nordica
Model	Björn Axén Flow Travel 5188
Power	1200-1600 W
Voltage	120-230 V~ (dual voltage)
Frequency	50/60 Hz
Speed Settings	2
Heat Settings	2
Cool Function	Yes (continuous or momentary)
Concentrator Nozzle	Included
Hanging Loop	Yes, on cord
Foldable Handle	Yes, for compact storage
Overheat Protection	Yes, automatic shut-off
Air Inlet Cleaning	Removable grille, brush cleaning
Weight (approx.)	400 g
Cord Length (approx.)	1.8 m
Warranty	2 years (limited manufacturer guarantee)
Intended Use	Domestic, travel

Frequently Asked Questions - Björn Axén Flow Travel 5188 OBH NORDICA

How do I set the voltage for different countries?

Turn the screw on the rear of the handle using the supplied key to select either 120V or 230V before plugging in.

Can I use the cool function continuously?

Yes, push the cool button upwards for continuous cold air, or press and hold for short bursts.

What happens if the hair dryer overheats?

It will automatically shut off. Switch it off, let it cool for a few minutes, then it can be used again.

How do I clean the air inlet?

Unplug the dryer, remove the air inlet grille, and clean dust or hair with a small brush or vacuum cleaner.

Is the handle foldable?

Yes, the handle can be folded for easy storage and travel.

Does this hair dryer come with a concentrator?

Yes, a concentrator nozzle is included for precise styling.

What is the warranty period?

OBH Nordica offers a 2-year limited guarantee against manufacturing defects in Sweden, Norway, Denmark, and Finland.

Can I use it in the bathroom?

Yes, but keep it away from water. Unplug immediately after use if near water, as moisture poses a hazard even when off.

What power and voltage does it support?

It operates on 120-230V, 50/60Hz, and draws 1200-1600W. Dual voltage makes it ideal for travel.

How do I store the hair dryer after use?

Fold the handle, use the hanging loop on the cord, and store in a dry place. Never wrap the cord tightly around the dryer.

USER MANUAL Björn Axén Flow Travel 5188 OBH NORDICA

BEGRENSET GARANTI for OBH Nordica

Garantien

1. Read the instruction manual carefully before use, and save it for future use.
2. Plug the appliance to a household outlet of 120-230V only, and use the appliance only for the intended use.
3. Always unplug the appliance from the mains supply when disorder is experienced, when not in use, and before cleaning and maintenance.
4. This appliance can be used by children aged 8 years and above and persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, if they have been given supervision or instruction concerning the use of the appliance in a safe way by a person responsible for their safety and they understand the hazards involved.
5. Children should be supervised to ensure that they do not play with the appliance. Children are not always able to understand potential risks. Teach children a responsible handling of electrical appliances.
6. Cleaning and user maintenance shall not be made by children, unless they are over the age of 8 and supervised.
7. Check that the cord is not hanging over the edge of the table.
8. The appliance should only be used under supervision.

9. Warning: Do not use this appliance near bathtubs, showers, basins or other vessels containing water.

10. The appliance should not be immersed in water or other liquids. Never use the appliance with wet hands and never place the appliance at a wet or damp surface.

11. Always unplug the appliance from the mains supply immediately after use, if the appliance is used in a bathroom since the proximity of water presents a hazard even when the appliance is switched off.

12. The appliance is protected against superheating caused by e.g. a covered or blocked air intake. If the appliance stops when in use, switch off the appliance to let it cool off before it is switched on again.

13. The air intake must not be covered when in use, and should be cleaned regularly.

14. Always examine appliance, cord and plug for damage before use. If the supply cord is damaged, it must be replaced by the manufacturer, or his service agent or a similarly qualified person in order to avoid a hazard.

15. For additional protection the installation of a residual current device (RCD) with a rated residual operating current not exceeding 30 mA is recommended. Ask your installer for advice.

16. The appliance is for domestic use only.

17. If the appliance is used for other purposes than intended, or is it not handled in accordance with the instruction manual, the full responsibility for any consequences will rest with the user. Any damages to the product or other things are not covered by the warranty.

Use

The hairdryer can be adjusted to 120 and 230V and is therefore ideal when you travel. Remember to set the desired voltage before you plug in the appliance. Select the voltage by turning the “screw” that is located on the rear of the handle to the required voltage setting using the accompanying key.

Wash, towel dry and brush your hair. If you like you can add some mousse or hair gel and then style your hair with the hairdryer.

Cool function

The different settings can be affected by the cool button (cold air). Push the button upwards for continuous use, or just keep it pressed for short use. The hair cools, which gives you a longer lasting styling. Push down the button or release it to shut of the function. When the cool function is activated the speed might increase a bit.

Concentrator

The concentrator spout concentrates the air current, when a hair style should be formed, e.g. with a round brush. The concentrator spout is mounted with a light pressure, and is twisted off after use. If the hair should be dried fast, remove the spout and choose a high temperature setting and high airflow.

Hanging loop

This hair dryer has a hanging loop on the cord which makes it easy to store after use.

Overheating

The hair dryer is protected against overheating, caused by e.g. a covered or blocked air intake or it the exhaust is blocked. In the event of overheating the hair dryer will stop automatically. If this happens, switch off the hair dryer, let it cool off, and the hair dryer will be ready again after a short while.

Cleaning and maintenance

• Always unplug the appliance from the mains supply before cleaning.
- Clean the air inlet by loosening the grille on the air inlet. Then remove any dust or hair using a small brush. You can also use a vacuum cleaner to clean the air inlet when the appliance is switched off.
- The surface is wiped with a soft, slightly wet cloth.
- The appliance should not be immersed in water or other liquids.
The handle can easily be folded for convenient storage.

Disposal of the appliance

Legislation requires that all electrical and electronic equipment must be collected for reuse and recycling. Electrical and electronic equipment marked with the symbol indicating separate collection of such equipment must be returned to a municipal waste collection point.

OBH Nordica LIMITED GUARANTEE

The Guarantee

OBH Nordica guarantees this product against any manufacturing defect in materials or workmanship during 2 years within Sweden, Norway, Denmark and Finland, starting from the initial date of purchase or delivery date.

This manufacturer's commercial guarantee covers all costs related to restoring the proven defective product so that it conforms to its original specifications, through the repair or replacement of any defective part and the necessary labour. At OBH Nordicas choice, a replacement product may be provided instead of repairing a defective product. OBH Nordicas sole obligation and your exclusive resolution under this guarantee are limited to such repair or replacement.

Conditions & Exclusions

OBH Nordica shall not be obliged to repair or replace any product which is not accompanied by a valid proof of purchase. The defective product may be returned to the store of purchase.

This guarantee applies only for products purchased and used for domestic purposes and will not cover any damage which occurs as a result of misuse, negligence, failure to follow OBH Nordica instructions, or a modification or unauthorised repair of the product, faulty packaging by the owner or mishandling by any carrier. It also does not cover normal wear and tear, maintenance or replacement of consumable parts, or the following:

• using the wrong type of water or consumable
• mechanical damages, overloading
• damages or poor results specifically due to wrong voltage or frequency as stamped on the product ID or specification
• ingress of water, dust or insects into the product
• scaling (any de-scaling must be carried out according to the instructions for use)
• damage as a result of lightning or power surges
• damage to any glass or porcelain ware in the product
• accidents including fire, flood, etc
• professional or commercial use

Consumer Statutory Rights

OBH Nordica's commercial guarantee does not affect the Statutory Rights a consumer may have or those rights that cannot be excluded or limited, nor rights against the retailer from which the consumer purchased the product. This guarantee gives a consumer specific legal rights, and the consumer may also have other legal rights which vary from Country to Country. The consumer may assert any such rights at his sole discretion.

These instructions are also available on our website www.obhnordica.com.

TEFAL - OBH Nordica Group AB

Löfströms Allé 5

172 66 Sundbyberg

Phone [phone]

www.obhnordica.com

Technical Data

OBH Nordica 5188

120-230V\~, 50/60 Hz

1200-1600W

2 speed settings/heat settings

Cool function

Concentrator

Protection against superheating

With reservation for running changes.

Two black Björn Axén tools with branding, shown from different angles (no text or symbols on the devices themselves)
