VM6422X1 - Dishwasher Mora - Free user manual and instructions

Product Type	Built-in Dishwasher
Brand	Mora
Model	VM6422X1
Dimensions (H x W x D)	85 cm x 60 cm x 60 cm
Weight	Approx. 50 kg
Power Supply	220-240 V, 50 Hz, 10 A
Energy Class	E (EU energy label scale)
Noise Level	49 dB(A)
Place Settings	13
Programs	Eco, Intensive, Normal, Quick, Glass Care
Key Functions	Delay Start (1-24h), Half Load, Extra Dry, Auto Open
Safety Features	Child Lock, Leak Protection System, Anti-flood Device
Maintenance	Self-cleaning filter, Salt and Rinse Aid indicators
Spare Parts Availability	Filters, spray arms, racks, seals easily replaceable
Noise Class	C
Water Consumption (Eco program)	9.5 L per cycle
Energy Consumption (Eco program)	0.94 kWh per cycle
Installation	Fully integrated under countertop

Frequently Asked Questions - VM6422X1 Mora

What are the dimensions of the Mora VM6422X1 dishwasher?

The Mora VM6422X1 is a standard built-in dishwasher with dimensions of 85 cm height, 60 cm width, and 60 cm depth. Ensure your cabinet opening matches these. Weight is approximately 50 kg.

How many place settings does the VM6422X1 hold?

This dishwasher can hold up to 13 place settings, suitable for a standard household. Adjust the upper rack to accommodate larger items.

What wash programs are available on the Mora VM6422X1?

It includes Eco, Intensive, Normal, Quick, and Glass Care programs. Eco is best for energy savings, Intensive for heavily soiled pots, and Quick for light loads.

How do I activate the child lock?

Press and hold the Child Lock button (usually with a key icon) for 3 seconds until the indicator lights up. Repeat to deactivate. This prevents accidental program changes during operation.

What should I do if the dishwasher doesn't drain?

First, clean the filter under the lower spray arm. Check the drain hose for kinks or blockages. Ensure the sink drain is not obstructed. If the issue persists, run a cleaning cycle with dishwasher cleaner.

What type of detergent should I use?

Use dishwasher detergent in powder, tablet, or gel form. For best results, choose a detergent with rinse aid and salt integrated. Always fill the detergent dispenser before starting a cycle.

How do I clean the dishwasher itself?

Regularly clean the filter after each use. Run an empty hot cycle with a dishwasher cleaner monthly. Wipe the door seals and dispenser with a damp cloth. Also, descaling may be needed in hard water areas.

Can I delay the start of the wash cycle?

Yes, the VM6422X1 features a Delay Start function up to 24 hours. Press the delay button repeatedly to set the desired hour, then close the door to start the countdown.

What does the 'Extra Dry' option do?

The Extra Dry function increases the drying temperature and extends the drying phase, ensuring dishes come out completely dry. Use it for plastic items or when low rinse aid is used.

How do I install the Mora VM6422X1 under a countertop?

Ensure the cabinet opening is at least 85 cm high, 60 cm wide, and 60 cm deep. Connect the water supply hose to a cold water source, and the drain hose to a sink drain or standpipe. Level the dishwasher using the adjustable feet. Finally, secure the top with brackets to the countertop.

USER MANUAL VM6422X1 Mora

Pure diagram of a cabinet or storage unit layout without any text, numbers, or symbols

Obsah

Vaše myčka 4

Diagram showing a salt container being transferred to a funnel-shaped container, with no text or symbols present.

Illustration of a metal rack containing various cylindrical and cylindrical components (no text or symbols)

Structural diagram of a steel-framed industrial cage with internal framework and upward/downward arrows indicating force or movement (no text or labels)

Dolní koš

Illustration of a basket containing various kitchen utensils and kitchenware (no text or symbols visible)

Technical line drawing of a mechanical assembly with rotating components (no text or symbols)

Košík na příbory

Three diagrams showing a container with a handle, a vertical structure, and a horizontal support structure (no text or symbols)

Technical illustration of a livestock cage with a conveyor belt system (no text or symbols)

Diagram showing a device with a circular component and a funnel-shaped container, both rotating around it (no text or symbols present)

Mechanical component with four arrows pointing to specific parts (no text or symbols visible)

Technical illustration of a mechanical assembly with a lever and rotating component (no text or symbols)

Mechanical assembly diagram showing a rotating fan or blade mounted on a base with an upward arrow indicating motion (no text or symbols present)

Cross-sectional diagram of a mechanical or architectural structure with layered components and circular elements (no text or symbols)
