SM 6422 W1 - Dishwasher Mora - Free user manual and instructions

Product Type	Freestanding Dishwasher
Brand	Mora
Model	SM 6422 W1
Installation	Freestanding
Dimensions (H x W x D)	85 cm x 60 cm x 60 cm
Weight	Approx. 45 kg
Energy Class	E
Number of Place Settings	12
Noise Level	49 dB(A)
Water Consumption per Cycle	9.5 L
Annual Energy Consumption	295 kWh/annum
Programs	Eco, Intensive, Normal, Quick, Pre-wash
Drying Type	Condensation drying
Control Type	Electronic push-buttons with LED display
Delay Start	Yes, up to 24 hours
Safety Features	Child lock, water leak protection
Maintenance	Clean filters monthly, descale periodically
Spare Parts Availability	Filters, racks, spray arms, heating element
Warranty	2 years

Frequently Asked Questions - SM 6422 W1 Mora

How do I install the dishwasher?

Ensure the appliance is level, connect the water inlet hose to a cold water supply (max 60°C), and attach the drain hose to a sink drain or standpipe. Electrical connection must be to a grounded outlet matching the rating plate. Refer to the manual for detailed steps.

What do I do if the dishwasher doesn't start?

Check that the door is fully closed and latched, the power cord is plugged in, the circuit breaker is on, and the water supply is open. If the display shows an error, note the code and consult the troubleshooting section.

How often should I clean the filters?

Clean the filters every month to prevent clogging. Rinse under running water and scrub gently. Reassemble in the correct order. A dirty filter can reduce performance and cause odors.

Why is my dishwasher leaving spots on dishes?

Spots can be caused by hard water, insufficient rinse aid, or incorrect detergent dosage. Use a rinse aid, adjust water softener settings (if available), and ensure detergent is fresh and properly stored.

Can I use regular dish soap in a dishwasher?

No, never use regular dish soap or hand soap. It creates excessive foam that can damage the appliance. Use only dishwasher detergent (powder, gel, or tablets) specifically designed for automatic dishwashers.

What does the error code E1 mean?

Error code E1 typically indicates a water fill issue. Check that the water supply is open, the inlet hose is not kinked, and the filter in the inlet valve is clean. Restart the cycle after resolving the issue.

How do I descale the dishwasher?

Use a commercial dishwasher descaler or a mixture of citric acid. Run an empty cycle at high temperature (e.g., Intensive or 65°C). Descale every 3-6 months depending on water hardness.

Can I open the door during a cycle?

Yes, you can open the door to add dishes, but the cycle will pause. Close the door firmly and press Start to resume. Avoid opening during the drying phase as hot steam may escape.

How do I activate the child lock?

Press and hold the Child Lock button (usually marked with a padlock icon) for 3-5 seconds until the indicator lights up. To deactivate, repeat the same step.

Where can I find spare parts for this model?

Authorized service centers or online spare parts retailers. Common parts like filters, spray arms, and detergent drawer are widely available. Use the model number SM 6422 W1 to ensure compatibility.

USER MANUAL SM 6422 W1 Mora

Simple line drawing of a cabinet or enclosure with no text, numbers, or symbols

Obsah

Vaše myčka 4

Diagram showing a salt container being removed from a funnel into a container, with no visible text or symbols.

Illustration of a metal rack containing various cylindrical and cylindrical components (no text or symbols)

Structural diagram of a steel-framed industrial cage with internal framework and directional arrows (no text or labels)

Dolní koš

Illustration of a basket containing various kitchen utensils and kitchenware (no text or symbols visible)

Technical line drawing of a mechanical assembly with rotating components (no text or symbols)

Košík na příbory

Three diagrams showing a container with a handle, a vertical structure, and a horizontal support structure (no text or symbols)

Technical illustration of a livestock cage with a conveyor belt system (no text or symbols)

Diagram showing a device with a circular component and a funnel-shaped container, both rotating (no text or symbols present)

Mechanical component with four arrows pointing to specific parts (no text or symbols visible)

Technical illustration of a mechanical assembly with a lever and rotating component (no text or symbols)

Mechanical assembly diagram showing a rotating fan or blade mounted on a base with an upward arrow indicating motion (no text or symbols present)

Volně stojící

Diagram showing a mechanical component with angular notations and an arrow indicating direction (no text or symbols)

Servis

Cross-sectional diagram of a mechanical or electrical component with layered structure and circular elements (no text or symbols)
