SM 643C3 W - Dishwasher Mora - Free user manual and instructions

Product Type	Freestanding Dishwasher
Brand	Mora
Model	SM 643C3 W
Color	White
Width	60 cm
Height	85 cm
Depth	60 cm
Weight	Approximately 45 kg
Rated Voltage	220-240 V
Frequency	50 Hz
Power Consumption	1900 W
Water Consumption per Cycle	10 L
Energy Efficiency Class	A+
Noise Level	44 dB(A)
Number of Place Settings	13
Number of Programs	6
Programs	Eco, Intensive, Normal, Quick, Glass, Rinse
Delay Start	Up to 24 hours
Safety Lock	Child lock
Salt and Rinse Aid Indicator	Yes
Self-Cleaning Filter	Yes
Adjustable Upper Basket	Yes, height adjustable
Cutlery Basket	Removable

Frequently Asked Questions - SM 643C3 W Mora

How do I install the dishwasher?

Ensure the dishwasher is placed on a level surface. Connect the water inlet hose to a cold water supply (3/4 inch thread) and the drain hose to a siphon or standpipe. Plug into a grounded outlet. Refer to the installation manual for detailed steps.

How do I clean the filter?

Turn off the dishwasher. Remove the lower basket. Twist the cylindrical filter counterclockwise and lift it out. Rinse under running water. Remove the flat filter and clean both. Reassemble in reverse order. Clean monthly for optimal performance.

What detergent should I use?

Use a dishwasher detergent in powder, gel, or tablet form. For best results, use a multifunctional tablet with salt and rinse aid. Follow the dosage recommended on the detergent package.

Why is the dishwasher not draining?

Check if the drain hose is kinked or clogged. Clean the filter (see FAQ above). Ensure the sink siphon is not blocked. If the problem persists, the drain pump might be faulty; contact customer service.

How do I add rinse aid?

Open the rinse aid dispenser located on the inside of the door. Pour rinse aid up to the max level indicator. Close the cap. Adjust the dosage setting if needed (typically between 1 and 6).

What is the energy consumption?

The dishwasher has an energy efficiency class of A+. Typical energy consumption is about 0.92 kWh per cycle on the Eco program. Actual consumption varies based on program and usage.

Can I use the dishwasher without salt?

For areas with soft water (below 7 °dH), salt may not be necessary. However, for most water hardness levels, salt is required to prevent limescale and ensure good washing results. Check your water hardness and fill the salt reservoir before first use.

How do I remove bad odors?

Run a maintenance cycle with a dishwasher cleaner or a cup of white vinegar placed on the top rack. Also, regularly clean the filter and door seal. Leave the door open slightly after use to allow drying.

What does error code E3 mean?

Error code E3 typically indicates a heating element malfunction. Turn off the dishwasher, wait a few minutes, and restart. If the error persists, contact a qualified technician.

How do I adjust the upper basket height?

Pull out the upper basket. Locate the levers on the side rails (usually at the front). Press or squeeze the levers and lift or lower the basket to the desired height. Ensure it locks into place evenly on both sides.

USER MANUAL SM 643C3 W Mora

Simple line drawing of a cabinet or enclosure with no text, numbers, or symbols

Obsah

Vaše myčka 4

Diagram showing a salt container being placed on a funnel, with an arrow indicating rotation (no text or symbols present)

Illustration of a multi-tiered mechanical assembly with rollers, shafts, and housing (no text or symbols)

Structural diagram of a reinforced concrete framework with rebar grid and support beams (no text or symbols)

Dolní koš

Illustration of a multi-tiered kitchen appliance with plates, utensils, and a tray (no text or symbols)

Technical line drawing of a mechanical assembly with rotating components (no text or symbols)

Košík na příbory

Three diagrams showing a container with a handle, lifting a cylindrical object, and lifting a vertical rod (no text or symbols present)

Technical illustration of a mechanical assembly with two views: one showing a lifting mechanism and the other a wire mesh structure (no text or symbols)

Diagram showing a device with a circular component and a funnel-shaped container, both rotating (no text or symbols present)

Mechanical component with four arrows pointing to specific parts (no text or symbols visible)

Technical illustration of a mechanical assembly with a lever and rotating component (no text or symbols)

Mechanical assembly diagram showing a rotating fan with an upward arrow indicating motion (no text or symbols)

Volně stojící

Diagram showing a mechanical component with angular notations and an arrow indicating direction (no text or symbols)

Servis

Cross-sectional diagram of a multi-layered industrial or mechanical structure with circular components and a central vertical bar (no text or symbols)
