| Product Type | Microcontroller |
| Manufacturer | Microchip Technology |
| Part Number | AVR16EB28 |
| Architecture | 8-bit AVR |
| Flash Memory | 16 KB |
| SRAM | 2 KB |
| EEPROM | 512 Bytes |
| Operating Voltage | 1.8V - 5.5V |
| Max CPU Speed | 20 MHz |
| Pin Count | 28 |
| Package Type | SOIC-28 |
| Operating Temperature Range | -40°C to +85°C |
| Low Power Modes | Idle, Power-down, Power-save |
| Peripherals | USART, SPI, I2C, Timers, 10-bit ADC, Analog Comparator |
| Number of I/O Pins | 23 |
| Programming Interface | ISP (SPI), UPDI |
| Maintenance | No regular maintenance required; handle with ESD precautions. |
| Safety Precautions | Use anti-static mat and wrist strap; avoid moisture and contaminants. |
| Compliance | RoHS, Halogen-free |
Frequently Asked Questions - AVR16EB28 Microchip
What is the AVR16EB28 microcontroller?
The AVR16EB28 is an 8-bit microcontroller from Microchip, featuring 16 KB of Flash memory, 2 KB SRAM, and 512 Bytes EEPROM in a 28-pin package.
What voltage range does the AVR16EB28 support?
It operates from 1.8V to 5.5V, allowing both low-voltage and standard 5V applications.
How can I program the AVR16EB28?
The device supports ISP (In-System Programming) via SPI and the newer UPDI interface. Use tools like Atmel-ICE or a simple USBasp programmer.
What is the maximum clock speed?
The maximum CPU clock speed is 20 MHz at 5V, but lower voltages may reduce the maximum frequency.
What peripherals are available on the AVR16EB28?
It includes USART, SPI, I2C, timers, a 10-bit ADC, and an analog comparator.
Can I use the AVR16EB28 in battery-powered applications?
Yes, it has low-power sleep modes (Idle, Power-down, Power-save) with current consumption as low as 0.1 µA in sleep.
What package options are available for the AVR16EB28?
Common packages include SOIC-28, TSSOP-28, and QFN-28. The pinout differs slightly between packages.
How do I reset the AVR16EB28?
The RESET pin is active low. Pull it high externally or use the internal power-on reset. A brown-out detector is also available.
What development tools support AVR16EB28?
Microchip's MPLAB X IDE and Atmel Studio support this device, along with the AVR-GCC compiler.
Is the AVR16EB28 RoHS compliant?
Yes, the device is RoHS and Halogen-free compliant.
