| Product Type | Cordless Hedge Trimmer |
| Brand | Blaupunkt |
| Model | CT6010 |
| Voltage | 18 V |
| Sword Length | 580 mm |
| Cutting Length | 520 mm |
| Cutting Capacity | 15 mm (max branch thickness) |
| No-Load Speed | 1300 rpm |
| Rotatable Handle | Yes |
| Blade Type | Laser cut blade |
| Electronic Brake | Yes |
| Blade Sleeve Included | Yes |
| Battery Compatibility | 18V Li-Ion: BP1820 (2.0Ah), BP1840 (4.0Ah), BP1850 (5.0Ah) – not included |
| Dimensions (HxWxD) | 100 x 22 x 23 cm |
| Weight | 2.5 kg |
| Sound Pressure Level (LpA) | 92 dB(A) (K=3.74 dB) |
| Noise Level During Operation | May exceed 85.52 dB(A) |
| Vibration Emission (ah) | 92 dB(A) (K=1.5 m/s²) |
| Permissible Operating Time | 35 minutes |
| Safety Features | Hand guard, dual-switch operation, blade brake |
| Maintenance | Clean and lubricate after each use; use thin machine oil or spray |
| Storage | Remove battery, store in dry place, out of reach of children |
| Intended Use | Domestic garden trimming of hedges and ornamental shrubs – not for branches over 20 mm |
| Wear Hearing Protection | Yes |
Frequently Asked Questions - CT6010 BLAUPUNKT
User questions about CT6010 BLAUPUNKT
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Outillage à main in PDF format for free! Find your manual CT6010 - BLAUPUNKT and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. CT6010 by BLAUPUNKT.
USER MANUAL CT6010 BLAUPUNKT
IMPORTANT INFORMATION
In order to achieve the highest satisfaction, enjoy the performance of the product and learn all its features and functions, please read this manual before using this product. Before using the device, read the manual and follow the instructions contained therein. The manufacturer is not liable for damage caused by the use of the device not in accordance with its intended use or improper handling. Retain the operating instructions so that they can also be used when using the product at a later date.
- The appliance must only be connected to a grounded socket outlet with characteristics in accordance with the values on the rating plate.
- Check that the total current consumption of all appliances connected to the wall socket does not exceed the maximum load of the fuse.
- If an extension cable is used, check that the total power consumption of the equipment connected to the extension cable does not exceed the load parameters of the extension cable. Arrange the extension cable in such a way as to avoid accidental pulling and tripping over it.
- The appliance is not intended to be controlled by an external timer, separate remote control or other equipment that can switch the appliance on automatically.
- Always disconnect the appliance from the power supply before maintenance work. When disconnecting the power cord, always pull it out of the socket by holding the plug. Never pull out the power cord by pulling on the cable, as the plug or cable may be damaged, in extreme cases even a fatal electric shock may occur.
• Do not leave the unit switched on. - Do not immerse the appliance in water or any other liquid.
- The appliance should be cleaned regularly as described in the section on Cleaning and maintenance of the appliance.
- Do not place the appliance near heat sources, flames, an electric heating element or on a hot oven. Do not place on top of any other appliance. - Take special care when using the appliance when children or pets are around.
- Do not allow children to play with the appliance.
- Do not use the appliance near flammable materials.
- Periodically check the condition of the power cord. If the non-removable power cord becomes damaged, it should be replaced by the manufacturer or a specialised repair facility or by a qualified person to avoid danger.
- Do not use the appliance with a damaged power cord or plug or if it has been dropped or damaged in any other way or is not working properly. Do not repair the appliance yourself, as there is a risk of shock. Take the damaged appliance to a competent service centre for inspection or repair. Any repairs may only be carried out by authorised service centres. Improper repair may pose a serious risk to the user.
- Use only original accessories and spare parts for the appliance or those recommended by the manufacturer. The use of accessories or parts not recommended by the manufacturer may damage the appliance and endanger your safety.
• A moment's inattention risks losing control of the tool.
- Avoid starting the power tool unintentionally. Make sure the power switch is in the OFF position before connecting the power tool to the mains. Carrying the power tool with your finger on the trigger or connecting the power tool to the mains after it has already been switched on can lead to accidents.
- Wear appropriate clothing. Do not work in loose clothing or wear jewellery while working. Keep hair, clothing and gloves away from moving parts. Moving parts of the power tool can catch and pull in loose clothing, jewellery or long hair.
- Remove any spanners or tools from the power tool before starting it. A tool or spanner still connected to the rotating part of the power tool can cause injury.
- Use caution when working with power tools, concentrate on your work and use common sense. Do not use a power tool when tired or under the influence of drugs, alcohol or medication. Even a moment's inattention when working with a power tool risks a serious accident.
- Keep children away from the work area and DO NOT allow children to pull on the power cord - this can cause serious injury.
- Before making any adjustments, changing accessories or putting the power tool away for storage, flip the switch to the off position to disconnect the power tool from the power supply. Such precautions reduce the risk of accidentally starting the power tool.
• Ensure that the vents are free of debris. - This tool should not be used by anyone under 16 years of age.
 | Read the user manual. |  | Use ear protection |
 |  | Wear protective glovesGeneral warning | |
 | Fire hazard |  | Wear protective clothing |
 | Electric shock hazard |  | Wear a protective mask |
 | Wear safety glasses |  | Wear respiratory protection |
- Warning of danger. Use extreme caution.
- Important, read the instructions and heed the warnings.
- Wear safety goggles.
- Use protective earmuffs.
- Always disconnect from the power source before repair or maintenance. If the cable is damaged, immediately remove the plug from the electrical outlet.
- Do not use the trimmer in the rain or in wet conditions.
- Hold the trimmer securely and operate with both hands.
Workplace safety
- Keep the work area neat and well lit. Disorder and poor lighting contribute to accidents.
- Before starting work, prepare and clear the area, remove all protruding stones, branches, wires, and other foreign objects from the ground that are a risk of tripping over.
• Take special care if working on sloping terrain or slopes. Do not use an electrically powered machine in explosive environments created by flammable liquids, gases or dust. - Do not use the trimmer in extreme fire or explosion hazards. The trimmer is not protected against water. Working in the rain or in a damp environment risks electric shock.
- Do not allow children or observers in areas where an electrically powered appliance is in use. Leave electrically powered garden equipment away from bystanders.
- The operator or user is responsible for accidents or hazards occurring to other persons or the environment.
Electrical safety
- Only connect the appliance to an outlet with characteristics consistent with the values on the rating plate. Do not expose electrically powered equipment to rain or wet
conditions. If water enters the power tool, the risk of electric shock increases.
• Do not stress the connection cables.
- Never use the connection cable to carry, pull electrically powered equipment or pull the plug from the socket.
- Keep the connection cable away from heat sources, oils, sharp edges or moving parts. Damaged or entangled connection cords increase the risk of electric shock.
• Safety rules for electrical machines and equipment
- ATTENTION: Before installing or using the appliance, it is essential to read the operating instructions and especially the safety instructions for use.
- Keep the instructions for reference and pass them on to future users of the unit. Failure to observe the stated safety instructions and warnings may result in electric shock, fire or serious injury.
- Do not allow children or young people to operate the appliance.
- Persons not familiar with the operating instructions should not install, maintain or use the appliance. This appliance is not intended for use by persons with reduced physical, sensory or mental capabilities or lack of experience or knowledge of the appliance, unless supervised or in accordance with the instructions for use given by those responsible for their safety.
Human safety
- Do not operate the trimmer if you are feeling tired or under the influence of alcohol, drugs or medication. Full concentration is required when using the machine and caution must be exercised. A moment's inattention while using the power tool can lead to an accident and
consequent serious injury or property damage.
- It is essential to wear personal protective equipment. Always wear close-fitting safety goggles (according to EN 166 or other national regulations). Wear ear protection due to the loudness of the equipment. The use of protective equipment such as a dust mask, non-slip safety shoes with uppers, protective gloves is also recommended.
- Wear close fitting clothing. Loose clothing, jewellery, scarves can get caught by the moving parts of the trimmer, which can lead to dangerous accidents. If the user has long hair, it should be secured and bundled.
- During operation, the appliance may eject various objects, sawdust, pieces of wood at high speed. There is a danger of injury. The use of suitable clothing is recommended.
- Before starting the power tool, remove all spanners and other tools used to adjust the unit. Leaving a spanner in a rotating part of the power tool may cause injury.
- Avoid working in an unnatural body position. Assume a correct and stable posture to avoid the possibility of losing balance. This will allow better control of the power tool in unpredictable situations.
- Avoid unintentional starting. Make sure the power cord is unplugged and the switch is in the off position before picking up or carrying the equipment. Carrying electrically powered equipment with your finger on the switch or connecting to the mains with the switch on may lead to an accident. Keep hands and feet away from moving (rotating) parts of the trimmer.
- Keep a safe distance from bystanders In spite of the inherently safe design, the use of protective measures and additional protective measures, there is always a risk of residual injury during operation.
- Do not use detergents or alcohol to clean the trimmer.
- Do not use attachments that are not specifically designed for the machine and recommended by the manufacturer. The fact that an accessory can be fitted to a power tool is no guarantee of safe use.
- The attachment system of the power tool must correspond to the dimensions of the power tool. Improperly dimensioned work tools cannot be sufficiently guarded or controlled.
- Personal protective equipment must be used. Depending on the type of work, wear a protective mask covering the entire face, eye protection such as safety goggles. Protect the eyes from airborne foreign bodies generated during work. Protect the respiratory tract against airborne dust and vapours with a dust mask. Exposure to noise over a prolonged period can lead to hearing loss.
- Keep bystanders at a safe distance from the range of the trimmer. Anyone in the vicinity of a working power tool must use personal protective equipment. Workpiece splinters or broken work tools can splinter and cause injury even outside the immediate range zone.
- Clean the ventilation slots of the equipment regularly.
- When holding the trimmer by the base handle, guide it with the auxiliary handle.
- Always switch off the trimmer when: - it is left unattended, - before adjustment and maintenance work, - after being struck by a foreign object, - abnormal vibration of the equipment is felt.
General information
- The appliance is intended exclusively for use in the domestic garden in accordance with the description and safety rules
contained in these instructions for use. When the trimmer is switched off, the line/blade continues to rotate for some time. Wait until the motor and the line/blade have come to a complete stop before restarting the machine. Do not switch the trimmer on and off at short intervals.
- The trimmer operator should wear decent footwear with non-slip soles and long trousers to protect the legs. Do not work barefoot or in flip-flops or sandals. Always use the trimmer with both hands. Only use the machine during daylight or in good artificial lighting.
Before starting the machine
- Check the condition of the trimmer and ensure that none of the components are damaged and that the line spool or blade is correctly attached and fastened. Before using the trimmer, check it for signs of wear or damage and return it to an authorised service centre if necessary. Check that bystanders and animals are at a safe distance from the trimmer (at least 15 metres). Disconnect the trimmer from the mains supply when not in use, before moving it to another work area, and before any work is carried out on the power tool (e.g. adjusting or cleaning).
USE PERSONAL PROTECTIVE EQUIPMENT
Wear safety goggles according to standard En166
Use protective masks according to En149
Use other precise personal protective equipment, depending on the type of work to be carried out.
Safety instructions for charger and battery
To connect the battery for charging, insert it into the charger and then connect the charger to the power source.
Protect the charger from rain and moisture. The charger may
only be used indoors.
Keep the charger clean.
Do not use the charger on flammable objects and substrates (e.g. paper) or in environments with explosive and/or flammable atmospheres.
Always provide adequate ventilation when charging, as fumes or electrolyte may leak from the battery if the battery is damaged due to improper handling/damage.
Unplug the charger from the wall socket when charging is complete. Do not leave it connected to a power source for longer than necessary.
Store and charge the battery in a dry place and make sure no water gets into it.
Keep the battery connectors clean and free from dirt.
Protect the battery from shocks, moisture and never open or mechanically damage the battery pack.
To check the charge level of the battery, do the following press the button on the battery pack and, if necessary charge the battery pack according to the number of LEDs and the expected operating time of the cordless tool.
Storage
Store cordless tools in a dry place out of the reach of children. For safety reasons, remove the battery pack before storing the cordless tool. When the battery pack is inserted in the cordless tool, it discharges faster. Protect the battery pack and tool from frost, high temperatures, moisture and water. Do not repair a damaged battery pack. Repairs to the battery pack may be carried out at the manufacturer or at an authorised service centre. Only charge the battery in chargers with the parameters specified by the manufacturer Storing or using the battery in unsuitable conditions may cause electrolyte
leakage. Damaged or modified batteries must not be used. Damaged or modified batteries may behave in an unpredictable manner, causing dangerous consequences.
Keep the battery away from fire and protect it from heat. The battery may explode if exposed to fire or temperatures exceeding 130^ C.
Inserting the battery
Note: The use of an unsuitable battery for the device may lead to malfunction or damage to the device. To insert the battery pack into the handle, push it in until you hear the locking mechanism lock (the battery pack should be positioned flush with the edge of the device)
Purpose
The garden tool is designed for domestic use, for trimming and cutting hedges and ornamental shrubs in gardens. The pruning shears must not cut branches over 20mm thick.
Before starting the machine
- The cutting elements should always be free of dirt. The blades should be cleaned after each use.
- Unclean blades work properly together, reducing the risk of jamming on pruned plants.
- Keep the cutting element away from your body and the power cord when cutting. The machine can easily cut off fingers or objects that get between the blades.
- Do not remove jammed material while the cutter blades are running. Before removing jammed material, make sure that the appliance cannot be started accidentally. Although the appliance is equipped with protection against accidental
starting, there is always a risk of starting. It is therefore necessary to take the additional precaution of pulling the plug out of the socket.
- Check the condition of the cutting blade before each use. Chipped, bent or otherwise damaged blades pose an additional hazard. Whenever the cutting unit is damaged, it must be replaced, or a new unit must be purchased. Using a power tool with a damaged cutting bar is dangerous to the health and life of the operator.
6) When cutting, hold the machine only by the front handle and the rear handle as the cutting bar may cut hidden electrical wires.
-
Before starting work, check the hedge for objects that are not part of the plant. - Wire, fence parts and other foreign objects, these can damage the cutting blades.
-
Carry the hedge trimmer by the front handle and with the engine switched off. When transporting and storing, place the supplied guard over the cutting element. - Proper handling will reduce the risk of injury.
-
Do not use the cutting bar as a lever to lift or move objects or to chop up plants. - The appliance has been designed to perform specific tasks. Using the power tool for purposes for which it was not designed creates a potential for dangerous situations.
-
If the power tool falls or is hit hard, it is advisable to contact service.
-
Do not allow yourself to fall into a rut after frequent use. Falling into a routine can result in safety rules being ignored, which can lead to accidents at work.
When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European Directive 2012/19/EU. Please inform yourself about the local separate collection system for electrical and electronic products. Used appliance should be delivered to the dedicated collecting points due to hazardous components, which may affect the environment. Do not dispose this appliance in the common waste bin.
Your products is designed a manufactured with high quality materials and components, which can be recycled and reused.
Device description
- Rear handle
5 Hand guard - Motor housing
6 Battery pack - Front handle with switch
- Rocker switch
- Blade
- Switch
Hand guard
Before starting work, first check that the hand guard is correctly fitted. The hand guard must be firmly fitted so that it cannot be accidentally slipped off the device. For this purpose, the tightness must be checked.
Switching on:
Press the on/off switch (3) of the front handle and the switch (8) of the rear handle simultaneously. handle.
Switching off:
Release either switch (3) or (8). The blade brake makes the blades stop.
Cutting hedges
Before starting work, select branches larger than 15 mm in diameter and cut them with the shears. It is advisable to start trimming the hedge from the sides. First move the shears from top to bottom remove the main shoots of the plants, then correct the lines by moving the shears upwards. After Once the sides of the hedge have been trimmed, you can start cutting the back (top) of the hedge.
Maintenance
Do not use solid grease to lubricate the trim. After each use, the cutting blade, in addition to cleaning it also requires a light lubrication. This should be done using maintenance oil, thin machine oil or special cleaning and lubricating agents in a
spray.
Keep the handle surfaces dry, clean and free of oil and grease.
Take a break after every 15 min of operation
BLAUPUNKT Cordless Hedge Trimmer CT6010
Voltage : 18 V
Sword Length: 580 mm
Cutting Length: 520 mm
Cutting Capacity: 15 mm
No Load Speed : 1300 rpm
Rotatable Handle
Laser Cut Blade
Electronic Brake
With Blade Sleeve
Battery: 18VLi-Ion, BP1820 2.0Ah (not included); BP1840 4.0 Ah-recommended (not included); BP1850
5.0 Ah (not included).
Dimensions: 100 x 22 x 23cm
Weight: 2.5 kg
Noise
Typical A-weighted noise level measured in accordance with ISO/TR 11688-1:
Sound pressure level (LpA): 92 dB (A)
Measurement uncertainty (K): 3.74 dB (A)
Noise level during operation may exceed: 85.52dB (A), (K) 87.64 dB
Wear hearing protection!
Vibrations
Total vibration value measured in accordance with En3774:
Vibration emission: ah = 92 dB(A)
Measurement uncertainty (K): Km = 1.5 m/s
Permissible Operating Time: 35 minutes of operation.
