DTS511 - Toothbrush BLAUPUNKT - Free user manual and instructions

Product Type	Electric Toothbrush
Brand	Blaupunkt
Model	DTS511
Power Supply	5V / 1A
Power Consumption	3W
Charging Time	Approximately 17 hours
Battery Indicator	LED diodes showing charge level; green LED flashes while charging
Brushing Modes	Clean, Soft, Massage, Whiten, Polish
Timer	2-minute automatic shut-off with 30-second interval alerts
Brush Head Compatibility	Replaceable; recommended Blaupunkt ACC024, ACC067
Head Replacement Interval	Every 3 months
Cleaning	Remove head and rinse handle and head; wipe charging unit with damp cloth
Safety Certifications	CE compliant, WEEE directive, Battery directive
Usage	For home use only; children aged 8+ under supervision
Warranty / Support	Contact service: tel. [phone], email [e-mail]

Frequently Asked Questions - DTS511 BLAUPUNKT

How long does it take to fully charge the toothbrush?

The full charging process takes approximately 17 hours. It is recommended to store the handle on the charging unit.

How can I tell when the battery is fully charged?

The green LED will flash while charging. When charging is completed, all LEDs will turn off.

What brushing modes are available?

There are five modes: Clean (standard), Soft (gentle), Massage (pulse to stimulate gums), Whiten (brushing and whitening), and Polish (intensive polishing for brighter effect).

How do I change the brushing mode?

Immediately after switching on the toothbrush, press the switch button again to cycle through modes.

Does the toothbrush have a timer?

Yes, it has a 2-minute automatic shut-off and signals every 30 seconds with a momentary break to remind you to switch brushing zones.

How often should I replace the brush head?

The brush head should be replaced every 3 months or sooner if bristles become frayed.

What replacement heads are compatible?

Use only original or recommended heads: Blaupunkt ACC024 and ACC067.

Can I use the toothbrush while it is charging?

No, the toothbrush should be switched off when placed on the charging unit. It is not designed for corded use.

Is the toothbrush waterproof?

The handle is designed for wet use, but the charging unit must be kept away from water. Do not immerse the handle or charging unit in water.

What should I do if the toothbrush is dropped?

If the toothbrush with the head is dropped, the head should be replaced even if no visible damage is seen, to ensure proper cleaning and safety.

USER MANUAL DTS511 BLAUPUNKT

White BLEX 1000 electric toothbrush with toothbrush and digital display (no text or symbols visible on body)

Enjoy it.

rrwkeu k ohnwul fkh dk e u wh f r whf nd gr e z ohnwulfn nduw hn d e chnwulfn e nhind chnwur pr ir nhih chnwul d red hwnd

ohnwul d hwnlfd d eh ó тъ р ти ъти и р Shul hchf wulf gh gl l chnwul l gd w hshw ol ohnwulol h kdp edkdul ohnwul n re elu wh

Important notes

- Before operating the appliance, please read the instructions manual and follow the instructions provided.

- The manufacturer is not liable for any damages resulting from use of the appliance contrary to its intended use, or its inappropriate use. Save this instructions manual so you will also be able to refer to it when using the product in the future.

- The appliance is intended for home use only. Do not use for other purposes contrary to its intended use.

- Connect the appliance only to an electrical supply with specifications in accordance with the information on the data plate.

- This appliance may be used by children aged 8 years and above, and by persons with reduced physical and/or mental capabilities, and by persons with little experience and knowledge concerning the appliance, only if they have been given supervision or instructions concerning the use of the appliance in a safe way, and they understand the hazards involved. Children should not play with the appliance. Unattended children should not be allowed to perform the cleaning and maintenance of the appliance.

- The charging unit should be kept away from tanks containing water, such as bathtubs, washbasins or toilets.

• Use only the manufacturer's original spare parts,

or those recommended by the manufacturer.

- Using accessories not recommended by the manufacturer can damage the appliance and threaten operational safety.

- If the toothbrush with the head is dropped, the head should be replaced, even if there are no visible damages.

- When you use the toothpaste with perhydrol, soda, or another whitening substance, the toothbrush handle should be thoroughly washed after use.

CE Device is compliant with EU directives: - Electromagnetic compatibility (EMC) Device marked CE mark on rating label

When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European Directive 2012/19/EU. Please inform yourself about the local separate collection system for electrical and electronic products. Used appliance should be delivered to the dedicated collecting points due to hazardous components, which may affect the environment. Do not dispose this appliance In the common waste bin.

Your product contains batteries covered by the European Directive2013/56/UE, which cannot be dispose with normal household waste. Please inform yourself about the local rules on separate collection of batteries because correct disposal helps to prevent negative consequences for the environmental and human health.

Environmental information

All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam(buffer) and poly ethylene (bags, protective foam sheet). Your system consists of material which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.

Your products is designed a manufactured with high quality materials and components, which can be recycled and reused.

Technical data

Power supply: 5V/1A

Power: 3W

1. Replaceable toothbrush head

2. Handle with drive

3. On/Off switch

4. Charging unit

5. Power monitor diodes

CHARGING THE BATTERY

Make sure that the toothbrush is switched off before placing it on the charging unit. Connect the charging unit (5) to the power supply. Place the toothbrush handle with drive on the charging unit. The full charging process can last more than 17 hours. It is recommended to store the toothbrush handle in the charging unit. The battery contains a protecting circuit against overcharging.

After placing the toothbrush handle in the charging base, the indicator lights will indicate the battery charge level. The more diodes lit, the more charged the battery is. The green LED will flash while the battery is charging. When charging is completed, the LEDs will turn off.

1. Use the replaceable toothbrush head (1) on the handle with a drive (4). Wet the toothbrush with water and apply a small amount of toothpaste.

2. Put the toothbrush in your mouth, on the teeth gently tilted toward the gums (as shown in the Figure)

3. Turn on your toothbrush with the switch button (2). You can change the brushing mode by pressing the switch button immediately after switching on the toothbrush.

4. To improve the efficiency of teeth cleaning, the mouth should be divided into four zones. Clean each zone for 30 seconds (the toothbrush signals with a momentary break when each 30 seconds expires). The toothbrush will switch off automatically after 2 minutes. To finish teeth cleaning earlier, turn off the toothbrush with the switch button

5. After switching the toothbrush off, remove the head (1) from the handle (4) and thoroughly rinse both elements.

6. Put the handle (4) onto the charging unit (5).

BRUSHING MODES

1. CLEAN - standard brushing mode

2. SOFT - gentle brushing mode

3. MASSAGE - pulse mode to stimulate the gums

4. WHITEN - brushing, whitening and polishing

5. POLISH - polishing – intensive tooth polishing mode, brighter whitening effect

CLEANING AND MAINTENANCE

Make sure that the charging unit is removed from the power supply before starting cleaning.

Wipe the inside of the charging unit with a wet cloth and then dry.

It is recommended to replace the toothbrush heads every 3 months. Recommended heads: BLAUPUNKT ACC024, ACC067

Device is compliant with EU directives: - Electromagnetic compatibility (EMC) Device marked CE mark on rating label

POUŽÍVANIE KEFKY NA ZUBY

BLAUPUNKT ACC024, ACC067.

BLAUPUNKT ACC024, ACC067.

Oluline info

02-801 Warsaw, Poland

phone: [phone]

e-mail: [e-mail]

www.blaupunkt.com

In case of questions or problems

please contact our service.

Tel. [phone]

E-mail: [e-mail]
