DED8727-51C - Lawn mower DEDRA - Free user manual and instructions

Product Type	Lawn Mower
Brand	DEDRA
Model	DED8727-51C
Power Source	Petrol
Engine Power	2.7 kW
Cutting Width	51 cm
Cutting Height Adjustment	Centralized, 5 positions (25-75 mm)
Grass Box Capacity	50 L
Mulching Function	Yes (with mulching plug)
Weight	30 kg
Dimensions (L x W x H)	1400 x 550 x 1000 mm
Wheel Size	Front: 200 mm, Rear: 250 mm
Handle Type	Foldable, ergonomic
Safety Features	Blade brake, operator presence control
Oil Recommended	SAE 10W-30 (4-stroke)
Fuel Tank Capacity	1.2 L
Spare Parts Available	Blade, air filter, spark plug, oil filter
Reparability	DIY-friendly with common tools

Frequently Asked Questions - DED8727-51C DEDRA

What type of fuel should I use for the DED8727-51C lawn mower?

Use unleaded petrol with an octane rating of at least 95 RON. Do not use E85 or diesel.

How do I start the mower?

Ensure the blade brake is released, prime the engine (if equipped), and pull the recoil starter firmly. Refer to the manual for detailed starting procedure.

What type of oil is recommended?

Use SAE 10W-30 4-stroke engine oil. Change the oil after the first 5 hours of use, then every season or 25 hours of operation.

How do I adjust the cutting height?

The cutting height is adjusted centrally via a lever. There are 5 positions ranging from 25 mm to 75 mm. Adjust while the engine is off.

How do I maintain the blade?

Disconnect the spark plug, tip the mower on its side (air filter up), and remove the blade bolt. Sharpen the blade with a file or replace if damaged. Balance the blade before reinstallation.

Can I use the mower for mulching?

Yes, the DED8727-51C supports mulching. Install the mulching plug (included) and remove the grass bag. Mulching works best when grass is dry and not too tall.

What safety features does this mower have?

It has a blade brake that stops the blade within seconds of releasing the handlebar, and an operator presence control that stops the engine if the handlebar is released.

How do I clean the mower after use?

Let the engine cool, then use a hose to spray the underside of the deck. Do not use high pressure. Clean the air filter and oil dipstick area. Wipe the body with a damp cloth.

Where can I find spare parts?

Spare parts such as blades, air filters, spark plugs, and oil filters are available from DEDRA dealers or online. Use genuine parts for best performance.

How should I store the mower during winter?

Drain the fuel tank or add fuel stabilizer, change the oil, clean the mower, and store it in a dry place. Disconnect the spark plug and cover the mower.

USER MANUAL DED8727-51C DEDRA

Black and white photo of a DEDRA lawn mower with visible branding and wheels (no text or symbols on the device itself)

Kontakt

W1

W2

W3

W4

W5

Opis piktogramów / Popis použitých piktogramů / Opis použivaných piktogramov / Panaudotů piktogramů aprašymas / Lietoto piktogrammu apraksts / Az alkalmazott piktogramok magyarázata / Interpretation des pictogrammes / Descripción de los pictogramas / Descrierea pictogramelor / Omschrijving van de gebruikte pictogrammen / Beschreibung der verwendeten Piktogramme

Nakaz: przeczytaj instrukcję obsługi / Příkaz: přečtěte návod k obsluze / Příkaz: oboznámte sa s užívatelškou príručkou / Privaloma: perskaitykite aptamavimo instrukciją / Norádíjums: rúpígi iepazistieties ar lietotája rokasgrámatá sniegto informáčiju / Utasítás: olvassa el az útmutató / Ordre: avant l'usage lire le mode d'emploi / Indicación: leer el manual de instrucciones / Obilgatoriu: citiți manualul de utilizare / Bevel: lees de gebruiksaanwijzing / Gebot: die Bedienungsanleitung lesen

Nakaz: stosować rękawice ochronne / príkaz: používejte ochranné rukavice / príkaz: používajte ochranné rukavice / privaloma: naudoti apsauginius akinius / pieprasíjums: lietot aizsardzības cimdus / utasítás: használjon védőkesztyút / ordre: utiliser les gants de protection / indicación: usar los guantes de protección / obligatoriu: purtați manuși de protectie / bevel: gebruik beschermende handschoenen / gebot: schutzhandschuhe sind zu benutzen

Nakaz: używać ochronników sluchu / použivajte ochranu sluchu / použivajte chrániče sluchu / privaloma; naudoti apsauginius akinius / lietojet dzirdes aizsardzības lidzekļus / utasítás; használjon fülvédőt / ordre; utiliser la protection de l'ouïe / usar protección para los oídos / trebuie să folosi-ți aparate pentru protecția auzului / gehoorbescherming gebruiken / der gehörschutz ist zu benutzen

Nakaz: stosować okulary ochronne / príkaz: používejte ochranné bryle / príkaz: používajte ochranné okuliare / prívaloma: naudoti apsauginius akinius / norádijums: něsājiet aizsargacenes / utasítás: viseljen védőszemüveget / ordre: utiliser les lunettes de protection / indicación: usar las gafas de protección / obligatoriu: folositi ochelari de protecție / bevel: draag veiligheidsbril / gebot: schutzbrille tragen

Nakaz: stosować obuwie ochronne / Objednávka: noste bezpečnostní obuv / Objednat: noste bezpečnostnú obuv / Užsakymas: dévékite apsauginius batus / Pasütjums: valkajlet drošības apavus / Rendelés: viseljen biztonsági cipôt / Comanda: purtați încăltăminte de siguranță / Bestellung: Sicherheitsschuhe tragen
