FIT F20 - Smartwatch iGET - Free user manual and instructions

Product Type	Smartwatch
Brand	iGET
Model	FIT F20
Water Resistance	IP68 (1.5m depth for 30 minutes, not salt water)
Display	Full touch screen
Connectivity	Bluetooth (via iGET FIT app)
OS Compatibility	Android and iOS
Main Functions	Heart rate monitor, pedometer, sleep tracking, notifications, multi-sport modes (walking, running, hiking, cycling, basketball), find phone, music control, weather, alarm, stopwatch, relax breathing exercise, gesture control
Sensors	Heart rate sensor, accelerometer
Charging	Magnetic USB cradle
Battery	Rechargeable lithium-ion
Operating Temperature	-10°C to +40°C
Safety Certifications	CE, RoHS
Warranty	24 months
Manufacturer	INTELEK spol. s r.o.
Package Contents	Smartwatch, charging cradle, user manual
Special Features	Customizable watch faces via app, alarm settings via app, music remote control
Notifications	Incoming calls, SMS, QQ, WeChat, WhatsApp
Gesture Control	Wrist rotation to wake screen
Sleep Tracking	Yes
Heart Rate Measurement	Yes

Frequently Asked Questions - FIT F20 iGET

How do I turn on/off the smartwatch?

To turn on, long press the side button. To turn off, long press the side button or go to MENU > Settings (gear) > System > Off.

How do I charge the smartwatch?

Connect the metal pins of the USB cradle to the metal contacts on the back of the watch until the charging icon appears.

Is the smartwatch waterproof?

It has IP68 protection, meaning it is resistant to water up to 1.5 meters depth for 30 minutes. However, it is not resistant to salt water.

How do I pair the watch with my phone?

Download the iGET FIT app from Google Play or App Store. Enable Bluetooth on your phone, then in the app go to Device and select your bracelet. Pair via the app, not directly from phone Bluetooth settings.

What sports modes are available?

The watch offers five sports modes: walking, running, hiking, cycling, and basketball.

How do I change the watch face?

Long press the touch screen on the main screen to select a different dial. You can also upload custom watch faces from the iGET FIT app.

How do I find my phone using the watch?

Go to MENU and select the Find Phone icon (blue phone with magnifying glass). The paired phone will ring.

How do I set an alarm?

Open the iGET FIT app on your phone. Go to Device and set up to five alarms. The watch will vibrate at the set time.

What should I do if the watch gets wet?

Dry the watch thoroughly and ensure the charging contacts are completely dry before charging. The warranty does not cover intentional water damage.

How do I disconnect the watch from my phone?

In the iGET FIT app, go to Device and tap Unpair. Then in your phone's Bluetooth settings, select Forget device.

USER MANUAL FIT F20 iGET

Complete user guide can be found on our website in PDF format.

www.iget.eu

SUPPORT:

h p://www.iget.eu/helpdesk

Czech....2

Slovak....13

German....23

English....33

Polish....43

Magyar....53

Warranty card....63

Základní informace:

Warning symbol with a stylized 'e' inside a triangle, no text or numbers present

Symbol of a trash bin crossed with two crossed lines, no text or numbers present

Warning symbol with a sine wave inside a triangle (no text or numbers)

Symbol of a trash bin crossed with two crossed lines, no text or numbers present

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

Individual technical parameters, the descrip on of the phone and the design may di er depending on the different versions of the phone and updates. Precise speci ca ons and other informa on can be found on website www.iget.eu. Misprints reserved.

FIT F20, F25 has a degree of protec on IP68, does not guarantee 100% water resistance in every condi ons! (According to manufacturer 1,5 m depth for 30 minutes, IP68 resistance does not apply to salt water.) A er contact with water or other liquid, we recommend that the watch be dried and check that the charging contact is dry before charging. The warranty does not apply to inten onal damage to smart watches.

A er the rst start of your smart watch and a er pairing with iGET FIT, check for a possible so ware update. Do not disconnect the device from the mobile phone or move away from the BT signal during the update.

The buyer is obliged to provide a serial number on the warranty card as well as in the delivery note and the proof of purchase. In this context, the buyer acknowledges that unless the serial number of goods is not marked on the proof of purchase, delivery note and in the warranty card and therefore it cannot be possible to compare this serial number marked on goods and its protec ve packaging with the serial number stated in the warranty card, delivery note and the proof of purchase and thus to verify that the goods runs from the seller, the service center is competent to claim such a goods automa cally and reject it immediately. The buyer

must instruct all persons to whom the goods would be subsequently sold. Product complaints do with your dealer if you are not on the web www.iget.eu indicated otherwise. The warranty card is on the last pages of this manual.

Safety warnings:

- The small parts of the watch can cause su oca on.

- Do not expose your watch to open re.

- The watch can produce a loud sound.

- The watch is not resistant to metal llings.

- Avoid exposure to magne c elds.

- Avoid extreme temperatures (-10°C, +40°C).

- On request, turn o your watch in hospitals and other medical facili es.

- Do not dismantle the watch.

- Use the watch only with cer ed equipment.

- Do not reckon only upon your watch during emergency situa ons.

- In case of any change in the watch's dimensions due to overhea ng, stop using the appliance un I the ba ery is replaced.

Damages requiring professional repair:

If such cases may occur, please, contact the authorized service or your distributor:

- Moisture got into the watch.

- The watch is mechanically damaged.

- The watch is extremely overheated.

For household use: The given symbol (crossed-out wheeled bin) on the product or at accompanying documents means that used electrical and electronic products should not disposed of with household waste. To ensure proper disposal of the product, hand it

Symbol of a trash bin with crossed lines indicating no waste or discharge, plus a solid black rectangle below (no text or labels)

over to a designated collec on point, where it will be accepted free of charge. The correct disposal of this product will help to save valuable natural resources and prevent any poten al nega ve impacts on the environment and human health, which could otherwise be caused by inappropriate disposal of wastes. For more details, please, contact your local authori es or the nearest collec on point. The improper disposal of this waste can be penalized in accordance with na onal regula ons. Informa on for users to disposal of electrical and electronic devices (corporate and business use): For proper disposal of electrical and electronic devices, ask for details from your dealer or distributor. Informa on for users to disposal of electrical and electronic devices in other countries outside EU: The above men oned symbol (crossed-out wheeled bin) is valid only in the countries of EU. For proper disposal of electrical and electronic devices, ask for details from your authori es or dealer. All is expressed by the symbol of crossed-out wheeled bin on product, packaging or in printed materials. Set up the claim for warranty repair of device at your dealer. If you have technical ques ons or problems, contact your dealer. Follow the rules for working with electrical

equipment. The user may not dismantle the device or replace any part of this. Opening or removing the covers poses the risk of electric shock. In case of incorrect reassembly and subsequent connec on you are also exposed to electric shock.

Declar a on of Conformity:

Company INTELEK spol. s r.o. hereby declares that all FIT F20 devices are in compliance with essen al requirements and other relevant provisions of Direc ve 2014/53/EU.

Company INTELEK spol. s r.o. hereby declares that all FIT F25 devices are in compliance with essen al requirements and other relevant provisions of Direc ve 2014/53/EU.

The full text of the EU Declara on of Conformity is available on this website www.iget.eu.

The warranty period of the product is 24 months, unless stated otherwise.

RoHS:

The components used in the device meet the requirements on the restric on of hazardous substances in electrical and electronic devices in accordance with Direc ve 2011/65/EU, 2015/863/EU. The RoHS declara on can be downloaded from www.iget.eu.

This device can be used in the following countries:

AT	BE	CY	CZ	DK	EE	FI	MT	NL	PL	PT	SK
SI	ES	DE	GR	HU	IE	IT	LV	LT	GB	IS	LI
NO	CH	BG	HR	RU	RO	FR	SE	LU	TR

Basic func ons and use

Turning on

Long press the side bu on to turn on the bracelet.

Turning o

Press and hold the side bu on to turn o the bracelet. Or go to MENU and select the se ng icon (gear), then the System and O menu.

Charging

Connect the metal pins of the USB cradle with the metal points on the back of the bracelet un I the charging icon appears on the screen.

Install iGET FIT on your phone.

Download: For Android devices, nd the iGET FIT app in the Google play store. For iOS devices, look for the iGET FIT app on the App Store.

Connec ng thebracelet with a mobile phone

Allow Bluetooth in the phone. For correct func onality, please ll in all data in pro le and allow to app the access to all authoriza on. In case you cannot nd the device, enable the loca on detect on. In the maim menu click on „device“ and choose your smart bracelet. Follow the steps, search the device name and connect it.

Do not connect the watch in the Bluetooth sentences

on the mobile phone, but always using the iGET FIT

applica on!

When pairing the watch in the Bluetooth sentences on the mobile phone, first pair the watch and pair it again using the applica on.

Disconnect the bracelet from your mobile phone

Open "iGET FIT" on your phone. In the main menu, click on "Device" and then on „Unpair“. In the Bluetooth sentences of the phone, select "Forget device".

Introduc on of func ons

You can li your hand / press the side bu on to turn on the screen.

The display is full touch, touch the icon to con rm the selec on.

Basic naviga on

Drag the touchpad from right to le to enter the MENU.

Drag from le to right to enter the list style menu.

Drag from the bo om up to enter the no ca on center.

Drag again to enter the heart rate record and drag again to view daily ac vi es

Drag from top to bo om to enter the quick setup menu.

Press the side bu on to return to the home screen.

Dialer

You can change the dial and choose the appropriate design by long pressing the touch screen on the main screen.

Pedometer

The bracelet will record your daily ac vity automa cally. Press the touch key: switch between the interfaces: Steps, Calories, and Distance. A er synchronizing with iGET FIT, you can check your sports data on your smartphone. Measured data are only indica ve.

Heart rate

Go to MENU. Select the heart rate icon starts the heart rate measurement. You can immediately see the heartbeat data on your bracelet. A er syncing with iGET FIT, you can check the heart rate data in your phone. The measured data is only indica ve.

No ca ons

To switch to the message interface, go to MENU and click on icon for messages. Here you can view no ca ons including incoming calls, SMS, QQ and Wechat, Whatsapp and other.

Mul -Sport mode

Go to MENU. Selec ng a SPORTS icon you will get to the ac vity subsec on.The bracelet has ve ac vi es: walking, running, hiking, cycling,

basketball. You can choose the mode you need, then go to the sport, the bracelet records sports data. To complete this exercise, press the touch key to stop and save the exercise.

Note: If the spor ng me is shorter than 5 min, the data will not be saved.

Find phone

In the MENU, select the blue mobile phone icon with the magnifying glass. If the bracelet is paired with iGET FIT, your phone will start ringing.

Upload a watch face from the applica on

Connect the watch to iGET FIT and select the Customize Dial menu, select the dial you like in this menu.

Alarm

You can set ve alerts in iGET FIT in the „Device“ menu. When the alarm is on, the bracelet will vibrate at that me.

Gesture control

In iGET FIT menu „Device“ you can set the style of gesture:

Wrist Rota on: When the wrist is rotated, the screen lights up.

Sleep

Go to the MENU and under the "Sleep" icon you can check your sleep data.

Weather

In the MENU under the "Weather" icon you can check the current weather status for your loca on. The func on is ac ve only when the device is connected to mobile applica ons and the Internet.

Music

In the MENU under the "MUSIC" icon you can remotely control the music player in your phone In the basic MENU, a er clicking on "STOPWATCH", you can start tracking the me or start the countdown.

Luminance adjustment

Drag from top to bo om to enter the quick setup menu. There you can adjust the intensity of the display backlight by clicking on the brightness symbol.

Relax

In the MENU, a er clicking on the "RELAX" icon, you will start a soothing breathing exercise.

Android se ngs when disconnec ng the watch from the applica on

Detailed solu on here h p://www.iget.eu/cs/op malizace-odpojovani-hod inek-od-telefonu

If the watch cannot be switched on, updated or charged, please contact us at helpdesk.intelek.cz.

Producer / exclusive importer of iGET products to EU:

INTELEK spol. s r.o., Ericha Roučky 1291/4, 627 00

Copyright©2020 INTELEK spol. s r.o. All rights reserved.

Warning symbol with a triangle containing a stylized 'e' and sound waves (no text or numbers)

Symbol of a trash bin with crossed lines indicating no waste, and a solid black rectangle below (no text or labels)

Warning symbol with a stylized ear inside a triangle (no text or numbers)

Symbol of a trash bin crossed with two crossed lines, no text or numbers present

Serial / Batch number: (S/N)

Date of sale:

Warranty un I:

Sale document number:

Seal of the store:

Informa on for Customers about Warranty Terms and Conditions:

Warranty shall apply to defects of purchased product, found during its warranty period. When purchasing a particular product, please consider carefully what proper es and func ons you expect your product to have. The fact that purchased product shall not sa sfy your later requirements shall not give any reason for complaint. Please, prior to the rst use of this product read carefully its opera ng instruc ons and follow these instruc ons consistently. We recommend you to keep original product packing

during the warranty period for possible transport of the product in such a way so as to prevent any product damage during its transport and handling.

For the purpose of due applica on of any complaint about the product we recommend you to ask Seller to ll-in and con rm this Warranty Card including iden ca on of serial number of purchased product, which shall comply with the serial number speci ed both in the document proving product purchase and delivery note and purchased product.

In this connec on Customer hereby takes into account that unless this Warranty Card speci es serial number of purchased product, i.e., comparison of such serial number iden ed in the product with the serial number iden ed in this Warranty Card and document of product purchase/or delivery note shall not allow to con rm that par cular product has come from Seller, in case of any doubts about the origin of such par cular product Seller shall be en tled to automa cally and without any other acts to reject the complaint of such goods.

Warranty shall not apply to:

product damage su ered by unquali ed installa on of rmware or its modi ca on;

product damage by sta c electricity;

product use for any other purposes than designed, described in a ached opera ng instruc ons;

damage to warranty seal of the producer, a ached to the product;

product damage inconsistent with the opera ng instruc ons, technical standards or safety

regula ons valid in the Czech Republic;

product damage resul ng from normal wear and

tear;

discharged ba eries, decrease in ba ery capacity caused by its wear and tear;

product defects caused by the use in dusty, polluted or in any other way dissa sfactory environment pursuant to a ached opera ng instruc ons.

Wear and tear of the product and its components caused by their common use (discharged ba eries, decreased capacity of accumulator, wear and tear of mechanical or displaying components, wear and tear of supply cables, headphones etc.) shall be subject neither to defect warranty nor quality warranty in the moment of take-over.

Furthermore, complaints about product parameters, not included in the opera ng instruc ons or in any commercial-technical documenta on of Seller, related to the product, shall not be subject to quality warranty in the moment of take-over.

In the event of any changes in the dimensions of the ba ery, discon nue use, and un I there is a change the ba ery with a new one.

Proof of product purchase, or delivery note, shall cons tute an integral part of this Warranty Card.
