GE 1500-38 - Lawn mower Gardol - Free user manual and instructions

Product Type	Electric Lawn Mower
Brand	Gardol
Model	GE 1500-38
Motor Power	1500 W
Cutting Width	38 cm
Cutting Height Range	25-75 mm
Height Adjustment	Central lever, 5 positions
Grass Box Capacity	45 L
Voltage	230 V
Power Cord Length	10 m
Weight	12 kg
Dimensions (L x W x H)	70 x 40 x 38 cm
Noise Level	85 dB(A)
Safety Features	Double switch operation, motor brake
Maintenance	Regular blade sharpening, clean after use
Spare Parts Availability	Blades, grass box, wheels available online
Repairability	Modular design, easy access to motor and blade
Warranty	2 years

Frequently Asked Questions - GE 1500-38 Gardol

How do I assemble the Gardol GE 1500-38 lawn mower?

Refer to the manual for step-by-step assembly. Typically, attach the handle, grass box, and adjust cutting height. Ensure all screws are tightened securely.

How do I start the mower?

Plug into a mains socket, press and hold the safety button, then pull the start handle towards you. Release the safety button after engine starts.

What is the correct cutting height for my lawn?

For typical grass, set cutting height between 30-50 mm. Avoid cutting more than one-third of grass blade length at a time to prevent stress.

How often should I sharpen the blade?

Sharpen the blade at least once per season or after 25 hours of use. A dull blade tears grass, leading to brown tips.

How do I clean the mower?

Disconnect from power, use a brush or cloth to remove grass clippings. Do not use water pressure as it may damage electrical components.

What should I do if the mower vibrates excessively?

Check if the blade is unbalanced or damaged. Also inspect for loose bolts or debris stuck under the deck. Tighten or replace parts as needed.

Can I use an extension cord?

Yes, use a heavy-duty outdoor extension cord with a minimum cross-section of 1.5 mm² and length up to 30 m. Ensure it is fully uncoiled to avoid overheating.

How do I replace the blade?

Unplug the mower, tilt it on its side, and use a wrench to remove the blade bolt. Install the new blade with the cutting edge facing the correct direction, and torque bolt to specifications.

What type of grass can this mower handle?

The GE 1500-38 is suitable for small to medium lawns with standard grass types. Not recommended for very thick or wet grass.

How do I store the mower during winter?

Clean thoroughly, sharpen blade, empty grass box. Store in a dry, frost-free place. Disconnect power cord and coil it up.

USER MANUAL GE 1500-38 Gardol

The electric lawn mower GE 1500-38 is suitable for clean-cut lawns in any garden. The blade is driven by a strong series motor for high torques, the perfect solution for cutting even higher grass. Optimized design for best handling in difficult-to-reach areas such as shrubbery, bushes, trees and etc. Completely closed base frame for a perfect air flow, to guarantee perfect cutting results every time!
