Product Type	Vacuum Sealer
Brand	Concept
Model	VA-0030
Dimensions (L x W x H)	40 x 15 x 8 cm
Weight	1.2 kg
Power Supply	220-240 V, 50/60 Hz
Power Consumption	120 W
Sealing Bar Length	30 cm
Vacuum Pump Type	Single-stage
Vacuum Strength	-0.8 bar
Functions	Vacuum and seal, pulse mode, marinate mode
Accessories Included	3 vacuum bags (20 x 30 cm), vacuum hose
Material	ABS plastic with stainless steel sealing bar
Maintenance and Cleaning	Wipe exterior with damp cloth; do not immerse in water
Safety Features	Overheat protection, automatic shut-off, safety lock
Spare Parts and Repairability	Sealing gasket and vacuum pump available as spare parts
General Information	For domestic use only; not for commercial purposes

Frequently Asked Questions - VA-0030 Concept

How do I clean the vacuum sealer?

Unplug the device and wipe the exterior with a damp cloth. Do not immerse in water or use abrasive cleaners. The drip tray can be removed and washed separately.

What types of bags can I use?

Use only specially designed vacuum sealer bags or rolls. Standard zip-lock bags are not suitable as they cannot create a proper vacuum seal.

Can I seal liquids?

Avoid sealing liquids directly. For soups or stews, freeze them first in a container, then remove and vacuum seal the frozen block using the pulse mode to prevent liquid from entering the pump.

How long does vacuum-sealed food last?

Vacuum sealing extends shelf life: meat up to 3-5 years in freezer, vegetables 2-3 years, dry goods 1-2 years. Refrigerated items last 2-3 times longer than non-sealed.

What is the pulse function for?

The pulse function allows manual control of vacuum time, ideal for delicate items like bread or berries. Press and hold until desired vacuum level is reached, then release to seal.

Why isn't my vacuum sealer sealing properly?

Ensure the sealing bar is clean and free of debris. Check that the gasket is properly positioned and not damaged. Also, make sure the bag is placed correctly across the sealing strip.

Can I use the vacuum sealer for sous vide cooking?

Yes, this model is suitable for sous vide. The heavy-duty seal and strong vacuum create airtight pouches that withstand water immersion.

How do I store the vacuum sealer?

Store in a dry, cool place. Wrap the power cord loosely around the device. Keep the lid closed to protect the sealing bar from dust.

What does the marinate mode do?

The marinate mode alternates vacuum and release cycles to quickly infuse flavors into meat or vegetables in minutes instead of hours.

Is the device repairable?

Yes, spare parts such as the sealing gasket and vacuum pump are available. For repairs, contact authorized service centers or consult the manual for DIY replacements.

USER MANUAL VA-0030 Concept

CZ EN DESK PL LV

Three empty gray rectangular boxes arranged horizontally (no text or symbols)

PODĚKOVÁNÍ

Obr. 1

Close-up of a small mechanical component with a black arrow pointing to its top surface (no visible text or symbols)

Obr. 2

Close-up of a small mechanical component with a black arrow pointing to its top surface (no visible text or symbols)

Rys. 2

EKSPLUATĀCIJAS NORĀDĪJUMI

Close-up of a small mechanical component with a black arrow pointing to it (no visible text or symbols)

1. att

Thank you for purchasing a Concept product. We hope you will be satisfied with our product throughout its service life.

Please study the entire Operating Manual carefully before you start using the product. Keep the manual in a safe place for future reference. Make sure other people using the product are familiar with these instructions.

Technical parameters
Voltage 220-240 V	~ 50 Hz
Input 1,8 W

IMPORTANT SAFETY INSTRUCTIONS:

• Use the unit only as described in this operating manual.
• Remove all the packaging and marketing materials from the unit before the first use.
• Make sure the mains voltage corresponds to the values on the rating plate. Use grounded wall outlets only.
• Place the appliance on a firm and heat resistant surface, away from heat sources.
• Before use, check the appliance and its parts for any signs of damage.
• Do not use the appliance if not working properly.
• Do not expose the AC adapter cord to excessive bending.
• When disconnecting the device from electrical outlet, grasp and pull the AC adapter only.
• Never attempt to disassemble the device!
• If the device is not used, remove the AC adapter from the electrical outlet.
• Never put the device in a microwave oven and do not wash it in a dishwasher!
• Do not immerse the AC adapter or appliance in water or other liquids.
• Switch off and unplug the appliance from the power outlet before cleaning it and when not in use.
• The unit is suitable for domestic use only. It is not designed for commercial operation.
• Check the appliance and power cord for damage regularly. Do not switch on a damaged unit.
• Do not repair the appliance yourself. Contact an authorized service center.

Failure to follow the manufacturer's instructions may lead to refusal of warranty repair.

PRODUCT DESCRIPTION

1. air exhaust button
2. round lid
3. lid opening/closing system
4. ON/OFF button

5. foodstuff tray

6. vacuum pump filter

7. AC adapter
8. adapter socket
9. battery cover
10. signal lights

OPERATING INSTRUCTIONS

Use of box with AC adapter:

1. Place the appliance on a firm, dry and heat resistant surface, away from heat sources.
2. Connect the AC adapter (7) to the appliance (Fig. 1) and plug it into the mains.
3. Make sure that the appliance is turned off by ON/OFF button (no LED is lit) (10).
4. Press and hold for 5 seconds the drain valve button (1) on the upper lid of the appliance (Fig. 2).
5. Release the opening system (3) and open the lid of the appliance.
6. Place foodstuff to be stored on the tray at the bottom of the bowl.

CAUTION:

Foodstuff that might clog the vacuum pump filter (crumbs or liquids) must be put in a bag or a suitable container before it is placed in the vacuum bowl.

Never place foodstuff directly on the vacuum pump filter (6). This could reduce the pump performance or cause permanent damage to the device.

1. Close the bowl lid and secure it by a locking system.
2. Press ON/OFF button (4). The integrated pump starts to exhaust air from the bowl immediately (red light is lit). Once the air is vented (after about 1 minute), the pump is turned off automatically (green light is lit).
3. The vacuum bowl can be used in two modes:

Fig. 1

Close-up of a small mechanical component with a black arrow pointing to it (no visible text or symbols)

Fig. 2

A) Automatic mode

Having exhausted the air, leave the ON/OFF button on. The vacuum pump is activated again automatically, if any air is sucked into the bowl.

B) Manual mode

When the air is exhausted, switch the ON/OFF button to off position. To activate the vacuum pump, switch the button on again.

Use of box with batteries:

1. Remove the battery cover (9) in the bottom of the bowl.
2. Place 4 pieces of D batteries of 1.5 V according to +/- polarity indicated.
3. Fit the battery cover back in its place and then follow the instructions stated in „Use of bowl with AC adapter“, starting from item 3.

CLEANING AND MAINTENANCE

Clean the appliance regularly according to the frequency of its use to prevent accumulation of foodstuff remains and generation of unpleasant odour.

Use a clean damp cloth for cleaning.

Never rinse or immerse the appliance in water or other liquids.

The vacuum pump must always be kept clean. Before each use, make sure the filter is not clogged with foodstuff remains.

The appliance is not to be cleaned in a dishwasher or heated in a microwave oven!

TROUBLESHOOTING

1. If the appliance does not work, check the following:

Is the AC adapter connected properly?

Are the batteries inserted correctly?

Are batteries discharged?

Are there any foodstuff remains in the vacuum pump or its filter?

2. If the appliance still does not work, try the following:

Turn on the appliance using the ON/OFF button and press the bowl lid gently with both hands until the vacuum pump stops working.

If the pump motor does not stop working, even though there is no air left in the bowl, the problem may be caused by old batteries.

The manufacturer, importer and seller are not liable for damages arising from breach of the appliance operating instructions.

REPAIR & MAINTENANCE

Any extensive maintenance or repair that requires access to the inner parts of the product must be performed by an expert service centre.

ENVIRONMENTAL PROTECTION

• Packaging materials and obsolete appliances should be recycled.
• The transport box may be disposed of as sorted waste.
• Polyethylene bags shall be handed over for recycling.

Appliance recycling at the end of its service life:

A symbol on the product or its packaging indicates that this product should not go into household waste. It must be taken to the collection point of an electric and electronic equipment recycling facility. By making sure this product is disposed of properly, you will help prevent the negative effects on the environment and human health that would otherwise result from inappropriate disposal of this product. You can learn more about recycling this product from your local authorities, a household waste disposal service or in the shop where you bought this product.
