Steel Pro - Kitchen scale OBH NORDICA - Free user manual and instructions

Product Type	Digital kitchen scale
Brand	OBH Nordica
Model	Steel Pro (9804)
Dimensions	Ultra slim design: thickness 13 mm
Weight Capacity	5 kg (11 lbs)
Resolution	1 g increments
Accuracy	± 1.0 %
Platform Material	Stainless steel
Display	Large LCD digital display
Power Source	1 lithium CR2032 battery (included)
Tare Function	Yes, resets to zero for multiple ingredients
Auto-Off	After approx. 180 seconds of non-use
Manual Switch-Off	Hold the ON/OFF button for a few seconds
Overload Indication	Display shows warning when exceeding 5 kg
Low Battery Indication	Battery symbol appears on display
Cleaning	Wipe with a slightly damp cloth; do not immerse in water
Safety	Not for use by persons with reduced capabilities without supervision
Intended Use	Domestic use only
Warranty	According to valid law; return to point of purchase with receipt
Repairability	Battery replacement; other repairs by distributor
Disposal	Electronic waste; separate collection required
Country of Origin	Denmark (OBH Nordica Denmark A/S)

Frequently Asked Questions - Steel Pro OBH NORDICA

How do I turn on the scale?

Place the scale on a flat surface and press the ON/OFF button lightly. The display will show '0' and the scale is ready for use.

How do I use the tare function?

After weighing the first ingredient, tap the UNITon button quickly. The display will reset to '0g' and show 'TARE' if over 50 g. You can then add the next ingredient.

What type of battery does the scale use and how do I replace it?

The scale uses one CR2032 lithium battery. Remove the battery door on the back, insert the new battery ensuring correct polarity, and reattach the door.

How do I clean the scale?

Wipe the scale with a slightly damp cloth and then dry it with a soft cloth. Never immerse the scale in water or other liquids.

What is the maximum weight the scale can measure?

The maximum capacity is 5 kg. If exceeded, the display will show an overload warning. Remove excess weight to continue.

Does the scale turn off automatically?

Yes, the scale automatically switches off after approximately 180 seconds of non-use to save battery. You can also manually turn it off by holding the ON/OFF button.

Why does the scale show an error or inaccurate reading?

Electronic scales are sensitive to temperature swings. Allow the scale to adapt to normal room temperature. Also ensure it is on a flat surface and the battery is fresh.

Is the scale covered by warranty?

Yes, warranty is according to valid law. Keep your receipt and return the scale to the store where it was purchased if needed.

How should I dispose of the scale and battery?

Dispose of the scale as electronic waste at a municipal collection point. Remove the battery and dispose of it separately at an authorized battery collection point.

Can the scale be used by children or persons with disabilities?

The scale is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities unless supervised by someone responsible.

USER MANUAL Steel Pro OBH NORDICA

steel pro //

kitchen scale //

Ultra slim 13 mm //

Capacity 5 kgs 1 g increment //

Stainless steel platform //

Tare Function //

Dn/off button //

Large LCD display //

OBH Nordica Denmark A/S

Ole Lippmanns Vej 1

2630 Taastrup

Tlf.: 43 350 350

www.obhnordica.dk

Tekniske data

OBH Nordica 9804

OBH Nordica Sweden AB

Box 58

163 91 Spånga

Tel [phone]

www.obhnordica.se

Tekniska data

OBH Nordica 9804

OBH Nordica Norway AS

Postboks 5334 Majorstuen

0304 Oslo

Tlf: 22 96 39 30

Faks: 22 96 39 40

www.obhnordica.no

Tekniske data

OBH Nordica 9804

OBH Nordica electronic kitchen scale

Before use

Before the kitchen scale is taken into use for the first time, please read this instruction manual thoroughly and keep it for future use.

About scales

There are several different types of scales: The traditional mechanical scale that estimates the weight on the basis of spring action - subsequently the weight can be read from a dial. The digital scale which is in fact also a mechanical scale with the exception that weight measurements are read from a display.

The modern electronic scale which performs weighing by means of an electronic sensor and converts the weight electronically for display reading. The advantage of the electronic scale over the mechanical or digital scales is first and foremost that it performs far more accurate weight measurements – and will continue to do so. The mechanical and digital scales become increasingly inaccurate over time, partly due to worn springs in these types of scales.

Please note that electronic scales are sensitive to major temperature swings. Inaccuracies may occur if the scale is cold. The scale works best at normal room temperature.

Replacement and insertion of batteries

The scale requires 1 lithium type CR2032 battery which must be inserted before the scale is taken into use. Please allow the scale to adapt to normal room temperature before use.

Remove the small door on the back of scale to insert the battery. The battery can now be inserted or replaced by placing it in the battery compartment so that the battery is fixed firmly – make sure that the battery is placed correctly.

Re-attach battery door. When battery replacement is required, will appear on the display.

Weighing

The scale reads '0'. Place the scale on a completely plain surface and switch on by pressing the button slightly. The scale is now ready for use. The scale can weigh up to a maximum of 5 kg.

Resetting

This kitchen scale is equipped with a practical reset function which enables all ingredients to be weighed directly in the same bowl, one at a time. When you have finished weighing the first ingredient, the scale is reset by a quick tap on the UNITon. If the ingredient weighs less than 50 g, the display reads '0g'. If the ingredient weighs more than 50 g, the display reads '0g' and 'TARE' in the lower left corner.

After resetting the scale is ready for weighing the next ingredient. Remember to reset after weighing each ingredient. If the most recently weighed ingredient is removed again after resetting, its weight will be displayed with a negative sign. Press reset and the scale is ready for use again. If the scale has not been reset after weighing the latest ingredient, and this ingredient is removed, the display will read '0' again.

If the scale is overloaded (a load of more than 5 kg), the display will read. Remove the surplus ingredients from the scale, and the scale is ready for weighing again.

Switch-off

To save battery life, the scale automatically switches off following approximately 180 seconds of non-use. The scale can also be switched off manually by holding the button for a few seconds.

Cleaning and maintenance

1. Read the instruction manual carefully before use, and save it for future use.
2. The appliance must not be immersed into water or other liquids. Should it get wet, it must be wiped off immediately, as liquids contain minerals which may result in rust in the electronic parts or which may totally destroy the electronic parts.
3. If the appliance gets dirty, the dirt can be wiped off with a slightly humid cloth, and then wiped with a dry cloth.
4. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.
5. Children should be supervised to ensure that they do not play with the appliance. Children are not always able to understand potential risks. Teach children a responsible handling of electrical appliances.
6. The appliance must not be used if it has been dropped on the floor, or if it is clear that the appliance is damaged. In such cases the appliance should be handed in for repair at the distributor where it was bought.
7. Use only new batteries of the correct size. Used batteries should always be removed, as they may leak chemicals which may damage the circuitry of the appliance.
8. The appliance is for domestic use only.
9. If the appliance is used for other purposes than intended, or is it not handled in accordance with the instruction manual, the full responsibility for any consequences will rest with the user. Any damages to the product or other things are not covered by the warranty.

Protecting the environment and disposing of batteries

Respect the environment when you replace the battery. An exhausted battery should never be part of ordinary household waste. Dispose of the exhausted battery at authorized collection points. Make sure that the battery is not too old or exhausted as there is a risk that it might leak acid. Remember to remove the battery before disposing of the product.

Disposing of the appliance

Legislation requires that all electrical and electronic equipment must be collected for reuse and recycling. Electrical and electronic equipment marked with the symbol indicating separate collection of such equipment must be returned to a municipal waste collection point.

Warranty

Claim according to valid law. Machine stamped receipt shall be enclosed if one wishes to make a complaint. The appliance shall be returned to the store where it was purchased.

OBH Nordica Denmark A/S

Ole Lippmanns Vej 1

2630 Taastrup

Tlf.: 43 350 350

www.obhnordica.dk

Technical data

OBH Nordica 9804

Maximum weight 5 kg with 1 g interval

The appliance must be disposed of as electronic waste

Reset function

LCD digital display

Automatic switch-off after approx. 180 seconds of non-use

1 lithium type CR2032 battery

Scale accuracy: +/- 1.0 %

With reservation for ongoing changes and improvements
