PSC-130 - Waffle Maker Sam Cook - Free user manual and instructions

Brand	Sam Cook
Model	PSC-130
Product Type	Waffle Maker
Power Supply	220-240 V ~ 50/60 Hz
Power Consumption	Approx. 800 W
Temperature Control	Adjustable thermostat (MIN to MAX) with LED indicator
Indicator Lights	Green: power on / ready; Red: heating
Heating Plates	Non-stick coated, top and bottom
Plate Material	Metal with non-stick coating
Housing Material	Plastic (estimated)
Non-slip Feet	Yes
Cord Length	0.7 m
Dimensions (approx.)	25 x 20 x 10 cm
Weight (approx.)	1.5 kg
Baking Time	5-10 minutes depending on batter and temperature
Safety Features	Automatic shut-off? Not specified; hot surface warning; do not immerse; keep away from children; grounding pin required
Cleaning	Wipe plates with damp cloth; do not immerse; avoid abrasive cleaners
Recommended Utensils	Wooden or plastic spatula; do not use metal utensils
First Use	Preheat on MAX for 10 minutes, then cool and wipe
Plate Change	Not interchangeable; do not mix different plates

Frequently Asked Questions - PSC-130 Sam Cook

How do I preheat the waffle maker for the first time?

Plug in the device, set the thermostat to MAX, and let it run for 10 minutes without batter. The LED will indicate heating. After 10 minutes, unplug, let it cool, and wipe the plates with a damp cloth.

Can I use metal utensils on the non-stick plates?

No, only use wooden or plastic spatulas to avoid damaging the non-stick coating. Metal utensils can scratch and ruin the surface.

Why does the LED indicator change color?

The LED turns red when the plates are heating and green when the set temperature is reached. It will cycle during baking to maintain the temperature.

How long does it take to bake waffles?

Typically 5-10 minutes, depending on the batter consistency and the temperature setting. Thicker batters and lower temperatures require more time.

Can I wash the waffle maker in water?

No, never immerse the appliance, cord, or plug in water. Clean the plates with a damp cloth and wipe the exterior with a wet cloth. Allow the device to cool completely before cleaning.

What is the power cord length?

The power cord is 0.7 meters long. Ensure the outlet is nearby to avoid stretching or tripping hazards.

Is the waffle maker suitable for children to use?

No, this appliance should not be used by children. It can be used by persons with reduced capabilities only under supervision. Keep the device and cord out of reach of children.

Can I use different batter recipes?

Yes, you can use any standard waffle batter. Adjust the temperature and baking time according to the recipe. Avoid overfilling the plates to prevent overflow.

What should I do if the waffle maker smokes during first use?

This is normal. The heating plates may emit a slight smoke or odor during initial conditioning. Run the device on MAX for 10 minutes, then wipe it clean. The smoke will not recur.

Can I replace the heating plates?

The manual does not specify replaceable plates. The plates are fixed and non-stick coated. Do not attempt to remove or interchange them.

USER MANUAL PSC-130 Sam Cook

A man in a apron cutting a knife with herbs and spices, surrounded by other spices (no text or symbols visible)

N/M 100% (M) 1/2007/1007/1008

Black and white photo of a modern flat-screen device with a glossy screen and a small base (no visible text or symbols)

INSTRUKCJA OBSŁUGI

INSTRUKCIA OBSEUGI.

USER MANUAL

1. 实验原理

2. 实验原理

OPSLRZADZENIA/DEVICE DESCRIPTION

Black-and-white photo of a man in traditional attire gesturing with his hand (no visible text or symbols)

MASTERCHEF LINE

EXECUTIVE

polymarie feel by a way past, in hithany sunset rechule

kredywn osteriwn i oktogi w e lperymenlow

Cooking today has become an art.

In preparing food, art means experimenting

and breaking stereotypes. Nevertheless,

Achieving great art requires us to combine

The artist's talent with excellent equipment. That is the case with Sam Cook.

5am-Clack products are designed for demanding people, based on the claims of our product to provide

despite the effects of many cigarettes, who can conspiring a lilyar pavanon. Their criteria in cooking is

characterizes by risk-taking and the courage in experiment

with date. If your kids compare and become a mixer chef in your own kitchen.

Black-and-white portrait of a man sitting on a stool, wearing a white shirt and black pants (no visible text or symbols)

Kuchnia jutra

3. GWARANCJĄ NIE SĄ OBJĘTE:

• Before use, thoroughly read the operation manual.
  • Extreme care is required in case of children presence in vicinity of the appliance!
• Do not use your roaster for any other purpose except of its assignment.
• Do not immerse the appliance, its cord and plug in water or any other fluids!
• Do not leave the roaster without su-

pervision in course of its operation.

• Always pull out the plug from the socket unless the appliance is used or before its cleaning.
- Do not use the roast-er in case of its dam-age, also if its cord or plug is damaged – in such case the appliance should be handed over to an authorized

service shop for re-pair.

• The use of any accessories not recommended by the manufacturer may result in damage of the appliance, fire or injuries.
- Do not use the roast er outdoors.
- Do not hang the cord on any sharp edges and prevent any contact with hot surfaces.

• Do not stand the roaster in vicinity of electric and

gas cookers, burners, ovens etc.

• Do not touch any hot surfaces in course of roasting – open the roaster by means of holder designed for this purpose only.
• Prior to commencing the cleaning, pull out the plug from the plug socket and allow the roaster to cool completely.
• When opening the appliance in course of roasting, proceed carefully owing to hot damp from the area

under the heating panels!!

• The roaster should be connected into the socket with grounding pin!
• This appliance can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved.

• Children shall not play with the appliance (including the accessories).
- This appliance shall not be used by children. Keep the appliance and its cord out of reach of children (including the accessories).
- Use on a flat, stable surface.
- The equipment is not designed to work with external schedulers or a separate control system.

Warning! Hot surface!

• Do not pull the plug by holding the power cord.
• Do not connect the power plug with wet hands.
• The temperature of surfaces may be higher when the appliance is in use.
• This appliance is intended for household use only.
• To avoid the risk of fire, do not place the appliance near flammable objects, such as curtains, tablecloths, etc.

Note!

• When placing the dough on the bottom heating plate make sure the baking mould is completely filled.
• During baking process the excess dough may flow out of the appliance.
• When waffles are ready, remove them carefully using wooden or plastic utensils.
• Keep your children safe: do not leave any parts of the packaging readily accessible

(i.e. plastic bags, cardboard boxes, polystyrene inserts, etc.).

• WARNING! Never let children play with plastic film or bags. Choking/ asphyxia-tion hazard!
• WARNING! Oils and fats may burn when overheated. Please be careful!
• WARNING! Do not use a combination of different baking plates

APPLIANCE DESCRIPTION

1. Heating plates (top and bottom)
2. Upper lid

3. Base of the appliance

4. Thermostat knob for temperature control and with an LED indicator.

5. Non-slip feet

Plates covered with non-stick coating.

PRIOR TO THE FIRST USE

ATTENTION! Before cleaning the heating plates make sure the appliance is unplugged!

1. Prior to the first use of the roaster, thoroughly wash the heating panels of the wafflemaker with the cloth moistened with warm water and thoroughly wipe with dry cloth thereafter.

2. Stand the appliance on a flat, stable and dry surface which is resistant to high temperatures.

3. Before using for the first time, the hot plates must be properly conditioned by running them hot. Place the appliance on a firm, dry, level and smooth surface, plug the power cord to the mains and set maximum temperature. Leave it running for 10 minutes. Next, unplug the appliance

from the mains and wait until it cools down completely. The hot plates may smoke slightly during this process. This is natural and will no recur during further use. Wipe the hot plates with a damp cloth and wipe them dry.

NOTE! The working surfaces of the wafflemaker are heated up to extremely high temperatures! Touch the holders only!

USING WAFFLE-MAKER

1. Oil the heating plates 1 with butter, margarine or other fat.
2. Connect the device to the mains - the LED indicator in the knob 4 will light up in green to signal successful connection to the mains. Turn the thermostat knob 4 to "MAX" - the process of heating up the cooking plates will begin and will be signalled by the LED indicator changing the colour to red. Close the upper cover and prepare the batter for wafers.
3. Once the wafer maker heats up sufficiently, the LED indicator will turn green. Depending on the type of batter and baking goal, use the knob 4 to set the temperature of

the cooking plates. The "MIN" setting corresponds to the lowest available temperature, while the "MAX" setting corresponds to the highest one. It is also possible to set any intermediate temperature between "MIN" and "MAX". While the wafers are being made, the LED indicator in the knob (4) will change its colour multiple times to indicate that cooking plates' temperature is maintained.

1. Open the top lid 2, place the dough onto the bottom heating plate 1 and gently close the lid.

2. When closing and opening the lid, proceed carefully owing to hot vapours escaping from the sides of the waffle-maker.

3. Baking the waffles may take from 5 to 10 minutes, depending on the batter and set temperature.
4. Open the top lid 2, take out the waffles using wooden or plastic spatula only.

NOTE! Do not use and metal and sharp knives or forks, otherwise the damages of heating surfaces may occur!

1. After baking turn the thermostat knob to "O", pull out the plug from the outlet and allow the appliance to cool down completely.

CLEANING AND MAINTENANCE

Before cleaning (and after baking), pull out the plug from the outlet and allow the appliance to cool down completely.

1. Thoroughly wash the heating plates 1 using damp cloth or towel.

2. Wipe the external surface of the waffle-maker using wet cloth.

NOTE! Do not immerse the appliance in water or any other liquids! Do not wipe the inside

of the appliance with acute, abrasive cloths or sponges, as this can damage the heating surfaces!

TECHNICAL SPECIFICATIONS

See the product's nameplate for technical specifications.

Length of power cord: 0.7 m

CAUTION! MPM agd S.A. may change the technical features of the product without notice.

Black-and-white portrait of a man with long hair sitting on a stool, wearing a white shirt and black pants (no text or symbols visible)

The kitchen of tomorrow

The kitchen is the best place to make your culinary dreams come true, and allow your cooking prowess to grow.

Test out new ideas and find better ways of doing things!

Never be afraid of new challenges, of fusing the old with the new, or of innovative tastes and ingredients.

New opportunities

Plan your culinary success with the right appliances.

Choosing the Sam Cook household brand is like enlisting professional help in your kitchen.

Surprise yourself with how easy it is to make something new and feel like a professional chef!

PROPER DISPOSAL OF THE PRODUCT (waste electrical and electronic equipment)

Poland

Proper disposal of the product (waste electrical and electronic equipment) Marking on the product indicates that after the service-life of the product expires, it should not be disposed with other type of municipal waste. Used equipment may have a negative impact on the environment and health of people due to potentially containing hazardous substances, mixtures and components. Mixing

electric waste with other types of waste or disassembling those in an unprofessional manner may cause a release of substances that are hazardous to the environment and health. Used equipment should be handed-over to a point for collection of electric waste. In order to obtain detailed information regarding the electric waste collection points, the user should contact the municipal point of electric waste collection or used equipment processing department.
