Flaat GK150 - Contact grill Eldom - Free user manual and instructions

Product Type	Contact grill
Brand	Eldom
Model	Flaat GK150
Power	2000 W
Voltage	220-240 V ~ 50/60 Hz
Functions	Contact grill (two-sided) and horizontal grill (open 180°)
Heating Plates	Non-stick coating (assumed)
Temperature Control	Adjustable thermostat with indicator lights
Indicator Lights	Red (power on) and green (heating)
Safety Features	Auto-adjusting cover, cool-touch handle, thermal cut-off (implied)
Cleaning	Wipe plates with damp cloth; do not immerse
Maintenance	Remove fat regularly via spout and container
Certifications	CE compliant (assumed)
Repair	Authorized service only
Accessories Included	Fat container (1)
Intended Use	Household only

Frequently Asked Questions - Flaat GK150 Eldom

How to use the Flaat GK150 as a contact grill?

Close the cover, set the thermostat to desired temperature, wait for green light to go off, open cover, place food, close cover gently. The cover automatically adjusts to food thickness.

How to open the grill to 180° for horizontal use?

Ensure the device is cold. Press the lock button (3) and lift the top cover by the holder (9) until it lies flat. Route the power cord away from the hot top cover.

How to clean the GK150?

Unplug and let cool. Wipe heating plates with paper towels to remove fat, then clean with a damp cloth. Do not immerse in water or use abrasive cleaners.

What do the indicator lights mean?

Red light indicates the grill is connected to power. Green light turns on when heating and off when the set temperature is reached.

Can I grill different thicknesses at the same time?

Yes, the top cover adjusts automatically to the thickness of the food, making it suitable for items of varying thickness.

What should I do if food sticks to the plates?

Use wooden or plastic utensils to avoid damaging the coating. Preheating properly and adding a little oil can help prevent sticking.

How to avoid burns while using the grill?

Use the handle (9) to open the cover. Never open when the device is hot. Keep children away and do not touch the hot surfaces.

Why does my grill emit smoke during first use?

This is normal due to manufacturing residues. Ensure good ventilation and run the grill without food for a few minutes until smoke stops.

What is the maximum power and voltage?

The GK150 operates at 2000W, 220-240V ~ 50/60 Hz.

Can I repair the grill myself?

No, only authorized service shops can repair the appliance. Unauthorized repairs void the warranty and may be dangerous.

USER MANUAL Flaat GK150 Eldom

Exterior view of a modern electric grill grater with black and white panels (no visible text or symbols)

DANE TECHNICZE

1. read the whole content of this user manual before using the appliance for the first time connect the connection cord to a socket which complies with the specification provided in the manual.
2. set the appliance on a flat, stable and high temperature resistant surface.
3. always disconnect the appliance from the mains by pulling the plug, not the power cord.
4. disconnect the appliance from the mains whenever it is not used or before cleaning it.
5. do not immerse the cord or the appliance in water.
6. do not use in open air.
7. do not use nearby inflammable materials such as furniture, bedding, paper, clothes, lace curtains, linings etc.
8. do not leave children without care nearby the appliance parts of the appliance become hot when the appliance is being used. You should hold the appliance only by the handgrip.
9. be careful when taking out the sandwiches. Ready made sandwiches are hot and can burn.
10. do not leave the appliance unattended when it is being used.

11. The device can be used by children aged 8 and older and by persons with limited physical, sensory or mental capabilities, or persons without sufficient experience and knowledge only under supervision or if previously instructed on the safe use of the appliance and the possible risks. Children shall not play with the appliance. Cleaning and maintenance that are the responsibility of the user shall not be carried out by children without supervision. Protect the appliance and the power cord against children under 8 years old.

12. Pay attention to make sure that the appliance is not played with by children.

13. do not carry or move the appliance when it is being used.
14. do not cover the appliance when it is being used.
15. do not put any products in metal foils into the appliance.
16. do not grasp the appliance with wet hands.
17. the appliance is intended for household use only.
18. a very hot stream of steam may come out of the appliance when the cover is being opened do not use the appliance if the power cord has been damages or when the appliance has fallen down or was damaged in another way. The appliance should be repaired by an authorized service shop; see the annexe or visit the site www.eldom.eu for the list of authorized service shops.
19. the appliance may be repaired only by an authorized service outlet.
20. Modernizing the appliance or using other spare parts or components for the appliance with the genuine ones is forbidden and threatens the safety of use.
21. Eldom Sp. z o. o. is not responsible for any potential damages caused by improper use of the appliance.

WARNING

- Opening the top cover is only allowed when the device is cold. Otherwise, there is a risk of burns.

- When opening the device route the power cord in such a way that it does not come into contact with the top cover.

This symbol is a warning against the high temperature of the appliance surface.

EN

1. Top cover
2. Plate lock
3. "180 degrees" lock
4. Feet
5. Body
6. Heating plates
7. Pilot lights
8. Thermostat
9. Holder
   10.Spout
   11.Fat container

SPECIFICATION

• Power: 2000W
• Voltage: 220-240 V\~ 50/60 Hz

DESIGNATION

GK150 electric grill is designed for grilling, frying, heating, etc. of different types of food. Thanks to the moveable top cover, the device can be used as a contact grill (simultaneous, two-sided roasting of different thickness products) or as a traditional, horizontal grill (after opening to 180 degrees).

■ SETTING UP THE APPLIANCE

Before using the appliance, make sure that the appliance, the plug and the power cable are in good technical order and whether all parts of the package were removed.

Before the first use, all parts of the appliance that are in contact with food must be thoroughly washed (see: Cleaning and maintenance).

Specific smell may be sensed during the first use, which results from the production process. It is a normal process and it will go away after a time. Ensure the proper ventilation in the room, e.g. opening the window. The first use of the appliance should be without products.

USE

Before using the device and plugging it in to the power supply mains with the parameters compliant with the ones indicated on the device, set the thermostat (8) in the "0" position.

CONTACT GRILL

• Set the device on a flat, stable and heat-resistant surface.
• Close the cover (1).
• If the products for grilling contain a large amount of fat you can lift the device by its moveable feet (4), and place one of the containers (11) under the spout (10).
• Connect the device to a power supply. A red pilot light will come on.
• Set the temperature using the thermostat (8). A green pilot light is lit when the device is heating up, and it turns off, when the device reaches the desired temperature.
• Open the cover (1) holding it by the holder (9). Place the products and gently close the cover (1). Do not push the cover (1) down, as you may crush the products, and do not block it during operation (3). The cover (1) will automatically adjust to the thickness of the products.
• The green pilot light turns on and off during frying. The thermostat maintains a proper temperature.
• Remove the products when they are done frying. In order not to damage the heating plates, use wooden or plastic, heat-resistant utensils.
• During the preparation of new portions of products, close the cover (1) in order to maintain the temperature.
• Empty the container (11) regularly.
• After the full completion of roasting, disconnect the device from the power supply.

HORIZONTAL GRILL

- Set the device on a flat, stable and heat-resistant surface. Push the lock button (3) and open the top cover holding it by the holder (9).

WARNING

Opening the top cover is only allowed when the device is cold. Otherwise, there is a risk of burns.

Route the power cord in such a way that it does not come into contact with the top cover.

• If the products for grilling contain a large amount of fat you can lift the device by its moveable feet (4), and place the containers (11) under the spouts (10).
• Connect the device to a power supply. A red pilot light will come on.
• Set the temperature using the thermostat (8). A green pilot light is lit when the device is heating up, and it turns off, when the device reaches the desired temperature.
  Place the products on the plates and grill turning them once in a while.

- The green pilot light turns on and off during frying. The thermostat maintains a proper temperature.

- Remove the products when they are done frying. In order not to damage the heating plates, use wooden or plastic, heat-resistant utensils.

- Empty the containers (11) regularly.

- After the full completion of roasting, disconnect the device from the power supply.

CLEANING AND MAINTENANCE

• before cleaning, unplug the appliance and leave it until it has cooled down
• do not immerse any part of the appliance in water or other liquids
• at the beginning wipe the heating plates with paper towels to remove the fat then clean the appliance and the cable with a slightly damp cloth. Before the next use, wipe the appliance dry.
• do not use detergents and solvents
• in case of residues which are hard to remove, do not use hard tools as they may damage the coatings applied on the plates of the appliance. It is best to put a wet cloth on heavy residues which will soften the

ENVIRONMENTAL PROTECTION

• the appliance is made of materials which can be recycled
• it should be handed over to the applicable collection point for the recycling of electrical and electronic equipment,

WARRANTY

• this appliance is designed for domestic use only
• it cannot be used for professional purposes or for other than the intended use,
• improper use will nullify the guarantee.
