BCH3358 - Heating Becken - Free user manual and instructions

Product Type	Heater
Brand	Becken
Model	BCH3358
Power Supply	AC 220-240V, 50/60Hz
Power Consumption	2000W
Heating Method	Convection
Adjustable Thermostat	Yes
Number of Heat Settings	3 (Low, Medium, High)
Overheat Protection	Yes, automatic shut-off
Tip-over Switch	Yes
Dimensions (W x H x D)	45.0 x 38.0 x 22.0 cm
Weight	3.2 kg
Control Type	Manual dial
Indoor Use Only	Yes
Certification	CE, RoHS
Cleaning Instructions	Wipe with a dry cloth, do not immerse
Replacement Parts	Contact Becken customer service
Warranty	2 years

Frequently Asked Questions - BCH3358 Becken

How do I set the thermostat on my Becken BCH3358 heater?

Turn the thermostat dial to your desired temperature. The heater will automatically maintain that temperature.

Can I use the heater in a bathroom?

No, the BCH3358 is designed for indoor use only and should not be used in moist environments like bathrooms unless specifically rated for such.

What should I do if the heater stops working suddenly?

Check if the tip-over switch or overheat protection has activated. Reset by turning off, unplugging, and allowing it to cool. Plug back in and turn on.

How often should I clean the heater?

Clean the exterior with a dry cloth every few weeks. Ensure the heater is unplugged and cool before cleaning.

Is there a filter that needs replacement?

The BCH3358 does not have a replaceable filter. Clean the air intake vents regularly with a vacuum to maintain efficiency.

Can I leave the heater unattended overnight?

It is not recommended to leave any heater unattended for extended periods. Always turn off and unplug when not in use.

What is the power cord length?

The power cord is approximately 1.5 meters long.

Does the heater have a fan?

This is a convection heater and does not include a fan. It heats air naturally.

How do I store the heater during summer?

Clean it, wrap the cord, and store in a dry place away from direct sunlight and dust.

Is the heater safe for use around pets?

Yes, but ensure pets do not come into contact with the heater surface during operation. It has tip-over protection.

USER MANUAL BCH3358 Becken

MANUAL DE INSTRUÇÕES

Modern armchair with blue velvet and cushion, accompanied by a potted plant on a small side table (no text or symbols visible)

Exterior view of a black Boeken solar heating device with control panel and ventilation slots (no visible text or symbols)

Dear client,

Thank you for purchasing this product.

The quality of this appliance has been certified by several laboratory tests. This instructions manual is provided to simplify the use of the appliance as well as to guarantee a safe use.

Please read carefully the instructions and safety measures described in this manual.

We sincerely hope you will be satisfied when using your new appliance.

INDEX

1. SAFETY INSTRUCTIONS 4

1.1. Power Supply 5
1.2. Power Cord and Other Cables 5
1.3. Humidity and Water 5
1.4. Cleaning 5
1.5. General Precautions 6

2. OPERATING INSTRUCTIONS 8

2.1. Product Description 8
2.2. Product usage 10
2.3. Maintenance 17
2.4. Troubleshooting 17

3. TECHNICAL SPECIFICATIONS 19

1. POST-SALE SERVICE 19
2. ENVIRONMENTAL PROTECTION 19

Convector Heater | Convector | Convector

BECKEN

1. SAFETY INSTRUCTIONS

	WARNING
	RISK OF ELECTRIC SHOCKDO NOT OPEN
Warning: to avoid the risk of electric shock, do not remove the cover. The interior does not contain any parts that can be repaired by the user. Ask for assistance from the Customer Support Service.

Important Warnings

Before using your appliance read this instructions manual carefully and keep it in a safe place as you may need to consult it in the future.

Before turning on your appliance, and to ensure a safe and correct operation, do not use if:

• It has fallen to the ground;
- You notice any evidence of damage;
- Any anomaly occurs during its operation.

To avoid hazards or deterioration of your appliance through incorrect use it is advisable to read these instructions thoroughly.

Your appliance may not be used for other purposes than the ones intended and solely for household use. Any damage resulting from using the appliance outside this scope, any incorrect use, as well as any manual modifications to the product will not be covered and automatically voids the warranty.

[you can trust]

Assistance

In case of malfunction, take your appliance to the Customer Support Service for assistance.

This appliance can be used by children from the age of 8 and by people with reduced physical, sensorial or mental capabilities and/or lack of experience and knowledge if they have been given instructions on using the appliance safely and if they understand the hazards involved. Children may not play with the appliance. Cleaning and maintenance must not be carried out by children without supervision.

These instructions are also available at www.suporteworten.pt

1.1. Power Supply

Make sure the main voltage is compatible with the appliance's. If this is not the case, please consult the Customer Support Service.

1.2. Power Cord and Other Cables

Do not tangle the cord or pull it to disconnect the appliance. Also, keep the cord away from warm surfaces.

Never use the appliance if it has a damaged cable or socket.

Take it to the Customer Support Service for replacement.

1.3. Humidity and Water

Do not use your appliance in humid places. Do not allow the appliance to become wet under any circumstances as this may be dangerous. To avoid fire hazard or electric shock do not expose your appliance to humidity or water. Furthermore, do not place your appliance under water (e.g. for cleaning).

1.4. Cleaning

To clean the exterior of the product, use a dry soft cloth only.

Convector Heater | Convector | Convector

BECKEN

1.5. General Precautions

- Please follow the instructions in the user manual which will help you to properly install and operate this product and enjoy its advanced features. Please keep the instructions for future reference.

- Read all instructions before using the product.

- Maintenance and service operations are only to be carried out by authorized professionals.

- Any damage caused by manual modifications to the product is not covered by the warranty.

- If this product is used for other purposes than the ones originally intended, or if it is not correctly connected, the product may become damaged and the warranty will be voided.

- Check the convection heater for visible external damage before use. Do not operate an appliance that has been damaged or dropped.

- If the appliance's mains power cable is damaged, it must be replaced by the Customer Support Service in order to avoid risks.

- The convection heater may be used by children aged 8 years old or higher and by persons with limited physical, sensory or mental capabilities or lack of experience and knowledge, provided they are under supervision or have been told how to use the appliance safely. They must also be aware of the potential risks. Cleaning and user maintenance tasks may not be carried out by children unless supervised.

- Children under 3 years old should be kept away from the appliance unless constantly monitored.

- Children aged older than 3 and younger than 8 years old may only switch the appliance On and Off if they are supervised or instructed in the safe use of the appliance and have understood the resulting dangers, provided the appliance is located or installed in its normal operating position.

- Children aged older than 3 and younger than 8 years old may not plug in, regulate or clean the appliance and may not carry out user maintenance tasks.

[you can trust]

- Caution - some of the convection heater parts may be very hot and cause burns. Be particularly careful when children and vulnerable persons are present.

- The convection heater's metal surfaces can become hot. Therefore, only hold the convection heater by its handles (9).

- All repairs must be carried out by the Customer Support Service. Improper repairs can pose significant risks to the user and will void warranty claims.

- Defective components must always be replaced with original replacement parts. Only by using original replacement parts can it be assured that the safety requirements are being complied with.

- Protect the convection heater from penetration by moisture and liquids.

- Always disconnect the power cable from the mains power socket by pulling on the plug; never pull on the cable.

- Avoid using extension cables.

- Do not use the convection heater near naked flames.

- The convection heater must not be placed immediately under or over a mains power socket.

- Do not use this convection heater together with a programmable switch, a timer, a separate remote-control system or any other system which switches on the heater automatically, as this could lead to a fire risk should the convection heater be covered or set up incorrectly.

- Disconnect the plug from the mains power socket if the convection heater malfunctions. Follow the same procedure during thunderstorms.

- The convection heater must not be used in the immediate vicinity of a bath, a shower or a swimming pool.

- The convection heater is to be installed so that a person in the bath or shower is unable to touch the switch and other controls.

- Do not expose the convection heater to spray and/or dripping water and do not place any objects filled with liquid, such as vases or open drink containers, on or near the appliance.

Convector Heater | Convector | Convector

BECKEN

2. OPERATING INSTRUCTIONS

2.1. Product Description

Familiarize yourself with all functions of the device.

[you can trust]

1. Control panel
2. Display
3. Air outlet
4. Remote control compartment
5. Air inlet
6. Feet
7. Temperature sensor
8. Main switch
9. Transportation handle
10. Selected heat setting display
11. "Fan" symbol
12. "Antifreeze" symbol
13. Selected measurement unit display
14. Fan button
15. Increase temperature
16. Decrease temperature
17. Timer button
18. Runtime display
19. Preset target temperature display
20. In-room measured temperature display
21. On/Off button
22. Infrared receiver for remote control
23. Button to select the measurement unit
24. Button to select the heating setting
25. Remote control
26. Button to select the heating setting
27. Fan button
28. Button to select the measurement unit
29. Decrease temperature
30. Battery compartment
31. Timer button
32. Increase temperature
33. On/Off button

Convector Heater | Convector | Convector

BECKEN

2.2. Product usage

Information concerning these operating instructions

Before using the convection heater, familiarise yourself with all handling and safety guidelines. Use the convection heater only as described and for the range of applications specified. Please also pass these operating instructions on to any future owner(s).

Intended use

This convection heater is intended only for heating indoor living spaces. It is intended for domestic use only, not for professional use!

It can be used free standing or mounted on a wall. It is not intended for use in areas where special conditions may apply, such as corrosive or potentially explosive atmospheres (dust, vapour or gas). Do not use the convection heater outdoors. It is not intended for any other use and it should not be used during extended periods of time.

Claims of any kind for damage arising as a result of incorrect use will not be accepted. This risk shall be borne solely by the user.

Safety

This appliance complies with statutory safety regulations. Improper use may result in personal injury and property damage.

Do not cover the appliance!

Covering the appliance can lead to overheating it, thus originating a fire!

Risk of fatal injury from electrocution!

Contact with live cables or components can result in fatal injury!

Please observe the following safety guidelines to prevent electrical hazards:

- Do not use the appliance if the power cable or the plug are damaged.

- Before using the appliance again, have a new mains power cable installed by Customer Support Service.

• The appliance housing must not be opened under any circumstances.

[you can trust]

There is a risk of electric shock if live connections are touched and the electrical and mechanical structure is changed.

Risk of injury if batteries are improperly handled

WARNING

- Keep batteries out of the reach of children. Children might put batteries into their mouth and swallow them. If a battery has been swallowed, seek medical assistance IMMEDIATELY.

- Do not throw batteries into a fire. Never subject batteries to high temperatures.

- Risk of explosion! Do not charge batteries unless they are explicitly labelled as “rechargeable”.

- Do not open the batteries or short-circuit them.

- Do not mix different types of batteries. Due to increased risk of leakage, empty batteries should be removed. The batteries should also be removed from the remote control if it is not being used for long periods of time.

- Battery acid leaking from a battery can cause skin irritation. In the event of contact with the skin, rinse with plenty of water. If the liquid comes into contact with your eyes, rinse thoroughly with water, do not rub and consult a doctor immediately.

- When handling leaking batteries, always use coated gloves and protective goggles!

- The chapter entitled “Before initial use” describes how to correctly insert and remove batteries.

BECKEN

Before first use

Package contents and transport inspection

- The appliance is supplied with the following components as standard:

- 1 convection heater

- 1 remote control

- 1 button cell

- 2 feet

- 4 screws for the feet

- These operating instructions

- Remove all packaging materials and all transport locks from the convection heater.

- Before connecting the convection heater, compare the connection data (voltage and frequency) on the rating plate with that of your mains power supply. These data must match so that no damages are sustained by the convection heater.

- Ensure that the mains power cable is not damaged and is not running over hot surfaces and/or sharp edges.

- Ensure that the mains power cable is not taut or knotted.

NOTE

- If possible, keep the appliance's original packaging for the warranty period so that the appliance can be packed properly for return shipment in the event of a warranty claim.

Set-up location requirements

For a safe and trouble-free use convection heater, install it in a place which fulfil the following requirements:

- The convection heater may only be operated in a vertical position and fully assembled.

- When on the floor, the convection heater must be placed on a firm, flat and even surface.

[you can trust]

• Minimum clearances between the housing and other objects must be maintained: 10 cm at the sides, 30 cm above, 15 cm below (with wall mounting) and 50 cm in front.
• Ensure that air can always enter and escape freely. Otherwise, there could be a heat build-up in the convection heater.
• Do not place the convection heater in a hot, wet or extremely moist environment or near flammable materials.
• The mains power socket must be easily accessible so that the power cable can be easily disconnected in an emergency.
• Ambient temperature range: 0 to +40 °C
  • Humidity (no condensation): 5-85 %

DANGER

Fire risk due to contact with materials!

There is a risk of fire if the heating elements come into contact with flammable materials!

• Do not place the convection heater near curtains and other flammable materials.
• Do not allow flammable materials (i.e. textiles) to come into contact with the convection heater.

Inserting the batteries in the remote control

If the battery in the remote control is dead, a new battery needs to be inserted.

- Open the battery compartment on the underside of the remote control (see description on the back of the remote control).

- Remove the old battery from the remote control.

- Insert a new battery into the battery compartment. Ensure the +/- terminals are correctly aligned.

- Slide the battery compartment back into the remote control.

Convector Heater | Convector | Convector

BECKEN

Installation CAUTION

- During assembly, lay the appliance on a soft surface, e.g. carpet, to avoid any damage.

Fitting the feet

- Place the appliance on a soft surface with the base uppermost.

- Fit the feet (6.) to the convection heater's bottom using 2 screws on each foot.

Handling and operation NOTE

- All functions can be used with the convection heater's buttons as well as with the remote control (25.).

This section provides you with important information on handling and using the appliance.

Switch the appliance On and Off

The main switch (8.) disconnects the appliance fully from the mains power supply.

- Insert the power plug into a mains wall socket.

- Switch on the appliance using the main switch (8.) first; alternatively, switch it off at the main switch if you are no longer using it.

- When switched on, the integrated control lamp in the main switch (8.) lights up. There will be a beep and the display (2.) lights up.

- Now press the On/Off button (21.) or (33.). The appliance is now ready for use.

Select the temperature NOTE

- The display (2.) shows the set target temperature (19.) and measured actual temperature (20.).

[you can trust]

- The temperature measurement is made by the temperature sensor (7). It may take some time until a whole room has reached this temperature.

- Press the (23.) or (28.) buttons to select the unit of measure, to select whether the temperature display uses °C or °F. The selected unit of measurement (13.) is shown on the display (2.).

- Press the "Increase temperature" button, (15.) or (32.), to increase the target temperature (19.) up to a maximum of 37^ C (99°F). The selected target temperature (19.) is shown on the display (2.).

- Press the "Decrease temperature" button, (16.) or (29.), to decrease the target temperature (19.) down to a minimum of 5^ C (41°F). The selected target temperature (19.) is shown on the display (2.).

Select heat setting

The heat setting determines how quickly the convection heater warms up. The convection heater has three heat settings:

• Level 1: 1 000 watts
• Level 2: 1 300 watts
• Level 3: 2 300 watts

- To select the heat setting press the buttons (24.) or (26.) repeatedly until the desired heat setting has been set.

The selected heat setting (10.) is shown on the display (2.).

Switch On the fan

The convection heater has a fan which can be used to distribute heated air throughout the room more quickly.

- Press the fan button (14.) or (27.) to switch the fan On or Off. If the fan is active, the "Fan" symbol (11.) appears on the display (2.).

NOTE

If the fan is switched off, the heat is concentrated more around the appliance and is not distributed so quickly around the room.

Convector Heater | Convector | Convector

BECKEN

Set heating time

The appliance has a timer that you can use to set the desired heating time between 1 to 24 hours. Once this period is over, the convection heater switches off automatically.

• Press the timer button (17.) or (31.) until the desired runtime (18.) is shown on the display (2.).
• To switch the timer off, press the timer button (17.) or (31.) repeatedly until no runtime (18.) appears on the display (2.).

Overheating protection

The convection heater is fitted with a thermostat-controlled overheating protector. If it the convection heater becomes too hot internally, the heating element switches Off automatically. As soon as it has cooled down, the heating element switches back On.

WARNING

As a general rule, there is a reason for overheating! It can mean a risk of fire!

• Check if the convection heater can dissipate the heat generated: is it covered or too close to a wall or other obstacle? Is the fan blocked?
• Check that neither the air inlet (5.) nor the air outlet (3.) are blocked and remove the cause.
• If possible, eliminate the problem or contact the Customer Support Service
• Even if you cannot find the problem's source, but the overheating protection is triggered again, return the appliance to the Customer Support Service for inspection or repair.

[you can trust]

2.3. Maintenance

CAUTION

Possible damage to the convection heater

Moisture can damage the convection heater.

• To avoid irreparable damage to the convection heater, ensure that no moisture gets into it during cleaning.
• Never immerse the convection heater in water and protect it from splashing or sprayed water.
• Clean the housing only with a soft damp cloth and a mild detergent.
• Remove dust deposits on the protective screen with a vacuum cleaner.

Transport and storage

• Always carry the convection heater by its handles (9.).

- Disconnect the mains power plug if you do not intend to use the appliance for an extended period of time.

- Store the appliance in a dry environment.

2.4. Troubleshooting

This section contains important information about fault identification and rectification.

WARNING

Observe the following safety information to avoid hazards and property damage:

- Repairs to electrical appliances should only be carried out by Customer Support Service. Improper repairs can cause considerable risks to users and damage to the appliance.

BECKEN

Fault causes and rectification

The following table will help you identify and rectify minor malfunctions:

Malfunction Possible cause Remedy
The appliance will not switch on.	The plug is not connected.The mains power socket is not supplying power.	The plug is not connected.The mains power socket is not supplying power.Put the power plug into the socket.Check the house mains fuse.
The appliance switches itself off automatically.	The overheating protection has been triggered.The selected temperature has been reached.	Allow the appliance to cool down.Clean the appliance.The appliance switches itself back on automatically as soon as the room temperature falls.Select a higher target temperature

NOTE

- If you are unable to resolve the problem by taking any of the aforementioned steps, please contact the Customer Support Service.

[you can trust]

3. TECHNICAL SPECIFICATIONS

General

Input voltage: 220-240 V \~

Mains voltage frequency: 50 Hz

Maximum output: 230 W

Humidity (no condensation): 5 to 85 %

Dimensions including feet (W x D x H): approx. 69 x 43 x 22 cm

Weight: approx. 4.8 kg

4. POST-SALE SERVICE

BECKEN has designed this appliance in order to guarantee maximum reliability. However, if a problem occurs do not attempt to open the appliance - there is a risk of electrical shock. If you are not able to solve the problem, please contact the Customer Support Service of any Worten, Modelo or Continente store in order to be assisted. Worten Equipamentos para o Lar provides a 2-year warranty for manufacturing defects from the date of purchase of the appliance.

WARNING: any attempt to repair the appliance without contacting the manufacturer or seller will void the warranty.

All users must be familiar with these instructions. Knowing what could go wrong can help prevent problems from occurring.

5. ENVIRONMENTAL PROTECTION

In order to protect the environment, we strive to reduce the volume of packaging used, limiting it to three easily sorted materials: cardboard, paper and plastic.

The appliance is manufactured using recyclable materials after disassembled by a specialized company. Please comply with local regulations concerning the recycling of all materials.

Symbol of a trash bin crossed with no text or labels

Convector Heater | Convector | Convector

Estimado cliente:

Convector Heater | Convector | Convector

BECKEN

Convector Heater | Convector | Convector

BECKEN

Convector Heater | Convector | Convector

BECKEN

Convector Heater | Convector | Convector

BECKEN

Convector Heater | Convector | Convector

BECKEN

Convector Heater | Convector | Convector

BECKEN

Symbol of a trash bin crossed with no text or labels

Convector Heater | Convector | Convector

Caro(a) cliente,

Convector Heater | Convector | Convector

BECKEN

1. INSTRUÇÕES DE SEGURANÇA

Convector Heater | Convector | Convector

BECKEN

Convector Heater | Convector | Convector

BECKEN

Convector Heater | Convector | Convector

BECKEN

Instalação

ATENÇÃO

Convector Heater | Convector | Convector

BECKEN

Symbol of a trash bin crossed with no text or numbers, representing waste sorting or disposal (no text present)

Convector Heater | Convector | Convector

BECKEN

Imported, produced and distributed by:

Worten Equipamentos p/o Lar S.A.
