| Product Type | Rotary Laser Level |
| Model | 5R |
| Brand | PLS |
| Laser Class | Class II (visible red laser, <1mW) |
| Self-Leveling Range | ±5° |
| Accuracy | ±1/8 inch at 100 ft (3mm at 30m) |
| Range (with detector) | Up to 800 ft (244 m) diameter |
| Rotation Speed | 600 RPM |
| Battery Type | 4 x AA alkaline or rechargeable |
| Battery Life | Approximately 30 hours (alkaline) |
| Power Source | Battery operated (4x AA) |
| Dimensions (H x D) | 6.5 x 6.5 x 7.5 inches (16.5 x 16.5 x 19 cm) |
| Weight (with batteries) | 3.2 lbs (1.45 kg) |
| Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Water Resistance | IP54 (dust and splash resistant) |
| Mounting Thread | 5/8-11 female |
| Scan Mode | Variable (adjustable width and speed) |
| Slope Capability | Dual axis slope (manual adjustment) |
| Included Accessories | Hard carrying case, laser detector, rod clamp, alkaline batteries, user manual |
| Recommended Maintenance | Clean lens with soft cloth; store in case when not in use |
| Warranty | Limited lifetime |
Frequently Asked Questions - 5R PLS
How do I turn on the PLS 5R laser level?
Press the power button located on the top of the unit. The laser will begin rotating and self-leveling automatically.
What batteries does the 5R use and how long do they last?
The 5R uses four AA batteries (alkaline recommended). Typical battery life is approximately 30 hours of continuous use.
Can the PLS 5R be used outdoors?
Yes, but its range may be reduced in bright sunlight. Using the included laser detector extends range up to 800 ft in outdoor conditions.
How do I calibrate the level?
The 5R features self-leveling within ±5°. For manual calibration or slope mode, refer to the user manual for specific steps.
What does the blinking light mean?
A blinking red light usually indicates the unit is out of level range or the batteries are low. Check the leveling feet and battery status.
Is the PLS 5R waterproof?
It is IP54 rated, meaning it is dust protected and resistant to splashing water, but not submersible. Avoid heavy rain.
How do I clean the laser lens?
Use a soft, dry cloth or a lens cleaning wipe. Do not use solvents or abrasive materials to avoid scratching the lens.
Can I use rechargeable batteries?
Yes, rechargeable NiMH AA batteries can be used. Note that battery life may be shorter than alkaline.
What is the warranty on the PLS 5R?
PLS offers a limited lifetime warranty against defects in materials and workmanship. Registration may be required.
How do I mount the laser on a tripod?
The base has a 5/8-11 female thread, compatible with most survey tripods. Screw the base directly onto the tripod head.
