| Product Type | Industrial Managed Switch |
| Model | 852-1605 |
| Ports | 8 x 10/100/1000BASE-T (RJ-45) + 4 x 1000BASE-SX/LX (SFP) |
| Dimensions (W x H x D) | 50 mm x 162 mm x 120 mm |
| Weight | 945 g |
| Protection Class | IP30 |
| Power Supply | 12 … 60 VDC, redundant (PWR/RPS) |
| Power Consumption (max.) | 18 W |
| Operating Temperature | -40 °C … +70 °C |
| Storage Temperature | -40 °C … +80 °C |
| Relative Humidity | 10 … 95 % (non-condensing) |
| Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1d, 802.1w, 802.1s, 802.1Q, 802.1p, 802.1ab, PROFINET CC-B |
| MAC Table Size | Up to 16,000 addresses |
| VLAN Support | Port-based and tag-based (4094 VIDs) |
| Jumbo Frame Size | 10240 bytes |
| Management Interfaces | CLI (console port, Telnet, SSH), Web-Based Management (WBM), SNMP v1/v2c/v3 |
| Redundancy | MRP (Media Redundancy Protocol), STP/RSTP/MSTP |
| Security Features | ACL, port-based MAC authentication, SNMPv3, SSH, Web authentication |
| Mounting | DIN rail (35 mm) |
| Scope of Delivery | Switch, protective covers for unused ports, RS-232 data cable for CLI |
| Maintenance and Cleaning | Clean housing and contacts with propanol; no contact spray; replace defective device |
| Repairability and Spare Parts | No user-serviceable parts; contact WAGO for repairs; SFP modules available separately |
| General Information | PROFINET IO device (CC-B), GSDML file included, supports Autonegotiation and Autocrossing on copper ports |
