MOD-16 - Vacuum Cleaner MPM - Free user manual and instructions

Product type	Compact canister vacuum cleaner
Brand	MPM
Model	MOD-16
Dust bag capacity	2.0 L
Power cord length	5.0 m
Reach	8 m
Filtration system	Motor filter and outlet filter (washable)
Suction power control	Slider on hose handle
Attachments	Floor-carpet attachment with brush mode, slit attachment with movable brush
Number of suction pipes	2 (extension pipes)
Dust bag indicator	Visual red indicator
Cord winder	Automatic with button
Carrying handles	Upper handle and lower groove handle
Storage	Guide for floor-carpet attachment; vertical storage possible
Safety features	Automatic shut-off (overheating), child safety (keep away from children under 8)
Usage environment	Indoor, dry surfaces only
Disposal	WEEE compliant – do not dispose with household waste

Frequently Asked Questions - MOD-16 MPM

How do I assemble the vacuum cleaner?

Attach the suction hose mounting ring to the connection opening and turn clockwise. Connect the suction pipes to the hose handle, then attach the desired nozzle. Ensure all connections are secure.

How do I replace the dust bag?

Unplug the vacuum cleaner. Press the upper cover button to open. Slide out the old bag holding the flange upward. Insert a new bag and close the cover securely.

How often should I clean or replace the filters?

Clean the motor and outlet filters every month or more frequently if heavily soiled. Wash with cool water and mild detergent, then dry completely before reinstalling. Replace if damaged.

What should I do if the suction power is low?

Check if the dust bag is full – replace if needed. Inspect the hose and pipes for blockages. Clean or replace filters. Also ensure the suction control slider is open.

Why does the vacuum cleaner overheat?

A slight temperature increase is normal, but if excessive, turn off immediately. Overheating can be caused by blocked filters or a full dust bag. Clean filters and replace bag, then restart if cool. If persists, contact service.

How do I use the floor-carpet attachment for hard floors?

The floor-carpet attachment has a brush mode. Press the button on top to extend bristles for hard floors. For carpets, retract the bristles. The flexible joint allows easy maneuvering.

Is the vacuum cleaner safe for use around children?

This appliance is not intended for use by children under 8 years. Supervise children near the vacuum. Store the appliance and cord out of reach of children under 8. Never let children play with plastic bags.

How do I wind the power cord?

Hold the cord with one hand and press the cord winder button with the other. Guide the cord to rewind slowly to avoid damage. Do not pull the cord beyond the red mark.

What can I vacuum with this cleaner?

This vacuum is designed for dry surfaces only. Do not collect flammable liquids, ashes, sharp objects, or anything wet. Use only on indoor floors and carpets.

How do I dispose of the vacuum cleaner at the end of its life?

Do not dispose with household waste. Take it to a designated WEEE collection point or contact your retailer for proper recycling. This helps protect the environment.

USER MANUAL MOD-16 MPM

Black and white compact vacuum cleaner with coiled hose and green control buttons (no visible text or symbols)

ODKURZACZ

MOD-16

PL INSTRUKCJA OBSŁUGI....3

GB USER MANUAL 9

RU ИНСТРУКЦИЯ ПО ОБСЛУЖИВАНИЮ....15

ELEKTROSTATYKA

Read carefully this manual before using the appliance.

Always remove the plug from the power outlet when not used, or before cleaning the appliance.

Before the first use check if mains voltage conform with vacuum cleaner.

Do not hang the power cord over sharp edges and do not allow the power cord to touch hot surfaces.

Do not pull the cord to unplug the appliance.

Do not leave the operating vacuum cleaner unattended.

- Close supervision is necessary when using the appliance near children.

Do not allow the vacuum cleaner to go over the power cord in case it can damage its insulation.

Do not try to use the vacuum cleaner if you suspect any technical damage.

Do not use the appliance, also if the power cord or plug is damaged - return the appliance for repair to an authorized service centre.

To avoid the risk of damage, fire or injury, always use the attachments recommended by the manufacturer.

Take extreme caution when cleaning the stairs.

Do not immerse the appliance, its cord and plug in water or any other liquids, keep it dry at all times.

Do not use the vacuum cleaner to collect flammable and corrosive liquids, solvents, matches, ash, cigarette ends, oil, sharp items etc. It can cause damage or even fire! Do not vacuum-clean near flammable liquids and substances!

Because of the vacuum cleaner plastic housing keep the appliance away from any heat sources (heaters, stoves etc.)

Do not cover the vacuum cleaner outlet and inlet!

This vacuum cleaner is designed for domestic use only.

This appliance is not intended for use by children under 8 years of age and individuals with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved. Cleaning and user maintenance shall not be carried out by children without supervision.

Children should be supervised to ensure that they do not play with the appliance.

- Store the appliance and its cord out of reach of children under 8 years of age.

Do not vacuum-clean people or animals, take special care not to move suction nozzles near eyes and ears.

Turn off and disconnect the appliance from supply circuit before replacing accessories.

Do not vacuum without bag, filters and in case of damage.

Check the hose, wand and suction nozzles and remove any litter from them.

Use the vacuum cleaner only indoors and on dry surfaces. Dry the washed carpets before vacuum-cleaning.

WARNING! Never let children play with plastic film or bags. Choking/asphyxiation hazard!

APPLIANCE OVERVIEW

1. On/off switch
2. Cord winder button
3. Guide
4. Dust bag filling indicator
5. Upper cover
6. Upper cover opening button
7. Suction hose connection opening
8. Carrying handle
9. Vertical carrying handle
10. Power cord
11. Outlet filter
12. Dust bag (2.0 l)
13. Wheels
14. Suction pipes (2 pcs.)
15. Suction hose mounting ring
16. Suction hose handle
17. Suction hose
18. Suction power control
19. Floor-carpet attachment
20. Slit attachment with movable brush
21. Motor filter

STATIC ELECTRICITY

Vacuum cleaning certain surfaces at a low air humidity may cause slight electrification of the appliance. This is natural, does not damage the appliance and does not constitute its defect. To minimise this phenomenon, it is recommended to:

• frequently discharge the appliance by touching items in the room with the metal pipe,
  increase air humidity in the room,
  use generally available anti-electrostatic products.

APPLIANCE ASSEMBLY

1. Place the suction hose mounting ring ⑮ in the connection opening ⑦ and then gently turn the ring clockwise. To disassemble those elements, gently turn the ring counter-clockwise and remove the suction hose from the vacuum cleaner opening.
2. Connect the suction pipe ⑭ to the handle ⑯ on the other side of the suction hose ⑰ Finally, attach a suction attachment or add another pipe ⑱ and then attach the suitable suction attachment to it.

USING THE APPLIANCE

1. Before turning on the vacuum cleaner, unwind the power cord ⑩ to a suitable length and plug it into the mains socket. The yellow mark on the power cord indicates the optimum length. Do not pull out the cord beyond the red mark! While unwinding the cord, do not press the cord winder button ②.
2. Press the switch ① to turn on the vacuum cleaner.
3. To wind the power cord, press the cord winder button ② with one hand, while holding the cord with another hand to prevent a sudden movement that could damage it.

Caution! If the suction pipe is blocked or the dust bag is full, the bag filling mark turns red. Then replace the dust bag or remove the cause of suction pipe blocking. Suction power can be adjusted with the suction power control slider 13. Move the slider slightly to reduce the suction power.

1. To ensure optimum appliance setting upon the completion of work, use the guide ③ in the rear of the vacuum cleaner. Place the rail in the rear of the floor-carpet attachment with connected suction hose and telescopic pipe on the guide. The second guide that facilitates vacuum cleaner storage in the vertical position is under the bottom of the appliance. To facilitate moving, the appliance is equipped with two handles. One handle ⑧ is in the upper part of the vacuum cleaner, while the second handle ⑨ is the housing groove below the suction hose connection opening.

ACCESSORIES OVERVIEW:

FLOOR-CARPET ATTACHMENT

Designed for cleaning large flat surfaces. It is equipped with castors that facilitate movement in difficult to access places and a flexible joint, connecting it with the suction hose, which allows directing at various angles. When you press the button on the upper attachment housing (switch it to the brush mode), a row of rigid bristles will appear on the bottom to facilitate cleaning hard floors.

SLIT ATTACHMENT WITH MOVABLE BRUSH

Used for cleaning difficult to access areas, such as in room corners, by and below pieces of furniture and in bends and slits. It is also perfect for cleaning computer keyboards, drawers, radiators or window frames.

REPLACING THE DUST BAG

To replace the dust bag, disconnect the appliance from the power supply, detach the suction hose ⑰, press the button ⑥ to open the upper cover ⑤, slide out the dust bag, while holding the flange with the inlet opening directed upwards. Install new dust bag.

AIR FILTER CLEANING AND REPLACEMENT

Normal use of the vacuum cleaner requires periodical replacement or cleaning of the air filter, which protects the motor from the side of the dust bag, and the air outlet filter. For this purpose, disconnect the appliance from the power supply and detach the suction pipe.

1. Remove the outlet filter ⑪ from the vacuum cleaner by pressing the lock button on the filter housing and then remove the filter cartridge from its housing.
2. Remove the motor filter 21 To access the filter, raise the vacuum cleaner cover 5 and remove the dust bag 12. Remove the motor filter 21 by lifting it upwards and then pull its cartridge out of the housing.
3. Wash both filter cartridges under running and cool water. For thorough washing, add a small amount of the detergent. Dry the filters thoroughly after washing.
4. Cartridges should be cleaned every month or more frequently (depending on the usage). If a cartridge is too contaminated or damaged, replace it with a new one.
5. While mounting cartridges, pay special attention to the proper position of the cartridge in the filter housing and the filter housing in the vacuum cleaner.

CAUTION: The filter cartridge being mounted must be completely dry. Mounting a wet filter may cause an electric shock.

CLEANING AND MAINTENANCE

1. Periodically clean the vacuum cleaner housing and other external elements with a damp cloth. This will allow maintaining good appearance of the appliance.

2. For this purpose, do not use sharp objects or any strong detergents (e.g. solvents), as this will cause permanent damage to the vacuum cleaner housing.

3. For air filters and dust bag, follow the above instructions.

IN CASE OF FAILURE

Failure type: Possible causes: Instructions:
front cover not thoroughly closed	dust bag not attached or attached improperly	attach the dust bag properly
vacuum cleaner housing overheating	a slight housing temperature increase is normal, but if the temperature increases considerably, immediately turn off the vacuum cleaner and contact the service
	strongly contaminated filters clean or replace the filters
low suction power	full dust bag replace the dust bag or empty the textilebag
	blocked hose or extension pipe remove all items blocking the hose or pipe

Technical parameters are indicated on the product nameplate.

Length of power cord: 5.0 m

Reach of vacuum cleaner: 8 m

Note! MPM agd S.A. reserves its right to modify the technical data.

PROPER DISPOSAL OF THE PRODUCT (waste electrical and electronic equipment)

Poland

This symbol on the product indicates that the product, after its lifetime, should not be disposed with other household wastes. To avoid harmful influence on the environment and human health due to uncontrolled waste disposal, dispose the waste device to the service point of waste household appliances or report collecting it from home. In order to obtain detailed information about the location and how to dispose the waste electrical and electronic equipment in a safe way, contact your retailer or local Department of

Environmental Protection. Do not dispose the device with other municipal waste

ЭЛЕКТРОСТАТИКА

ELEKTROSTATIK

We wish you satisfaction from using the product and invite you to check a wide range of other MPM appliances
