Hamburg - Suitcase PRINCESS - Free user manual and instructions

Product Type	Suitcase with built-in scale and removable charger
Brand	Princess
Model	Hamburg
Maximum Load (Scale)	10 kg (S), 15 kg (M), 20 kg (L)
Scale Tolerance	±2.5 kg
Scale Display Units	kg and lbs (toggle via KG/LBS button)
Battery Type	CR2032 (A-brand only)
Battery Location	Rear side of scale, inside suitcase
Lock Type	3-digit combination lock (pull or push style)
Charger	Removable power box unit, stored inside suitcase
Charger Removal	Open inner zipper, cut zip tie (first use), slide out unit
Sliding Cover Lock	Lock cover after charger removal to prevent tampering
Usage Instructions	Place on flat surface, press ON/OFF, lift by side handle, read weight
Safety Precautions	Do not expose to rain or humidity; use only CR2032 batteries
Maintenance	Replace battery if scale unresponsive or display shows 'LO'
Manual Languages	English (PDF download available)

Frequently Asked Questions - Hamburg PRINCESS

How do I set the combination lock on my Princess Hamburg suitcase?

For a pull lock: ensure lock is at 0-0-0, press button A in direction of arrow, hold, rotate wheels B to your 3-digit code, release button. For a push lock: same steps but press button A in arrow direction. Do not release button while setting code.

How do I use the built-in scale?

Place the suitcase on a flat surface with the LCD screen facing up. Press ON/OFF. When '0' appears, lift the suitcase by the side handle and hold still. The weight displays after a few seconds. Press ON/OFF to turn off.

How do I switch between kilograms and pounds?

Press the KG/LBS button to toggle the display between kilograms (kg) and pounds (lbs).

What battery does the scale use and how do I replace it?

Use only CR2032 batteries. The battery compartment is on the rear side of the scale (inside the suitcase). Slide open the cover, replace the battery observing polarity, and close.

The scale shows 'LO' or does not turn on. What should I do?

The battery is low or dead. Replace with a new CR2032 battery. If still unresponsive, check battery contacts or contact support.

How do I remove the charger from the suitcase?

Open the inner zipper. On first use, cut the zip tie. Pull up the lid and slide out the charger unit. Then close and lock the sliding cover to prevent unauthorized access.

What is the maximum weight the scale can measure?

The maximum load depends on suitcase size: 10 kg for size S, 15 kg for size M, 20 kg for size L. Tolerance is ±2.5 kg.

Can I use the scale in wet conditions?

No. Never expose the suitcase to rain or humidity as it may damage the scale. Keep dry.

How do I lock the sliding cover after removing the charger?

Slide the cover closed and engage the lock mechanism. This prevents anyone from placing items in your suitcase without your knowledge.

Is the charger removable for use as a separate unit?

Yes, the charger is designed to be removable and can be used independently. Follow the removal instructions and store safely.

USER MANUAL Hamburg PRINCESS

Here you can find our instruction manuals.

Below is an overview of our most common instructions for use.

If you don't see the manual you're looking for, don't worry! Let us know via our contact page and one of our colleagues will contact you as soon as possible.

PULL LOCK INSTRUCTIONS

• The lock is set to 0-0-0
• Press the A button in the direction of the arrow
• While holding in the button, choose your 3-digit code by turning the wheels (B)
• Release the button to set your code
• Make sure that you do not release the button while setting the code

PUSH LOCK INSTRUCTIONS

• The lock is set to 0-0-0
• Press the A button in the direction of the arrow
• While holding in the button, choose your 3-digit code by turning the wheels (B)
• Release the button to set your code
• Make sure that you do not release the button while setting the code

SUITCASE WITH A BUILT-IN SCALE

Note: Please read these instructions carefully. Observe the instructions for safe use.

Use the product with care and for the purpose for which it is intended.

Failure to do so may cause the wrong weight to display or potentially cause damage. Store these instructions for future use.

1) SAFETY INSTRUCTIONS

• Never expose the suitcase to rain or humidity. This may cause damage to the scale.
• Only use A-brand CR2032 batteries.

2) SPECIFICATIONS

• Maximum load for suitcases in size S/M/L 10/15/20 kg
- Tolerance ± 2.5kg
- Unit on display kg, lbs

3) INSTRUCTIONS FOR USE

• Place the luggage on a flat surface, with the LCD scale screen facing upwards.
• Press the button marked 'ON/OFF'.
• Once the number zero (0) is displayed on the LCD screen, lift the suitcase by the side handle. Hold the suitcase still for a few seconds.
• The total weight of the luggage will be displayed on the LCD screen.
• Switch off the scale by pressing the 'ON/OFF' button again.
• By pressing the button marked 'KG/LBS', the LCD display will toggle between kilograms and pounds.

4) MAINTENANCE

Check and replace the battery if the scale does not respond to the 'ON/OFF' button, or the display reads 'LO'.

The battery is located on the rear side of the scale, i.e. on the inside of the suitcase. Here you will find a cover.

Slide it open to replace the battery. Pay attention to the positive/negative pole markings.

Diagram of a hand pressing down on a mechanical component with arrows indicating motion (no text or symbols)

Illustration of a suitcase with upward arrows indicating motion or movement (no text or symbols)

POWER BOXPOWER BOX

The charger is removable and can also be used as a separate unit.

REMOVING THE CHARGER

Open the zipper inside the suitcase. When using it for the first time, cut off the zip tie.

Pull up the lid and slide out the charger-unit. Close and lock the sliding cover.

Three technical line drawings of a mechanical housing component with cutouts and mounting holes, shown from different angles (no text or symbols present)

PLACING THE CHARGER

Three technical line drawings of a remote control casing (no text or symbols)

LOCKING THE CHARGER

Once you have removed the charger, lock the sliding cover. This will prevent somebody from placing something in your suitcase without you noticing.

Top-down schematic of a device casing with mounting holes and a central internal component (no text or symbols)

TRAVEL LIKE A ROYAL
