Product Type	Camping Tent (Lightweight, Cat. A)
Brand	Crivit
Model	IAN 106598
Capacity	3 Persons
Dimensions (Vestibule + L x W x H)	110 + 240 x 210 x 150 cm
Water Column	2000 mm
Pole Material	Fiberglass
Tent Material	Breathable Polyester, Net, PE
Performance Grade	Grade 2 (Mild Weather)
Scope of Delivery	Inner Tent, Outer Tent, 2 Black Poles, 1 Grey Pole, 20 Tent Pegs, Pole Bag, Peg Bag, Packsack, Storage Net, Assembly Instructions
Assembly	Test assembly recommended before trip; spread inner tent, fix corners, assemble poles diagonally, secure with clips, add outer tent, guy ropes
Safety Instructions	No open flames inside, keep ventilation open, do not erect under trees, avoid storms and snow
Condensation	Normal; reduce by good ventilation
Care & Cleaning	Brush dry dirt, clean with water only; no chemical cleaners; seal seams occasionally
Storage	Dry place out of direct sunlight; remove from packsack for long-term storage
Disposal	Separate materials, environmentally friendly disposal
Warranty	3 years from date of purchase
Service GB	Tel: [phone] (£0.10/min), Email: [e-mail]
Service IE	Tel: [phone] (€0.08/min peak, €0.06/min off-peak), Email: [e-mail]

Frequently Asked Questions - IAN 106598 CRIVIT

How many people can the tent accommodate?

The tent is designed for up to 3 persons.

What is the water column rating?

The tent has a water column of 2000 mm, suitable for mild rain conditions.

Can I use the tent in snow or storms?

No, this tent is not designed for extreme weather such as snow or storms. It is intended for mild weather conditions only.

How do I reduce condensation inside the tent?

Condensation is normal. Ensure good ventilation by keeping openings clear to reduce moisture buildup.

How should I clean the tent?

Brush off dry dirt and rinse with clean water only. Do not use chemical cleaning products. Seal seams occasionally with a commercial seam sealer.

Can I cook inside the tent?

No, never use open flames or cook inside the tent due to fire risk and toxic fumes. Cook outside only.

How is the tent assembled?

Spread the inner tent, fix corners with pegs. Assemble the two black poles and insert diagonally through loops. Secure with clips. Add the outer tent and grey pole. Secure with pegs and guy ropes. See manual for detailed steps.

How should I store the tent when not in use?

Store in a dry place away from direct sunlight. For long-term storage, remove from the packsack to prevent mildew.

What is the warranty period?

The tent comes with a 3-year warranty from the date of purchase, covering material and workmanship.

How can I repair small tears or holes?

Use a repair kit from a specialist shop for small tears. Replace broken tent poles immediately.

USER MANUAL IAN 106598 CRIVIT

Exterior view of a modern camping tent with a dome-shaped roof and visible interior space (no signage or text)

Double-Roof TenT

G

Before reading, told out the illustration page and get to know all of the functions of your unit.

M M D

Assembly instructions

DE AT CH

Iglu-DoppelDachzeit

Aufbauanleitung

GS/IE Instructions and Safety Notice Page 06

Completely blank white image with no visible content, text, or symbols.

GB IE

Scope of Delivery 6

Technical data 6

Intended use 6

Safety instructions 6-7

Assembly 7

Disassembly 7-8

Maintenance 8

Care 8

Storage 8

Notes for disposal 8

3 years warranty 8

DE AT CH

Lieferumfang 9

Technische Daten 9

With your purchase you have decided on a high-quality product. Get to know the product before you start to use it. Carefully read the following assembly instructions. Use the product only as described and only for the given areas of application. Keep these instructions safe. When passing the product on to a third party, always make sure that the documentation is included.

Scope of Delivery (Fig. A)

(1) - Inner tent 1 x
(2) - Outer tent sheet 1 x
(3) - Tent poles, blac 2 x
(4) - Tent poles, grey 1 x
(5) - Tent pole bag 1 x
(6) - Tent pegs 20 x
(7) - Tent peg bag 1 x
(8) - Packsack 1 x
(9) - Storage net 1 x

Assembly instructions 1 x

Technical data

Material: Fibreglass poles, breathable polyester / net / PE

Water column: 2000mm

Size: 110 + 240 × 210 × 150cm

(vestibule + L x W x H)

Category: Cat. A Camping tent (lightweight) Performance grade: Grade 2 - Tent for use in generally mild weather conditions. Not designed for extreme and mountain use.

Intended use

This product serves as an outdoor sleeping and living space. It is suitable for three persons. The product is not designed for use in snow or storms.

Safety instructions

Risk of injury!

WARNING!

Risk of suffocation for children!

Do not leave your children unattended near a tent that is not erected, or let them play with the tent. There is the risk that children may suffocate when playing with the tent material.

WARNING!

Do not use an open flame in the tent and never use benzine or gas lamps due to the dangerous fumes. Cook outside the tent.

Safety precautions for fire and ventilation

Caution:

• When using gas or other flammable appliances, additional ventilation is necessary;
• Do not place any hot appliances near to the walls, ceiling or curtains;
  • Always observe the safety instructions for these devices;
• Never allow children to play near to hot appliances;
• Keep the exit clear;
• Ensure that you know the provisions for fire on the premises;
• Ensure that the ventilation openings are always open, in order to avoid suffocation.

WARNING!

Risk to life from lightening!

Do not erect the tent directly under trees.

During thunderstorms there is the risk of lightning strikes, which can set the tent or tree on fire or cause the tree to fall.

- Do not camp in snow and storms, and consider different and changing weather and wind conditions.

Avoid damage to property!

• Do not erect the tent so that the tent entrance is in the direction of the wind. Wind could damage the tent.
• All the tent materials suffer material fatigue and bleaching if they are exposed to prolonged, strong sunlight. For this reason, when the tent is to be used over longer periods, erect it in a shady position. Do not leave the tent assembled unnecessarily.

Assembly

NOTE!

Perform a test assembly before the camping trip. In doing so, ensure that all the accessories are present.

Selecting a location for placing the tent

Choose a place that is as flat and clean as possible. Avoid dips in the ground. Remove stones, branches and other sharp objects in order to prevent damage to the tent floor. Use natural shade, such as hedges, rocks, etc. Use the appropriate pegs for sandy ground in order to prevent accidental loosening of the tension.

NOTE!

Insert the pegs into the ground at a slight angle to achieve good strength but without causing tension in the tent surface. The tent material and tension points should only be slightly taut, so that it can compensate for pressure from the wind. Ensure that there is not too much pressure on the tent. Check the tent tension according to weather condition.

NOTE!

Water condensation occurs basically in every tent, however particularly during strong fluctuations in temperature. After a night in the tent, there will be drops of condensation on the inner wall. Condensation is not evidence of leakiness. Good ventilation reduces condensation in the tent.

1. Spread the base of the inner tent flat on the ground, close the zips for the entrance and fix the loops at all four corners with the pegs (Fig. B).
2. Build together the segments of the tent poles (3) and (4). Slide the two black tent poles (3) diagonally through the loops in the middle of the inner tent (Fig. C). Secure the inner tent on the tent poles using the clips (Fig. D).
3. Turn the tent around and insert the metal pins at the corners of the inner tent into the end of the tent poles so that these are under tension (Fig. E).
4. The storage net (9) can now be hooked onto the roof ridge in the interior of the inner tent (Fig. F).
5. Place the outer tent over the inner tent (Fig. G). Secure the outer tent using the bands to the tent poles and at the crossing point in the frame. Push the grey tent poles (4) through the frame tunnel in the outer tent (Fig. H). Right the frame up and insert the metal pins from the corners of the inner tent into the end of the tent poles. Secure the outer tent with 10 pegs and ensure that the loops at the four corners are fixed with the pegs of the inner tent (Fig. I).
6. Secure each of the 6 guy ropes with a peg. The length of the guy ropes can be adjusted with the tensioner (Fig. J).

Disassembly

NOTE!

Disassemble the tent, if possible, when clean and dry to prevent the formation of mould and mildew. After disassembling in rain, immediately dry the tent. Clean all the parts thoroughly before packing them away.

• Remove the pegs and guy ropes.
• Remove the tent poles, fold them together and disassemble the inner and outer tents.

Folding scheme

• Fold the outer and inner tent into squares and adjust the sizes to match the maximum width of the packsack.
• Place the tent poles and pegs into the respective packaging.
• Place the inner tent onto the outer tent. Place the tent peg bag and tent pole bag in the middle of the inner tent and finally roll up the inner and outer tents.
• Place the tent, tent pole bag and tent peg bag in the packsack and close the zip.

Maintenance

In the case of small tears and holes, use a repair kit from a specialist shop. Immediately replace broken tent poles. Oil the zips a little if they become stiff.

Care

Brush dirt off the dry tent surface; if necessary treat with clean water. Do not use a chemical cleaning product. Seal the tent seams from time to time. For this, use a commercial seam sealer.

Five abstract geometric symbols arranged horizontally: three circles, two triangles, one square, and one cross (no text or labels)

Storage

Store the product in a dry place to prevent the mould and weather marks. If it is not used for a longer period, take the product out of the packsack and store it in a dry place out from direct sunlight.

Notes for disposal

Please dispose of the packaging and product separated according to materials and in an environmentally-friendly manner! Dispose of the product through an approved waste disposal firm or by using your local municipal administration. Observe the current applicable legislation.

3 years warranty

The product was produced with great care and under constant supervision. You receive a three-year warranty for this product from the date of purchase. Please retain your receipt.

The warranty applies only to material and workmanship and does not apply to misuse or improper handling. Your statutory rights, especially the warranty rights, are not affected by this warranty.

With regard to complaints, please contact the following service hotline or contact us by e-mail.

Our service employees will advise as to the subsequent procedure as quickly as possible. We will be personally available to discuss the situation with you.

Any repairs under the warranty, statutory guarantees or through goodwill do not extend the warranty period. This also applies to replaced and repaired parts. Repairs after the warranty are subject to a charge.

IAN: 106598

GB Service Great Britain

Tel.: [phone]

(£ 0.10/Min.)

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

(0,08 EUR/Min., (peak))

(0,06 EUR/Min., (off peak))

E-Mail: [e-mail]

All items are also available for purchase directly from our online shop: www.delta-sport.info
