IAN 293008 - Lighting Livarno Lux - Free user manual and instructions

Product type	LED table lamp
Brand	Livarno Lux
Model	IAN 293008
Supply voltage	220–240 V~, 50/60 Hz
Max rated power	40 W
Bulb type	LED incandescent, E27 base
Protection class	II
Dimensions (model 54808)	Concrete base: 9 x 9 cm, height 12.8 cm
Dimensions (model 54809)	Metal base diameter 10 cm, glass diameter 10 cm, glass height 20 cm
Cable length	160 cm
Use	Indoor, dry and enclosed spaces
Package contents	1 lamp, 1 LED bulb, assembly instructions, warranty card
Base materials	Concrete (model 54808) or metal (model 54809)
Warranty	3 years
After-sales service	EGLO France: [phone] / EGLO Belgium: [phone]
Recycling	Recyclable packaging, product to be disposed of according to local regulations

Frequently Asked Questions - IAN 293008 Livarno Lux

What type of bulb to use?

Use an LED incandescent bulb with E27 base, maximum power 40 W.

How to replace the bulb?

Unplug the lamp, let it cool for at least 15 minutes. Unscrew the bulb counterclockwise and screw in the new one clockwise.

Is the lamp dimmable?

No, the light intensity is not adjustable.

Can I use this lamp outdoors?

No, it is exclusively designed for indoor use in dry, enclosed spaces.

How to clean the lamp?

Unplug and let cool. Use a dry, lint-free cloth. Do not use harsh detergents and do not immerse in water.

What to do if the lamp does not turn on?

Check that the bulb is screwed in and the plug is connected. If the problem persists, test with another bulb or contact after-sales service.

Is there a risk of burns?

Yes, the bulb becomes very hot. Wait for it to cool before touching. Do not cover the lamp.

What is the warranty?

The warranty is 3 years from the date of purchase, covering material and manufacturing defects.

How to get instructions in another language?

On notice-facile.com, choose your language and provide your email to receive a translation.

Is the packaging recyclable?

Yes, the packaging is made of recyclable materials. Please sort it according to local guidelines.

USER MANUAL IAN 293008 Livarno Lux

Operation and Safety Notes

NL BE

LED-TAFELLAMP

Before reading, unfold both pages containing illustrations and familiarise yourself with all functions of the device.

FR BE

GB / IE Operation and Safety Notes Page 11

C

C

Intended use Page 12

Scope of delivery Page 12

Technical Data Page 12

Safety Page 13

Safety Notices......Page 13

Operation Page 14

Mounting the light....Page 14

Using the lamp Page 14

Inserting / replacing the bulb....Page 14

Maintenance and Cleaning......Page 14

Disposal Page 14

Declaration of Conformity Page 15

Warranty / Service centre Page 15

Warranty Page 15

Service address......Page 15

Warranty card....Page 16

List of pictograms used
	Read the instructions! Observe the warn	and safety notices!
[2420]	Safety instructionsInstructions for use		Accident hazard and risk of fatal injuryfor infants and children!
	This light is only suitable for indooruse in dry and enclosed spaces.		Warning! Risk of electric shock!
	Volt (AC) Warning - Hot surfaces!
	Hertz (mains frequency) Not dimmable
	Watt (effective power)		Dispose of the packaging and theproduct in an environmentally friendlymanner!
	Safety class II

LED Desk Lamp

Introduction

Congratulations on the purchase of your new product. You have chosen a high-quality product. Please be sure to care-

fully read all the instructions for use. Fold out the page with illustrations. These instructions are part of the product and contain important information on setup and handling. Always observe all safety instructions. Before using this product for the first time, verify that the correct voltage is present and that all parts are properly mounted. If you have any questions or are unsure about operating the product, please contact your distributor or the service centre. Please keep these instructions in a safe place and pass them on to third parties if necessary.

Intendeduse

This light is only suitable for indoor use in dry and enclosed spaces. This product is only intended for private house-

hold use.

- Scope of delivery

Check that all the parts are present and that the appliance is in perfect condition immediately after unpacking.

1 Table Lamp
1 LED filament light bulb
1 Operating instructions including warranty card

●TechnicalData

Item number: 54808

Operating voltage: 220–240 V\~ 50/60 Hz

Light bulb: LED filament light bulb, E27, 4W

Max. rated power.: 40 W

Protection class: II/☐

Dimensions:

Edge dimensions

(concrete base): 9 x 9 cm

Height

(concrete base): 12.8 cm

Mains lead length: 160 cm

Item number: 54809

Operating voltage: 220-240V\~50/60Hz

Light bulb: LED filament light bulb, E27, 4W

Max. rated power.: 40 W

Protection class: II/

Dimensions:

Metal base

diameter: 10 cm

Height (base): 7 cm

Glass diameter: 10 cm

Height (glass): 20 cm

Distributor:

Edi Light GmbH, Heiligkreuz 22, A-6136 Pill, www.edi-light.com

●Safety

Safety Notices

Damage due to failure to comply with these operating instructions will invalidate the warranty! We assume no liability for consequential damage! We assume no liability for property damage or personal injury due to improper handling or failure to observe the safety notices!

WARNING! RISK OF AC- CIDENT AND DANGER TO LIFE FOR INFANTS AND CHILDREN!

This device may be used by children aged 8 years and up, as well as by persons with reduced physical, sensory or mental capacities, or those lacking experience and / or knowledge, as long as they are supervised or instructed in the safe use of the device and they understand the associated risks. Do not allow children to play with the device. Cleaning and user maintenance must not be performed by children without supervision.

Do not leave the light or packaging material lying unattended. Plastic film or bags, plastic

parts, etc. can turn into dangerous toys for children.

Avoid the risk of fatal injury from electric shock

We assume no liability for property damage or personal injury due to improper handling or failure to observe the safety notices!
■ Never use the light if any defects have been identified.
■ Always check the lamp and the mains cable with the plug for any damage before connecting it to the mains.
- Ensure that the light does not come into contact with water or other liquids under any circumstances.
■ Never open any of the components of the electrical equipment or insert any objects into the same components. This will pose a risk of fatal injury from electric shock.
■ Touch only the insulated part of the plug when connecting to or disconnecting from the mains supply!
To prevent hazards, if the external flexible lead on this lamp is damaged it must be replaced by the manufacturer, its service representative or an equally qualified professional!
Before use, verify the available mains voltage matches the voltage required for operating the light (220–240V\~, 50/60Hz).

Preventing fire and injury hazards

CAUTION! RISK OF BURNS

DUE TO HOT SURFACES! Ensure

the light has been switched off and

has cooled down before touching it to avoid burns. Lamps become very hot.

• Check each bulb for damage immediately after unpacking.
• Replace defective bulbs with new ones immediately. Before replacing the bulb always remove the mains plug from the socket.
• Allow the lamp to cool for at least 15 minutes before replacing a defective bulb.

Do not cover the lamp with objects. Fire can result from excessive heat development.
■ Position the lamp so it is protected from moisture and dirt.
Never leave the light unattended whilst in operation. Excessive heat can result in a fire.
■ The LED light is not dimmable.

Do not look directly into the light source (lamp, LED, etc.). Do not look into the light source (lamp, LED, etc.) with an optical instrument (e.g. magnifier).

Operation

- Mounting the light

☐ Remove the packaging materials.
☐ If the illuminant is not yet installed, screw it clockwise into the socket.

Using the lamp

□ Completely unwrap the power cord.
☐ Insert the mains plug into the socket.
☐ Turn the light on and off with the on / off switch.

- Inserting / replacing the bulb

WARNING! RISK OF ELECTRIC SHOCK! Unplug the mains plug from the socket.

CAUTION! RISK OF BURNS DUE TO HOT SURFACES! Allow the light to cool down completely.

☐ Turn the defective bulb carefully anticlockwise out of the bulb socket.
☐ Use a clean, lint-free cloth to replace a bulb.
☐ Screw the lamp clockwise into the socket.
☐ Please refer to the chapter "Technical Data" to see which bulbs are required for the respective model.

● Maintenance and Cleaning

WARNING! RISK OF ELECTRIC SHOCK! Remove the mains plug from the socket before you clean the lamp.

WARNING! RISK OF ELECTRIC SHOCK! For electrical safety reasons do not clean the lamp with harsh deter-

gents and never immerse it in water.

CAUTION! RISK OF BURNS DUE TO HOT SURFACES! Allow the light to cool down completely.

• Do not use solvents such as petrol and the like, as they could damage the lamp.
  ☐ Only use a dry, lint-free cloth for cleaning.

●Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities. The Green Dot is not valid for Germany.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics / 20-22: paper and fibre-board/80-98: composite materials.

The product and packaging materials are recyclable, dispose of it separately for better waste treatment. The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening

hours can be obtained from your local authority.

● Declaration of Conformity

This product fulfils the requirements of the applicable European and national directives. The relevant declarations and documents are held by the manufacturer. This product meets the requirements of the German Equipment and Product Safety Act.

We reserve the right to make technical and visual changes to the product in the interest of product improvement. Typographical and printing errors excepted.

● Warranty / Service centre

Warranty

We provide a 3 year warranty from the date of purchase.

Our products are manufactured using modern production methods and are subject to precise quality control. We guarantee this product is of good quality. During the warranty period any defects in material or manufacture will be replaced free of charge In the event of an unexpected defect, please return the carefully packaged product to the service address specified.

The warranty does not extend to damage due to improper handling as well as wear items and consumables. These can be ordered from the telephone number listed for a charge.

Repairs not covered by the warranty (e.g. light bulb) may also be requested at cost from the service address listed.

The product will be repaired at the specified service location. Timely processing and return can only be ensured by sending the product directly to this address.

For additional product information, to order accessories or have a question about the service process, please contact our Customer Service Department at the telephone number specified. Please include

the item number (see Technical Data) when inquiring about the product.

Serviceaddress

Great Britain/Irland

EGLO UK Ltd.

Unit 12 Cirrus Park

Lower Farm Road

Moulton Park Industrial Estate

Northampton NN3 6UR

T: [phone]

E: [e-mail]

IAN 293008

Please have your receipt and item number (e.g. IAN 12345) ready as your proof of purchase when enquiring about the product.

Warrantycard

Return address:

Name / First name:

Country/Postal code/City/Street

address:

Phone:

Item number / Description:

Purchase date / Point of purchase:

Description of the defect:

Date / Signature:

Non-warranty cases:

Please return the unrepaired item, carriage paid.

Please provide pricing. Repair the product against charge.

NL-4906 AA OOSTERHOUT (NBR)

T: [phone]

E: [e-mail]

België

EGLO BELGIUM B.V.B.A.

Antwerpsesteenweg 247

B-2950 KAPELLEN

T: [phone]

E: [e-mail]

IAN 293008

EGLO ČESKO-MORAVSKÁ SVÍTIDLA SPOL. S.R.O.

Náchodská 2479/63

CZ-193 00 PRAHA 9 Horní Počernice

T: [phone]

E: [e-mail]

IAN 293008

(Edf. Best Point) 2° - 16A

San Fernando de Henares

E-28830 MADRID

T: [phone]

E: [e-mail]

IAN 293008
