Gulliver 10031991 - Kettle Klarstein - Free user manual and instructions

Product Type	Electric Kettle
Brand	Klarstein
Model	Gulliver 10031991
Power Supply	220-240V~ 50/60Hz
Power Consumption	1850-2200 W
Capacity	Approx. 1.7 L (estimated from standard size)
Temperature Settings	60°C, 70°C, 80°C, 90°C, 100°C (boil)
Keep Warm Function	Yes, after reaching selected temperature
Auto Shut-Off	Yes, when water boils or after keep warm cycle
Lid Type	Push-button opening; also fill via spout
Water Level Indicator	Yes, with Min (0.5L) and Max marks
Base Unit	360° rotational; cord storage underneath
Filter	Removable mesh strainer for clean pouring
Materials	Stainless steel heating plate (rust spots possible)
Safety Features	Boil-dry protection; auto shut-off if lid not closed
Cleaning	Wipe exterior; rinse interior; do not immerse
Decalcifying	Regularly with descaling agent (not boiled)
Usage Indoors Only	Yes
Item Number	10031990 / 10031991 (this model)

Frequently Asked Questions - Gulliver 10031991 Klarstein

How do I turn on the kettle to boil water?

To boil water, simply press the ON/OFF button on the right. The kettle will heat water to 100°C and automatically shut off. Do not press a temperature button.

How do I select a specific temperature like 70°C for tea?

Press one of the temperature buttons (60°C, 70°C, 80°C, 90°C). The kettle will heat to that temperature and then automatically stop. The indicator light will change from flashing to constant.

Does the kettle have a keep warm function?

Yes. First select a temperature (60-90°C), then press the left button to activate keep warm. The kettle will maintain that temperature until you cancel it by pressing the left button again.

What should I do if the kettle turns off before boiling?

This is usually due to limescale buildup. Run a decalcifying cycle using a descaling agent (follow product instructions). Do not boil the solution as it may foam.

Can I fill the kettle through the spout?

Yes, you can fill through the spout without opening the lid. Alternatively, press the button on the handle to open the lid for filling.

How do I clean the kettle?

Always unplug first. Do not immerse in water. Wipe the exterior with a damp cloth. Rinse the interior occasionally with clean water. Clean the mesh filter by lifting it out.

What is the minimum water level?

Fill at least 0.5 L to prevent dry boiling. The water level should be visible in the window and not exceed the MAX mark.

Why won't the kettle switch on?

After dry boiling (running with little or no water), let the kettle cool down for a few minutes. The thermal protector will reset, and it will work again.

Can children use this kettle?

Children aged 8 and above can use it under supervision. Keep the kettle and cord out of reach of children under 8. Cleaning should be done by children only if supervised.

What should I do if the kettle does not switch off?

Ensure the lid is closed and locks properly. Also check that the mesh filter is correctly inserted. The auto shut-off relies on steam detection.

USER MANUAL Gulliver 10031991 Klarstein

Symbol of a trash bin with crossed lines indicating no waste or restriction, and a solid black rectangle below (no text or labels)

Congratulations on purchasing this equipment. Please read this manual carefully and take care of the following hints on installation and use to avoid technical damages. Any failure caused by ignoring the items and cautions mentioned in the operation and installation instructions are not covered by our warranty and any liability.

CONTENTS

Technical Data 9

Safety Advice 10

Getting started 11

Using 12

Cleaning 12

Troubleshooting 13

Disposal Considerations 14

TECHNICAL DATA

Item number 10031990	10031991
Power supply 220 -240 V~ 50/60 Hz
Power consumption 1850	W - 2200 W

SAFETY ADVICE

Read the following instruction carefully before using the appliance for the first time.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Children should be supervised to ensure that they do not play with the appliance.
• The appliance may only be connected to a power supply whose voltage and frequency comply with the specifications on the rating plate!
  • Never use or pick up the appliance if

- The supply cord is damaged

- The housing is damaged

• he appliance must only be connected to an earthed socket.
- If necessary an extension cable suitable for 10A can be used.
- If the appliance or the supply cord is damaged, it must be replaced by the manufactory, its service agent or similarly qualified person, in order to avoid hazard.
- Iways place the appliance on a flat, level surface.
- he appliance must be switched off and the mains plug withdrawn before cleaning and maintenance.
- The appliance and accessories become hot during operation. Use only designated handles and knobs. Allow to cool down before cleaning or storage.
- The mains cable must not come into contact with any hot parts of the appliance.
- Do not immerse the appliance in water or any other liquid. Attention: If the kettle is overfilled there is a risk that the boiling water may spray out, which could scald or burn! Therefore never fill the kettle above the maximum marking.
• Never operate appliance with open lid.
- Do not use or place the appliance on a hot surface or near source of heat.
- Only use the kettle for heating water!
• The kettle can only be used with the stand provided.
• Appliance is for indoor use only.
- This appliance is intended for domestic use only. The manufacturer cannot accept any liability for possible damage caused by improper or incorrect use.
- This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in safe way and understand the hazards involved.
- Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.
- Keep the appliance and its cord out of reach of children less than 8 years.

GETTING STARTED

1. Before first use, rinse the inside and wipe the outside of the kettle with a damp cloth.
2. Press the button to open the lid, pour water into the kettle. It is also possible to fill the kettle through the spout, without opening the lid. Make sure water level is visible in the water level indicator, but not exceeding the MAX. mark.
3. Place the base unit on a firm and flat surface. Plug the mains plug into a wall socket. Excess cord can be wound into the bottom of the base unit.

USING

1. Fill at least 0.5 L to ensure that kettle will not be dry boiling quickly. Recommended temperature.

Recommended temperature:

• 60 °C for baby mixtures

• 70 °C for delicate teas(green/white)
  • 90 °C for instant coffee or soup
  • 100 °C for perfect black tea

• Close the lid and make sure that it snaps in correctly. Otherwise, the auto switch off function will not work reliably. Place the kettle on the bases correctly. The buzzer will buzz, all the buttons will be flashing once, If there is not any operation, all the button functions stand by

• To heating: press the respective temperature button to select temperature (60 °C/70 °C/80 °C/90 °C) you want and start heating immediately, the indication light of selected button will keep flashing. For boiling water (100 °C) just press the ON/OFF button on the right (without pressing a temperature button). Once the water temperature reaches the target temperature, the buzzer will buzz and the indication light will change to constant for 15s, the heater will automatic turn off. If there is not any operation in 15s, the indication light will turn off. Press selected button can cancel the heating program. Press other button will not stop the heating program but change the target temperature to new selected temperature.
• To keep warm press a temperature button to select temperature (60 °C/70 °C/80 °C/90 °C), you want and then press the button on the left to start keep warm program. Once the water temperature reaches the target temperature, the indication light of selected button will change from flashing to constant, and the machine will stop heating and start to keep warm. Pressing the left button can cancel the keep warm program.

CLEANING

1. Before cleaning, always unplug the appliance. Never rinse or immerse the kettle or base unit in water. Just wipe with a damp cloth, using no abrasive detergents. Occasionally rinse out the kettle with clean water.
2. To clean the mesh filter, grab the strainer insert and lift out.
3. Cleaning the heating plate- superficial spots of rust may appear on the base unit. Remove with a stainless steel cleaning agent.
4. Decalcifying is recommended regularly, depending on water hardness. Fill the kettle with water and decalcified according to decalcified product instructions. Do not boil the solution as it may foam over. Afterwards, rinse kettle thoroughly with fresh water.

TROUBLESHOOTING

Problem Possible cause Solution
The appliance switches off before boiling.	Too much lime scale at the heating element of the kettle.	Run the decalcifying procedure.
The appliance does not switch off.		Close lid until it locks. Insert the mesh filter correctly.
The appliance cannot be switched on.	After operating with little or no water, the appliance has not cooled down sufficiently.	Allow to cool a short time and try again.

DISPOSAL CONSIDERATIONS

Symbol of a waste bin with crossed lines indicating no waste, and a solid black rectangle below (no text or labels)

According to the European waste regulation 2012/19/EU this symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council or your household waste disposal service.

Your product contains batteries covered by the European Directive. 2006/66/EC, which cannot be disposed of with normal household waste. Please check local rules on separate collection of batteries. The correct disposal of batteries helps prevent potentially negative consequences on the environment and human health.

Declaration of Conformity

Producer: Chal-Tec GmbH, Wallstraße 16, 10179 Berlin, Germany

This product is conform to the following European Directives:

2011/65/EU (RoHS)

2014/30/EU (EMC)

2014/35/EU (LVD)
