Gulliver 10031990 - Kettle Klarstein - Free user manual and instructions

Brand	Klarstein
Model	Gulliver 10031990
Product Type	Electric Kettle
Capacity	1.7 L
Power Supply	220-240 V~ 50/60 Hz
Power Consumption	1850 - 2200 W
Temperature Settings	60 °C, 70 °C, 80 °C, 90 °C, 100 °C (boil)
Keep Warm Function	Yes, at selected temperature (60-90 °C)
Auto Shut-Off	Yes
Boil-Dry Protection	Yes
Cordless Operation	Yes, with power base
Cord Storage	Yes, excess cord can be wound under base
Removable Mesh Filter	Yes
Material	Stainless steel and plastic
Safety Features	Earthed socket required; not for children under 8 without supervision; do not immerse; use only with supplied stand
Cleaning	Wipe with damp cloth; do not immerse; decalcify regularly
Spare Parts / Repairability	Not user-serviceable; contact manufacturer or qualified person for repairs

Frequently Asked Questions - Gulliver 10031990 Klarstein

How do I use the kettle for the first time?

Before first use, rinse the inside and wipe the outside of the kettle with a damp cloth. Fill water through the open lid or spout, ensuring the level between MIN and MAX. Place on the base and plug in.

What temperature settings are available and what are they for?

The kettle has settings for 60°C (baby mixtures), 70°C (delicate teas like green/white), 80°C, 90°C (instant coffee or soup), and 100°C (boiling for black tea). Press the desired temperature button to start heating.

How does the keep warm function work?

Select a temperature (60-90°C) using the temperature buttons, then press the left keep warm button. The kettle will heat to that temperature and maintain it. Press the keep warm button again to cancel.

How do I clean the kettle?

Always unplug the kettle before cleaning. Never immerse it or the base in water. Wipe with a damp cloth and mild detergent. The mesh filter can be removed and rinsed separately.

How do I decalcify the kettle?

Decalcify regularly depending on water hardness. Fill with water and a decalcifying agent according to the product instructions. Do not boil the solution as it may foam; instead, let it sit. Then rinse thoroughly with fresh water.

What should I do if the kettle does not switch on?

If the kettle does not switch on after use with little or no water, it may have overheated. Allow it to cool down for a short time and try again. Ensure the lid is properly closed and the kettle is correctly placed on the base.

What should I do if the kettle does not switch off?

Check that the lid is fully closed until it locks. Also ensure the mesh filter is inserted correctly. If the problem persists, excessive limescale may require a decalcifying procedure.

Is the kettle safe for children?

Children aged 8 years and above can use the kettle under supervision. Younger children must be kept away from the appliance and cord. The kettle becomes hot during use; use only the handles and knobs.

Can I immerse the kettle in water for cleaning?

No, never immerse the kettle or its base in water or any other liquid. Only wipe with a damp cloth. Immersion can cause electric shock or damage.

What is the capacity of the kettle?

The kettle has a capacity of approximately 1.7 liters. Always fill between the MIN (0.5 L) and MAX markings to avoid overfilling or dry boiling.

USER MANUAL Gulliver 10031990 Klarstein

KLARSTEIN NIEI SRA T TEIN NIEI SRA T K LAR KLARSTEIN NIEI SRA T TEIN NIEI SRA T K LAR KLARSTEIN NIEI SRA T TEIN NIEI SRA T K LAR KLARSTEIN NIEI SRA T

KLARSTEIN

Gulliver

Wasserkocher

Electrical Kettle

Symbol of a trash bin with crossed lines indicating no waste or restriction, and a solid black rectangle below (no text or labels)

Congratulations on purchasing this equipment. Please read this manual carefully and take care of the following hints on installation and use to avoid technical damages. Any failure caused by ignoring the items and cautions mentioned in the operation and installation instructions are not covered by our warranty and any liability.

CONTENTS

Technical Data 9

Safety Advice 10

Getting started 11

Using 12

Cleaning 12

Troubleshooting 13

Disposal Considerations 14

TECHNICAL DATA

Item number 10031990	10031991
Power supply 220 -240 V~ 50/60 Hz
Power consumption 1850	W - 2200 W

SAFETY ADVICE

Read the following instruction carefully before using the appliance for the first time.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Children should be supervised to ensure that they do not play with the appliance.
• The appliance may only be connected to a power supply whose voltage and frequency comply with the specifications on the rating plate!
• Never use or pick up the appliance if
• The supply cord is damaged
• The housing is damaged
  • he appliance must only be connected to an earthed socket.
• If necessary an extension cable suitable for 10A can be used.
• If the appliance or the supply cord is damaged, it must be replaced by the manufactory, its service agent or similarly qualified person, in order to avoid hazard.
• Iways place the appliance on a flat, level surface.
• he appliance must be switched off and the mains plug withdrawn before cleaning and maintenance.
• The appliance and accessories become hot during operation. Use only designated handles and knobs. Allow to cool down before cleaning or storage.
• The mains cable must not come into contact with any hot parts of the appliance.
• Do not immerse the appliance in water or any other liquid. Attention: If the kettle is overfilled there is a risk that the boiling water may spray out, which could scald or burn! Therefore never fill the kettle above the maximum marking.
  • Never operate appliance with open lid.
• Do not use or place the appliance on a hot surface or near source of heat.
• Only use the kettle for heating water!
  • The kettle can only be used with the stand provided.
  • Appliance is for indoor use only.
• This appliance is intended for domestic use only. The manufacturer cannot accept any liability for possible damage caused by improper or incorrect use.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in safe way and understand the hazards involved.
• Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.
• Keep the appliance and its cord out of reach of children less than 8 years.

GETTING STARTED

1. Before first use, rinse the inside and wipe the outside of the kettle with a damp cloth.
2. Press the button to open the lid, pour water into the kettle. It is also possible to fill the kettle through the spout, without opening the lid. Make sure water level is visible in the water level indicator, but not exceeding the MAX. mark.
3. Place the base unit on a firm and flat surface. Plug the mains plug into a wall socket. Excess cord can be wound into the bottom of the base unit.

USING

1. Fill at least 0.5 L to ensure that kettle will not be dry boiling quickly. Recommended temperature.

Recommended temperature:

• 60 °C for baby mixtures

• 70 °C for delicate teas(green/white)
  • 90 °C for instant coffee or soup
  • 100 °C for perfect black tea

• Close the lid and make sure that it snaps in correctly. Otherwise, the auto switch off function will not work reliably. Place the kettle on the bases correctly. The buzzer will buzz, all the buttons will be flashing once, If there is not any operation, all the button functions stand by

• To heating: press the respective temperature button to select temperature (60 °C/70 °C/80 °C/90 °C) you want and start heating immediately, the indication light of selected button will keep flashing. For boiling water (100 °C) just press the ON/OFF button on the right (without pressing a temperature button). Once the water temperature reaches the target temperature, the buzzer will buzz and the indication light will change to constant for 15s, the heater will automatic turn off. If there is not any operation in 15s, the indication light will turn off. Press selected button can cancel the heating program. Press other button will not stop the heating program but change the target temperature to new selected temperature.
• To keep warm press a temperature button to select temperature (60 °C/70 °C/80 °C/90 °C), you want and then press the button on the left to start keep warm program. Once the water temperature reaches the target temperature, the indication light of selected button will change from flashing to constant, and the machine will stop heating and start to keep warm. Pressing the left button can cancel the keep warm program.

CLEANING

1. Before cleaning, always unplug the appliance. Never rinse or immerse the kettle or base unit in water. Just wipe with a damp cloth, using no abrasive detergents. Occasionally rinse out the kettle with clean water.
2. To clean the mesh filter, grab the strainer insert and lift out.
3. Cleaning the heating plate- superficial spots of rust may appear on the base unit. Remove with a stainless steel cleaning agent.
4. Decalcifying is recommended regularly, depending on water hardness. Fill the kettle with water and decalcified according to decalcified product instructions. Do not boil the solution as it may foam over. Afterwards, rinse kettle thoroughly with fresh water.

TROUBLESHOOTING

Problem Possible cause Solution
The appliance switches off before boiling.	Too much lime scale at the heating element of the kettle.	Run the decalcifying procedure.
The appliance does not switch off.		Close lid until it locks. Insert the mesh filter correctly.
The appliance cannot be switched on.	After operating with little or no water, the appliance has not cooled down sufficiently.	Allow to cool a short time and try again.

DISPOSAL CONSIDERATIONS

Symbol of a waste bin with crossed lines indicating no waste, and a solid black rectangle below (no text or labels)

According to the European waste regulation 2012/19/EU this symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council or your household waste disposal service.

Your product contains batteries covered by the European Directive. 2006/66/EC, which cannot be disposed of with normal household waste. Please check local rules on separate collection of batteries. The correct disposal of batteries helps prevent potentially negative consequences on the environment and human health.

Declaration of Conformity

Producer: Chal-Tec GmbH, Wallstraße 16, 10179 Berlin, Germany

This product is conform to the following European Directives:

2011/65/EU (RoHS)

2014/30/EU (EMC)

2014/35/EU (LVD)
