Product Type	DLP Projector
Brand	Optoma
Model	DW318E
Native Resolution	1024 x 768 (XGA)
Brightness	2500 ANSI lumens
Contrast Ratio	2000:1
Lamp Type	UHP 190 W lamp
Lamp Life (Normal Mode)	3000 hours
Lamp Life (Eco Mode)	4000 hours
Power Supply	100-240 V, 50/60 Hz
Power Consumption (Normal Mode)	230 W
Standby Power Consumption	< 1 W
Dimensions (W x D x H)	286 x 192 x 97 mm
Weight	2.5 kg
Video Inputs	1x VGA, 1x S-Video, 1x Composite, 1x HDMI
Audio Input	1x 3.5 mm Jack
Audio Output	1x 3.5 mm Jack
Keystone Correction	Vertical ± 40°
Noise Level (Normal Mode)	30 dB
Noise Level (Eco Mode)	28 dB
Maintenance and Cleaning	Clean the air filter every 500 hours with a vacuum cleaner
Security	Kensington lock, automatic shutdown in case of overheating
Spare Parts and Repairability	Replacement lamp (model SP.83G01.001), air filter
General Information	Compliant with Canadian NMB-003 standard (Class B)

Frequently Asked Questions - DW318E OPTOMA

How to replace the lamp of the Optoma DW318E projector?

Turn off the projector and unplug it. Let it cool for at least 30 minutes. Remove the lamp cover (screw on the side). Replace the old lamp with a new one (ref. SP.83G01.001). Close the cover and reset the lamp counter in the menu.
Note: Always use an original Optoma lamp.

How to clean the air filter?

The air filter is located under the projector. Remove it and vacuum the dust with a low-power vacuum cleaner. Do not wash the filter with water. Put it back after drying.
Frequency: every 500 hours of use.

What connections are available on the DW318E?

The projector has an HDMI input, a VGA (PC) input, an S-Video input, a composite input, a 3.5 mm audio input, and a 3.5 mm audio output.

How to correct a distorted image (keystone effect)?

Use vertical keystone correction via the menu or remote control. Press the 'Keystone' button and adjust with the directional arrows.
Range: ± 40°.

Can I use the projector wirelessly?

No, the DW318E does not have built-in Wi-Fi. You can use an external wireless HDMI adapter for wireless projection.

What to do if the projector does not turn on?

Check that the power cable is properly connected and the outlet works. If the indicator blinks red, wait for the projector to cool down (overheating). If the problem persists, contact Optoma support.

How to switch between input sources?

Press the 'Source' button on the remote control or control panel. Select the desired source (HDMI, VGA, etc.) with the arrows and confirm with 'OK'.

What is the maximum image size?

The image diagonal can reach 300 inches (7.62 m) depending on the projection distance. Consult the distance chart in the manual for precise calculation.

How to reset the lamp counter?

After replacing the lamp, go to the OSD menu, select 'Settings' > 'Reset lamp counter' and confirm. This operation is necessary for proper lifetime tracking.

Can I use the projector in the rain or outdoors?

No, the DW318E is designed for indoor use only. Protect it from moisture and extreme temperatures. Use a protective cover if necessary.

USER MANUAL DW318E OPTOMA

Line drawing of a projector with a circular lens and control panel (no text or symbols)

INHALTSVERZEICHNIS

SICHERHEIT 4

Illustration of a projector with a lens and screen, labeled 'Projektor Netzka' below (no other text or symbols)

Line drawing of a cable with two connectors, no text or symbols present

Line drawing of a Tragetasche device with two bags and cables (no text or symbols on the diagram itself)

Diagram of VGA-Kabel connector with two connectors and cable routing (no text or symbols on diagram)

Simple 3D illustration of an oval-shaped object with internal lines, labeled 'Objektivabdeckung' below (no other text or symbols)

Pure diagram of a heat exchanger with red prohibition symbol (no text or labels)

Pure diagram of a refrigerator with red prohibition symbol (no text or labels)

Illustration of hands using a pliers to adjust a component with red arrows indicating direction (no text or symbols)

PROJEKTOR VERWENDEN

Haupt-Seite

Werkzeuge-Seite

IT-Helpdesk kontaktieren

PROJEKTOR VERWENDEN

Illustration of a projector with internal components and a blue arrow indicating the blade (no text or symbols present)

ZUSÄTZLICHE INFORMATIONEN

ZUSÄTZLICHE INFORMATIONEN
