Product Type	Blender
Brand	Gastroback
Model	Design Mixer Mini 40897
Dimensions (W x D x H)	Approx. 175 x 158 x 326 mm
Weight	Approx. 2.2 kg
Power Supply	220-240 V AC, 50/60 Hz, 10 A
Power Consumption	Max. 500 W
Capacity (Min - Max)	0.2 L - 0.8 L
Speed Settings	2 speeds (Low: 19,000 rpm, High: 21,000 rpm) + Pulse
Jug Material	Borosilicate glass (heat-resistant up to 60°C)
Blade Material	Titanium-coated
Safety Features	Safety interlock, overload protection, anti-slip base
Cord Length	Approx. 80 cm
Dishwasher Safe Parts	Blender jug (glass body, blade assembly, silicone seal), lid, measuring cup (upper rack recommended)
Motor Base Cleaning	Wipe with damp cloth; do not immerse or dishwasher
Continuous Operation Limit	1 minute, then at least 1 minute break
Overload Protection	Self-resetting; automatic shut-off on overheating
Intended Use	Household use only
Warranty	2 years from date of purchase
Accessories Included	Measuring cup, lid, silicone seal

Frequently Asked Questions - Design Mixer Mini 40897 Gastroback

How do I assemble the blender jug correctly?

First, ensure the silicone seal is placed on the blade assembly. Then place the glass body onto the blade assembly, turn upside down, and screw the threaded sleeve clockwise by hand. Tighten securely. Test for leaks with water before use.

What is the maximum amount I can blend at once?

Do not exceed the upper grading line of 800 ml. The minimum amount is 200 ml. Overfilling can cause spillage and poor mixing.

Can I blend hot liquids or soups?

The glass jug can handle temperatures up to 60°C. Allow hot food to cool to at least 60°C before filling. Do not pour boiling liquids as it may crack the glass.

What should I do if the motor stops during operation?

Switch OFF immediately (turn ON/OFF switch to >0<) and unplug. The overload protection may have triggered. Let the appliance cool for at least 30 minutes. Remove any blockages and reduce the load. Check for jamming.

How do I clean the blender jug thoroughly?

Rinse with warm water, then fill with 200-300 ml warm dishwater, run on low speed for a few seconds. Disassemble the jug to clean the blade assembly with a soft nylon brush. All jug parts are dishwasher safe (upper rack). Dry completely before reassembling.

Is the motor base dishwasher safe?

No. Never immerse the motor base or power cord in water or liquids. Wipe with a damp cloth only. Do not let liquids enter the ventilation slits at the bottom.

What is the pulse function used for?

The pulse function (switch position >P<) provides short, powerful bursts for tasks like crushing ice or creaming butter. Hold the switch at P until desired consistency, then release to stop automatically.

Why does the appliance smell when first used?

A slight burnt smell is normal when the appliance is new. It will disappear after a few uses. If the smell persists or becomes strong, stop using and contact support.

What should I do if the blender jug leaks?

Check that the threaded sleeve is tight, the silicone seal is in place and clean, and all sealing surfaces are smooth. Disassemble and reassemble correctly. If leaks continue, replace damaged parts (silicone seal or blade assembly).

How long is the warranty period?

Gastroback offers a 2-year warranty from the date of purchase covering manufacturing and material defects. Proof of purchase is required. Warranty does not cover misuse or commercial use.

USER MANUAL Design Mixer Mini 40897 Gastroback

Exterior view of a modern kitchen blender with a black handle and control knob (no text or symbols on the device itself)

Close-up of a circular mechanical component with a central transparent ring (no visible text or symbols)

Exterior view of a modern kitchen blender with a black handle and control knob (no text or symbols on the device itself)

Art.-No. 40897 »Design Mixer Mini«

Read all provided instructions before first usage!

Model and attachments are subject to change

For household use only!

TABLE OF CONTENTS

Knowing Your New Design Mixer Mini 34

Important Safeguards 35

General Safety Instructions....35

Important Safeguards for Electrical Appliances 37

Moving Parts—Risk of Injuries....39

Technical Specifications 40

Properties of Your New Design Mixer Mini 41

Tips for Processing 41

Selecting the appropriate speed 41

Overload protection 42

Before First Use....43

Operation 43

Assembling the Blender Jug 45

Processing Food 45

Solving Problems 48

Care and Cleaning 52

Cleaning the blender jug 52

Disassembling the blender jug and removing stubborn residues....53

Cleaning the motor base....55

Storage 56

Notes for Disposal 57

Information and Service 57

Warranty 58

DEAR CUSTOMER!

Congratulations to your new Gastroback Design Mixer Mini!

The electric mixer Gastroback Design Mixer Mini purees variety of foods and prepares mixed drinks of all kinds in a few seconds. The appliance is easy to use and easy to clean; the components are corrosion resistant and hygienic.

The powerful 500 watt motor of the appliance possesses 2 speed levels and a pulse function. The mixing bowl is made of heat-resistant glass. With the integrated volume marks and a built- in lid barlot for quantities up to 30 ml, you can easily measure your ingredients. Please read this manual carefully. The quickest way to get all the benefits of your new Design Mixer Mini is to inform Yourself before use about all the features!

We hope that you will enjoy your new Gastroback Design Mixer Mini.

Your Gastroback GmbH

KNOWING YOUR NEW DESIGN MIXER MINI

IMPORTANT SAFEGUARDS

Carefully read all instructions, before operating this appliance and save for further reference. Do not attempt to use this appliance in any other way and for any other purpose, than described in these instructions (intended use). Any other use, especially misuse, can cause severe injuries or damage by electric shock, heat, or fire. Do not use any parts of the appliance with any other device or for any purpose not described in this booklet.

These instructions are an essential part of the appliance. Do not pass the appliance without this booklet to third parties. Any operation, repair and technical maintenance of the appliance or any part of it other than described in these instructions may only be performed at an authorised service centre (see: 'Warranty').

GENERAL SAFETY INSTRUCTIONS

• This appliance is for household use only and NOT intended for use in moving vehicles. Do not operate or store the appliance in humid or wet areas or outdoors. Any use of accessories, attachments or spare parts (e.g. jug, seal) that are not recommended by the manufacturer or damaged in any way may result in injuries to persons and/or damage.
• Check the entire appliance regularly for proper operation (e.g. check for distortion, cracks, chipped edges, leaks, corroded pins of the power plug). Do not operate the appliance, when liquids escape during operation. Do not operate the appliance, when the appliance or any part of it is likely to be damaged, to avoid risk of fire, electric shock or any other injuries to persons and/or damage. The appliance or its parts are likely to be damaged, if the appliance has been subject to inadmissible strain (e.g. over heating, mechanical or electric shock, moisture in the motor base), or if there are any cracks or leaks, excessively frayed or melted parts, or distortions, or if the motor does not work properly. If one of these cases occur during operation, immediately unplug the appliance, and get in contact with an authorized service centre for examination and/or repair.

- Operate the appliance on a well accessible, stable, level, clean, dry, and suitable large table or counter that is resistant against fat and water.

Always wipe off spilled liquids immediately. Only place the blender jug on dry and clean surfaces. Particles or moisture could damage the coupling at the base of the blade assembly or the seals.

• Always handle the blender jug with special care. Do not expose the blender jug to any excessive mechanical stress, or extreme variations in temperature to avoid injuries and damage. The blender jug is only suited for temperatures up to 60°C. Do not use the blender jug any more, with the glass cracked or chipped in any way. Even small splinters could cause severe injuries, when getting into your food or beverages.
• Do not attempt to process very hard ingredients via the appliance. The Design Mixer Mini is not suited for grinding nuts or chopping hard chocolate or any similar types of food or spices.
• Be aware that the appliance could move around during operation due to vibrations. Always keep the appliance in sufficient distance to the edge of the table or counter and to other objects. For operation, leave at least 20 cm of free space on each side.
• Do not place any clothes or tissue or other foreign objects under or on the appliance during operation, to avoid risk of fire, electric shock and overheating. Do not place the appliance over a power cord or on wet or inclined surfaces (e.g. sink or drain board).
• This appliance may be used or handled by persons (including children from 8 years and above) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, if they have been given supervision and/or instruction concerning the use of the appliance by a person responsible for their safety, and if they understand and consider the involved hazards. Even cleaning may not be performed by children without supervision. Children must always be supervised to ensure that they do not play with the appliance or any part of the appliance or the packaging. Always keep the appliance where it is dry, frost-free, and clean, and where young children cannot reach it. Do not leave the appliance or any part of it unattended, when in reach of young children.
• Do not place the appliance or any part of it on or near hot surfaces (e.g. burner, heater, or oven).

- Do not leave the appliance unattended when connected to the power supply. Always switch OFF (turn ON/OFF switch to >0<) and unplug the appliance, before moving or cleaning the appliance and when the appliance is not in use. Do not use any hard or sharp-edged objects with the appliance (e.g. forks, knives, scrapers). To avoid overheating, before operation, always fill a sufficient amount of food into the blender jug (at least 200 ml). However, do not fill in more than 800 ml (upper grading line on the blender jug). If the blender jug is overfilled, liquids may run out.

• Do not place any hard and/or heavy objects on or in the appliance or any part or accessory of it. Do not use any hard or sharp-edged objects for operation or cleaning. Only use cooking utensils made of rubber, wood, or plastic. Do not use violence to avoid damage.
• Do not leave any food dry on the surfaces of the appliance (see: 'Care and Cleaning'). Do not use any abrasive cleaners, cleaning pads (e.g. metal scouring pads), or any corrosive chemicals (e.g. bleach) for cleaning. Do not place the motor base or power cord in an automatic dishwasher!
• The blades of the blade assembly are very sharp. Use caution, when handling the blade assembly to avoid injuries. Always hold the blade assembly by the rim when handling the blade assembly. If required, use a nylon brush for cleaning the blade assembly.

IMPORTANT SAFEGUARDS FOR ELECTRICAL APPLIANCES

The appliance is driven electrically. Place the appliance near a suitable wall power outlet to connect the appliance directly to a separately connected and protected mains power supply with protective conductor (earth/ground) connected properly. Ensure that the ratings of your mains power supply correspond to the requirements of the appliance (220/240 V AC, 50/60 Hz, rated for 10 A).

- The installation of a residual current operated circuit breaker (r.c.c.b.) with a maximum rated residual operating current of 30 mA in the supplying electrical circuit is strongly recommended. If in doubt, contact your electrician for further information.

• In various foreign countries, the specifications for power supplies are subject to incompatible norms. Therefore, it is possible that power supplies in foreign countries do not meet the requirements for safe operation of the appliance. Thus, before operating the appliance abroad, ensure that safe operation is possible.
• Do not use any desk top multi socket outlet, external timer, remote control systems or extension cord. The power outlet must always be easily accessible so that it would be possible to unplug the appliance immediately in case of any malfunction or danger.
• The pins of the power plug must be smooth and clean without discolourations. Always handle power cords with care. Do not place the appliance on a power cord. Power cords may never be knotted, twisted, pulled, strained or squeezed. Do not let the plug or power cord hang over the edge of the table or counter. The power cord may never touch hot surfaces, sharp edges, or any moving parts. Ensure that no one will pull the appliance by the power cord. Take care not to entangle in the power cord. Always grasp the plug to disconnect the power cord. Do not touch the appliance or power plug with wet hands, while the appliance is connected to the power supply.
• Always ensure that the blender jug is assembled completely and correctly and not leaking, before placing the blender jug onto the motor base. Always wipe off spilled liquids immediately. Do not place or immerse the motor base or power cord in water or any other liquid. DO NOT spill or drip any liquids on the motor base or the power cord to avoid risk of fire and electric shock.
• When parts of the appliance are leaking during operation and/or liquids accumulate under the motor base or run down on the motor base, immediately unplug the appliance. If in doubt, check the blender jug for leakage, before operating the appliance again. Refer to the instructions in chapter 'Solving Problems'.
• There are ventilation slits at the bottom of the motor base. Do not operate the appliance, when liquid run under the appliance, thus getting into the interior of the motor base. Always immediately unplug the appliance, when liquids ran on or under the appliance. Then clean

and dry the appliance thoroughly and contact an authorised service centre for examination.

- Always remove the blender jug from the motor base before filling the blender jug or taking out your food. Ensure that the exterior of the blender jug is always clean and dry, before placing it onto the motor base to avoid risk of electric shock, overheating, and fire or damage to the appliance.

MOVING PARTS—RISK OF INJURIES

⚠ WARNING: During operation, very sharp blades are moving on high speed within the blender jug. Thus, the appliance could cause high risk of severe injuries and damage, when used improperly.

• The blades of the blade assembly are very sharp. Only touch the blade assembly at the rim, when handling it.
• Do not attempt to operate the appliance without the blender jug placed on the motor base. Do not attempt to remove the jug base ring from the glass body. As well, the blade assembly may not be disassembled. However, do not place the jug base ring and/or the blade assembly onto the motor base without the glass body. Do not touch the drive wheel in the motor base socket while the appliance is connected to the power supply.
• Always turn the ON/OFF switch to >0< (OFF) and wait until the blades come to a complete standstill, before removing the blender jug from the motor base. Please, take into consideration that the motor will still be turning for a moment, after switching OFF.
• Do not leave the appliance switched on uselessly.
• Do not grasp into the blender jug or put any foreign objects (e.g. cooking utensils, hair, brushes, or clothes) into the blender jug with the blender jug placed on the motor base and the appliance plugged in. Always remove the blender jug from the motor base, before adding further ingredients or pushing the ingredients down on the inner walls of the blender jug. Only use cooking utensils made of wood, rubber, or plastics with the appliance to avoid damage to the

glass body and/or the blades of the blade assembly.

• Always close the blender jug with the lid and the measuring cup locked securely in the lid, before operation. Otherwise, splashes could escape from the jug and liquids could run out.
• When processing solid ingredients (e.g. hard types of fruits or vegetables) or overfilling the blender jug or the selected speed setting is too low, the motor could stall or get stuck. In this case, always switch OFF the appliance immediately (turn the ON/OFF switch to >0<) to avoid overheating. Please adhere to the instructions, given in chapter 'Solving Problems'.
• The appliance will process your food within seconds. Do not operate the appliance for more than 1 minute continuously. Make breaks of at least 1 minute, before switching on the appliance again.

TECHNICAL SPECIFICATIONS

Model:	Art.-No.: 40897 Design Mixer Mini
Power supply:	220/240V AC, 50/60Hz, 10A
Power consumption:	max. 500W
Length of power cord:	approx. 80cm
Weight:	approx. 2.2kg
Dimensions:	(width x depth x height) approx. 175 x 158 x 326 mm
Capacity:	0.2 litres (200 ml) to 0.8 litres (800 ml)
Speed:	Position >1<: 19 000 revolutions per minute (+-15%) Position >2<: 21 000 revolutions per minute (+-15%)
Certification:

These specifications may change without notice.

PROPERTIES OF YOUR NEW DESIGN MIXER MINI

Your new Design Mixer Mini is intended for chopping solid food (e.g. onions, carrots, apples) mixing beverages, sauces, and soups, and stirring runny batters (e.g. for pancake or waffles). However, please keep in mind that the Design Mixer Mini cannot substitute all other kitchen utensils. The appliance is NOT suited for puréeing potatoes, beating egg whites, making minced meat, extracting the juice of fruits and vegetables, kneading very heavy dough (e.g. yeast dough), or grinding very hard ingredients (e.g. nuts, hard chocolate).

TIPS FOR PROCESSING

• Pour liquid ingredients first in the Design Mixer Mini, if not specified otherwise in the recipe.
• Cut solid foods (vegetables, fruits, cheese, cooked meats, fish and seafood) in approx. 2 cm pieces. Do not overload the motor with too hard or too large ingredients. Turn the appliance OFF (turn the ON/OFF-switch to >0<), when the motor stalls to avoid overheating (see 'Solving Problems').
• Process the ingredients just a few seconds. It is better to check the quality of the product in between, then obtaining a result that is too fine and possibly watery and mushy.
• With two speeds (ON/OFF switch position >1< or >2<) and the pulse function (turn the ON/OFF switch to >P<) you can prepare easily, versatile and quickly a variety of food (see below).

SELECTING THE APPROPRIATE SPEED

Simply turn the ON/OFF switch to the desired speed setting >1< or >2<, or use the pulse function >P<. The appropriate speed setting is determined by the textures of the ingredients and the desired consistency (see the following table). To use the pulse function (ON/OFF switch position >P<), turn and hold the ON/OFF switch in position until the ingredients have reached the desired consistency. With the pulse function, the ON/OFF switch will be set back automatically, when releasing it. Please find some guidelines for selecting the suitable speed setting in the following table.

Speed Setting	Switch Position	Function and Examples	Use
Pulse Function	P ice crushing	short, powerful impulse movements; creaming butter/marge	Crushing Ice: place 1 to 12 ice cubes in the blender jug and hold the switch at position P until the ice pieces have the desired size.Tip: Before processing, place the blender jug in the refrigerator.
Slowly 1 purée; prepare		baby food	Cook your food, let it cool down and place it into the blender jug.Add a sufficient amount of liquid.IMPORTANT: Always observe the maximum temperature (60°C), when filling food into the blender jug.
		frothing; suited for whipped cream	Add sugar or flavours to taste.
		mixing and stir-ring; cream soups	Insert liquid first, then the other ingredients.
Quickly 2 whisking; for fruit dishes			Cut fresh fruit into 2 cm pieces and insert into the blender jug. Add yogurt, cream, or sour milk.
			Cut fresh fruit into 2 cm pieces and insert into the blender jug.

OVERLOAD PROTECTION

The mixer is fitted with a self-resetting overload protection device, which safeguards against overheating the motor. Overheating may be caused by ...

• too much food in the blender jug.
- hard ingredients block the blades.
• too sticky and too heavy load (e.g. heavy dough).
- the drive shaft of the blade assembly and/or the drive shaft in the motor base is damaged. You feel an unusual high resistance, when rotating the blades and/or the drive wheel.

If overheating occurs, the appliance will automatically switch off the motor. In this case, switch OFF the appliance (turn ON/OFF switch to >0<) and unplug. Remove the obstacle (see: 'Solving Problems') and leave the appliance cool down for at least 30 minutes. Thereafter, you may try to reactivate the appliance.

IMPORTANT: If you can turn the drive shafts of the motor base and/or blade assembly only with noticeable high resistance, the appliance may not be used furthermore. Please, contact an authorised service centre for examination and repair.

BEFORE FIRST USE

WARNING: DO NOT let young children play with the appliance or any part of it or the packaging! The blades of the blade assembly are very sharp. Always handle the blade assembly with care to avoid injuries and damage. The blender jug is made of glass, therefore it is fragile! Do not expose the blender jug to extreme variations in temperature. Always unplug the appliance before moving or cleaning it, and when it is not in use. Do not place the kettle or power base in an automatic dishwasher. Do not place or immerse the motor base or power cord in water or other liquids or spill any liquids on the motor base or power cord. Do not use any abrasive or corrosive cleaners for cleaning to avoid damage to the surfaces.

1. Unpack the appliance and all parts and accessories carefully. Check that no parts are damaged or missing (see: 'Knowing Your New Design Mixer Mini'). Carefully remove all packaging, shipping materials, stickers, and promotional materials. However, DO NOT remove the model label.
2. Before first use and after a longer period of storage, clean all parts of the appliance (see: 'Care and Cleaning').

OPERATION

⚠ WARNING: Always ensure that the appliance and all its parts and accessories are out of reach of young children. The main part of the blender jug is made of glass and could break or crack when handled carelessly. Even small splinters and shards could cause severe injuries when getting into your food and beverages. Thus, always handle the glass parts with special care to avoid injuries and damage. Do not use any glass parts any longer when these parts are broken, cracked, or chipped in any way.

Unplug the appliance, before cleaning the appliance, and when the appliance is not in use. Do not leave the motor base unattended while connected to the power supply.

Do not hold your hands or any foreign objects (e.g. cooking utensils) into the blender

jug with the blender jug placed on the motor base. Always switch OFF (turn ON/OFF switch to >0<), wait until the blades come to a complete standstill and remove the blender jug from the motor base, before opening the lid and taking out or checking your food or pushing your food down in the blender jug. Only use cooking utensils made of wood, rubber, or plastic with the appliance. Do not use violence, especially when removing obstacles blocking the blades to avoid damage to the blades.

Ensure to place the appliance on a level, flat, stable, and dry surface. Do not place the appliance near the edge of the working space or on inclined surfaces. Take into consideration that the appliance could move around due to vibrations during operation.

Always keep your workspace clean and dry during operation. Immediately wipe off spilled liquids or splashes using a dry cloth. Do not place the motor base on wet or moist surfaces or on any clothes. Do not let any liquids run under or on the motor base. If any liquids ran into the motor base or run out during operation, immediately unplug the appliance (see: 'Solving Problems'). If in doubt, contact an authorised service centre for examination (see also: 'Solving Problems').

Always remove the blender jug from the motor base, before filling the blender jug or removing the lid. Only place the blender jug on a clean, dry, stable and level surface. Do not expose the blender jug to extreme temperature variations (e.g. pouring hot water into the blender jug just after crushing ice). The maximum temperature of food and liquids filled into the blender jug is 60^ C. Always close the blender jug with the lid and measuring cup before operation. Otherwise, liquids and splashes could escape. Always ensure that the exterior of the blender jug is dry and clean, before placing the blender jug onto the motor base.

CAUTION: The appliance will not work without the blender jug on the motor base. However, do not remove the blender jug from the motor base during operation, to avoid damage to the drive wheel (in the motor base) and the coupling (in the blade assembly). Always switch OFF (turn ON/OFF switch to >0<) and wait for the blades to stop complete, before removing the blender jug from the motor base. To avoid overheating, before operation, always fill a sufficient amount of food or liquid into the blender jug (at least 200 ml). Do not fill in more than 800 ml to avoid overflow. Do not leave any food in the blender jug after use, to avoid that any residues dry on the surfaces or go off within the blender jug (see: 'Care and Cleaning').

IMPORTANT: If your Design Mixer Mini is still new, you may notice a burnt smell, when starting the motor. This is no reason for concern and will vanish with repeated use.

⚠ WARNING: The blades of the blade assembly are very sharp. Handle with care to avoid injuries. Only touch the blade assembly by the outer rim.

CAUTION: Before assembling the blender jug, ensure that the sealing surfaces on the blade assembly, silicone seal, and glass body are completely clean and smooth. Even the threads on the glass body and threaded sleeve must be completely clean. Particles and residues of food on the surfaces could damage the parts of the blender jug and leading to leakage of the blender jug.

1. Ensure that the sealing surfaces at the silicone seal, blade assembly and bottom of the glass body as well as the threads at the glass body and the threaded sleeve are absolutely clean and smooth.
2. Hold the blade assembly at the outer rim with the blades facing upwards and place the silicone seal on the outer rim of the blade assembly.
3. Place the glass body onto the blade assembly.
4. Turn the glass body with the blade assembly in it upside down.

Note:

The threaded sleeve can only be mounted in one orientation. Turn it clockwise for assembling the blender jug.

1. Ensure that the silicone seal lies evenly between the glass body and blade assembly. Then carefully screw the threaded sleeve on the glass body. Tighten the threaded sleeve by hand.
2. Via a cup of clear tap water, test the blender jug for leakage. If water runs out simply tighten the threaded sleeve a little more. If required, wipe dry carefully before usage. With the blender jug assembled leak-free and the exterior of the blender jug completely dry, the blender jug is ready for use.

PROCESSING FOOD

CAUTION: Do not fill any hot food into the blender jug to prevent the glass body from bursting. Always leave cooked food cool down to no more than 60°C before filling. The mixer operates only with the blender jug mounted. If you remove the blender jug during operation the mixer stops automatically. Do not remove the blender jug during operation to avoid damage to the drive wheel and coupling.

You should fill in liquid ingredients at first. Cut solid ingredients in 2 cm pieces. Do not overfill the blender jug. Otherwise, liquids could run out or the motor could stall.

Additionally, with the blender jug overfilled, you may get an uneven and poor mixing result.

IMPORTANT: The blender jug is no measuring device. If your recipe requires exact amounts, please use a separate measuring cup.

1. Remove the blender jug from the motor base. Prepare your food and fill the ingredients into the blender jug.
2. Close the blender jug with the lid and press the lid down. Insert the measuring cup. There are two protrusions on the exterior of the measuring cup. Place the measuring cup into the lid with these protrusions sliding into the grooves in the lid. Lock the measuring cup by turning it clockwise.
3. Ensure that the blender is switched OFF (turn the ON/OFF switch to >0). Ensure that the bottom of the blender jug is clean and dry.
4. Place the blender jug on the motor base. If required, turn the blender jug a little until it settles down on the motor base and stands firmly. The appliance is now ready for operation.

WARNING: Do not remove the lid and/or grasp into the blender jug or holding any type of objects into the blender jug with the motor agitating and/or the blender jug placed on the motor base. Do not remove the blender jug, while the motor is agitating. Always switch OFF the appliance (turn the ON/OFF switch to >0<) and wait until the blades stop complete. Thereafter remove the blender jug from the motor base before grasping into the blender jug or holding any objects into the blender jug.

1. Via the ON/OFF switch, select the desired speed setting: >1< (slowly), >2< (quickly) or >P< (pulse). The motor starts running immediately.

CAUTION: If the motor slows down during operation or gets stuck, immediately switch OFF the appliance (turn ON/OFF switch to >0). Please, adhere to the instructions in chapter 'Solving Problems'.

The appliance will process your food within seconds. Do not leave the appliance operate continuously for more than 1 minute. Make a break of at least 1 minute after 1 minute of continuous operation.

Note:

The motor will start only with the blender jug placed on the motor base correctly. When using the pulse function >P<, the ON/OFF switch will turn back to >0<, as soon as you release the ON/OFF switch.

1. After a few seconds of operation, switch back to >0< to switch OFF the appliance.

2. With the blades standing still, grasp the blender jug at the handle and remove it from the motor base. Thereafter remove the lid to check the results or, if required, push the ingredients down, which are sticking to the inner walls of the jug, using a plastic spoon.

Note:

If you wish to add some further ingredients only, it is best to remove the measuring cup from the lid by turning the measuring cup counterclockwise first and then lift it up and out. Fill the ingredients via the opening in the lid. Before starting the appliance again, do not forget to replace the measuring cup.

1. If required, close the lid and replace the blender jug onto the motor base. Let the appliance operate for some further seconds.
2. If your food has reached the desired consistency, switch OFF the appliance (ON/OFF switch to >0<). Thereafter remove the blender jug from the motor base and remove the lid.
3. Empty the blender jug. Runny food (e.g. beverages or runny batters) may be poured. With a more heavy and/or sticky mixture, use a wooden or plastic spoon to take your food out.
4. Clean the appliance immediately after each usage (see: 'Care and Cleaning'). Do not leave any residues dry on the surfaces.

SOLVING PROBLEMS

⚠ WARNING: Do not attempt to use this appliance for any other than the intended use, described in these instructions. Maintenance and repair of the appliance must be performed only by an authorized service centre. Do not use the appliance when it is probably damaged or is not working as expected.

The Design Mixer Mini is reliable and robust and will work smoothly usually when operated properly. However, if a problem occurs, in most cases you will able quite easily to solve it. The following error table is intended to assist you.

Problem Reason The	Solution
The appliance is live, but not working.	CAUTION: Always switch OFF immediately (turn ON/OFF switch to >0<), if the motor does not start agitating at once when switched on.
	The blender jug is not placed correctly on the motor base.	Try to turn the blender jug a little. It must slide down on the motor base until it stands stable and will not wobble.
	The food in the jug is too heavy.	Add some liquid. Leave the appliance cool down. Then try again.
	Hard pieces of food block the blades.	Remove the blender jug from the motor base. Then remove the obstacle. Try again.
	The overload protection has been triggered.	You have subjected the motor to excessive load. Please adhere to the instructions given in section 'Overload Protection'. Leave the appliance cool down for at least 30 minutes. Make breaks of at least 1 minute after continuous operation of 1 minute.
There is a slight smell of burning, when starting the motor.	The appliance is still new.	With the appliance still new, this is normal and no reason for concern.
The motor is slowing down considerably during operation or stalls.	The mixture in the blender jug is too heavy.	Try the high speed >2<. Add some liquid or reduce the amount of food in the blender jug. Process your food in portions.
	Hard ingredients block the blades.	Crush hard ingredients (e.g. nuts, hard chocolate) before filling them into the blender jug.
The motor stops during working. You cannot start the motor again.	Switch OFF immediately (turn ON/OFF switch to >0<) to avoid overheating. Then check the following items.CAUTION: Do not overload the motor via ingredients, which are too hard or too large. Do not overfill the blender jug. Process hard ingredients in portions. The appliance is not suited for grinding nuts, hard chocolate or other very hard ingredients.
	The blender jug is not assembled completely and correctly.	Assemble the blender jug according to the instructions in section 'Assembling the Blender Jug'.
	The blades are blocked.	Remove the blender jug from the motor base and remove the obstacle using wooden or plastic cooking utensils. However, do not use violence to avoid damage to the blade assembly.
	The load is too hard or too heavy.	Crush very hard ingredients (e.g. nuts, hard chocolate) before filling them into the blender jug. Add some liquid or take out a part of the mixture in the blender jug. Process your food in portions. Try speed setting >2<.
The threaded sleeve at the base of the blender jug is working loose. Liquid is escaping.	Immediately switch OFF (turn ON/OFF switch to >0<) and unplug the appliance. Remove and empty the blender jug. Clean and dry the motor base. If liquid entered the ventilation slits at the bottom of the motor base, contact an authorised service centre for examination.
	The blender jug is not assembled correctly. Perhaps, the silicone seal is missing.	Assemble the blender jug according to the instructions in section 'Assembling the Blender Jug'. Before operation, ensure that the blender jug is leak-free by filling in some water.
	The threaded sleeve is not tight enough.	Tighten the threaded sleeve a little more. However, do not over-tighten. If the problem persists, please refer to the next point.
You cannot keep the blender jug from leaking. Liquid escapes at the bottom of the blender jug.	Disassemble the blender jug and check the sealing surfaces of the glass body, silicone seal and blade assembly. Check for dried-on residues of food or any damage (e.g. scratches, cracks, deformation).CAUTION: Do not operate the appliance with unsuited, polluted, or damaged parts. Only use spare parts recommended by the manufacturer. If required, contact your vendor. Use some water to test the blender jug for leakage, before placing the blender jug onto the motor base.
	Residues of food stick to the sealing surfaces of the glass body, silicone seal, and/or blade assembly.	Clean the parts (see: 'Disassembling the Blender Jug and Removing Stubborn Residues'). Thereafter, assemble the blender jug according to the instructions given in section 'Assembling the Blender Jug'.
	Silicone seal, glass body, and/or blade assembly are damaged.	Replace any damaged parts by spare parts recommended by the manufacturer. Assemble the blender jug according to the instructions given in section 'Assembling the Blender Jug'.
	The silicone seal is missing.	Assemble the blender jug completely and correctly before placing the blender jug onto the motor base (see: 'Assembling the Blender Jug').
You cannot unscrew the threa-ded sleeve.	IMPORTANT: Always ensure to turn the threaded sleeve counter-clockwise for disassembling.
	The threaded sleeve may be screwed on very tightly.	Lay your hand on the glass body with the handle at the back of your hand. Turn the threaded sleeve with the other hand. Alternatively, hold the glass body with both hands, while a second person turns the threaded sleeve to unscrew it.
Water accumu-lates under the motor base or runs down on the exte-rior of the blender jug.	WARNING: Immediately unplug the appliance. Wipe dry the appliance completely, before using the appliance again. Always ensure that liquids cannot get into the ventilation slits at the bottom of the motor base.
	There is too much food in the blender jug.	Always observe the maximum fil-ling level of 800 ml. With vigorously frothing food, you should fill in some-what smaller amounts.
	You spilled some liquid when filling or moving the blen-der jug.	Avoid spilling any liquids on the exte-rior of the blender jug during filling. Always ensure to hold the blender jug level when it is filled. Ensure that the exterior of the blender jug is clean and dry, when placing the blender jug onto the motor base.
	The lid and/or measuring cup is missing or not assembled cor-rectly.	For operation the rim of the lid must lie completely on the rim of the blender jug. The measuring cup must be locked in the centre of the lid. If required, press down the lid somewhat firmer to seal the blender jug tightly.
	The seal at the rim of the lid is dama-ged.	Replace the lid. Get in contact with your vendor for original spare parts.
	The blender jug is leaking.	Check the blender jug for leakage. Do not use the appliance with the blender jug leaking (see above).

CARE AND CLEANING

⚠ WARNING: Always ensure that all parts of the appliance are out of reach of young children. Always switch OFF (turn the ON/OFF switch to >0<) and unplug, before moving or cleaning the appliance and when the appliance is not in use.

The blades of the blade assembly are very sharp. Always take special care when disassembling the blender jug and/or handling the blade assembly to avoid injuries.

Do not spill or pour any liquids on or in the motor base or power cord. Do not place or immerse the motor base or power cord in any liquids to avoid damage, risk of fire, and electric shock.

Glass can break or crack easily. Always use special care while handling the blender jug. Do not expose the blender jug to extreme temperature variations.

Do not use abrasive cleaning agents or aggressive liquids (e.g. bleach, solving agents) for cleaning the appliance or any part of it, to avoid damage to the surfaces and seals. Do not use any hard or sharp-edged objects for cleaning (e.g. scoring pads, knives, scrapers). Do not use violence.

DO NOT clean the motor base or power cord in an automatic dishwasher!

⚠ WARNING: Use extreme caution when working in the area of the blades; be careful not to cut on the sharp blades and not to damage the blades. Glass may crack easily, when handled carelessly. Please, use special care, when handling glass parts to avoid damage and injuries caused by splinters and shards. Do not expose the glass body to extreme temperature variations to avoid cracking. Always observe the maximum temperature for the glass body (60°C).

1. Empty the blender jug completely and rinse loosely adhering food with clean water.
2. Then fill 200 ml-300 ml warm dishwater into the blender jug (up to 60°C). Seal the blender jug with the lid and measuring cup. Switch the appliance ON (turn the ON/OFF switch to position >1<) and let the appliance work for a few seconds.
3. Switch the appliance OFF (ON/OFF-switch position >0<). Wait until the blades stop, and remove the blender jug from the motor base. Unplug the appliance.

4. Remove the lid from the blender jug. Residues still sticking to the interior of the blender jug may be removed easily via a soft nylon brush. However, please keep in mind that the blades are very sharp. Do not touch the blades with your hands. After cleaning, pour out the dishwater.

5. Clean the lid and measuring cup in warm dishwater. Thereafter rinse the parts with clear water.

6. Thoroughly wipe dry all parts. Thereafter, leave the parts of the appliance dry naturally for approx. 30 minutes, where they are out of reach of young children.

Note:

In most cases, the blender jug will already be hygienically clean now. However, if residues of food stick to the blade assembly still, you should disassemble the blender jug for cleaning the parts.

Note:

You may clean the blender jug, lid, and measuring cup in an automatic dishwasher. If possible, place the parts on the upper rack.

DISASSEMBLING THE BLENDER JUG AND REMOVING STUBBORN RESIDUES

⚠ WARNING: Use extreme caution when working in the area of the blades; be careful not to cut on the sharp blades and not to damage the blades. Glass may crack easily, when handled carelessly. Please, use special care, when handling glass parts to avoid damage and injuries caused by splinters and shards. Do not expose the glass body to extreme temperature variations to avoid cracking. Always observe the maximum temperature for the glass body (60°C).

⚠️ CAUTION: Do not use any hard or sharp-edged objects for cleaning. Do not use any abrasive cleaners. Otherwise the sealing surfaces of the blender jug could get damaged!

IMPORTANT: The threaded sleeve could be screwed on very tightly. Always ensure to turn the threaded sleeve counter-clockwise for disassembling the blender jug. Handle the silicone seal with care to avoid damage.

Note:

You may clean all parts of the blender jug (glass body, blade assembly, silicone seal, lid, and measuring cup) in the automatic dishwasher. If possible, place the parts on the upper rack.

1. Remove the lid and measuring cup from the blender jug. Place the blender jug upside down on a stable surface. While holding the glass body with one hand turn the threaded sleeve counter-clockwise to remove the threaded sleeve.
2. Holding the blade assembly by the rim, pull the blade assembly carefully out of the glass body. Remove the silicone seal.
3. Stubborn residues can be removed easily, after soaking the parts in warm dish-water for approx. 10 minutes.
4. After soaking, brush the blade assembly and threaded sleeve with a soft nylon brush. Doing so, do not touch the blades with your fingers but hold the blade assembly by the rim to avoid injuries. Ensure not to scratch on the sealing surfaces of the blade assembly.
5. Clean the glass body and silicone seal using a soft cloth or sponge. Ensure not to damage the silicone seal.

IMPORTANT: Replace the parts, if you cannot get them completely clean this way.

1. Rinse all parts with clear water.
2. After cleaning, dry all parts thoroughly and leave them dry naturally for approx. 1/2 hour, where they are out of reach of young children.
3. Reassemble the blender jug after cleaning (see: 'Assembling the Blender Jug'). This way, no one can touch the blades unintentionally.

CLEANING THE MOTOR BASE

⚠ WARNING: Always unplug the appliance before cleaning the motor base. Do not pour or spill water or other liquids on the motor base or leave any liquids run on or under the motor base. Do not immerse the motor base in liquids or place it on wet or damp surfaces. Always wipe off spilled liquids immediately. Do not place the motor base in an automatic dishwasher! There are ventilation slits at the bottom of the motor base. Please ensure that no water can run or drip into these openings.

⚠️ CAUTION: Do not poke in the motor base socket with any hard objects to avoid damage to the drive wheel. If required, use a soft dry brush to clean the motor base socket.

If liquids got into the motor base socket, always clean and dry the motor base socket thoroughly.

1. Unplug the appliance.
2. Wipe the motor base with a damp, not dripping cloth.
3. If required, use a soft brush to clean the motor base socket. To avoid damage to the drive wheel, use caution when cleaning the drive wheel. Do not use violence. If moisture has gone into the motor base socket, clean and dry the motor base socket very carefully and thoroughly.
4. Wipe dry the complete motor base. Leave the motor base dry naturally for approx. 1/2 hour. The motor base must be completely dry, before re-assembling the appliance and using it again.

STORAGE

WARNING: Young children must be supervised that they do not play with the appliance or any part of it. When the appliance is not in use, always unplug the appliance. Do not place the blade assembly onto the motor base without the glass body.

Do not hold the appliance by the power cord for moving the appliance to avoid damage. Remove the blender jug from the power base for moving the appliance to prevent the blender jug from falling down. Always handle the glass body with special care to avoid damage.

The power cord may never be knotted, twisted, pulled, strained or squeezed. Do not let the plug or power cord hang down.

Do not place any hard or heavy objects on or in the appliance or any part of it. Do not use any parts or accessories of the appliance for any other appliance or any other purpose than described in this booklet.

Please store the appliance in a frost free, clean and dry place where it is out of reach of young children and where it is protected against excessive load (e.g. mechanical or electric shock, heat, direct sunlight). The temperature for storage may not exceed 40^ C.

1. Clean the appliance before storing (see: 'Care and Cleaning'). Completely assemble the blender jug after cleaning (see: 'Assembling the Blender Jug'). This way the parts are protected against loss and no one can touch the blades unintentionally.
2. Place the motor base on a clean, stable, and level surface, where the appliance cannot fall. To protect the motor base socket from dust, we recommend to place the blender jug onto the motor base.
3. For storage, you may wind the power cord loosely around the bottom of the motor base.

NOTES FOR DISPOSAL

Dispose of the appliance and packaging must be effected in accordance with the corresponding local regulations and requirements for electrical appliances and packaging. Please contact your local disposal company.

Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills, dumps, or refuse incineration, hazardous substances can leak into the groundwater or can be emitted into air, thus getting into the food chain, and damaging your health and well-being as well as poisoning flora and fauna. When replacing old appliances with new once, the vendor is legally obligated to take back your old appliance for disposal at least for free of charge.

INFORMATION AND SERVICE

Please check www.gastroback.de for further information. For technical support, please contact Gastroback Customer Care Center by phone: [phone] or e-mail [e-mail].

Please refer to our home page for a copy of these operating instructions in pdf format.

WARRANTY

We guarantee that all our products are free of defects at the time of purchase. Any demonstrable manufacturing or material defects will be to the exclusion of any further claim and within 2 years after purchasing the appliance free of charge repaired or substituted. There is no Warranty claim of the purchaser if the damage or defect of the appliance is caused by inappropriate treatment, over loading or installation mistakes. The Warranty claim expires if there is any technical interference of a third party without a written agreement. The purchaser has to present the sales slip in assertion-of-claim and has to bear all charges of costs and risk of the transport.

Note:

Customers from Germany and Austria: For repair and service, please send Gastroback products to the following address: Gastroback GmbH, Gewerbestr. 20, D-21279 Hollenstedt, Germany.

Customers from other countries: Please contact your dealer.

Please agree that we cannot bear the charge of receipt. Submission of appliances: Please ensure packing the appliance ready for shipment without accessories. Add the sales slip and a short fault description. The processing time after receipt of the defective appliance will be approx. 2 weeks; we will inform you automatically. After the warranty period, please send defective appliances to the given address. You will get a free quotation and, thereafter, can decide, whether we shall repair the appliance to the costs possibly accrued, send back the defective appliance for free of charge, or dispose of the appliance for free of charge.

The appliance is intended for household use only and NOT suited for commercial usage. Do not attempt to use this appliance in any other way or for any other purpose than the intended use, described in these instructions. Any other use is regarded as unintended use or misuse, and can cause severe injuries or damage. There is no warranty claim of the purchaser if any injuries or damages are caused by unintended use.

GASTROBACK GmbH

Gewerbestraße 20. 21279 Hollenstedt / Germany Telefon [phone]. Telefax +49(0)4165/2225-29 [e-mail] . www.gastroback.de
