Product Type	Hand Blender (Stick Blender)
Brand	KORONA
Model	23515
Rated Voltage	220-240 V ~ 50/60 Hz
Rated Power	600 W
Protection Class	II
Continuous Operation Time	1 minute (CO-Time)
Speed Settings	Normal (I) and Turbo (II) with variable speed control wheel
Blade Material	Stainless steel (sharp)
Motor Unit Material	Plastic
Blender Attachment	Removable, with blade guard
Dishwasher Safe Parts	Blender attachment is not dishwasher safe
Immersion Capability	Only blender part can be immersed; motor unit must not be immersed
Intended Use	Processing soups, sauces, dips, baby food, fruit and milk shakes
Safety Features	Automatic shut-off when released, blade guard, overheating protection
Guarantee	2 years
Country of Origin	Manufactured for KORONA electric GmbH, Germany
Weight (approx.)	0.8 kg
Dimensions (approx. length)	40 cm
Included Accessories	Blender attachment

Frequently Asked Questions - 23515 KORONA

How do I attach the blender to the motor unit?

Align the blender attachment with the motor unit and rotate to lock according to the silkscreen logo. An open padlock symbol indicates unlocked, and a down arrow indicates locking direction.

What is the maximum continuous operating time?

The maximum continuous operating time (CO-Time) is 1 minute. After that, let the motor cool down before using again.

Can I blend hot liquids with this blender?

No, never use boiling liquids. Allow them to cool down to lukewarm first to avoid serious burns or damage.

How should I clean the blender attachment?

Disconnect the appliance and detach the blender. Clean it in warm water with dishwashing detergent, rinse, and dry. The blender is not dishwasher safe. Stubborn stains can be removed with vegetable oil. The motor unit should only be wiped with a damp cloth.

What does the speed control wheel do?

When using speed setting I (normal), the speed control wheel adjusts the blending speed. Rotate upward to increase speed and downward to decrease.

What should I do if the blade jams during operation?

Immediately switch off the appliance, disconnect it from the mains, and remove the blockage. Never reach into the blade area while the appliance is plugged in.

Can I blend ice, nuts, or other hard foods?

No, this blender is not designed for hard foods like nuts, ice, or chocolate. Processing such items may damage the blade or motor.

How should I store the appliance after use?

Store the appliance in a clean, dry place out of reach of children. Ensure it is completely cool and dry before storing. Do not wind the cord around the appliance.

What is the guarantee period and how do I claim it?

The product is guaranteed for 2 years against defects in materials and workmanship. To claim, provide the purchase receipt and contact KORONA Service in Germany ([e-mail], phone [phone]).

Is it safe for children to use this blender?

Children aged 8 years and above can use the blender under supervision. Children younger than 8 should be kept away from the appliance and its cord. Always unplug when not in use.

USER MANUAL 23515 KORONA

Black-and-white photo of a tall glass of juice with strawberries on the side (no text or symbols visible)

CE

Exterior view of a Korona brand blender (no text or symbols on body)

Before use, please read these instructions carefully and keep them in a safe place for future reference. When passing on the appliance to a third party, make sure to include these instructions for use.

This appliance is only intended and suitable for processing foods and liquids. All other use or modification of the appliance is not intended by the manufacturer and might entail a risk of damage or injury. This appliance is not intended for commercial use!

Safety:

This symbol identifies hazards which may cause injuries!

This symbol identifies electric shock hazards!

General Safety Instructions

• Manufacturer takes no responsibility for any damage caused by incorrect use.
• Incorrect or improper use can damage the appliance and cause injuries to the user.
• Before connecting this appliance to the mains, make sure your local voltage matches the technical data of the appliance. Otherwise the appliance may overheat and get damaged.

Caution! Danger of electric shock!

- Never put the appliance, cord or plug into water or any other liquid.

• Do not use the appliance near a sink or wash basin.
• Do not use the appliance with wet hands.
• Do not use the appliance outdoors.

An electric appliance is not a toy!

• Never leave the appliance unattended during use.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.

- Keep the appliance and its cord out of reach of children less than 8 years.

- Always unplug your appliance when it is not in use, and before cleaning.

- Always pull the plug – not the cord.

- Keep the appliance and the cord well away from any hot surfaces to avoid any damage to the appliance.

- Make sure the cord may not inadvertently be pulled or cause anyone to trip when in use. Do not allow the cord to hang over sharp edges.

- Do not bend the cord or wind it round the appliance.

Do not use the appliance,

• if the cord is damaged.
• in case of malfunction.

• if the appliance was dropped or is damaged otherwise.
  Have it checked and, if necessary, repaired by a qualified person. Never attempt to make any modifications to or repair the appliance yourself.

• Only use accessories evaluated for use with this appliance.

• Never attempt to drive any objects into the appliance.
• Never attempt to open the housing yourself!

Special Safety Instructions

Warning! To avoid the possibility of injury/damage to the appliance, electric shock, risk of fire and burns!

• Only use the appliance for its intended purpose (processing small amounts of foods) and as described in this manual.
• Never touch the rotating parts/blades with your hands and/or other objects when using the appliance. This could lead to serious injuries and/or damage to the appliance.
• Careful, when cleaning the blade, it is very sharp.
• Never use any boiling liquids. Allow those liquids to cool down first (lukewarm) to avoid serious injuries/burns.
• If the cutting knife should experience any problems during operation, switch off the appliance, disconnect it from the mains and remove the blockage.
• Never process any hard foods, e.g. nuts, ice, chocolate, etc.
• Whilst processing pieces of food, only fill up the mixing cup to 2/3, as the mix will rise due to the rotation of the blade. Never process large quantities at one time.
• When exchanging accessories always disconnect it from the mains.
• Never immerse the blender completely into the ingredients.
• Keep the appliance out of the reach of children.
  • Continuous Operation: 1 Minute.

Product Description

1. Motor unit
2. Blender
3. Speed Control button
   (I=normal / II=turbo)
4. Speed control wheel
5. Cutting knife
6. Power cord and plug

Before First Use

• Remove all packaging material and check whether the appliance is complete and undamaged.
• Fully unwind the power cord (6).
• Clean the appliance as specified under „Cleaning and Care“.

Warning: Plastic bags are a danger to toddlers and s, therefore keep them away to avoid suffocation.

Operation

Your stick blender can be used for processing soups, sauces, dips, baby-foods and for mixing fruit and milk shakes

Never touch the rotating parts/blades with your hands and/or other objects when using the appliance. This could lead to serious injuries.

Attach / Release the Blender

Rotate the blender unit to lock and unlock according to the silkscreen logo.

Processing of foods

1. Put the resp. ingredients into a mixing cup or another suitable container. Cut the ingredients intopieces (2cm) first.

2. Attach the blender (2) to the motor unit (1) as described under Attach / Release the Blender and make sure it is properly locked.

3. Lower the blender (2) into the ingredients and make sure that the blade guard is completely covered.

4. Connect the power plug (6) to a properly installed wall socket.
5. Start the mixing process by pressing the speed control button (3). Depending on the foods and the amount, choose the speed setting (I=normal or II=Turbo).

Note: While using speed setting I, speed can be adjust by speed control wheel (4). Rotate upward to increase speed and roated downward to decrease speed.

1. Once the mixing process is complete release the speed control button (3) of your appliance and disconnect it from the mains.

To properly blend the ingredients, move the appliance up and down and in circles.

Attention: The appliance is equipped with a pulse switch which does not engage. Once the speed button is released the appliance switches off, automatically.

Warning: DO NOT operate the appliance longer than 1 minutes (CO-time) at a time, to avoid overheating of the appliance.

Cleaning and Care

Before cleaning, always switch off the appliance and disconnect it from the mains. Let it completely cool down. Never immerse the motor unit (1) in water. Danger! Electric Shock!

Clean the appliance as soon as possible after use with a damp cloth and do not use any aggressive cleaning agents. Release the blender (2) as described under Attach / Release the Blender. Clean it in warm water using some dishwashing detergent.

Rinse with clear water and dry it properly. The blender (2) is not dishwasher safe. Stubborn stains can be removed with some vegetable oil.

The blade is extremely sharp. Risk of injury!

After use, store the appliance in a clean and dry place and keep it out of the reach of children.

Disposal Instructions

Waste electrical devices marked with this sign must not be disposed of with your household waste, but – according to the EU directive on Waste Electric And Electronic Equipment of 24th March 2005 – are to be collected separately. Therefore, please return this device at the end of its life cycle to special collection points for disposal or your local dealer.

Your stick blender 23515 is packed in a retail box. Such boxes are recyclable waste, i.e. they are reusable or recyclable.

Technical Data:

Voltage: 220 - 240 V \~ 50/60 Hz

Rated Power: 600 W

CO-Time: 1 Minutes

Protection Class: 11

CO-Time: The CO-Time (Continuous Time) describes the time how long an appliances may be used without the motor being damaged or overheating. After the appliance has run for this period of time it must be switched off to allow the motor to cool

down.

Subject to change without notice!

Guarantee:

This product is guaranteed against defects in materials and workmanship for a period of 2 years.

This guarantee is not valid:

• if the appliance has not been used in accordance to the instructions
  • for damages due to wear and tear (batteries, etc.)
  • for damages known by customer at time of purchase
  • for damages caused by owner

This guarantee does not affect your statutory right, nor any legal right you may have as a costumer under applicable national legislation governing the purchase of goods.

In order to assert his/her right in a guarantee case during the guaranteed period, the customer must provide evidence of the date of purchase (receipt).

The guarantee is to be asserted against

KORONA electric GmbH, Sundern/Germany.

Service Address:

KORONA Service

Am Steinbach 9

59872 Meschede-Enste

Germany

Telephone Hotline: [phone]

Mail: [e-mail]

web: www.korona-electric.de

within 2 years after the date of purchase. In case of guarantee the customer is given the right to get the appliance repaired at our own or at an authorized shop. Further rights (due to guarantee case) are not given to the customer.

Abstract geometric design with curved gray shapes on white background (no text or symbols)

Ref: 23515/13-2015.8
