Product Type	Laptop (Mobile Workstation)
Brand	Fujitsu
Model	Celsius Mobile H270
Release Year	2009
Processor	Intel Core 2 Duo (typical)
Memory (RAM)	Up to 4GB DDR2
Storage	2.5" SATA HDD (up to 320GB)
Optical Drive	DVD Super Multi (CD/DVD)
Display	15.6" or 17" TFT (estimated)
Audio	High Definition Audio
Modem	56k V.92
Network	Gigabit Ethernet, optional WLAN
Battery	Li-Ion, rechargeable
Power Supply	AC adapter 100-240V, 50-60Hz
Weight	Approx. 2.8 kg (6.2 lbs)
Dimensions (WxDxH)	Approx. 360 x 260 x 35 mm
Operating System	Windows Vista/XP (as preinstalled)
Security	BIOS password (User/Supervisor)
Certifications	FCC Part 15 Class B, ICES-003, CE
Accessories Included	AC adapter, power cord, user manual

Frequently Asked Questions - Celsius Mobile H270 FUJITSU

How do I clean my Fujitsu Celsius Mobile H270 laptop?

Use a soft, lint-free cloth slightly dampened with water or a mild cleaning solution. Do not use abrasive cleaners or solvents. Ensure the device is powered off and unplugged before cleaning. Refer to the manual's cleaning section for details.

What should I do if I forget my BIOS password?

If you forget the User or Supervisor password, contact Fujitsu support. The manual warns that password recovery may require technical assistance and could result in data loss.

Can I upgrade the RAM on the Celsius Mobile H270?

Yes, the laptop supports up to 4GB of DDR2 RAM. It has two SODIMM slots. Refer to the manual for installation instructions and compatible memory types.

How do I replace the battery?

The Li-Ion battery is user-replaceable. Power off the laptop, disconnect the AC adapter, slide the battery release latch, and remove the battery. Insert a new battery until it clicks into place. Dispose of old batteries properly.

Does the Celsius Mobile H270 have a built-in modem?

Yes, it has a 56k V.92 internal modem. The manual includes FCC Part 68 compliance information and telephone connection requirements.

Is the laptop compatible with Windows 10?

The original operating system was Windows Vista or XP. While Windows 10 may run with basic drivers, official support is limited. Check Fujitsu's website for driver availability.

What type of hard drive does it use?

It uses a 2.5-inch SATA hard drive. The manual does not specify maximum capacity, but common sizes were 80GB to 320GB.

How can I configure the Wi-Fi?

If equipped with a WLAN module, enable it via the hardware switch (if any) or in the BIOS. Install the appropriate driver and use Windows network settings to connect to a wireless network.

What are the important safety precautions for this laptop?

Do not use near water, avoid overheating, use only the specified AC adapter, handle lithium battery with care (risk of explosion if replaced incorrectly), and ensure proper ventilation.

Where can I download the manual or drivers?

Visit Fujitsu's support website at http://ts.fujitsu.com/support. Enter the model name 'Celsius Mobile H270' to find manuals, drivers, and additional resources.

USER MANUAL Celsius Mobile H270 FUJITSU

© Fujitsu Technology Solutions 2009

2009/08

Published by

Fujitsu Technology Solutions GmbH

http://ts.fujitsu.com/support

All rights reserved, including intellectual property rights. Technical data subject to modifications and delivery subject to availability. Any liability that the data and illustrations are complete, actual or correct is excluded. Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their own purposes may infringe the rights of such owner. For further information see http://ts.fujitsu.com/terms_of_use.html

Order-No. Fujitsu Technology Solutions: A26391-K200-Z226-1-19

ProfessionalNotebook

Betriebsanleitung

InnovativeTechnologie...1

WichtigeHinweise 3

InnovativeTechnologie....1

CDs/DVDshandhaben.... 22

CD/DVD-Anzeige 22

High Definition Audio 48

Regulatorynotices....68

Regulatory information for notebooks without radio device 68

DOC(IndustryCANADA)Notices 69

FCCRegulatoryinformationfornotebookswithradiodevice.... 7 1

Stichwörter 73

InnovativeTechnologie...

Line drawing of a laptop with labeled parts (1 and 2), showing front and side views without any text or symbols beyond labels.

Line drawing of a laptop with an attached drive, showing the open lid and base (no text or symbols)

Technical line drawing of a mechanical component with an arrow indicating direction (no text or symbols)

Diagram showing a rolled document being placed on a flat surface with an arrow indicating direction (no text or symbols)

Diagram showing a folded paper or sheet being compressed with an arrow indicating compression, and a warning symbol (no text or labels present)

Diagram of a mechanical component with two directional arrows labeled 1 and 2, no text or symbols present.

Diagram of a mechanical component with a clamped part and a directional arrow, no text or symbols present

Diagram showing a folded paper or sheet with an arrow indicating direction, and a small icon with a triangle below (no text or symbols)

Diagram showing a mechanical component with an arrow pointing to a bracket and a separate plate (no text or symbols)

Diagram of a mechanical component with an arrow indicating direction (no text or symbols)

Diagram showing a folded paper or sheet with a black arrow pointing to it, and a small icon below (no text or symbols)

Diagram showing a mechanical assembly with a bracket and a separate plate, no text or symbols present

Diagram showing a connector with a cable and resistor, no text or symbols present

Pure technical line drawing of a rectangular component with a labeled dimension '1' and diagonal lines, no text or symbols present.

Line drawing of a laptop with an attached device showing a small icon (no text or symbols)

High DefinitionAudio

User-und/oderSupervisor-Passwortvergessen

IfthereisnoFCClogoandalsonoFCCIDonthedevicethenth device is not approved by the Federal Communications Commission (FCC) of the USA. Although it is not explicitly forbident to travel the U Strading area acarrying this device, but to avoid trouble at customs clearance Fujitsu Technology Solutions GmbH recommends not to bring this device into the U Strading area.

Regulatoryinformationfor notebookswithoutradiodevice

NOTICE:

Changes or modifications not expressly approved by Fujitsu Technology Solutions couldvoid this user's authority to operate the equipment.

NoticetoUsersofRadiosandTelevision

Theselimitsaredesignedtoprovidereasonableprotectionagainsttharmfulinterferenceina residentialinstallation. This equipment generates, uses, and can radiateradiofrequencyenergy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorientorrelocatethereceivingantenna.
- Increase these separation between the equipment and receiver.
- Connect the equipment into an outlet that is on a different circuit than the receiver.
- Consultthedealeroranexp eriencedradio/TVtechnicianforhelp.

NoticetoUsersoftheUSTelephoneNetwork

YournotebookmaybesuppliedwithaninternalmodemwhichcomplieswithPart68ofthe FCCrules.OnthisnotebookisalabelthatcontainstheFCCRegistrationNumberandthe RingerEquivalenceNumber(REN)forthisequipmentamongotherinformation.Ifrequested, the user must provide their telephone company with the following information:

1. Thetelephonenumbertowhichthenotebookisconnected.
2. The Ringer Equivalence Num ber(REN) forthisequipment.
3. The equipment requires a standard modular jack type USOCRJ-11C which is FCC Part 68 compliant.
4. The FCC Registration Number

This equipment is designed to be connected to the telephone network or premises wiring using astandardmodularjacktypeUSOCRJ-11CwhichisFCCPart68compliantandalinecord betweenthemodemandthetelephonenetworkwithaminimumof26AWG.

TheRENisusedtodeterminethenumberofdevicesthatyoumayconnecttoyourtelephone lineandstillhaveallofthosedeVICESringwhenyournumberiscalled.Toomanydevices ononelinemayresultinfailuretoringinresponsetoanincomingcall.Inmost,butnotall, areas the sum of the RENs of all of the devices should not exceed five (5). To be certain ofthenumberofdevicesyoumayconnecttoyourline,asdeterminedbytheRENs,contact your local telephone company. If this equipment causes harm to the telephone network, your telephonecompanymaydiscontinueyourservicetemporarily.Ifpossible,theywillnotifyyou in advance. If advance notice is not practical they will notify you as soon as possible. You will also be advised of your right to file a complaint with the FCC.

ThisfaxmodemalsocomplieswithfaxbrandingrequirementsperFCCPart68.

Yourtelephonecompanywillprobablyaskyoutodisconnectthisequipmentfromthetelephone networkuntiltheproblemiscorrectedandyouaresurethattheequipmentisnotmalfunctioning. Thisequipmentmaynotbeusedoncoin-operatedtelephonesprovidedbyyourtelephone company. Connection to party lines is subject to state tariffs. Contact your state's public utility commission,publicservicecommissionorcorporationcommissionformoreinformation.

This equipment includes automatic dialing capability. When programming and/or making test call to emergencies:

- Remain on the line and briefly explain to the dispatcher the reason for the call.

- Performsuchactivitiesinoff-peakhours,suchasearlymorningorlateevening.

FCCrulesprohibittheuseofnon-hearingaidcompatibletelephonesinthe followinglocationsorapplications:

- Allpublicorsemipubliccoin-operatedorcreditcardtelephones.

- Elevators, highways, tunnels (automobile, subway, railroad or pedestrian) where a person with impaired hearing might be isolated in an emergency.

- Places where telephones are specifically installed to alert emergency authorities such as fire, police or medical assistance personnel.

• Hospital rooms, residential health care facilities, convalescent homes and prisons.

•Hotel, motelorapartmentlobbies.

- Storeswheretelephonesareusedbypatronstoordermerchandise.

- Public transportation terminals where telephones are used to call taxes or to reservelodging torrentalcars.

- Inhotelandmotelroomsasatleasttenpercentoftheroomsmustcontainhearing aid-compatibletelephonesorjacksforplug-inhearingaidcompatibletelephoneswhich willbeprovidedtohearingimpairedcustomersonrequest.

DOC(IndustryCANADA)Notices

NoticetoUsersofRadiosandT television

ThisClassBdigitalapparatu smeetsallrequirementsofCanadianInterference-CausingEquipment Regulations.

This equipment meets the applicable Industry Canada Terminal Equipment Technical Specifications. This is confirmed by the registration number. The abbreviation, IC, before theregistration numbers, is nifiesthat registration was performed based on a Declaration of Conformity indicating that Industry Canada technical specifications were met. It does not imply that Industry Canada approved the equipment. Before connecting this equipment to atelophonelin the usersh ould ensure that it is permissible to connect this equipment to the local telecommunicati on facilities. The users should be aware that compliance with the certification standards does not prevent service degradation in some situations.

Repairstotelecommunica tionequipmentshouldbemadebyaCanadianauthorized maintenancefacility.A nyrepairsoralterationsnotexpresslyapprovedbyFujitsuor

anyequipmentfailuresmaygivethetelecommunicationcompanycausetorequestthe usertodisconnecttheequipmentfromthetelephoneline.

NOTICE:

TheRingerEquivalenceNumber(REN)forthisterminalequipmentis0.0.TheRENassigned toeachterminalequipmentprovidesanindicationofthemaximumnumberofterminals allowedtobeconnectedtoatelephoneinterface.Theterminationonaninterfacemay consistofanycombinationofdevicessubjectonlytotherequirementthatthesumofthe RingerEquivalenceNumbersofallthedevicesdoesnotexceedfive.

CAUTION:

Forsafety, users should ensure that the electrical ground of the power utility, the telephonelines and themetallic water pipes are connected together. Users should NOT attempt to make such connection themselves but should contact the appropriate electric inspection authority or electrician. This may be particularly important in rural areas.

CAUTION:

To reduce the risk of fire, use only 26AWG or larger telecommunications line cord.

For Authorized Repair Technicians Only

CAUTION:

For continued protection against risk of fire, replace only with the sametypeandratingfuse.

WARNING:

DangerofexplosionifLit hium(CMOS)batteryisincorrectlyreplaced.Replaceonly withthesameorequivalen ttyperecommendedbythemanufacturer.

Disposeofusedbatteries accordingtothemanufacturer'sinstruction.

FCCRegulatoryinformationfornotebookswithradiodevice

Federal Communications Commission statement

ThisdevicecomplieswithPart15ofFCCRules.Operationissubjecttothefollowing twoconditions:(1)thisdevicemaynotcauseinterference,and

(2) this device must accept any interference, including interference that may cause undesired operation of this device.

FCCInterferenceStatement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference or radiocommunication.

However, there is no guarantee that interference will not occur in particular installation.

If this equipment does cause harmful interference or radioortelevision reception, which can be determined by turning the equipment off and, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorientorrelocatethereceivingantenna.
2. Increase the distance between the equipment and thereceiver.
3. Connect the equipment to an outlet on a circuit different from the one there receiver is connected to.
4. Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Pleasenotethefollowingregulatoryinformationrelatedtotheoptionalradiodevice.

FCCRadioFrequencyExposurestatement

This radiodevice has been evaluated under FCC Bulletin OET65 Cand found compliant with the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF

Exposure from radio frequency devices. The radiated output power of this radio device is far below the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a manner that the potential for human contact during normal operation is minimized. When using this device, a certain separation distance between antenna and near by person must be maintained to ensure RF exposure compliance. In order to comply with RF exposure limits established in the ANSI C95.1 standards, the distance between the antennas and the user should not be less than 20 cm (8 inches).

RegulatoryNotesandStatements

Radiodevice, Health and Authorization for use

Radiofrequencyelectromagneticenergyisemittedfromtheradiodevices.Theenergylevelsof these emissions, however, are far much less than the electromagnetic energy emissions from wirelessdevicessuchasmobilephones.Radiodevicesaresafeforusebyconsumersbecause they operate within the guidelines found in radio frequency safety standards and recommendations.

The use of theradiodevices may be restricted in some situations or environments, such as:

• onboardanairplane, or
•inanexplosiveenvironment,or
•insituationswheretheinterferencerisktootherdevicesorservicesis perceivedoridentifiedasharmful.

In cases in which the policy regarding use of radio devices in specific environments is not clear (e.g., airports, hospitals, chemical/oil/gas industrial plants, private buildings), obtain authorizationousethesedevicespriortooperatingtheequipment.

RegulatoryInformation/Disclaimers

Installation and use of this radio device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications made to this device that are not expressly approved by the manufacturer may void the user's authority to operate the equipment. The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution or attachment of connecting cables and equipment other than those specified by the manufacturer. It is the responsibility of the user to correct any interference caused by such unauthorized modification, substitution or attachment. The manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failure to comply with these guidelines.

Exportrestrictions

Thisproductorsoftwarecontainsencryptioncodewhichmaynotbeexportedor transferredfromtheUSorCanadawithoutanapprovedUSDepartmentofCommerce exportlicense. ThisdevicecomplieswithPart15ofFCCRules,aswellasICES003B/NMB003B.Operationissubjecttothefollowingtwoconditions:

(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesirable operation.

Modifications not expressly authorized by Fujitsu Technology Solutions may invalidatetheuser'srighttooperatethisequipment.

Stichwörter

56k-Modem30

A

Akku

Aufladen17

Regulatoryinformation

Notebookswithradiodevice71

Notebookswithoutradiodevice68

Reinigung5
