Product Type	Hi-Fi Mini System with CD/MP3/Bluetooth/FM Radio
Brand	Karcher Audio
Model	MC 6540BT
Dimensions (W x D x H)	352 x 85 x 196 mm
Power Supply	DC 9V 2.0A (external adapter)
Radio Frequency Range	FM 88 - 108 MHz
CD Playback	Yes (CD, CD-R, CD-RW)
USB MP3 Playback	Yes (USB flash drives)
Bluetooth Wireless Range	Approx. 10 meters
AUX Input	3.5 mm stereo input
Dual Alarm	Yes (Alarm 1 and 2)
Sleep Timer	Yes (10-90 minutes via remote)
Equalizer Presets	Flat, Rock, Classic, Pop, Jazz
Programmable Tracks	Up to 20 tracks
Repeat Modes	Single track, all tracks
FM Stereo/Mono	Selectable (FM ST button)
Radio Presets	Up to 20 presets
Display	LCD display
Remote Control	Yes (includes sleep timer control)
Clock	12/24 hour format
Snooze	Yes (9 minutes)
Cleaning	Wipe with dry cloth; do not use chemical cleaners
Safety	Do not expose to water or heat; use only specified power source
Laser Class	Class 1 (for CD)
Battery Disposal	Batteries not included; dispose according to local regulations

Frequently Asked Questions - MC 6540BT Karcher Audio

How do I set the clock?

Ensure the unit is in standby mode. Press the CLK SET button. Use the ◀/▶ buttons to select 12h or 24h format. Press CLK SET again, then set the hours with ◀/▶. Press CLK SET again to set minutes. Press CLK SET once more to confirm.

How do I set an alarm?

In standby mode, press and hold the ALARM 1 or ALARM 2 button for 2 seconds. Set the hour with ◀/▶, then press the alarm button again to set minutes. Press again to select wake mode: CD, RADIO, or BUZZER.

How do I pair a Bluetooth device?

Press FUNCTION to select Bluetooth mode (bT). Press PAIR. On your device, search for MC 6540BT in Bluetooth settings. If a passcode is requested, enter 0000. Once connected, the Bluetooth light stays on.

Why is my CD not playing?

Check that the CD is inserted with the printed side facing outward. Ensure the disc is not scratched or dirty. Try cleaning it with a soft cloth from the center outward. Also ensure the CD is compatible (CD, CD-R, CD-RW).

How do I store radio presets?

Tune to the desired station. Press and hold the PRESET button until the preset number flashes. Use ◀/▶ to select a preset location (P01-P20), then press PRESET again to confirm.

How do I use the sleep timer?

While playing, press the SNOOZE button on the remote control repeatedly to select 90, 80, ... 10 minutes. The display shows SLEEP. To cancel, press until 00 appears.

Can I use a USB extension cord for the USB port?

No. The USB port only supports direct connection of standard USB flash drives. Extension cords are not supported and may cause playback issues.

How should I clean the unit?

Always unplug the unit before cleaning. Wipe the exterior with a dry, clean cloth. Do not use chemical cleaners or detergents, as they may damage the surface.

What should I do if the unit does not turn on?

Check that the DC adapter is properly connected to the unit and a working wall outlet. Ensure the outlet supplies the correct voltage. If the unit still does not power on, contact qualified service personnel.

How can I prevent hearing damage?

Start with a low volume and increase slowly. Do not listen at high volume for extended periods. If you hear ringing or discomfort, reduce the volume immediately. Refer to the hearing safety section in the manual.

USER MANUAL MC 6540BT Karcher Audio

1. Read Instructions - All the safety and operating instructions should be read before the appliance is operated.
2. Retain Instructions - The safety and operating instructions should be retained for future reference.
3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to.
4. Water and Moisture – Do not use the apparatus near water (e.g. bath tub, sink, swimming pool) or in wet places or tropical climates. Do not place objects filled with liquids, such as vases, on top of the apparatus. Do not expose the apparatus to dripping or splashing.
5. Setup – The apparatus should only be placed on a stable, flat surface. Do not let the apparatus fall down or expose it to shock.
6. Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.
7. Ventilation - The appliance should be situated so that its location or position does not interfere with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or, placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.
   Ensure a minimum distance of 5 cm around the apparatus for sufficient ventilation. Ensure that the ventilation is not impeded by covering the ventilation openings with items such as newspapers, table-cloths, curtains, etc.
8. Heat - The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat.
9. Power Sources - The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance.
10. Cables and Plugs – The mains plug shall remain readily operable. All cables should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
11. Cleaning - The appliance should be cleaned only as recommended by the manufacturer. Clean by wiping with a dry and clean cloth. Do not use chemical cleaners or detergents. Always pull the mains plug before cleaning the unit.
12. Non-use Periods - The power cord of the appliance should be unplugged from the outlet when left unused for a long period of time.
13. Object and Liquid Entry - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings.
14. Damage Requiring Service - The appliance should be serviced by qualified service personnel when:
    a) The power-supply cord or the plug has been damaged; or
    b) Objects have fallen, or liquid has been spilled into the appliance; or
    c) The appliance has been exposed to rain; or
    d) The appliance does not appear to operate normally or exhibits a marked change in performance; or
    e) The appliance has been dropped, or the enclosure damaged.
15. Servicing - The user should not attempt to service the appliance beyond that described in the operating instructions. All other servicing should be referred to qualified service personnel.
16. Open Fire – Keep the apparatus away from open fires. Do not place naked flame sources, such as lighted candles on the apparatus.
17. Thunderstorms – During a thunderstorm the mains plug should be unplugged.
18. Safety Check – After servicing the technician should conduct a safety check in order to ensure that the apparatus is working properly and safely.

19. Batteries – Always place batteries in the correct polarization into electrical components. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. Do not mix old and new batteries. Take attention to the environmental aspects of battery disposal. Batteries shall not be exposed to excessive heat such as sunshine, fire or the like. Remove batteries before disposing of the product.

20. Volume Levels – To prevent possible hearing damage, do not listen at high volume levels for long periods.

21. Headphones (if applicable) – Excessive sound pressure from earphones and headphones can cause hearing loss.

WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to dripping or splashing.

WARNING: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer servicing to qualified service personnel.

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

DO NOT STARE INTO BEAM – INVISIBLE LASER RADIATION

Batteries

Batteries may not be disposed of in regular house hold trash. Every consumer has the obligation to return batteries to special disposal locations.

Disposal of Used Electrical & Electronic Equipment

The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste. Please, dispose of this equipment at your applicable collection point for the recycling of electrical & electronic equipments waste. By ensuring the correct disposal of this product, you will help prevent potential hazards to the environment and to human health, which could otherwise be caused by unsuitable waste handling of this product. The recycling of materials will help conserve natural resources. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

1. Handling discs

• Always keep the CD compartment shut to prevent dust or dirt from getting into the CD mechanism.
- Do not touch the recorded surface.
- Do not stick paper or write on either side of the CD.
- Do not bend the CD.
- Only handle a disc on its outer edges.

1. Storing discs

• To avoid scratches/damages always put CDs back into their cases after use.
- Do not expose CDs to direct sunlight, dust, dirt, high temperatures, high humidity or water.

1. Cleaning discs

2. Use a soft cloth to wipe fingerprints and dust from the disc surface.

3. Carefully move the cloth from the center of the disc to its edge:

Correct False

- Never use benzene, thinners, record cleaner fluid or antistatic spray to clean CDs.

1. Compatibility
2. Due to the numerous compression methods, some discs may not play.

NOTES ABOUT THIS INSTRUCTION MANUAL

1. This instruction manual is published by the manufacturer without any warranty. Corrections and changes of this instruction manual for the removal of typographic mistakes and editorial inaccuracies as well as due to (technical) improvements (changes) of the devices can be done by the manufacturer at any time without announcement. Changes of this kind are considered in future versions of this user manual. All rights reserved.
2. All figures are only for illustration and do not always show the exact representation of the product.
3. This unit is not intended for use by persons (including children) with reduced physical, sensory, or mental capacities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the unit.

FURTHER NOTES ON THE DEVICE

Setting a safe volume level

• If you continually listen to loud music, your hearing gradually adapts to it and gives you the impression that the volume is lower.
• What seems normal to you can be already for long time too loud and unhealthy.
• To protect yourself from this, set the volume to a low level.
- Increase the volume slowly.
- Damage to your hearing can be extensive and cannot be reversed.
• If you notice a hearing problem, please consult a doctor.

Condensation

- Condensation may occur when moving the device from a cold to a warm environment. If there is moisture inside the player, it may not operate properly. Don't turn on the device and wait about one hour for the moisture to evaporate.

Saving energy

- If the unit is not used for a long period of time, it should be unplugged from the AC socket

Unpacking

• Take out carefully the unit from the packing. Please keep the packing for further use.
- Carefully remove possible protection cardboards and slipcovers.

Location Of Controls

1. SNOOZE / VOLUME-
2. SNOOZE / VOLUME+
3. STANDBY button
4. FUNCTION button
5. EQ / CLK SET button
6. FM-ST / REPT. button
7. PRESET / PROG. button
8. ALARM 1 / ALARM 2 button

9. PAIR / STOP ■ button

10. PLAY/PAUSE ▶ button

11. ▲JECT button

12. SKIP Hutton

13. SKIP ▶ button

14. AUX Input

15. DC power input

16. Speakers

17. LCD display

18. USB port
19. ⬤JECT button
20. FUNCTION button
21. MUTE button
22. VOLUME+ button
23. SKIP ▶ button
24. VOLUME-button
25. INFO button
26. EQ button
27. SLEEP button
28. SNOOZE button
29. STANDBY button
30. PLAY/PAUSE ▶Button
31. CLK SET button

32. PAIR button

33. SKIP Hutton

34. STOP ■ button
35. PROG / PRESET button
36. FM ST button
37. REPEAT button
38. ALARM 2 button
39. ALARM 1 button
40. Antenna
41. Bluetooth pairing light
42. Folder
43. +10

Power Supply

• The unit requires DC 9V 2.0A .
- Plug the supplied adaptor cable into the connector on the back of the unit and the other end into a suitable wall socket.
• Make sure that the output power of the wall outlet matches the required power of the adaptor.
- Adaptor must be plugged in to operate. The unit does not operate on batteries.

Basic Functions

Switching the Unit On & Off

1. Power the unit as described above.
2. The unit is now in standby mode and the time will be shown in the display.
3. To switch the unit on, press the STANDBY button.
4. To switch the unit off into standby mode, press the STANDBY button once again.

Clock Setting

The clock can only be set while the unit is in standby mode.

1. While the unit is in standby mode, press the CLK SET button. The time format will be shown.
2. Select between 12h display and 24h display by pressing the /←buttons.
3. Press the CLK SET button again. The hours will start flashing.
4. Set the current hours by pressing the /buttons.
5. Press the CLK SET button again. The minutes will start flashing.
6. Set the current minutes by pressing the /◀buttons.
7. Press the CLK SET button again to confirm all settings. The time is now set.

Alarm Setting

An alarm can only be set while the unit is in standby mode.

This unit enables you to set 2 separate alarms. You can select to wake to CD, radio or buzzer.

1. While the unit is in standby mode, press and hold for 2 seconds the ALARM 1 or ALARM 2 button. The symbol 📋 (or ) and the hour of alarm 1 (or alarm 2) will flash.
2. Set the desired hour by pressing the /buttons.
3. Press the ALARM 1 (or ALARM 2) button again. The minutes will start flashing.
4. Set the desired minutes by pressing the /buttons.
5. Press the ALARM 1 (or ALARM 2) button again to select the wake up mode.
6. Select between CD, radio, or buzzer by pressing the /buttons.

Activating/Deactivating an Alarm

- To activate a previously set alarm, press the respective ALARM button (1 or 2) while the unit is in standby mode. The alarm symbol 🔒 (or ) appears in the display. This alarm will now ring at the previously set time.

- To deactivate a set alarm, press the respective ALARM button (1 or 2) while the unit is in standby mode. The alarm symbol 🔒 (or ) will disappear from the display. This alarm is now deactivated and will not ring.

Checking a Set Alarm

- Press the INFO button to check at what times and modes the alarms are set.

Stopping an Active Alarm

- When the alarm is sounding, press the ALARM 1 or ALARM 2 button to turn it off. The alarm icon will disappear from the display. You must activate the alarm again in order for it to function again the next day.

Snooze Function

The snooze function allows you to delay an active alarm for 9 minutes. To do so, press the SNOOZE button once while the alarm is active. The alarm will stop and come on again after 9 minutes. The alarm icon will be flashing during this period. To turn off this function, press the respective ALARM button (1 or 2).

Sleep Function (via Remote Control)

The sleep function enables you to set a countdown timer after which the unit will turn itself into standby mode automatically.

• While listening, repeatedly press the SNOOZE button on the remote control to select a desired countdown after which the radio will turn itself off automatically.
  • You can select 90, 80, 70, 60, 50, 40, 30, 20 or 10 minutes. "SLEEP" will be shown in the display.
  • To check the remaining time on the countdown, press the SNOOZE button once.
• If you want to cancel the function, press the SNOOZE button repeatedly until "00" appears in the display. "SLEEP" will disappear from the display.

Equalizer Presets

While listening, repeatedly press the EQ button to change the euqalizer preset. You can select between Flat, Rock, Classic, Pop, Jazz.

Radio

1. Switch the unit on as described previously.
2. Press the FUNCTION button repeatedly to select "RADIO". The frequency will be shown in the display.
3. Select a desired radio station by pressing the ◀ button repeatedly.
4. To automatically search for the next available radio station, press and hold for 2 seconds the or ▶button.
5. If a station is broadcasting stereo, you can press the FM ST button for best sound. If a station is broadcasting in mono, it is usually better to turn FM ST off.
6. For the best FM reception completely unroll the FM wire antenna.

Radio Station Presets

This unit enables you to store up to 20 radio stations.

1. Tune to a radio station which you would like to store.
2. Press and hold for 2 seconds the PRESET button. The presets will start flashing (e.g. "P01").
3. Select a desired preset place from P01 - P20 on which you want to store the current frequency by pressing the left button.
4. Press the PRESET button again to confirm your setting.
5. Repeat steps 1 - 4 to store up to 20 frequencies.
6. To recall a stored frequency, repeatedly press the PRESET button until you reach the desired preset.

CD Operation

Playing Discs

1. Switch the unit on and select the CD mode by pressing the FUNCTION button.
2. Press the ELECT button to open the CD compartment.
3. Insert a disc with the printed side facing outward.
4. Press the ELECT button again to close the CD compartment.
5. The CD is being read and the total no. of tracks will be displayed.
6. Press the PLAY/PAUSE button to start the playback.

7. To temporarily stop the playback (pause), press the PLAY/PAUSE ▶II button once. Press the button again to resume playback.

8. To stop playback, press the STOP ■ button.

Fast Forward / Fast Rewind & Skipping Tracks

• To jump to the beginning of the currently playing track, press the ◀ button once. Press it a second time to skip to the previous track.
• To skip to the next track, press the button once.
• To fast forward the currently playing track, press and hold the ▶ button. Once you reach the desired section of the track, release the button to resume normal playback.
• To fast rewind the currently playing track, press and hold the button. Once you reach the desired section of the track, release the button to resume normal playback.

Repeat Modes

At any time during playback,

• press the REPEAT button once to repeat the current track. "REPT. 1" will be shown in the display.
• press the REPEAT button twice to repeat all tracks. "REPT. ALL" will be shown in the display.
• press the REPEAT button a third time to deactivate the repeat function.

Programming Track Order

You may store up to 20 tracks in a desired sequence.

1. While in CD stop mode, press the PROG. button. "PROG." will be flashing and "P-01" will be shown.
2. Using the and buttons, select the track to be played first in the sequence.
3. Press the PROG. button again. "P-02" will be shown in the display.
4. Repeat the steps 2 - 3 to select up to 20 tracks for your sequence.
5. Press the PLAY/PAUSE ▶II button to start the playback of your sequence.
6. To delete your sequence, press the STOP ■ button twice.

USB MP3 Playback

This unit is equipped with a USB socket which can accept and play MP3 files stored on standard USB flash drives (also known as “pen drives”) which are for memory storage.

1. Insert a suitable USB flash drive into the USB port on the unit.
2. Switch the unit on and select the USB mode by pressing the FUNCTION button.
3. The USB flash drive will be read and the total number of tracks will be shown in the display.
4. Press the PLAY/PAUSE button to start the playback.
5. To temporarily stop the playback (pause), press the PLAY/PAUSE ▶II button once. Press the button again to resume playback.
6. The basic skip and search functions are the same as in CD mode.
7. If there are several folders stored on your USB device, you can select between these by repeatedly pressing the FOLDER button.
8. To skip 10 tracks at once, press the +10 button.
9. To stop playback, press the STOP ■ button.

Notes:

• A USB device must always be connected directly to the USB port of this product. The use of a USB extension cord is not supported by this product. The USB port of this product cannot communicate with a computer directly.
• The reading time for a USB drive varies depending on the speed of the memory device and the number of songs and folders. In some cases the reading time may be as long as 60 seconds.
• Always switch off the unit before removing a USB flash drive to prevent damage to your USB device or memory card. The manufacturer is not responsible for the loss or damage of data.
• This unit does not support USB MP3 players due to their inherent lack of software compatibility. Only USB “pen drives” (flash memory usb drives) can be used for MP3 playback.
• Only MP3 files can be played. Due to numerous methods of compression it could be that some files or USB flash drives cannot be played.

This unit can wirelessly stream audio from any Bluetooth ^® device within approximately 10 metres. Obstacles such as walls and other devices may limit this range.

Simply pair the device and enjoy wireless playback and control from your compatible Bluetooth ^® device.

1. Switch the unit on and select the Bluetooth ^ mode "bT" by pressing the FUNCTION button.
2. Turn on the Bluetooth ^® function in your device. Please refer to your device's manual for further details.

3. Press the PAIR button.
   Pairing with a new device for the first time: BT pairing light flashes slowly. Connecting to an already paired device: BT pairing light flashes fastly.

4. Go to your device's Bluetooth ^® settings.

Add or search for devices. When the model no. "MC 6540BT" appears, select the device. If asked for a pass code, enter "0000".

1. Once a device is connected, the BT pairing light will be lit steadily.

2. You can now play music on your device, it will be heard over the unit speakers.

3. Next time you switch on the unit, it will connect to the last paired device.

Note: Only one device can be paired and played at a time.

Volume Control

Increase and decrease the volume using the VOL+ and VOL- buttons on the unit/remote control and using the volume controls on your device.

Note: If there is no playback, ensure that neither the unit nor your Bluetooth® device are set to zero volume and the right device for playback is paired.

Additional Guidelines for Bluetooth® Devices

- The short wave radio signals of a Bluetooth and medical devices.

- Switch off the device where it is prohibited.

® device may impair the operation of other electronic

Compatibility Disclaimer

- Wireless performance is dependent on your device's Bluetooth ^ wireless technology. Refer to your device's user manual.

- The manufacturer cannot be held liable for any loss or leakage of or damage to data.

AUX Input

You can connect the audio output of an external device such as an MP3 player to this unit to listen to the sound of that device through the amplifier of this music system.

• To connect the external device please use a standard stereo audio cable (3.5 mm to 3.5 mm plugs) (not included) to connect the headphone out or audio line out of the external device to the AUX input socket of this unit.
• Switch the unit on and select the AUX mode "LINE" by pressing the FUNCTION button.
• Switch the external device (e.g. MP3 player) on.
• Start playback of the external device and adjust the volume control of the main unit to the desired level.
• Remember to switch off the unit when you are finished using the external device.

Specifications

Power Supply: DC 9V--2.0A (external adaptor)

Radio Frequency Range: FM 88 - 108 MHz

Dimensions (WxDxH) ca.: 352 x 85 x 196 mm

Technical specifications and design may change without notice.

We, Karcher AG, herewith confirm that this product is in line with the basic requirements of regulation 1999/5/EG and further relevant regulations.

A copy of the declaration of conformity can be obtained at the following address:

Or online at the following link:

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Karcher is under license. Other trademarks and trade names are those of their respective owners.

Bluetooth® QDID: B019664

Karcher

www.karcher-products.de
