Type of product	Hand blender
Brand	Gastroback
Model	Design Hand Blender Advanced Pro 40975
Power consumption	1000 W
Voltage	220-240 V, 50-60 Hz
Dimensions (approx.)	40 x 7 x 7 cm (length x width x height)
Weight (approx.)	1.2 kg
Cord length	1.2 m
Blending shaft material	Stainless steel
Housing material	High-quality plastic
Variable speed control	Yes, with 12 speeds
Turbo boost function	Yes
Attachments included	Blending shaft, whisk, chopper attachment, 600 ml beaker
Safety features	Overload protection, non-slip handle, safety switch
Dishwasher safe parts	Yes, all detachable parts (blending shaft, whisk, chopper, beaker)
Warranty	2 years

Frequently Asked Questions - Design Hand Blender Advanced Pro 40975 Gastroback

How do I clean the hand blender?

Detach the blending shaft and other accessories. Rinse them under running water or place them in the dishwasher (top rack). Wipe the motor unit with a damp cloth. Do not immerse the motor unit in water.

Can I blend hot liquids?

Yes, but allow liquids to cool to at least 60°C before blending to avoid splashing and damage. Do not overfill the beaker.

What attachments are included?

The set includes a stainless steel blending shaft, a whisk for whipping cream and eggs, a chopper attachment for nuts and vegetables, and a 600 ml beaker.

How do I use the turbo boost function?

Press the turbo boost button on the handle to activate maximum power for short bursts. Ideal for crushing ice or tough ingredients.

Is the hand blender suitable for crushing ice?

Yes, with the turbo boost function and stainless steel blade, it can crush ice cubes. Do not operate longer than 30 seconds continuously.

What is the warranty period?

The Gastroback Design Hand Blender Advanced Pro comes with a 2-year warranty against manufacturing defects.

Can I use the blender in a pot or pan?

Yes, the blending shaft is long enough to reach into pots. Ensure the pot is heat-resistant and not non-stick coated to avoid scratching.

How do I change the speed?

Use the slider on the handle to adjust speed from 1 (low) to 12 (high). The device includes a variable speed control for precise blending.

What does the overload protection do?

If the motor overheats or is overloaded, it will automatically shut off. Allow the blender to cool for 15 minutes before restarting.

Are spare parts available?

Yes, replacement blending shafts, whisks, choppers, and beakers can be purchased from Gastroback customer service or authorized dealers.

USER MANUAL Design Hand Blender Advanced Pro 40975 Gastroback

Black and silver kitchen brush with a blue circular button and 'BALTIMBACK' branding on the stand (no text-heavy elements)

Close-up of a metallic circular object with internal patterns, possibly a lens or dial (no visible text or symbols)

Close-up of a metallic object with a star-like pattern, possibly a lens or dial (no text or symbols visible)

Close-up of a wireframe mechanical component with no visible text or symbols

Close-up of a black and transparent plastic kitchen brush (no text or symbols visible)

Zerkleinerer

Glass of orange juice with a dark base, no text or symbols visible

Mixbehälter

Black and silver kitchen brush with a blue handle and perforated base (no visible text or symbols)

Read all provided instructions before first use!

Model and attachments are subject to change!

For household use only!

TABLE OF CONTENTS

KNOWING YOUR DESIGN HAND BLENDER ADVANCED PRO....26

IMPORTANT SAFEGUARDS 27

Safeguards for daily operation 27

Important safeguards for all electrical appliances....30

Moving parts – risks of injuries to persons 31

TECHNICAL SPECIFICATIONS....32

OPERATION 32

Before first use....32

Using the stainless steel blender.... 33

Using the stainless steel whisk 34

Using the mashed potatoes attachment 36

Using the chopper attachment 37

CARE AND CLEANING....40

STORAGE....42

NOTES FOR DISPOSAL....42

INFORMATION AND SERVICE 42

WARRANTY 43

DEAR CUSTOMER!

Congratulations! Your new Design Hand Blender Advanced Pro comes with some remarkable features for preparing your dishes.

The appliance is designed for mixing and stirring of liquid foods, and for pureeing and chopping of not very hard foods such as carrots, potatoes, meat and other. Your new Design Hand Blender Advanced Pro is perfectly suited for mixing drinks and milkshakes as well as preparing dips, sauces, soups, mayonnaise and baby food.

There is no need to fill the food in a special vessel, just use any suitable vessel you have at your disposal, for example, process soups and sauces directly in the coo-king pot.

The chopper attachment processes nuts, herbs and spices for a delicious modern way of cooking.

The powerful 800 W motor handles the tasks in seconds. The stainless steel blades of the blender stick and chopper are very robust.

These instructions for use will inform you about the various functions and features, which make it easy to take pleasure in your new hand blender.

We hope that you will enjoy your new hand blender.

Your Gastroback GmbH

KNOWING YOUR

DESIGN HAND BLENDER ADVANCED PRO

Variable Speed Switch

Speed continuously adjustable (scale 1-5)

LED Bluelight Start Button

ON/OFF-Button

Ergonomic Soft Touch Handle

For safe and comfortable application

800 Watt Motor Power

Release-Buttons

For changing and removing accessories

Stainless Steel Blender

Easy and quick to change

Attachments

Close-up of a metallic mechanical component with reflective surfaces (no visible text or symbols)

Close-up of a metallic object with a star-like symbol on its surface (no text or symbols visible)

Abstract wireframe illustration of a mechanical or fluid system with no visible text or symbols

Close-up of a black and transparent kitchen blender with a central handle (no text or symbols visible)

Chopper

(500 ml) with non-slip lid e.g. Parmesan cheese, chocolate shavings (dishwasher safe)

Glass of orange-colored beverage on a dark base (no text or symbols visible)

MixingVessel

(800 ml) with non-slip lid perfect for preparing sauces, dips, baby food, shakes or smoothies, suited for storing in the fridge (dishwasher safe)

IMPORTANT SAFEGUARDS

Carefully read all instructions before operating and save the instructions for future reference. Do not attempt to use this appliance for any other than the intended use, as described in these instructions. Any other use, especially misuse, can cause severe injury or damage by electric shock, fire or moving mechanical parts. Never leave the appliance unattended when in operational mode.

These instructions are an essential part of the appliance. Do not pass the appliance without this booklet to third parties.

Any operation, repair and technical maintenance of the appliance or any part of it other than described in these instructions may only be performed at an authorised service centre. Please contact your vendor.

• The appliance is designed for normal household quantities. Do not operate or store the appliance outdoors or in damp or wet areas. Do not use the appliance on boats or moving vehicles.
• Do not attempt to operate the appliance using any parts or accessories not recommended by the manufacturer. Do not operate the appliance, when the appliance or any part of it is likely to be damaged, to avoid risk of fire, electric shock or any other damage or injury to persons. Do not attempt to open the motor housing or to repair the power cord. Check the entire appliance regularly for proper operation. The appliance is likely to be damaged if the appliance was subject to inadmissible strain (i.e. overheating, mechanical or electric shock) or if there are any cracks, excessively frayed parts, distortions or the gear stalls or sticks. In this case, immediately unplug the appliance and return the entire appliance (including all parts and accessories) to an authorised service centre for examination and repair.

- The appliance is suited for processing normal household quantities of food.

Note:

The appliance is suited only for short-time operating. Use the appliance for no longer than 1 minute, and don't operate hard food for no longer than 10 seconds. If processing large quantities of food, regularly interrupt the operation and unplug the appliance for a few minutes, allow the motor to cool down.

- Do not leave the appliance unattended while it is plugged into the power outlet.

- Before use, always make sure that the appliance is properly and completely assembled (see >Operation<). Do not leave any food to dry on the surfaces of the appliance.

- Always ensure, that the appliance is assembled correctly before connecting the appliance to the mains power supply. Always handle the entire appliance and the tools with care and without violence.

- Do not lift, pull or carry the appliance by the accessories. To move or operate the appliance, always hold on to the motor housing.

- Do not touch the blades or the whisk while the appliance is connected to the power outlet. Do not hold any foreign objects into the blender, whisk or the chopper attachment while the appliance is connected to the power outlet.

- Do not use any fragile vessels with the appliance (i.e. fine drinking glasses or china). We recommend using medium-sized stainless steel or plastic vessels (such as the vessel provided). During operation, ensure that the processing tool will not touch the interior of the vessel.

- Close supervision is necessary when the appliance is used near young children. Do not let young children play with any parts of the appliance or the packing. The appliance is not intended for use by children or infirm persons without supervision. Take care that no one pulls the appliance by the power cord, especially when young children are near. Place the appliance on a clean, dry and stable surface where it is protected from inadmissible strain (i.e. mechanical or electric shock, overheating, frost, moisture) and where young children cannot reach it.

- The blades are very sharp. Do not touch the blades. Always handle the blades with great care to avoid any injuries.

- Operate the appliance on a well accessible, stable, level, dry, and suitable large table or counter that is resistant against water, fat, and heat. If you are working with hot ingredients, pay attention not to hold the appliance (the motor block) directly into the hot steam to avoid condensation as far as possible. Do not place the appliance near the edge of

the table or counter or on inclined or wet surfaces or where it can fall.

- Always release the ON-button, unplug the appliance, wait for the motor to reach standstill, before taking off or assembling any accessories, and placing the appliance on a suitable surface, where it cannot fall.

- Do not place the appliance or any part of it in a range, or on or near hot surfaces (e.g. burner, heater or oven).

- Do not immerse the motor housing or power cord in water or any other liquid. Do not pour or drip any liquids on the motor housing or power cord. When liquids are spilled on the motor housing, immediately unplug the appliance and dry the motor housing to avoid risk of electric shock or fire. Do not attempt to operate the appliance, when liquids are on or in the motor housing. With the appliance connected to the power supply, do not touch the appliance with wet hands or when the appliance is damp or wet or is touching wet surfaces. In this case do not touch the appliance but immediately unplug the power cord from the power supply and dry the appliance (see >Care and cleaning).

- Do not clean the motor block, the power cord or the whisk holder in an automatic dishwasher!

- To avoid damage, do not use any abrasive cleaners, corrosive chemicals (i.e. disinfectants, bleach) or cleaning pads for operation or cleaning. Do not use any hard or sharp utensils for operation or cleaning.

- The appliance is intended for blending and mixing food. Do not use the appliance for any other purpose.

- The appliance is not suited for chopping extremely hard food, such as nutmeg, coffee beans and grain.

- Do not operate the appliance, when the appliance or any part of it is likely to be damaged, to avoid risk of fire, electric shock or any other injuries to persons and/or damage. The appliance or its parts are likely to be damaged, if the appliance has been subject to inadmissible strain (e.g. overheating, mechanical or electric shock), or if there are any cracks, excessively frayed or melted parts, or distortions, or if the

appliance is not working properly. If one of these cases occur during operation, immediately unplug the appliance. Get in contact with an authorized service centre for examination and/or repair. Never operate the appliance with broken or crooked tools to avoid injuries trough moving parts and overheating of the appliance.

• Always immediately unplug the appliance after use and before assembling or dismantling the appliance and its tools and before laying down the appliance.
• Before operation, always ensure that the appliance is assembled and connected completely and correctly according to the instructions in this booklet. Do not handle the appliance or any part of it with violence. Do not let remains of the food dry on the appliance and its tools.
• Do not hold your hands or any foreign objects (e.g. clothes, cooking utensils) on the appliance, with the appliance connected to the power supply.

IMPORTANT SAFEGUARDS FOR ALL ELECTRICAL APPLIANCES

Ensure that the voltage rating of your mains power supply corresponds to the voltage requirements of the appliance (220/240 V, 50/60 Hz, AC). Always connect the appliance directly to a mains power supply wall socket with protective conductor (earth) connected properly. Do not use any multiple electrical adapters. The installation of a residual current safety switch with a maximum rated residual operating current of 30 mA in the supplying electrical circuit is strongly recommended. If in doubt, contact your local electrician for further information.

- In various foreign countries, the specifications for power supplies are subject to incompatible norms. Therefore it is possible that power supplies in foreign countries do not meat the requirements for safe operation of the appliance. Thus, before operating the appliance abroad, ensure that safe operation is possible.

- Do not leave the appliance unattended while connected to the power supply. Always release the ON-button and immediately unplug the appliance after operation and if it is not in use and before laying it down, cleaning and/or assembling or dismantling. Always grasp the

plug to disconnect the appliance from the power outlet.

• The appliance is only suited for household use only.
• Always handle the power cord with care. Do not pull or strain the power cord. The power cord may never be knotted or squeezed. Do not let the power cord hang over the edge of the table or counter. Take care not to entangle in the power cord.
• Do not touch the appliance with wet hands to avoid risk of electric shock. Do not touch the appliance, when it is damp or wet and connected to the mains power supply. In this case, immediately unplug the appliance.

MOVING PARTS - RISKS OF INJURY TO PERSONS

• The blades are extremely sharp. Do not touch the blades with your hands or any other objects (hair, clothes, brushes, cooking utensils), when the appliance is connected to the power supply. Always handle the tools of the appliance with care and without violence to avoid injury to persons and damage. Always ensure, that the appliance is assembled correctly, before connecting the appliance to the mains power supply.
• Before switching on the appliance, always immerse the blender blade or in the food, to avoid excessive splashing. Do not immerse the processing tool too deep (max. half height of the processing tool).

TECHNICAL SPECIFICATIONS

Model:	Art. No. 40975 Design Hand Blender Advanced Pro
Power supply:	220-240 V AC, 50/60 Hz
Maximum power consumption:	800 W
Length of power cord:	approx. 130 cm
Weight:	motor block: approx. 775 g stainless steel blender: approx. 200 g stainless steel whisk with holder: approx. 84 g mashed potatoes attachment: approx. 275 g mixing vessel: approx. 196 g chopper attachment (assembled): approx. 390 g
Dimensions:	motor block: approx. 50 x 210 mm (ø x H) stainless steel blender: approx. 65 x 220 mm (ø x H) stainless steel whisk with holder: approx. 60 x 240 mm (ø x H) mashed potatoes attachment: approx. 90 x 225 mm (ø x H) mixing vessel: approx. 105 x 210 mm (ø x H) chopper attachment (assembled): approx. 140 x 180 mm (ø x H)

OPERATION

BEFORE FIRST USE

⚠ WARNING: The blades are very sharp. Do not touch the blades. Always handle the tools by the shaft.

Remove all promotional materials and packaging from the appliance and its tools, but do not remove the rating label. Before first use and after a long period of storage, clean the appliance with a damp soft cloth and warm soapy water (see >Care and cleaning).

Note:

While pressing the ON-button the speed of the blade is adjustable with the variable speed switch.

USING THE STAINLESS STEEL BLENDER

The hand blender is perfectly suited for preparing dips, sauces, soups, mayonnaise and baby food as well as for mixing and milkshakes.

⚠ WARNING: Always release the ON-button, wait until the motor stops and unplug the appliance before lifting the blending tool out of the food, laying down the appliance or assembling/dismantling the blending tool.

Before connecting the appliance to the mains power supply, always ensure that the appliance is assembled correctly, according to the following instructions. Do not touch the blades of the blending tool with your hands or any objects (i.e. hair, clothes, tissue), when it is mounted and the appliance is connected to the mains power supply. Before pressing the ON-button, immerse the processing tool in the food (up to the half of its height at most), to avoid excessive splashing and dripping of liquids onto the appliance.

1. Prepare your food and fill it into a sufficiently large and high-sided vessel (like the vessel provided).

⚠ WARNING: The provided vessel is not heat resistant. The max. temperature is 70 degrees. Let the boiling food cool down a little bit before starting to blend.

1. Ensure, that the appliance is unplugged.
2. Place the shaft of the stainless steel blender onto the motor block and press together until it snaps into place. There may be no gap between the motor housing and the stainless steel blender. The blender shaft must be locked firmly and may not wobble.
3. Immerse the stainless steel blender into the food. Choose the speed with the variable control switch. It is to be expected, that the food will splash during operation. When processing hot meals, do not hold the appliance in the rising steam to avoid condensation on the motor housing. Immediately wipe off condensate on the motor housing. The lower part of the stainless steel blender should be always covered with food to avoid splashing.

Note:

Process food with a sufficient amount of liquid.

1. Connect the power plug to a suitable wall power outlet.
2. Hold on to the vessel with one hand and press the ON-button to start the motor. Slowly circle the blender during operation. Hold the hand blender upright in the mixing vessel during operation to avoid splashing.

⚠️ CAUTION: Do not use the appliance in continuous operation for more than 1 minute to avoid overheating. If processing large quantities of food, regularly interrupt the operation and unplug the appliance for a few minutes, allow the motor to cool down.

1. Blend your food to the desired quality but at least after 1 minute of continuous operation release the ON-button.
2. Wait until the motor stops, before you lift the blending tool out of the food.
3. Always unplug the appliance immediately after operation. Lay down the appliance on a stable, dry and clean surface, where it cannot fall.

⚠ WARNING: Always release the ON-button, wait until the motor stops completely and unplug the appliance before assembling or dismantling the blending tool.

1. Release the stainless steel blender from the motor block by pressing both release-buttons. Clean the appliance in accordance to the instructions in chapter >Care and cleaning>. Do not leave any food to dry on the surface of the appliance.

PROCESSING GUIDE FOR THE STAINLESS STEEL BLENDER

food max. amount max. operation preparation
boiled potatoes 100 g 1 min.	2 cm
boiled onion 100 g 1 min.	2 cm
boiled carrots 100 g 1 min.	2 cm
lard 150 g 1 min. /
egg 1 l min. /
vinegar 14 g	1 min.

USING THE STAINLESS STEEL WHISK

Use the whisk only for whipping cream, beating egg whites and mixing sponges and ready-mix desserts.

⚠ WARNING: Always release the ON-button, wait until the motor stops and unplug the appliance before lifting the whisk tool out of the food, laying down the appliance or assembling/dismantling the whisk tool.

Before connecting the appliance to the mains power supply, always ensure that the appliance is assembled correctly, according to the following instructions. Do not touch the whisk tool with your hands or any objects (i.e. hair, clothes, tissue), when it is mounted and the appliance is connected to the mains power supply. Before

pressing the ON-button, immerse the processing tool in the food (up to the half of its height at most), to avoid excessive splashing and dripping of liquids onto the appliance.

1. Prepare your food and fill it into a sufficiently large and high-sided vessel (like the vessel provided).

WARNING: The provided vessel is not heat resistant. The max. temperature is 70 degrees. Let the boiling food cool down a little bit before starting to blend. The whisk holder is not dishwasher safe!

1. Ensure, that the appliance is unplugged.
2. Place the shaft of the stainless steel whisk into the whisk holder. Place the whisk holder onto the motor block and press together until it snaps into place. There may be no gap between the motor housing and the stainless steel whisk. The whisk holder must be locked firmly and may not wobble.
3. Immerse the stainless steel whisk into the food. Choose the speed with the variable control switch. It is to be expected, that the food will splash during operation. When processing hot meals, do not hold the appliance in the rising steam to avoid condensation on the motor housing. Immediately wipe off condensate on the motor housing. The lower part of the stainless steel whisk should be always covered with food to avoid splashing.
4. Connect the power plug to a suitable wall power outlet.
5. Hold on to the vessel with one hand and press the ON-button to start the motor. Slowly circle the appliance during operation. Hold the appliance upright in the mixing vessel during operation to avoid splashing.

CAUTION: Do not use the appliance with the stainless steel whisk in continuous operation for more than 2 minutes to avoid overheating. If processing large quantities of food, regularly interrupt the operation and unplug the appliance for a few minutes, allow the motor to cool down.

1. Blend your food to the desired quality but at least after 2 minutes of continuous operation release the ON-button.
2. Wait until the motor stops, before you lift the whisk out of the food.
3. Always unplug the appliance immediately after operation. Lay down the appliance on a stable, dry and clean surface, where it cannot fall.

⚠ WARNING: Always release the ON-button, wait until the motor stops completely and unplug the appliance before assembling or dismantling the tools.

1. Release the stainless steel whisk form the motor block by pressing both release-buttons. Clean the appliance in accordance to the instructions in chapter >Care and cleaning>. Do not leave any food to dry on the surface of the appliance.

PROCESSING GUIDE FOR THE STAINLESS STEEL WHISK

food max. amount max. operation
Egg frost 2 or 4 eggs 2 min.

USING THE MASHED POTATOES ATTACHMENT

This attachment is perfect for preparing mashed potatoes. It also can be used for preparing carrot mash. Make sure to use cooked food.

⚠ WARNING: Always release the ON-button, wait until the motor stops and unplug the appliance before lifting the mashed potatoes attachment out of the food, laying down the appliance or assembling/dismantling the mashed potatoes attachment.

Before connecting the appliance to the mains power supply, always ensure that the appliance is assembled correctly, according to the following instructions. Do not touch the whisk tool with your hands or any objects (i.e. hair, clothes, tissue), when it is mounted and the appliance is connected to the mains power supply. Before pressing the ON-button, immerse the processing tool in the food (up to the half of its height at most), to avoid excessive splashing and dripping of liquids onto the appliance.

1. Prepare your food and fill it into a sufficiently large and high-sided vessel (like the vessel provided).

⚠ WARNING: The provided vessel is not heat resistant. The max. temperature is 70 degrees. Let the boiling food cool down a little bit before starting to mash.

1. Ensure, that the appliance is unplugged.

2. Place the shaft of the mashed potatoes attachment onto the motor block and press together until it snaps into place. There may be no gap between the motor housing and the mashed potatoes attachment. The mashed potatoes attachment must be locked firmly and may not wobble.

3. Immerse the mashed potatoes attachment into the food. Choose the speed with the variable control switch. It is to be expected, that the food will splash during operation. When processing hot meals, do not hold the appliance in the rising steam to avoid condensation on the motor housing. Immediately wipe off condensate on the motor housing. The lower part of the mashed potatoes attachment should be always covered with food to avoid splashing.

Note:

Process food with a sufficient amount of liquid.

1. Connect the power plug to a suitable wall power outlet.
2. Hold on to the vessel with one hand and press the ON-button to start the motor. Slowly circle the appliance during operation. Hold the appliance upright in the mixing vessel during operation to avoid splashing.

Caution: Do not use the appliance in continuous operation for more than 1 minute to avoid overheating. If processing large quantities of food, regularly interrupt the operation and unplug the appliance for a few minutes, allow the motor to cool down.

1. Blend your food to the desired quality but at least after 1 minutes of continuous operation release the ON-button.
2. Wait until the motor stops, before you lift the mashed potatoes attachment out of the food.
3. Always unplug the appliance immediately after operation. Lay down the appliance on a stable, dry and clean surface, where it cannot fall.

⚠ WARNING: Always release the ON-button, wait until the motor stops completely and unplug the appliance before assembling or dismantling the tools.

1. Release the mashed potatoes attachment from the motor block by pressing both release-buttons. Clean the appliance according to the instructions in chapter >Care and cleaning>. Do not leave any food to dry on the surface of the appliance.

PROCESSING GUIDE FOR THE MASHED POTATOES ATTACHMENT

food max. amount	max. operation preparation
boiled potatoes 500 g	30 sec. 2 cm
boiled carrots 500 g	30 sec. 2 cm

USING THE CHOPPER ATTACHMENT

Chopper is perfectly suited for hard food, such as chopping meat, cheese, onion, herbs, garlic, carrots, walnuts, almonds, prunes etc.

Note:

Don't chop extremely hard food, such as ice cubes, nutmeg, coffee beans and grains.

⚠ WARNING: Always release the ON-button, wait until the motor stops and unplug the appliance before opening the chopper and taking out the food, laying down the appliance or assembling/dismantling the mini-chopper.

Before connecting the appliance to the mains power supply, always ensure that the appliance is assembled correctly, according to the following instructions. Do not touch the blade of the chopper with your hands or any objects (i.e. hair, clothes, tissue), when it is mounted and the appliance is connected to the mains power supply.

1. Prepare your food.

WARNING: The chopper vessel is not heat resistant. The max. temperature is 70 degrees. Let the boiling food cool down a little bit before filling it into the vessel.

1. Ensure, that the appliance is unplugged.

⚠ WARNING: The blade of the chopper is very sharp. Do not touch the blades. Always handle the tools by the shaft.

1. Place the blade of the chopper on the centre pin of the vessel. Than turn it clockwise to lock it into place. Always place the chopper vessel on the non-slip-rubber base to avoid injuries.
2. Place the prepared food into the chopper and place the lid onto the vessel. Fill the vessel only up to the 500 ml mark. Place the shaft of the chopper onto the motor block and press together until it snaps into place. There may be no gap between the motor housing and the chopper. The blender shaft must be locked firmly and may not wobble.
3. Choose the speed with the variable control switch.
4. Connect the power plug to a suitable wall power outlet.
5. Hold on to the chopper vessel with one hand and press the ON-button to start the motor.

CAUTION: Do not use the appliance with the chopper attachment in continuous operation for more than 1 minute to avoid overheating. If processing large quantities of food, regularly interrupt the operation and unplug the appliance for a few minutes, allow the motor to cool down.

1. Chop your food to the desired quality, but at least after 1 minute of continuous operation release the ON-button.

2. Wait until the motor stops. Always unplug the appliance immediately after operation or before assembling/disassembling the tools. By pressing both release-buttons remove the motor block from the chopper attachment and place the motor block on a suitable surface, where it cannot fall.

⚠ WARNING: Always release the ON-button, wait until the motor stops completely and unplug the appliance before assembling or dismantling the tools.

1. Clean the appliance in accordance to the instructions in chapter >Care and cleaning>. Do not leave any food to dry on the surface of the appliance.

PROCESSING GUIDE FOR THE CHOPPER ATTACHMENT:

food max. amount max. operation
meat 250 g 8 sec
herbs 50 g 8 sec
nuts 100 g 8 sec
cheese 100 g 5 sec
bread 80 g 5 sec
onions 150 g 8 sec
biscuits 150 g 6 sec
soft fruit 200 g 6 sec

CARE AND CLEANING

⚠ WARNING: To avoid injury to persons and damage, always release the ON-button, wait for the motor to stop completely and unplug the appliance immediately after operation and before laying down, dismantling or cleaning the appliance. With the appliance connected to the power supply, do not touch the assembled tool with your hands or any objects.

Note:

The blades are very sharp. Do not touch the blades. Always handle the tools by the shaft.

DO NOT clean the motor block, the stainless steel blender, the whisk holder, the chopper lid or the power cord in an automatic dishwasher. Do not immerse these parts in any liquids or spill any liquids on it. Always wipe off spilled liquids immediately. Do not pour or drip any liquids on the motor housing or power cord. Do not place the appliance on wet or damp surfaces. When liquids are spilled on the motor housing, immediately unplug the appliance and dry the motor housing to avoid risk of electric shock or fire. Always handle with care and without violence.

CAUTION: Do not use abrasive cleaners, cleaning pads, corrosive chemicals (disinfectants, bleach) or any sharp or hard objects (i.e. metal scouring pads) for cleaning, for this could damage the surfaces.

Note:

After processing very salty ingredients clean the appliance immediately to avoid stains and damage.

Carefully clean the appliance and the vessel with a damp sponge or cloth and warm soapy water. Soak stubborn residues on the processing tools in warm dish-water for ca. 10 minutes and then remove the residues with a soft washing brush.

1. Always release the ON-button, wait for the motor to stop completely and unplug the appliance from the power outlet before cleaning.

⚠️ CAUTION: Always handle with care and without violence. To disassemble the processing tools, press both release-buttons to release the lock.

1. Remove the used tool by pressing with one hand both release-buttons and grasping the shaft of the used tool with the other hand. Then remove the processing tool. Clear the leftover food with a plastic or wooden spoon, pay attention not to scratch the vessel to avoid damage.

2. Clean the processing tools with a soft nylon washing brush and warm dish-water. Rinse the processing tools thoroughly under running water. Pay attention to the blades to avoid injuries. Soak stubborn residues in warm dish-water for ca. 10 minutes before cleaning.

When processing strongly coloured food, colour change may occur on the plastic parts of the appliance. Wipe these parts with vegetable oil before cleaning these. The vessel may turn milky and dull over time. This will not affect the functions of the appliance.

1. Wipe the motor block and power cord with a damp soft cloth. Take care not to spill or drip water or any other liquids on the motor housing.
2. Thoroughly dry the motor block and all parts of the appliance. Possibly leave the appliance to air dry before assembling the appliance. Pay attention that all parts are out of reach for children.

The stainless steel whisk (not the whisk holder), the blade for the chopper and the chopper (not the chopper lid), the mixing vessel and both non-slip-rubber bases can be cleaned in the dishwasher.

STORAGE

Always clean the appliance before storing (see >Care and cleaning). Ensure to store the appliance where it is clean, dry and safe from frost, direct sunlight and inadmissible strain (mechanical or electric shock, heat, moisture) and where it is out of reach of young children. Place the appliance on a clean and stable surface, where it can not fall. Do not place any hard or heavy objects on the appliance. You may wind the power cord loosely around the motor housing.

To avoid touching the blades unintentionally, it is good advice to store the blade of the chopper in the chopper closed with the lid.

NOTES FOR DISPOSAL

Dispose of the appliance and packaging must be effected in accordance with the corresponding local regulations and requirements for electrical appliances and packaging. Please contact your local disposal company. Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills, dumps, or refuse incineration, hazardous substances can leak into the groundwater or can be emitted into air, thus getting into the food chain, and damaging your health and well-being. When replacing old appliances with new once, the retailer is legally obligated to take back your old appliance for disposal at least for free of charge.

INFORMATION AND SERVICE

Please check www.gastroback.de for further information. For technical support, please contact Gastroback Customer Care Center by phone: [phone] or e-mail [e-mail].

WARRANTY

We guarantee that all our products are free of defects at the time of purchase. Any demonstrable manufacturing or material defects will be to the exclusion of any further claim and within 2 years after purchasing the appliance free of charge repaired or substituted. There is no Warranty claim of the purchaser if the damage or defect of the appliance is caused by inappropriate treatment, over loading or installation mistakes. The Warranty claim expires if there is any technical interference of a third party without a written agreement. The purchaser has to present the sales slip in assertion-of-claim and has to bear all charges of costs and risk of the transport.

Note:

Customers from Germany and Austria: For repair and service, please send Gastroback products to the following address: Gastroback GmbH, Gewerbestr. 20, D-21279 Hollenstedt, Germany.

Customers from other countries: Please contact your dealer.

Please agree that we cannot bear the charge of receipt. Submission of appliances: Please ensure packing the appliance ready for shipment without accessories. Add the sales slip and a short fault description. The processing time after receipt of the defective appliance will be approx. 2 weeks; we will inform you automatically. After the warranty period, please send defective appliances to the given address. You will get a free quotation and, thereafter, can decide, whether we shall repair the appliance to the costs possibly accrued, send back the defective appliance for free of charge, or dispose of the appliance for free of charge.

The appliance is intended for household use only and NOT suited for commercial usage. Do not attempt to use this appliance in any other way or for any other purpose than the intended use, described in these instructions. Any other use is regarded as unintended use or misuse, and can cause severe injuries or damage. There is no warranty claim of the purchaser if any injuries or damages are caused by unintended use.

GASTROBACK GmbH
