USER MANUAL HMIP-FAL24-C10 Homematic IP

Mounting instruction and operating manual

Electrical power adapter with black cord and terminal block, connected to a black electrical plug (no text or symbols visible)

Lieferumfang

Anzahl Bezeichnung

Printed in Hong Kong

Technical line drawing of a device with two components, one showing a vertical support and arrow indicator (no text or symbols)

Inhaltsverzeichnis

1 Homematic IP Transformer for Floor Heating Actuators – 24 V

1 Operating manual

Documentation © 2016 eQ-3 AG, Germany.

All rights reserved. This manual may not be reproduced in any format, either in whole or in part, nor may it be duplicated or edited by electronic, mechanical or chemical means, without the written consent of the publisher.

Typographical and printing errors cannot be excluded. However, the information contained in this manual is reviewed on a regular basis and any necessary corrections will be implemented in the next edition. We accept no liability for technical or typographical errors or the consequences thereof.

All trademarks and industrial property rights are acknowledged. Printed in Hong Kong

Changes may be made without prior notice as a result of technical advances.

150652 (web)

Version 1.1 (05/2020)

Table of contents

1 Information about this manual....18
2 Hazard information....18
3 Function and device overview .....21
4 General system information 22
5 Mounting....22
6 Start-up 23
6.1 Installation instructions 23
6.2 Installation.... 25
7 Maintenance and cleaning....26
8 Technical specifications....26

1 Information about this manual

Please read this manual carefully before beginning operation with your Homematic IP component. Keep the manual so you can refer to it at a later date if you need to. If you hand over the device to other persons for use, please hand over this manual as well.

Symbols used:

Attention!

This indicates a hazard.

Please note: This section contains important additional information.

2 Hazard information

Do not open the device. It does not contain any parts that can be maintained by the user. If you have any doubts, have the device checked by an expert.

For safety and licensing reasons (CE), unauthorized change and/or modification of the device is not permitted.

The device may only be operated in dry and dust-free environment and must be protected from the effects of moisture, vibrations, solar or other methods of heat radiation, cold and mechanical loads.

The device is not a toy; do not allow children to play with it. Do not leave packaging material lying around. Plastic films/bags, pieces of polystyrene, etc. can be dangerous in the hands of a child.

We do not assume any liability for damage to property or personal injury caused by improper use or the failure to observe the hazard information. In such cases, any claim under warranty is extinguished! For consequential damages, we assume no liability!

The device may only be used for fixed installations. The device must be securely attached within a fixed installation.

The transformer is part of the building installation. The relevant national standards and directives must be taken into consideration during planning and set-up. The device has been designed solely for operation on a 230 V/50 Hz AC supply. Only

qualified electricians (to VDE 0100) are permitted to carry out work on the 230 V mains. Applicable accident prevention regulations must be complied with whilst such work is being carried out. To avoid electric shocks from the device, please disconnect the mains voltage (trip the miniature circuit-breaker). Non-compliance with the installation instructions can cause fire or introduce other hazards.

Please take the technical data into account before connecting a load. All load data relates to ohmic loads. Do not exceed the capacity specified for the device.

The device has not been designed to support safety disconnection.

Exceeding this capacity could lead to the destruction of the device, fires or electric shocks.

Before the actuator is connected, remove the fuse from the fuse box or remove the plug from the socket.

Observe the installation instructions for installation in distribution systems (DIN VDE 0100-410).

The device may only be operated within residential buildings.

Using the device for any purpose other than that described in this operating manual does not fall within the scope of intended use and shall invalidate any warranty or liability.

3 Function and device overview

The Homematic IP Transformer for Floor Heating Actuators – 24 V is required for the installation and operation of the Homematic IP Floor Heating Actuator – 10/6 channels, 24 V (HmIP-FAL24-C6 and HmIP-FAL24-C10).

You can easily install the device on a DIN rail next to the Homematic IP Floor Heating Actuator – 6/10 channels, 24 V and connect it to the floor heating actuator.

Device overview (see figure 1):

(A) Spring latch for DIN rail mount
(B) Cable with mains plug
(C) Connection cable for floor heating actuator

4 General system information

The transformer is part of the smart home system Homematic IP and required for the installation and operation of the Homematic IP Floor Heating Actuator 10/6 channels, 24 V.

The available functions provided by the Homematic IP system in combination with other components are described in the Homematic IP User Guide. All current technical documents and updates are provided at www.eQ-3.de.

eQ-3 AG hereby declares that this device complies with the essential requirements and other relevant regulations of Directive 1999/5/EC. You can find the full declaration of conformity at www.homematic-ip.com.

5 Mounting

For the 24 V operation of the Homematic IP Floor Heating Actuator, the Homematic IP Transformer for Floor Heating Actuators - 24 V has to be installed. For mounting the transformer to a DIN rail, please proceed as follows:

- Place the transformer next to the floor heating actuator onto the DIN rail (see fig. 2).

For further information on installation of the floor heating actuator, please refer to the user manual of the device.

• Latch the transformer by pressing the spring latch (A) upwards (see fig. 2).
• Make sure that the spring latch engages properly and that the device is securely seated on the rail.

6 Start-up

6.1 Installation instructions

Please read this entire section before starting to install the device.

Please note! Only to be installed by persons with the relevant electro-technical knowledge and experience!*

Incorrect installation can put

• your own life at risk;
• and the lives of other users of the electrical system.

Incorrect installation also means that you are running the risk of serious damage to property, e.g. because of a fire. You may be personally liable in the event of injuries or damage to property.

Contact an electrical installer!

\*Specialist knowledge required for installation:

The following specialist knowledge is particularly important during installation:

• The “5 safety rules” to be used: Disconnect from mains; Safeguard from switching on again; Check that system is deenergised; Earth and short circuit; Cover or cordon off neighbouring live parts;
• Select suitable tool, measuring equipment and, if necessary, personal safety equipment;
• Evaluation of measuring results;
• Selection of electrical installation material for safeguarding shut-off conditions;
  • IP protection types;
  • Installation of electrical installation material;
• Type of supply network (TN system, IT system, TT system) and the resulting connecting conditions (classical zero balancing, protective earthing, required additional measures etc.).

For secure operation, the device can be installed in a power distribution panel according to VDE 0603, DIN 43871 (low-voltage sub-distribution board), DIN 18015-x. The installation must be made on a mounting rail (DIN rail) according to EN50022. Installation and wiring have to be performed according to VDE 0100 (VDE 0100-410, VDE 0100-510 etc.). Please consider the technical connection requirements (TAB) of your energy supplier.

Please observe the hazard information in section "2 Hazard information" on page 14 during installation.

6.2 Installation

To install the transformer, please proceed as follows:

- Connect the transformer to the corresponding connection terminals of the floor heating actuator using the connection cable (C).

For further information on installation of the floor heating actuator, please refer to the user manual of the device.

- Plug the mains plug of cable (B) of the transformer into a socket.

Continue with the installation and configuration of the floor heating actuator. For further information, please refer to the user manual of the device.

7 Maintenance and cleaning

The product does not require any maintenance. Enlist the help of an expert to carry out any maintenance or repairs.

Clean the device using a soft, lint-free cloth that is clean and dry. You may dampen the cloth a little with lukewarm water in order to remove more stubborn marks. Do not use any detergents containing solvents, as they could corrode the plastic housing and label.

8 Technical specifications

Device short description: HmIP-FAL24-TR

Primary: 230 V/50 Hz

Secondary: 24 V/36 VA

Degree of protection: IP20

Protection class: II

Ambient temperature: 0 - 50 °C

Dimensions (W x H x D): 80 x 75 x 52 mm

Weight: 718 g

Subject to technical changes.

Instructions for disposal

Symbol of a recycling bin with crossed lines and a blank rectangular base (no text or numbers)

Do not dispose of the device with regular domestic waste! Electronic equipment must be disposed of at local collection points for waste electronic equipment in compliance with the Waste Electrical and Electronic Equipment Directive.

Information about conformity

The CE sign is a free trading sign addressed exclusively to the authorities and does not include any warranty of any properties.

For technical support, please contact your retailer.
