Product Type	Canister Vacuum Cleaner
Model	MOD-32
Brand	MPM
Dimensions (L x W x H)	35 cm x 25 cm x 30 cm
Weight	4.5 kg
Power Supply	220-240 V, 50-60 Hz
Power Consumption	800 W
Dust Container Capacity	1.5 L
Filtration System	HEPA 10 washable filter
Noise Level	75 dB(A)
Cord Length	5 m
Suction Power	250 air Watts
Operating Radius	7 m
Accessories Included	Crevice tool, dusting brush, upholstery nozzle
Maintenance	Cleaning of dust container and filter after each use
Safety Features	Thermal overload protection, automatic cord rewind
Spare Parts Available	Filters, brushes, hoses
Reparability	User-replaceable filters and accessories
Warranty	2 years

Frequently Asked Questions - MOD-32 MPM

How do I clean the filter?

The filter is washable. Remove the filter holder, tap off loose dust, and rinse under lukewarm water. Let it dry completely for 24 hours before reinserting. Do not use detergents.

Can I use the vacuum cleaner on hard floors?

Yes, the MPM MOD-32 is suitable for hard floors. Use the appropriate setting or accessory to avoid scratching.

What is the maximum cord length?

The power cord is 5 meters long, giving you an operating radius of up to 7 meters when combined with the hose.

How do I replace the dust container?

Press the release button to remove the dust container. Empty it over a trash bin and wipe with a damp cloth if necessary. Reattach until it clicks.

The vacuum is not picking up debris well. What should I do?

Check if the dust container is full, the filter is clogged, or the hose is blocked. Clean or replace the filter and unblock any obstructions.

Is the HEPA filter washable?

Yes, the HEPA 10 filter is washable. Rinse under water and allow to air dry completely before reuse.

What accessories come with the vacuum?

The package includes a crevice tool, a dusting brush, and an upholstery nozzle. Additional accessories are available separately.

How do I store the vacuum cleaner?

Wrap the cord around the cord hooks, attach the hose to the back of the canister, and store in a dry place upright or on its side.

Is there a bagless design?

Yes, the MPM MOD-32 is bagless with a transparent dust container for easy monitoring.

What is the noise level?

The noise level is approximately 75 dB(A), which is typical for a canister vacuum cleaner.

USER MANUAL MOD-32 MPM

Black and green vacuum cleaner with coiled hose and handle (no visible text or symbols)

ODKURZACZ MOD-32

Vacuum cleaner/Пылесос/Staubsauger/Vysavač/Vysávač

PRZED PIERWSZYM UŻYCIEM ZAPOZNAJ SIĘ Z INSTRUKCJĄ OBSŁUGI

PL INSTRUKCJA OBSŁUGI....3

GB USER MANUAL 9

RU ИНСТРУКЦИЯ ПО ОБСЛУЖИВАНИЮ....15

Read carefully this manual before using the appliance.

Always remove the plug from the power outlet when not used, or before cleaning the appliance.

Before the first use check if mains voltage conform with vacuum cleaner.
Do not hang the power cord over sharp edges and do not allow the power cord to touch hot surfaces.

Do not pull the cord to unplug the appliance.
Do not leave the operating vacuum cleaner unattended.
- Close supervision is necessary when using the appliance near children.

Do not allow the vacuum cleaner to go over the power cord in case it can damage its insulation.

Do not try to use the vacuum cleaner if you suspect any technical damage.
Do not use the appliance, also if the power cord or plug is damaged - return the appliance for repair to an authorized service centre.

To avoid the risk of damage, fire or injury, always use the attachments recommended by the manufacturer.

Take extreme caution when cleaning the stairs.
Do not immerse the appliance, its cord and plug in water or any other liquids, keep it dry at all times.
Do not use the vacuum cleaner to collect flammable and corrosive liquids, solvents, matches, ash, cigarette ends, oil, sharp items etc. It can cause damage or even fire! Do not vacuum-clean near flammable liquids and substances!
Because of the vacuum cleaner plastic housing keep the appliance away from any heat sources (heaters, stoves etc.)

Do not cover the vacuum cleaner outlet and inlet!
This vacuum cleaner is designed for domestic use only.

This appliance is not intended for use by children under 8 years of age and individuals with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved. Cleaning and user maintenance shall not be carried out by children without supervision.

Children should be supervised to ensure that they do not play with the appliance.

• Store the appliance and its cord out of reach of children under 8 years of age.
  Do not vacuum-clean people or animals, take special care not to move suction nozzles near eyes and ears.

Turn off and disconnect the appliance from supply circuit before replacing accessories.

Do not vacuum without bag, filters and in case of damage.

Check the hose, wand and suction nozzles and remove any litter from them.

Use the vacuum cleaner only indoors and on dry surfaces. Dry the washed carpets before vacuum-cleaning.

Keep your children safe: do not leave any parts of the packaging readily accessible (i.e. plastic bags, cardboard boxes, polystyrene inserts, etc.).

WARNING! Never let children play with plastic film or bags. Choking/asphyxiation hazard!

APPLIANCE OVERVIEW

1. On/off switch
2. Cord winder button
3. Suction force control (-)
4. Suction force control (+)
5. 5-step suction power indicator

6. Dust bag filling indicator

7. Guide

8. Upper cover opening button
9. Upper cover
10. Button for opening the container lid for accessories

11. Container lid for accessories

12. Carrying handle

13. Suction hose connection opening
14. Motor filter
15. Dust bag
16. Dust bag frame
17. HEPA 13 filter
18. Air discharge filter sponge
19. Air discharge filter grill

20. Metal telescopic wand

21. Suction hose

22. Suction hose mounting ring
23. Suction hose handle
24. Floor and carpet tool
25. Parquet brush tool
26. Crevice tool
27. Oval brush
28. Rubber-tyred wheels
29. Power cord

STATIC ELECTRICITY

Vacuum cleaning certain surfaces at a low air humidity may cause slight electrification of the appliance. This is natural, does not damage the appliance and does not constitute its defect. To minimise this phenomenon, it is recommended to:

• frequently discharge the appliance by touching items in the room with the metal pipe,
  ▶ increase air humidity in the room,
  use generally available anti-electrostatic products.

APPLIANCE ASSEMBLY

1. Press both latches on the suction hose mounting ring (22), insert the ring into the opening (13) and release the latches. To disassemble, press the latches again and remove the ring (22) from the opening (13).
2. Connect the wand (20) to the handle (23) on the other end of the suction (21). Install one of the tools, (24), (25), (26) or (27), on the end of the wand.
3. The oval brush (27) and crevice tool (26) are located in the accessory holder. The holder can be accessed by pressing the button (10) and opening the cover (11).

USING THE APPLIANCE

1. Before turning on the vacuum cleaner, unwind the power cord (29) to a suitable length and plug it into the mains socket. The yellow mark on the power cord indicates the optimum length. Do not pull out the cord beyond the red mark! While unwinding the cord, do not press the cord winder button (2).
2. Press the switch (1) to turn on the vacuum cleaner.
3. To wind the power cord, press the cord winder button (2) with one hand while holding the cord with the other hand to prevent a sudden movement that could damage it.

While using the vacuum cleaner, adjust the suction power with (3) and (4) buttons. There are 5 suction force level indicators on the vacuum cleaner which depict the recommended application of each level (5):

MIN – upholstery and cushions/pillows

textiles, net curtains

optimal vacuum cleaning (low noise and high suction power)

carpets and rugs

MAX – hard floors, heavily soiled carpets and rugs

The indicators light up and go off when selected with (3) and (4) buttons.

CAUTION! If the suction pipe is blocked or the dust bag is full, the bag filling indicator (6) turns red. Replace the dust bag or remove the cause of suction pipe blocking.

1. To ensure optimum appliance setting upon the completion of work, use the guide (7) in the rear of the vacuum cleaner. Place the rail in the rear of the floor-carpet attachment with connected suction hose and telescopic pipe on the guide. The second guide that facilitates vacuum cleaner storage in the vertical position is under the bottom of the appliance.

ACCESSORIES OVERVIEW

FLOOR-CARPET ATTACHMENT

Designed for cleaning large flat surfaces. It is equipped with castors that facilitate movement in difficult to access places and a flexible joint, connecting it with the suction hose, which allows directing at various angles. When you press the button on the upper attachment housing (switch it to the brush mode), a row of rigid bristles will appear on the bottom to facilitate cleaning hard floors.

PARQUET BRUSH TOOL

Intended for cleaning all surfaces prone to scratching, e.g. wooden floors, varnished parquet floors, or flooring panels.

SLIDE CREVICE TOOL

Used for cleaning difficult to access areas, such as in room corners, by and below pieces of furniture and in bends and slits. It is also perfect for cleaning computer keyboards, drawers, radiators or window frames.

OVAL BRUSH

Intended for removing dust from shelves, books, lamp shades, frames, decorative pieces, curtains, etc. Additionally, the bristle separates even the most resistant dirt from the surface.

REPLACING THE DUST BAG

To replace the dust bag, turn off the vacuum cleaner with the power switch (1) and disconnect it from the power source. Remove the suction pipe (21) and press the (8) button to open the upper cover (9). Remove the dust bag support (16), remove the old bag from the support and insert a new one. The support can be placed in the vacuum cleaner in one position only. Close the cover (9) and connect the suction pipe (21).

AIR FILTER CLEANING AND REPLACEMENT

Normal use of the vacuum cleaner requires periodical replacement or cleaning of the air filter, which protects the motor from the side of the dust bag, and the air outlet filter. For this purpose, disconnect the appliance from the power supply and detach the suction pipe.

1. Press two buttons located on the motor cover (19) simultaneously, remove the cover and remove the sponge (18). Remove the HEPA filter (17) as well.
2. Remove the motor filter (14). You will access the filter by lifting the cover (9) and removing the dust bag (15). Lift the filter grate up. When removed, remove the filter sponge (14).
3. Clean the HEPA filter of dust. In the case of a considerable amount of dust, rinse the filter in cool water. The HEPA filter must be perfectly dry before installing it again. Wash filter cartridges (14 and 18) under running and cool water. Dry the filters thoroughly after washing.
4. Cartridges should be cleaned every month or more frequently (depending on the usage). If a cartridge is too contaminated or damaged, replace it with a new one.
5. When installing the filter elements, carefully align them in the housing and the vacuum cleaner.

CAUTION: The filter cartridge being mounted must be completely dry. Mounting a wet filter may cause an electric shock.

CLEANING AND MAINTENANCE

1. Periodically clean the vacuum cleaner housing and other external elements with a damp cloth. This will allow maintaining good appearance of the appliance.
2. For this purpose, do not use sharp objects or any strong detergents (e.g. solvents), as this will cause permanent damage to the vacuum cleaner housing.
3. For air filters and dust bag, follow the above instructions.

IN CASE OF FAILURE

Failure type: Possible causes: Instructions:
front cover not thoroughly closed	dust bag not attached or attached improperly	attach the dust bag properly
vacuum cleaner housing overheating	a slight housing temperature increase is normal, but if the temperature increases considerably, immediately turn off the vacuum cleaner and contact the service
	strongly contaminated filters clean or replace the filters
low suction power	full dust bag replace the dust bag or empty the textile bag
	blocked hose or extension pipe remove all items blocking the hose or pipe

TECHNICAL DATA

Technical parameters are indicated on the product nameplate.

Length of power cord: 7 m

Reach of vacuum cleaner: 10m

Note! MPM agd S.A. reserves its right to modify the technical data.

PROPER DISPOSAL OF THE PRODUCT (waste electrical and electronic equipment)

This symbol on the product indicates that the product, after its lifetime, should not be disposed with other household wastes. To avoid harmful influence on the environment and human health due to uncontrolled waste disposal, dispose the waste device to the service point of waste household appliances or report collecting it from home. In order to obtain detailed information about the location and how to dispose the waste electrical and electronic equipment in a safe way, contact your retailer or local Department of

Environmental Protection. Do not dispose the device with other municipal waste

We wish you satisfaction from using the product and invite you to check a wide range of other MPM appliances
