Brand	Parkside
Model	PAMSG 20-Li B1
Product Type	Rechargeable Battery
Technology	Lithium-Ion (Li-Ion)
Rated Voltage	20 V max. (direct current)
Capacity	2.0 Ah
Energy Value	40 Wh
Number of Cells	5
Compatibility	All Parkside X 20 V Team devices
Compatible Charger	Chargers from the Parkside X 20 V TEAM series
Charging Time (with PLG 20 A4/A3, etc.)	35 to 60 minutes depending on charger
Recommended Charging Temperature	+4 to +40 °C
Storage Temperature	+20 to +26 °C
Charge Level Indicator	LED (red, orange, green)
Main Functions	Powering Parkside X20V tools, checking charge level via button
Safety	Protection against heat, fire, water, short circuits; detailed safety instructions
Maintenance and Cleaning	Clean contacts and vents with a soft brush; do not use solvents
Long-term Storage	Charge to 40-60%, store at room temperature, check every 3 months
Disposal	Recyclable, do not dispose of with household waste, drop off at store or recycling center
Warranty	3 years from purchase date
After-sales Service (Belgium)	Tel. [phone] (Lux.), email [e-mail]
Spare Parts and Repairability	Spare parts available during warranty period; repair by authorized service only
Reference Number (IAN)	481666_2410

Frequently Asked Questions - PAMSG 20-Li B1 PARKSIDE

Which chargers can I use for the Parkside PAMSG 20-Li B1 battery?

Use only chargers from the Parkside X 20 V TEAM series, such as PLG 20 A4, PLG 20 A3, PLG 20 C3, PDSLG 20 A1 or SmartPLGS 2012 A1. Never use a charger of a different type.

How do I check the charge level of the battery?

Press the button (4) on the battery. The LEDs (3) indicate the charge: red = low, red+orange = medium, red+orange+green = maximum.

How long does it take to fully charge the battery?

Charging time depends on the charger: about 60 minutes with PLG 20 A4 or A3, and 35 minutes with PLG 20 A3/C3, PDSLG 20 A1 or SmartPLGS 2012 A1 in fast mode. ECO mode on SmartPLGS takes 120 minutes.

Can I use this battery with all Parkside tools?

Yes, it is compatible with all devices from the Parkside X 20 V Team series.

What to do if the battery does not charge or the LEDs flash?

If the red and green LEDs flash simultaneously, the battery is defective. If only the red flashes, the battery temperature is too cold or too hot. Let it cool down or warm up to room temperature (4-40 °C) before trying again.

How to store the battery if not used for a long time?

Store it partially charged (40-60%, two LEDs lit) in a dry place at 20-26 °C. Check the charge every 3 months and recharge if necessary.

Can I repair the battery myself if it fails?

No, never attempt to repair a damaged battery. Only the manufacturer or an authorized after-sales service can safely perform repairs.

How do I dispose of the battery at the end of its life?

Do not dispose of it with household waste. Take it to a collection point (store or recycling center) intended for batteries and accumulators. Follow local recycling guidelines.

What is the warranty for the Parkside PAMSG 20-Li B1 battery?

The warranty is 3 years from the purchase date. It covers material and manufacturing defects. Keep the receipt as proof of purchase.

Where can I find the reference number (IAN) of my product?

The IAN number (481666_2410) is on the product rating plate, on the sticker on the back of the battery, or on the cover of the user manual.

USER MANUAL PAMSG 20-Li B1 PARKSIDE

PDF ONLINE
parkside-diy.com

OWIM GmbH & Co. KG

Stiftsbergstraße 1

74167 Neckarsulm

GERMANY

Model No.: HG08297

Version: 05/2025

IAN 481666_2410

8=

20 V 2 Ah AKKU / 20V 2Ah RECHARGEABLE BATTERY / 20 V 2 Ah BATTERIE PAP 20 B1

DE AT CH

AKKU 20 V 2 Ah

Operation and safety notes

FR BE

Operation and safety notes Page 32

FR/BE

VORSICHT! EXPLOSIONSGEFAHR!

Gerät entsorgen

Warnings and symbols used.... Page 34

Introduction ...... Page 35

Intended Use ...... Page 36

Contents ...... Page 36

Parts list .... Page 36

Technical data..... Page 37

General safety notes .... Page 39

First use ...... Page 43

Charging the rechargeable battery ..... Page 43

Operation...... Page 44

LED status .... Page 44

Checking the rechargeable battery charge level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Removing/inserting the

rechargeable battery ..... Page 45

Cleaning..... Page 46

Maintenance

and storage..... Page 46

Disposal Page 47

Simplified EU

declaration

of conformity ...... Page 49

Warranty..... Page 50

Warranty claim procedure... Page 51

Service ...... Page 53

Warnings and symbols used The following warnings are used in this instruction manual, on the packaging and on the rating label:
	Follow the warnings and safety notes!
	Direct current/voltage
	Protect the battery pack against heat and continuous intense sunlight.
	Protect the battery pack against water and moisture.
	Protect the battery pack from fire.
	Read and observe the instruction manual.
	This symbol in combination with the word “Info” provides additional useful information.
	Safety-relevant information and other notesInstructions for use

RECHARGEABLE BATTERY 20V 2Ah

● Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended Use

The product is compatible with all devices from the Parkside X 20 V Team series. The product may only be charged using chargers from the Parkside X 20 V TEAM series.

This product is not intended for commercial use. Any other usage of or modification to the product is deemed to be improper and carries a significant risk of accidents. The manufacturer accepts no responsibility for damage(s) attributable to misuse.

- Contents

1 Rechargeable Battery
1 Instruction manual

Parts list

1 Release button for rechargeable battery
2 Rechargeable battery
3 Charging level LEDs (red/orange/green)
4 button (charging level)

5 Mains cord with mains plug
6 Rapid battery charger (not included)
7 Charging control LED – red
8 Charging control LED – green

- Technical data

Battery: PAP 20 B1

Type: Li-Ion (Lithium Ion)

Rated voltage: max. 20V

(Direct current)

Capacity: 2.0Ah

Cells: 5

Energy value: 40 Wh

Recommended

ambient

temperature: max. 45 °C

While charging: +4 to +40 °C

During

operation: +4 to +40 °C

During storage: +20 to +26 °C

To charge the rechargeable battery, only use the chargers from the Parkside X 20 V TEAM series.

Charging time for Battery PAP 20 B1:

Charger Charging time
PLG 20 A4,PLG 20 C1	60 minutes
PLG 20 A3, PLG 20 C3,PDSLG 20 A1	35 minutes
Smart PLGS 2012 A1	35 minutes(quick charging mode)120 minutes(ECO charging mode)

NOTE:

The actual charging time may be slightly different from the above stated depending on the ambient temperature and the condition of the battery pack. The information is subject to change without prior notice.

Customers can order compatible replacement batteries and chargers from Lidl online shops for the following countries:

Germany (lidl.de), France (lidl.fr), Belgium (lidl.be), Czech Republic (lidl.cz), Netherlands (lidl.nl), Poland (lidl.pl), Slovakia (lidl.sk), Spain (lidl.es)

Customers from all other countries can order from www.optimex-shop.com.

General safety notes

⚠ WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and serious injury.

SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE.

a) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of rechargeable battery may create a risk of fire when used with another rechargeable battery.

b) Use power tools only with specifically designated rechargeable batteries. Use of any other rechargeable batteries may create a risk of injury and fire.

c) When the rechargeable battery is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.

d) Under abusive conditions, liquid may be ejected from the rechargeable battery; avoid contact. If contact accidentally

occurs, flush the affected area with water. If liquid contacts eyes, additionally seek medical help.

Liquid ejected from the battery may cause irritation or burns.

CAUTION! RISK OF EXPLOSION!

Never charge non-rechargeable batteries!

Protect the rechargeable battery from heat, for example from continuous exposure to sunlight, fire, water and moisture.

There is a risk of explosion.

e) Do not use a damaged or modified rechargeable battery with the tool.

Damaged or modified batteries exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.

f) Do not expose a rechargeable battery or tool to fire or excessive temperature. Exposure to fire or temperatures above 130 °C may cause an explosion.
g) Follow all charging instruction and do not charge the rechargeable battery or tool outside the temperature range specified in the instructions. Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of the fire.
h) The safety instructions of the compatible chargers must be observed.

Service

a) Have your power tool serviced by a qualified repair person using only identical replacement parts.

This will ensure that the safety of the power tool is maintained.

b) Never service damaged battery

packs. Service of battery packs should only be performed by the manufacturer or authorized service providers.

- First use

● Charging the rechargeable battery

i INFO:

The rechargeable batt ² may be charged at any time without reducing the service life. Interrupting the charging process does not damage the rechargeable battery.
- Charge the rechargeable battery before use when it is at medium or low charging level.
The charging control LEDs (7 and green 8) indicate the status of the charger 6 (not included) and the rechargeable battery (see Fig. A).

1. Insert the rechargeable battery 2 into the charger 6 (not included).

2. Connect the mains plug 5 to a socket-outlet.

3. When the rechargeable battery is fully charged, remove the rechargeable battery from the charger 6 (not included). Disconnect the mains plug from the socket-outlet.

Operation

LED status

Red LED 7 lights up – The rechargeable battery 2 is charging.

Green LED 8 lights up – The rechargeable battery is fully charged.

Green and red LED flash – The rechargeable battery is defective

Red LED flashes – The rechargeable battery is too cold or too warm.

Green LED lights up (without rechargeable battery) – The charger 6 is ready for use.

- Checking the rechargeable battery charge level

☐ Press the ➕ button 4 to check the status of the rechargeable battery 2.

The status/remaining charge shows on the charging level LEDs 3 as follows (see Fig. A):

- Red + orange + green = maximum charge

• Red + orange = medium charge
• Red = low charge

- Removing/inserting the rechargeable battery

CAUTION! RISK OF INJURY!

■ Only insert the rechargeable battery once the battery operated tool is ready for use.

☐ To insert the rechargeable battery 2, place it on the guide track and push it into the charger 6. The rechargeable battery audibly snaps into place.

☐ To remove the rechargeable battery from the charger, press the rechargeable battery release button 1 and pull out the recharge- able battery.

● Cleaning

CAUTION! RISK OF INJURY AND DAMAGE!

- Never use flammable or combustible solvents around battery packs, charger, or tools.

□ Clean out dust and debris from the vents and electrical contacts of the charger 6 and the rechargeable battery 2 using a soft brush.

● Maintenance and storage

Only store the rechargeable battery 2 partially charged. The rechargeable battery should be charged to 40 to 60 % (red and orange LED of the charging level LEDs 3 light up) before storing for extended periods.

☐ Check the rechargeable battery charge about every 3 months when storing for extended periods. Recharge as necessary.

● Disposal

The packaging is made of environmentally friendly materials, which may be disposed of through your local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibreboard/80–98: composite materials.

Product:

The product incl. accessories, manual and packaging materials are recyclable and are subject to extended producer

responsibility.

Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your wornout product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries/rechargeable batteries must be recycled. Return the batteries/rechargeable batteries and the product to the available collection points.

Environmental damage through incorrect disposal of the batteries / rechargeable batteries!

Remove the batteries / battery pack from the product before disposal.

Batteries / rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows:

Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries / rechargeable batteries at a local collection point.

● Simplified EU declaration of conformity

CE mark indicates conformity with relevant EU directives applicable for this product.

● Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period is

not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects.

● Warranty claim procedure

So that your request can be processed quickly, please observe the following instructions:

For all inquiries, please have the receipt and item number (e.g., IAN 481666_2410) ready as proof of purchase.

The article number can be taken from the identification label on the product, engraving on the product, the front cover of your manual (at the bottom left), or the sticker on the back or bottom of the product.

If malfunctions or other defects arise, first contact the service department indicated below by phone or email.

You can then send a product recorded as defective to the communicated service address postage-free, making sure to enclose proof of purchase (receipt) and information on the details of the defect and when it occurred.

You can download and view this and numerous other manuals at parkside-diy.com. This QR code takes you directly to parkside-diy.com. Choose your country and use the search screen to search for the operating instructions. Entering the item number (IAN) 481666_2410 takes you to the operating instructions for your item.

PDF ONLINE
parkside-diy.com

Service

GB Service Great Britain

Tel.:[phone]

E-Mail:[e-mail]

IE Service Ireland

Tel.:[phone]

E-Mail:[e-mail]

PRÉCAUTION ! RISQUE D'EXPLOSION !

Ne chargez jamais des batteries non rechargeables !

PDF ONLINE
parkside-diy.com

- Service après-vente

FR

Service après-vente France

Tél.:[phone]

E-Mail:[e-mail]

BE

OPGELET! ONTPLOFFINGSGEVAAR!

PRZESTROGA! NIEBEZPIECZEŃSTWO EKSPLOZJI!

PDF ONLINE
parkside-diy.com

Serwis

Serwis Polska

Tel.:[phone]

E-Mail:[e-mail]

UPOZORNĚNÍ! NEBEZPEČÍ VÝBUCHU!

PDF ONLINE
parkside-diy.com

Servis

UPOZORNENIE! HROZÍ RIZIKO VÝBUCHU!

PDF ONLINE
parkside-diy.com

Asistencia

FORSIGTIG! EKSPLOSIONSFARE!

PDF ONLINE
parkside-diy.com

Service

DK

Service Danmark

Tel.:[phone]

E-Mail:[e-mail]

PDF ONLINE
parkside-diy.com

Assistenza

VIGYÁZAT! ROBBANÁSVESZÉLY!

PDF ONLINE
parkside-diy.com

Szerviz

HU
