USER MANUAL FR-6701 TRISTAR

EN | Instruction manual

Black TESMA air fryer with digital display and control panel (no visible text or symbols)

FR-6701

\*\*\* TRISTAR

PARTS DESCRIPTION / ONDERDELENBESCHRUVING / DESCRIPTION DES PIÈCES / TEILEBESCHREIBUNG / DESCRIPCIÓN DE LAS PIEZAS / DESCRIÇÃO DOS COMPONENTES / DESCRIZIONE DELLE PARTI / BESKRIVNING AV DELAR / OPIS CZĘŚCI / POPIS SOUĆASTÍ / POPIS SÚĆASTÍ

Labeled diagram of a black air fryer with control panel and digital display showing temperature reading.

SAFETY

• By ignoring the safety instructions the manufacturer cannot be held responsible for the damage.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
• Never move the appliance by pulling the cord and make sure the cord cannot become entangled.
• The appliance must be placed on a stable, level surface.
• This appliance is only to be used for household purposes and only for the purpose it is made for. In worst case the food can catch fire. (i.e. do not use more than one tea spoon of oil, no meat that will release to much grease or water intended for boiling foods.
• This appliance shall not be used by children aged less than 8 years. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Keep the appliance and its cord out of reach of children aged less than 8 years. Cleaning and user maintenance shall not be made by children unless older than 8 and supervised.

• To protect yourself against an electric shock, do not immerse the cord, plug or appliance in the water or any other liquid.
• The appliance is to be connected to a socket-outlet having an earthed contact (for class I appliances).
• WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of an electric shock.
• Keep the appliance and its cord out of reach of children less than 8 years.
• The temperature of accessible surfaces may be high when the appliance is operating.
• The appliance is not intended to be operated by means of an external timer or a separate remote-control system.

- Surfaces indicated with this logo are liable to get hot during use.

STAR

Instruction manual

• In order to prevent disruptions of the airflow do not put anything on top of the appliance and make sure there is always 10 centimeter of free space around the appliance.
  • After the baking process the appliance needs to cooldown, this cooling process will activate automatically when the timer is done. Avoid to unplug the appliance from the net socket before the cooling process is finished because the remaining hot air can damage the appliance.
• This appliance is intended to be used in household and similar applications such as:
• Staff kitchen areas in shops, offices and other working environments.
• By clients in hotels, motels and other residential type environments.
• Bed and breakfast type environments.
  • Farm houses. SAVE THESE INSTRUCTIONS HOUSEHOLD USE ONLY

Waste electrical products should not be disposed of with

household waste. Please recycle where facilities exist. Check with your local Authority or local store for recycling advice.

This product complies with conformity requirements of the sole European regulations or directives.

The Green Dot is the registered trademark of Der Grüne

Punkt – Duales System Deutschland GmbH and is protected as a trademark worldwide. The logo may only be used by customers of DSD GmbH holding a valid trademark usage contract or by engaged waste management companies within the Federal Republic of Germany. This also applies to reproduction of the logo by third parties in a dictionary, an encyclopaedia or an electronic database containing a reference manual.

This symbol is used for marking materials intended to come tact with food in the European Union as defined in regulation 1935/2004.

The universal recycling symbol, logo, or icon is an

internationally recognized symbol used to designate recyclable materials. The recycling symbol is in the public domain and is not a trademark.

The Eurasian Conformity mark (EAC) is a certification mark to indicate products that conform to all technical regulations of the Eurasian Customs Union.

The product and packaging materials are recyclable, subject to extended manufacturer responsibility. Dispose it separately, following the illustrated packaging symbols, for better waste treatment. The Triman logo is valid in France only.

Separate collection / Check your local municipal guidelines.

PARTS DESCRIPTION

1. Tray
2. Basket
3. Basket handle
4. Air inlet
5. Control panel
6. Vent windows
7. Temperature plus/minus
8. Time/Temperature display
9. Time plus/minus
10. Pre-heat mode
11. 9 Pre-set Cooking Programs
12. Start/Pause button
13. On/Off button

BEFORE THE FIRST USE

• Remove all packaging material.

• Do not use the device if the power cord or adaptor is damaged or when not functioning properly.

• Remove any stickers or labels from the appliance.

• Thoroughly clean the parts with hot water, some washing-up liquid and a non-abrasive sponge.
• Wipe the inside and outside of the appliance with a moist cloth.
• Place the appliance on a stable, horizontal and level surface, do not place the appliance on non-heat-resistant surfaces.
• When the device is turned on for the first time, a slight odour will occur. This is normal, ensure adequate ventilation. This fragrance is only temporary and will disappear soon.
• Place the removable grid in the pan properly. NOTE: do not use the appliance without this grid.
• Do not cover the air outlets while the device is on.
• This appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge, unless they have been given supervision or instruction.
• Never touch the mains plug, cord or device with wet or damp hands.
• Do not place the appliance underneath or close to curtains, window coverings etc.
• During hot air frying, keep your hands, face and other body parts away from the air outlets.
• Unplug the unit if strange sounds, smell, or smoke comes from it. Wait for the smoke emission to stop before removing the basket or tray from the appliance.
• This is an air fryer that works on hot air. Do not fill the pan with oil or frying fat.

TRISTAR

Instruction manual

• In order to prevent disruptions of the airflow do not put anything on top of the appliance and make sure there is always 10 centimeter of free space around the appliance.
• Never immerse the electrical appliance in water or any other liquid.
  • Always unplug the appliance and let it cool down completely before cleaning.

USE

• Put the mains plug in an earthed wall socket.
• Carefully pull the pan out of the air fryer.
• Put the ingredients in the pan, make sure the removable grid is placed in the pan before you put in the ingredients.
• Slide the pan back into the air fryer.
• Press the power button to turn on the appliance.
• The default temperature is 180^ . The default time is 15 minutes.
• The temperature control range is 50^ - 200^ . In the process of temperature control, the display will flicker for 3 seconds. Once the flickering stops, the temperature is set. Adjust the temperature by using the temperature plus/minus button.
• The time setting range is 1-60 minutes. Adjust the time by using the time plus/minus button.

• The different cooking pre-sets can be used to cook different food. Select a pre-set cooking program by pressing the pre-set touch button until it shows the icon of the desired cooking pre-set.

• Cooking pre-sets have different times and temperatures. Refer to the table below for an overview of the applicable working times.

• From here, you can make any desired adjustments to the pre-set time and/or temperature by pressing the time or temperature push button and use the plus/minus buttons to adjust the time/temperature.
• Press on the start/pause button to start the cooking process.
• Press the start/pause button again to pause the cooking process
• Do not touch the pan during and some time after use, as it gets very hot. Only hold the pan by the handle.

Programmed modes

- There are 9 pre-set programs and a pre-heat setting. The table below indicates the default time and temperature.

Symbol Program Temperature (°C) Time (min)
	Pre-heat 180 3
	French fries 200 18
	Meat 200 12
	Drumstick 200 20
	Steak 180 12
	Cake 160 25
	Shrimp 180 8
	Fish 180 10
	Chicken 200 30
	Vegetables 160 10

• When you press the start/pause button, the Airfryer will start the corresponding program. When you have chosen the wrong program, you can cancel by pressing the start/pause button. After this you can select another function. It is also possible to adjust the chosen program by changing the time and temperature.
• To pause a program, press the start/pause button.

• Excess oil from the ingredients is collected on the bottom of the pan.

• Some ingredients require shaking halfway through the preparation time. To shake the ingredients, pull the pan out of the appliance by the handle and shake it. Then slide the pan back into the air fryer.

• When you hear the timer beep, the set preparation time has elapsed. The device will shut off after 20 seconds. Pull the pan out of the appliance and place it on a heatresistant surface.
• Check if the ingredients are ready. If the ingredients are not ready yet, simply slide the pan back into the appliance and set the timer to a few extra minutes.

Tips

• Shaking smaller ingredients halfway during the preparation time optimizes the end result and can help prevent unevenly fried ingredients.
• Add some oil to fresh potatoes for a crispy result. Fry your ingredients in the air fryer within a few minutes after you've added the oil.
• Do not prepare extremely greasy ingredients such as sausages in the air fryer.
• Place a baking tin in the pan if you want to bake a cake or quiche or if you want to fry fragile ingredients or filled ingredients.
• You can also use the air fryer to reheat ingredients. To reheat ingredients, set the temperature to 150^ for up to 10 minutes.

CLEANING AND MAINTENANCE

• Before cleaning, unplug the appliance and wait for the appliance to cool down.
• Never immerse the device in water or any other liquid. The device is not dishwasher proof.

TRISTAR

Instruction manual

• Clean the pan and removable grid with hot water, some washing-up liquid and a non-abrasive sponge. The pan and removable grid are not dishwasher-proof.
• If dirt is stuck to the removable grid or the bottom of the pan, fill the pan with hot water with some washing-up liquid. Put the removable grid in the pan and let the pan and the grid soak for about 10 minutes.
• Clean the appliance with a damp cloth. Never use harsh and abrasive cleaners, scouring pad or steel wool, which damages the appliance.

ENVIRONMENT

This appliance should not be put into the domestic garbage at the end of its durability, but must be offered at a central point for the recycling of electric and electronic domestic appliances. This symbol on the appliance, instruction manual and packaging puts your attention to this important issue. The materials used in this appliance can be recycled. By recycling of used domestic appliances you contribute an important push to the protection of our environment. Ask your local authorities for information regarding the point of recollection.

Support

You can find all available information and spare parts at www.tristar.eu!
