Product type	Toilet seat with lid
Brand	Blumfeldt
Model	Lamera
Seat material	Duroplast (urea-formaldehyde resin, cellulose, minerals)
Closing system	Soft Close damping
Hinge type	Stainless steel and plastic
Shock absorbers	Hydraulic plastic
Stops	Polyethylene bumpers
Installation	With expansion anchors or direct screwing
Package contents	Seat with lid, 2 hinges, 2 anchors, 2 anti-slip washers, 2 screws, 2 covers
Recommended cleaning	Mild neutral pH soap solution
Prohibited products	Abrasive, chlorine-based or acidic agents
Compatibility	Standard toilet bowl
Manufacturer	Chal-Tec GmbH, Wallstraße 16, 10179 Berlin, Germany
Warranty	2 years (according to legislation)

Frequently Asked Questions - Lamera Blumfeldt

How to install the Lamera toilet seat?

Installation is done in two steps: first fix the expansion anchors into the bowl, then place the hinges with anti-slip washers and screw. Do not fully tighten before aligning the seat. A video is available by scanning the QR code on the manual.

Is the seat compatible with all toilet bowls?

Yes, the Lamera seat is designed for standard toilet bowls. The instructions include two mounting methods: with expansion anchors or direct screwing, allowing adaptation to most models.

What does Soft Close mean and how does it work?

Soft Close is a hydraulic damping system that allows the lid and seat to close slowly and silently, preventing slamming and extending the product's lifespan.

How to clean the duroplast seat?

Use a soft cloth soaked in neutral pH soapy water. Avoid abrasive, acidic or chlorinated cleaners. Rinse immediately any contact with aggressive products and dry with a soft cloth.

Can the seat turn yellow over time?

Duroplast is a material resistant to UV and stains. However, using inappropriate cleaners can cause yellow discoloration. Follow care recommendations to preserve its appearance.

Are the hinges adjustable?

Yes, during installation, the screws are not fully tightened to allow precise alignment of the seat. Once the position is adjusted, tighten the screws and place the covers.

Can I replace the shock absorbers?

The hydraulic shock absorbers are integrated into the hinges. In case of malfunction, it is recommended to contact the manufacturer for spare parts or replacement under warranty.

Is the product guaranteed?

Yes, the legal 2-year warranty applies. For manufacturing defects, contact the customer service of Chal-Tec GmbH.

How to remove the seat for cleaning?

Press the button under the seat to unclip it. Lift it with both hands to remove it. After cleaning, replace it by snapping it back into place.

Is duroplast material ecological?

Yes, duroplast is composed of urea-formaldehyde resin (69%), cellulose (28%), minerals and pigments. It contains no environmentally harmful substances and is recyclable.

USER MANUAL Lamera Blumfeldt

Berlin Brands Group UK Limited

PO Box 42

272 Kensington High Street

London, W8 6ND

United Kingdom

Dear Customer,

Congratulations on purchasing this device. Please read the following instructions carefully and follow them to prevent possible damages. We assume no liability for damage caused by disregard of the instructions and improper use. Scan the QR code to get access to the latest user manual and more product information.

CONTENTS

Mounting with Dowels 8

Mounting with Screws 9

Care Instructions 10

Manufacturer & Importer (UK) 10

MATERIAL COMPOSITION

Hinges Stainless steel/plastic
Soft Close damper set Hydraulic dampers made of plastic
Damper fluid Sliding fluid
Buffer Polyethylene
Note: The material of the toilet seat is made of duroplast (UF A 10, urea formaldehyde resin) dyed through, which is free from environmentally harmful substances. Thermoset is produced from 69% urea formaldehyde resin, 28% cellulose, 3% minerals, pigments, lubricants and moisture.

MOUNTING WITH DOWELS

①	②
Place the expansion dowels in the recess of the toilet.	Attach the anti-slip washer to the bottom of the black hinge and place both on the recess of the toilet. Insert the screws through the slot of the hinges into the inserted expansion anchors. Do not tighten the screws completely and then place the toilet seat on the hinges. Now you can align the toilet seat.
③	④
Remove the toilet seat again. Tighten the screws and place the stainless steel cover on the hinges.	Place the toilet seat back on the hinges.
⑤	Required for installation:
	Screwdriver Toilet seat (1x) Expansion dowels (2x) Hinges (2x) Anti-slip washers (2x) Screws (2x) Hinge covers (2x)
If you press the button 1x, you can remove the toilet seat with both hands afterwards.

MOUNTING WITH SCREWS

①	②
Place the anti-slip washer on the black hinge, then insert the screw through the slot of the hinge. Place the U-shaped metal bracket on the screw and attach the nut. Place everything into the recess of the toilet bowl. Hold the hinge firmly and tighten the screw so that it can still be moved tightly.	Place the toilet seat on the hinge base to fit the seat to the toilet bowl. Adjust the position of the seat until it fits properly and tighten the screw.
③	④
Remove the toilet seat again. Tighten the screws and place the stainless steel cover on the hinges.	Place the toilet seat back on the hinges.
⑤	Required for installation:
	Screwdriver Toilet seat (1x) Metal brackets (2x) Hinges (2x) Anti-slip washers (2x) Screws (2x) Hinge covers (2x) Nuts (2x)
If you press the button 1x, you can remove the toilet seat with both hands afterwards.

CARE INSTRUCTIONS

This toilet seat was made with care. If you follow a few simple cleaning instructions, it will delight you with its beauty, comfort and quality every day.

• The surface of the toilet seat is closed and non-porous, which helps to ensure optimal hygiene. Do not use abrasive, chlorine or acidic detergents, as they can damage the surface and cause yellowish discoloration.
• Use only a mild, PH-neutral soap solution for cleaning.
• If the toilet seat or hinges have come into contact with toilet cleaner or other aggressive cleaning agents, rinse them immediately with clean water.
• After cleaning, wipe off any remaining moisture on the seat and hinges with a soft cloth.
• When cleaning, make sure that the toilet seat and lid are open or removed until the cleaning agent in the bowl is completely flushed away.

MANUFACTURER & IMPORTER (UK)

Manufacturer:

Chal-Tec GmbH, Wallstrasse 16, 10179 Berlin, Germany.

Importer for Great Britain:

Berlin Brands Group UK Limited

PO Box 42

272 Kensington High Street

London, W8 6ND

United Kingdom
