Product Type	Synthetic Thatch Roof
Brand	Vevor
Model	T505550-5
Dimensions (L x W)	5000 x 500 mm
Color	Straw Yellow (Natural Color)
Material	Synthetic Fibers
Intended Use	Exterior Decorative Roofing
Fixing Method	Cable ties, wire, nails (garden nails, straight nails, self-tapping screws) or structural adhesive
Eave Installation	First row along the reference line, then gradual overlap; from the 3rd to the 6th row, overlap 2-3 cm; above the 6th row, spacing 6.5-7 cm
Ridge Installation	For oblique ridge: lay both sides first, then spread from bottom to top; for positive ridge: lay after main surface, adjust by cutting small pieces
Finish	Press the tiles to get a fluffy effect (high curvature) or smooth effect (low curvature)
Safety	Do not walk on the roof after installation; wear protective equipment during installation
Maintenance	Do not use for fire or insect prevention
Installation Recommendation	Avoid too tight or too loose fastening; use the staggered laying method
Manufacturer	Shanghaimuxinmuyeyouxiangongsi, Shuangchenglu 803nong11hao1602A-1609shi, Baoshanqu, Shanghai 200000, China
Technical Support	www.vevor.com/support
Warranty	Warranty certificate included
Australia Importer	SIHAO PTY LTD, 1 ROKEVA STREET, ASTWOOD NSW 2122
United States Importer	Sanven Technology Ltd, Suite 250, 9166 Anaheim Place, Rancho Cucamonga, CA 91730

Frequently Asked Questions - T505550-5 Vevor

How to install the Vevor T505550-5 thatch roof?

Installation varies by scenario. For the eave, nail the first row along the reference line, then overlap subsequent rows. For the ridge, lay both sides first, then spread from bottom to top. Use cable ties, nails, or adhesive to fix. Refer to the manual for details.

What are the dimensions of model T505550-5?

Model T505550-5 measures 5000 mm in length and 500 mm in width.

Is the thatch roof fireproof?

No, the product is not designed for fire prevention. Do not use it for that purpose.

Can you walk on the roof after installation?

No, it is not recommended to walk on the roof after installation. Avoid bending the tiles by hand.

How to achieve a fluffy or smooth effect?

After installation, press and choose the curvature of the tiles: a high degree of curvature gives a fluffy effect, a low degree gives a smooth effect.

What tools are needed for installation?

You will need cable ties, wire, nails (garden nails, straight nails, self-tapping screws) or structural adhesive. Also plan for protective equipment.

How to maintain the thatch roof?

No specific maintenance is mentioned. However, do not use the product for insect prevention or fire prevention.

What is the difference between models T505540 and T505550?

Models differ in dimensions: T505540-1 (1000x400 mm), T505540-5 (5000x400 mm), T505540-10 (10000x400 mm) and T505550-5 (5000x500 mm). The T505550-5 is wider.

Is the product suitable for indoor use?

The product is designed for exterior decorative roofing. Its indoor use is not specified.

Where to find Vevor technical support?

Visit the website www.vevor.com/support for assistance and the warranty certificate.

USER MANUAL T505550-5 Vevor

Affordable. Reliable. Home Improvement.

THATCH ROOFING

MODEL: T505540-1 & T505540-5

T505540-10 & T505550-5

Technical Support and E-Warranty Certificate

www.vevor.com/support

MODEL: T505540-1 & T505540-5

T505540-10 & T505550-5

This is the original instruction. Please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product received. Please forgive us that we won't inform you again if there are technology or software updates on our product.

Technical parameters

Model	Size (L * W)	Colour
T505540-1	1000*400 mm	Spotted Yellow (Color R5055)
T505540-5	5000*400 mm
T505540-10	10000*400 mm
T505550-5	5000*500 mm

Installation - Roof

Note: The installation method may be different in different scenarios. The installation procedure is for reference only.

1. Eaves part:

In the first row, along the reference line (keel), nail the real part of the thatch along the eaves;

Second row, overlapping; The third row to the sixth row, each row cup back basically overlapping, highlighting the eaves thick effect; Above the sixth row, 6.5cm - 7cm (the width of the thatch tile part).

2. Ridge part:

Oblique ridge: first lay the main surface on both sides of the thatched house, then synchronously spread the spine shape from the bottom to the top to form a rain guide; Positive ridge: after the roofing thatch tiles are laid, close the positive ridge; Tips: For oblique ridge and positive ridge thatch pieces, adjust the angle to the main surface of the thatch shingle part to fit the size. According to the width of the ridge, cut the thatch tiles into small pieces for installation. The effect is natural and easy to close. Use 2-3 small pieces (determine the shear size based on the ridge width). First spread on both sides, then spread a piece in the middle to form the backbone effect.

3. Finishing work after installation:

After the entire thatch roof is installed, you can properly press and pick the bending of the thatch tile to make it smooth and natural (especially the eaves part). You can choose from a fluffy effect (with a high degree of thatch bending) or a smooth effect (with a low degree of thatch bending) to finish as needed.

4. Installation tips:

Do not be too compact or too loose when installing, so as not to affect the effect; The thatched grass along the eaves suggests that the grass lines should be long and overlapping, and the first six rows of the eaves are basically overlapped, highlighting the heavy effect of floating and hanging; Color and style are spread according to the proportioning scheme; Take the dislocation paving method, the overall effect from the bottom up, do not see the base layer of the roof, the effect.

Fixing method

1. Bind with cable ties or iron wire and rope;
2. fixed with nails, yard nails, straight nails, or self-tapping screws;
3. Use structural adhesive or double-sided adhesive to fix.

Matters needing attention

1. After installation is completed, do not tread on it; use hand folding;
2. Not used for fire and insect prevention after installation;
3. During the installation process, pay attention to safety and do a good job of protection.

Manufacturer: Shanghai Muxin Muye Youxiangongsi

Address: Room 1602A-1609, No. 11, Lane 803, Shuangcheng Road, Baoshan District, Shanghai 200000, CN.

Imported to AUS: SIHAO PTY LTD. 1 ROKEVA STREET, EASTWOOD NSW 2122, Australia

Imported to USA: Sanven Technology Ltd. Suite 250, 9166 Anaheim Place, Rancho Cucamonga, CA 91730
