HT-1E - Crepe maker Vevor - Free user manual and instructions

Product type	Commercial crêpe maker
Brand	Vevor
Model	HT-1E
Dimensions (approx.)	40 x 30 x 20 cm
Weight (approx.)	6 kg
Power supply	120 V 60 Hz (North America) or 220-240 V 50 Hz (Europe/Australia)
Power	1700 W (120 V) / 3000 W (220-240 V)
Plug type	American or European depending on version
Cooking plate	Non-stick
Recommended temperature range	160-200 °C (320-400 °F)
Temperature adjustment	Continuous rotary knob
Heating indicator light	Yes (turns on/off with thermostat)
Material	Steel with non-stick coating
Usage	Indoor only
Cleaning	Soft brush, no abrasive cleaners, do not immerse
Safety	Unplug after use, do not leave unattended, hot surface
Warranty	Technical support and electronic warranty certificate at www.vevor.com/support
Included accessories	Scraper
Repairability	Contact authorized after-sales service for any repairs

Frequently Asked Questions - HT-1E Vevor

What is the ideal temperature for crêpes?

The recommended temperature is 160 to 200 °C (320-400 °F). Adjust the thermostat within this range for perfect crêpes.

How to clean the non-stick plate?

Use a soft brush to remove residues and oil. Never use abrasive cleaners or hard/sharp objects to avoid damaging the non-stick coating. Wipe the outside with a soft, dry cloth.

What to do if smoke or odor occurs during first use?

This is normal for many heating appliances. Let the appliance heat empty for a few minutes until the smoke/odor disappears. It does not affect safety.

Can I use other batters besides the special pre-mixed powder?

It is strongly recommended to use a special pre-mixed crêpe powder. Using the wrong formula may cause burning. If burning occurs, set to 60 °C (140 °F) and pour a little water on the plate to soften the burnt batter, then scrape.

How to properly turn off the machine?

Turn the temperature knob counterclockwise to the lowest position, then unplug the cord from the outlet. Wait for the appliance to cool before storing.

Does the appliance turn off automatically?

No, the appliance does not have an automatic shut-off. You must unplug it after use and never leave it unattended.

Can I use the machine outdoors?

No, the appliance is designed for indoor use only, away from flammable liquids, gases, dust, and explosive environments.

What to do if the power cord is damaged?

The cord must be replaced by the manufacturer, service agent, or similarly qualified person to avoid hazard. Do not use the appliance with a damaged cord.

Where to find spare parts or assistance?

Contact after-sales service via www.vevor.com/support for technical help, electronic warranty, or spare parts.

Is the appliance under warranty?

Yes, Vevor offers an electronic warranty. Register your product at www.vevor.com/support to activate the warranty and get technical assistance.

USER MANUAL HT-1E Vevor

Technical Support and E-Warranty Certificate www.vevor.com/support

We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represent estimate of savings you might benefit from buying certain tools with us compared to top brands and does not necessarily mean to cover all categories of tools offered. You are kindly reminded to verify carefully when you are placing an order with us that you are actually saving half in comparison with the top major brands.

MODEL: HT-1E / HT-2E

NEED HELP? CONTACT US!

Have product questions? Need technical support? Please feel free to contact us:

Technical Support and E-Warranty Certificate www.vevor.com/support

This is the original instruction. Please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of the user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.

	Warning-To reduce the risk of injury, user must read instructi manual carefully.
[CKZG]	Indoor use only.
	Pay attention to high temperatures to prevent burns.
	CORRECT DISPOSALThis product is subject to the provision of European Directive 2012/19/EC. The symbol showing a wheelie bin crossed throu indicates that the product requires separate refuse collection i European Union. This applies to the product and all accesso marked with this symbol. Products marked as such may not discarded with normal domestic waste, but must be taken to collection point for recycling electrical and electronic devices
	Compliance is a EC & UK security certification.

SAFETY WARNINGS AND PRECAUTIONS

Thank you for using this product. In order to make sure that you can operate the machine correctly, read this instruction carefully before operating it and keep it properly for future reference. Please read this page's precautions and safety rules to ensure your safe use. This manual will outline safety warnings, precautions for operating, maintenance, and cleaning. The warnings and instructions reviewed in this manual cannot cover all possible conditions and situations that may occur. Caution and common sense are not built into this product since the users will comply with these codes. Please consult a doctor before starting a training

program or engaging in strenuous endurance activity on the device.

Please read ALL the instructions before using your machine.

1. Ensure the voltage in your outlet is the same as indicated on the appliance rating label.
2. Do not let minors and pets get close to or touch the machine.
3. Do not touch the hot surface directly with your hands. Always use the hat knob for operation.
4. Do not immerse the cord or plug into water or other liquids to prevent electric shock.
5. Do not immerse the appliance in water or any other liquid.
6. Unplug the machine from the outlet when not in use and before cleaning. Unplug the appliance before installing or removing parts and before cleaning.
7. Cool down the hot parts before operation and cleaning.
8. Do not operate the device with a damaged cord or plug, malfunctioning, or mechanical damage. Send it to your nearest authorized service centre for examination and repair (only technicians should open the unit).
9. Using accessories or attachments not provided or recommended by the manufacturer may cause injury.
10. If the machine is not to be used for an extended period, unplug it, cover it, and store it in a dry and safe place.
11. Do not leave the power cord hanging over the edge of a table or counter, and do not let it come into contact with any hot surfaces.
12. Do not place the unit on or near hot air, electric burners, or heaters. Switch off the power to the socket before plugging in or unplugging. Hold the plug instead of pulling on the cord.
13. Do not use this unit for purposes other than the indicated usage.
14. KEEP IT OUT OF CHILDREN'S REACH. Never leave it unattended while in use.
15. DO NOT CLEAN IT WITH ANY ABRASIVE MATERIAL.
16. Always check that this machine is plugged into a grounded outlet with the appropriate electrical supply. Ensure that the wall outlet being used is adequately grounded. If not, you must install a grounded outlet. Have the work performed by a certified electrician appropriately qualified to meet local safety and electric codes.
17. Regularly check that the power outlet, plug, and cord in use are in good working condition. Any damaged components should be promptly repaired by a certified electrician who is qualified to meet local safety and electrical codes. Even if your power cord is functioning properly, it's important to keep it away from water and avoid letting it run over carpets or heating devices to prevent potential hazards.
18. It is absolutely prohibited to use this machine in the presence of flammable liquids, gases, dust, or any other explosive situation. This strict rule is in place to ensure your safety and prevent potential accidents.
19. Do not move the machine before cooling and during heating.
20. Do not operate the machine in an appliance garage or under a wall call. Always unplug the unit from the electrical outlet when storing it in an appliance garage. Otherwise, it would cause a fire risk, especially if the machine touches the garage wall or the door touches it as it closes.
21. Type Y attachment: If the supply cord is damaged, it must be replaced by the manufacturer, service agent, or similarly qualified persons to avoid a hazard.
22. Children shall not play with the appliance. Children shall not clean or perform user maintenance without supervision.
23. Inspect before every use.
24. DO NOT CLEAN IT WITH ANY ABRASIVE MATERIAL.
25. Never leave it unattended while in use. Never leave the child unattended.
26. Pet urine and feces can damage the product, please keep away.

WARNING:

This appliance is not intended for use by young or infirm persons unless supervised by a responsible person to ensure that they can use the appliance safely. Young children should be supervised to ensure that they do not play with the product. Pets should stay away from the product.

PRODUCT PARAMETERS

MODEL	Region	Voltage	Power	Plug Type
HT-1E	North America	AC120 V 60Hz	1700W	American PLUG
	Europe	AC220-240V50Hz	3000W	European PLUG
	Australia	AC220-240V50Hz	3000W	Australia PLUG
HT-2E	North America	AC120 V 60Hz	1700W+1700W	American PLUG
	Europe	AC220-240V50Hz	6000W	European PLUG
	Australia	AC220-240V50Hz	6000W	Australia PLUG

Attention:

1. Please use an appropriate external power supply according to the product voltage.
2. Do not exceed the maximum load specified in the product manual.

OPERATING INSTRUCTIONS

Before using the appliance for the first time, peel off any promotional and packaging materials and check that the cooking plates are clean and dust-free. If necessary, wipe them over with a damp cloth. Spread over with an absorbent kitchen towel and wipe off any excess oil.

Note: When your appliance is heated for the first time, it may emit slight smoke or odor, which is normal for many heating appliances, and will not affect the safety of your appliance.

1. Place the machine on a clean, dry, level surface near a plug base outlet.
2. Adjust the temperature knob to the lowest temperature position, check again whether the product and power cord are intact, and connect the plug to the
3. Insert the plug into the socket to ensure that the machine is powered on.
4. Select the desired temperature with the control knob. It is recommended to set at 320-400°F (160-200°C).
5. Allow the unit to reach desired temperature. The heating indicator light will turn off when the desired temp is reached.
6. The waffle iron grids are non-stick.
7. After the temperature reaches the set value, pour the batter onto a non-stick

heating plate and apply it evenly with a scraper.

1. Add the ingredients you need and roll them up for consumption after the product is cooked.
2. Repeat the steps above to make multiple waffles.
3. After finishing, for safety, turn the temperature knob counterclockwise to the limit position and cut off the power.

Note: It works this way repeatedly to ensure the temperature is within a specific range. During the machine's operation, the heating indicator cycles on and off.

TIPS

1. Please use specialized premix powder. Using the wrong premix powder batter formula can cause physical burning.
2. If the wrong premixed powder is used and causes burning, the temperature should be adjusted to 60°C (140°F), and a small amount of water can be poured onto the non-stick coating. Use a scraper to scrape off the burnt part.

CLEANING AND MAINTENANCE

1. After use, turn the temperature knob to the lowest temperature, unplug, and allow the product to cool down.
2. Use a soft brush to clean the residue and oil on the mold surface.
3. For the exterior, wipe with a soft, dry cloth. Never use an abrasive cleanser or harsh pad.
4. Please clean regularly to avoid dirt buildup.

Note: Do not use hard and sharp objects to clean the mold to avoid damaging the non-stick coating.

Note: Before using it again, reassemble according to the instructions.

Warning: Do not use liquid to rinse the product directly to avoid water damage to internal components.

STORAGE

1. Always unplug the machine before storage.
2. Always ensure the machine is cleaned, cooled, and dried before the string
