USER MANUAL FC-4DH-02120-T Vollrath

HotDrop-inswithDryWells

ThankyouforpurchasingthisVollrathequipment.Beforeoperatingthe equipment,readandfamiliarizeyourselfwiththefollowingoperating andsafetyinstructions.SAVETHESEINSTRUCTIONSFORFUTURE REFERENCE.Savetheoriginalboxandpackaging.Usethispackaging toshiptheequipmentifrepairsareneeded.

SAFETYPRECAUTIONS

Toensuresafeoperation,readthefollowingstatementsandunderstand theirmeaning.Thismanualcontainssafetyprecautionswhichare explainedbelow.Pleasereadcarefully.

WARNING

Warningisusedtoindicatethepresenceofahazardthatwillorcan causeseverepersonalinjuryordeath.

CAUTION

Cautionisusedtoindicatethepresenceofahazardthatwillorcan causeminorormajorpersonalinjuryifthecautionisignored.

NOTICE: Notice is used to note information that is important but not hazard-related.

Toreduceriskofinjuryordamagetotheequipment:

• This equipment must be installed by a qualified person.
- Useonlygroundedelectricaloutletsthatmatchtheratedvoltageon thenameplate.
NOTICE: Do NOT modify the chordor plug on the drop-in. Modifying any component may damage the drop-in or cause injury, and will void the warranty. Seethespecificationsheet on Vollrath.com forelectrical specifications.
- Donotuseanextensioncordwiththisequipment.Donotplugthis equipmentintoapowerstripormulti-outletpowercord.
- This equipment should only be used in a flat, level position.
- Donotspraythecontrolsortheoutsideofequipmentwithliquidsorcleaningagents.
- Keep the equipment and power cordaway from open flames, electric burners over excessive heat.
- Donotusefoodpansdeeperthan6"(15.2cm).
• Notforusewithplasticpans.
- Donotoperateequipmentifitisdamagedormalfunctioning.
•Donotoperateunattended.
- Unplugandallowtheequipmenttocoolbeforecleaningormoving.
- Donotcleanthisequipmentwithsteelwool.

3D rendering of a rectangular industrial enclosure with six rectangular cavities and internal grating, connected by wires (no text or symbols visible)

ItemNo.No.ofWells
FC-4DH-01120-I	One
FC-4DH-01208-I
FC-4DH-01120-T
FC-4DH-01208-T
FC-4DH-02120-I	Two
FC-4DH-02208-I
FC-4DH-02120-T
FC-4DH-02208-T
FC-4DH-03120-I	Three
FC-4DH-03208-I
FC-4DH-03120-T
FC-4DH-03208-T
FC-4DH-04208-I	Four
FC-4DH-04208-T
FC-4DH-05208-I	Five
FC-4DH-05208-T
FC-4DH-06208-I	Six
FC-4DH-06208-T

FUNCTIONANDPURPOSE

This drop-in is intended and designed to hold containers of food at properserving temperatures. Hot food stations are not intended for designed to cook raw food to prepare food. Food must be prepared and placed in food stations at properserving temperatures. This equipment is not intended for household, industrial or laboratory use.

	CAUTION
	BurnHazardDonottouchhotfood,liquidorheatingsurfaceswhileequipmentisheatingoroperating.

NOTICE: Donotusefoodpansdeeperthan6"(15.2cm).

NOTICE: Donotuseplasticpans.

1. Plugelectrical power cord into a outlet that matches herated voltage on the name plate.
2. Turnthetemperaturecontroltothemaximumheatsetting.Coverthe well(s).Preheatfor30minutes.
3. Placecontainers of hot food, above 140°F (60°C), intopreheated equipment.
4. Reduceheatsettingtoalevelthatwillmaintainasafeholding temperatureandmaintainfoodquality.

NOTICE:Monitorfoodtemperaturecloselyforfoodsafety. The UnitedStatesPublicHealthServicerecommendsthathot foodbeheldataminimumof140°F(60°C)tohelpprevent bacteriagrowth.

1. Use gloves, mittsorpotholder stop protect hands when removing hot food containers.

CLEANING

CAUTION

BurnHazard

Hotsurfacesandfoodcanburnskin.Allowthehotsurfacesto coolbeforehandling.

Tomaintaintheappearanceandincreasetheservicelife,cleanyour equipmentdaily.

NOTICE: Donotusecausticcleaning chemicals, steelwoolor commerciallimeremovalproductstocleantheequipment. Thoroughlyrinseequipmentwithwateraftercleaning.

1. Remove hot food containers. Use gloves, mittsorpotholder to protect hands
2. Turnthetemperaturecontroltothe "0" setting.
3. Unplugthedrop-in.
4. Allowthedrop-intocoolcompletely.
5. Removetheshieldfromthebottomofthewell.
6. Handwashtheshieldinsoapywater.
7. Drytheshield.
8. Useadampclothorspongedippedinsoapywatertocleanthe insideofthewellandtheoutsideoftheequipment.
9. Useadampclothorspongetothoroughlywipeoffthesoapywater.

TROUBLESHOOTING

ProblemMightbeCausedByCourseofAction
Drop-indoesnotheattothe correcttemperature.	Loworincorrectvoltagetounit.	Verifythatvoltageratingonthedrop-inmatchesthesourcevoltage.If not,havealicensedelectricianinstallpropersourcevoltage.

Thispageintentionallyleftblank.

SERVICEANDREPAIR

ServiceablepartsareavailableonVollrath.com.

To avoid serious injury or damage, never attempt to repair the unit or replace a damaged power cord yourself. Do not send units directly to TheVollrathCompanyLLC.PleasecontactVollrathTechnicalServicesforinstructions.

When contacting Vollrath Technical Services, please be ready with the item number, model number (if applicable), serial number, and proof of purchaseshowingthedatetheunitwaspurchased.

WARRANTYSTATEMENTFORTHEVOLLRATHCO.L.L.C.

This warranty does not apply to products purchased for personal, family or household use, and The Vollrath Company LLC does not offer a written warranty top purchasers for such uses.

The Vollrath Company LLC warrants the products it manufactures or distributes against defects in materials and workmanship as specifically described in our full warranty statement. In all cases, the warranty runs from the date of the end user's original purchase date found on the receipt. Any damages from improper use, abuse, modification or damage resulting from improper packaging during return shipment for warranty repair will not be recovered under warranty.

Forcompletewarrantyinformation,productregistrationandnewproductannouncement,visitwww.vollrath.com.

Outperform every day."

www.vollrath.com

The VollrathCompany, L.L.C.

1236North18thStreet

Sheboygan, WI53081-3201U.S.A.

MainTel:800.624.2051or920.457.4851

MainFax:800.752.5620or920.459.6573

CustomerService:800.628.0830

CanadaCustomerService:800.695.8560

TechnicalServices

[e-mail]

InductionProducts:800.825.6036

CountertopWarmingProducts:800.354.1970

Toasters:1-800-309-2250

AllOtherProducts:800.628.0832

3D rendering of a rectangular industrial or electrical enclosure with multiple recessed grating and internal channels (no text or symbols visible)

Num.d'art.Compartiments
FC-4DH-01120-I	Un
FC-4DH-01208-I
FC-4DH-01120-T
FC-4DH-01208-T
FC-4DH-02120-I	Deux
FC-4DH-02208-I
FC-4DH-02120-T
FC-4DH-02208-T
FC-4DH-03120-I	Trois
FC-4DH-03208-I
FC-4DH-03120-T
FC-4DH-03208-T
FC-4DH-04208-I	Quatre
FC-4DH-04208-T
FC-4DH-05208-I	Cinq
FC-4DH-05208-T
FC-4DH-06208-I	Six
FC-4DH-06208-T
