WIFILOFS21FBK - Lamp NEDIS - Free user manual and instructions

Product type	Outdoor Wi-Fi smart projector
Brand	Nedis
Model	WIFILOFS21FBK
Intended use	Outdoor lighting for exterior areas
Connectivity	Wi-Fi
Compatible app	Nedis SmartLife
Power supply	Safety extra low voltage (SELV)
Input voltage	12 V DC
Power consumption	12 W
Luminous flux	800 lm
Color temperature	3000 K - 6500 K (adjustable)
Protection rating	IP44
Dimensions (W x L x H)	150 x 100 x 50 mm
Weight	0.3 kg
Material	Aluminum and plastic
Color	Black
Protection class	III (extra low voltage)
Beam angle	120°
LED lifetime	25,000 hours
Warranty	2 years
Maintenance and cleaning	Disconnect power before cleaning; use a soft dry cloth; do not use harsh chemicals
Safety	Do not open the product; do not immerse in water; disconnect before maintenance; keep out of reach of children
Spare parts and repairability	Not user-serviceable; contact a qualified technician

Frequently Asked Questions - WIFILOFS21FBK NEDIS

How to install the WIFILOFS21FBK projector?

Fix the projector to the wall or ceiling using the included brackets. Connect it to a suitable power source (12 V DC). Download the Nedis SmartLife app and follow the pairing instructions.

Can I use this projector indoors?

Yes, the product is intended for indoor and outdoor use. However, its IP44 rating makes it particularly suitable for outdoor use.

How to connect the projector to the Nedis SmartLife app?

Make sure your phone is connected to a 2.4 GHz Wi-Fi network. Open the app, add a new device, scan the QR code or enter the model manually. Follow the instructions to complete pairing.

What to do if the projector does not respond?

Check the power supply and cable. Try restarting the projector by unplugging and plugging it back in. If the problem persists, reset it by holding the reset button for 5 seconds.

How to reset the projector to factory settings?

Locate the reset button (usually near the power cable). Hold it pressed for 5 to 10 seconds until the LED flashes rapidly. Release; the device will restart in pairing mode.

What are the safety precautions to follow?

Never open the housing. Always unplug the projector before cleaning or maintenance. Do not immerse it in water. Keep packaging out of reach of children to avoid choking hazard.

Can I change the color temperature of the projector?

Yes, via the Nedis SmartLife app, you can adjust the color temperature between 3000 K (warm white) and 6500 K (cool white).

What is the lighting angle of the projector?

The beam angle is 120 degrees, providing wide light coverage for outdoor areas.

Is the projector compatible with voice assistants?

Yes, via the Nedis SmartLife app, you can connect it to Amazon Alexa or Google Assistant for voice control.

How to clean the projector?

First unplug it. Use a soft dry cloth to remove dust. Do not use harsh chemicals or abrasives. Avoid touching the LED directly.

USER MANUAL WIFILOFS21FBK NEDIS

Wi-Fi Smart Floodlight

Safety instructions

Icon of a house with Wi-Fi signal symbol inside a hexagon (no text or numbers)

Nedis SmartLife

WIFILOFS21FBK / WIFILOFC21FBK

Illustration of two computer monitors with black frame and stand (no text or symbols)

EN Safety instructions 3
DE Sicherheitshinweise 7
FR Consignes de sécurité 11
NL Veiligheidsvoorschriften 16
IT Istruzioni di sicurezza 20
ES Instrucciones de seguridad 24
PT Instruções de segurança 28
SV Säkerhetsanvisningar 32
FI Turvallisuusohjeet 36
NO Sikkerhetsinstruksjoner 39
DA Sikkerhedsinstruktioner 43
HU Biztonsági utasítások 47
PL Instrukcje bezpieczeństwa 51
EL Οδηγίες ασφάλειας 55
SK Bezpečnostné pokyny 60
CS Bezpečnostní pokyny 64
RO Instructiuni de siguranță

Wi-Fi Smart Floodlight

WIFILOFS21FBK/

WIFILOFC21FBK

For more information see the extended manual online: ned.is/wifilofs21fbk | ned.is/wifilofc21fbk

Aboutthisdocument

This document is the user manual and contains all the information for correct, efficient, and safe use of the product.

Ensure you have fully read and understood the instructions in this document before you install or use the product. Keep the packaging and this document for future reference.

Symbolsused

WARNING!	Signal word used to indicate a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION!	Signal word used to indicate a potentially hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTICE	Signal word used to address practices not related to physical injury.

Intendeduse

This product is intended as an outdoor floodlight to illuminate outdoor areas.

This product is intended to be used with the Nedis SmartLife app.

This product is intended for indoor and outdoor use.

Only use the product as described in this user manual.

Safety symbols on the product

SymbolDescription

Indication to warn for electric shock.

Product that operates at a Safety Extra Low Voltage (SELV). The voltage of the product is low enough (<50V AC or 120V DV) to prevent dangerous electric shocks, even if touched directly. Class III product do not require insulation or grounding for protection.

Safetyinstructions

Ensure you have fully read and understood the instructions in this document before you install or use the product. Keep the packaging and this document for future reference.

WARNING!

Electricalhazard:

• Do not open the product. The product may only be opened by an authorised technician for maintenance.
• Do not immerse the product in water or other liquids.
• Disconnect the product from the power source before cleaning.
• Disconnect the product from the power source before service and when replacing parts.

Firehazard:

- Do not use the product if a part is damaged or defective. Always replace a damaged or defective product immediately.

Chokinghazard:

- Do not let children play with the packaging material. Always keep the packaging material out of the reach of children.

CAUTION!

Trippinghazard:

- Always keep the power cable and the product away from usual walkways.

NOTICE

• Only use the product as described in this document.
• Do not make any adjustments to the product. Adjustments may affect safety, warranty and proper operation.
• Do not drop the product and avoid bumping.
• Children should be supervised to ensure that they do not play with the product.
• Do not use aggressive chemical cleaning agents when cleaning the product.

Disposal

The product is designated for separate collection at an appropriate collection point. Do not dispose of the product with household waste.

For more information, contact the retailer or the local authority responsible for the waste management.

DeclarationofConformity

We, Nedis B.V. declare as manufacturer that the product WIFILOFS21FBK / WIFILOFC21FBK from our brand Nedis®, produced in China, has been tested according to all relevant CE standards and regulations and that all tests have been passed successfully. This includes, but is not limited to the RED 2014/53/EU regulation.

The complete Declaration of Conformity (and the safety datasheet if applicable) can be found and downloaded via:

nedis.com/WIFILOFS21FBK#support nedis.com/WIFILOFC21FBK#support
