KA-5046BK - Food Processor Brentwood - Free user manual and instructions

Product Type	Mandoline and Manual Grater
Brand	Brentwood
Model	KA-5046BK
Dimensions (approx.)	30 x 12 x 10 cm
Weight (approx.)	0.8 kg
Power Source	None (manual)
Material	Plastic and Stainless Steel
Number of Blades	6
Blade Types	Mandoline, Julienne, Fine Grater, Medium Grater, Coarse Grater, Wavy Slicer
Container Capacity	1.5 Liters
Main Functions	Slice, Grate, Julienne
Safety Pusher	Hand guard with pins
Pouring Spout	Yes, integrated into the lid
Cleaning	Hand wash or dishwasher safe (all removable parts)
Safety	Very sharp blades, safety hand guard mandatory
Spare Parts	Extra blades available (ref. not provided)
Repairability	Not user-serviceable
Usage	Indoor household use only
Warranty	1 year (according to retailer)

Frequently Asked Questions - KA-5046BK Brentwood

How to install the blade on the Brentwood KA-5046BK mandoline?

Place the chosen blade into the blade holder (part no. 2) ensuring it snaps in place. Then attach the holder to the container before adding the lid.

Can I wash the blades in the dishwasher?

Yes, all removable parts, including the blades, are dishwasher safe. Handle the blades with care to avoid cuts.

How to use the hand guard?

Attach the vegetable onto the pins under the hand guard (part no. 1) by pressing lightly. Slide the hand guard towards the blade to slice safely.

Which blade to use for fries?

Use the julienne blade (part no. 8) to get even sticks.

Is the pouring spout removable?

No, the pouring spout is integrated into the lid (part no. 4). It allows emptying the container without opening the lid.

What if the food does not slide easily?

Do not force. Apply constant and even pressure. If necessary, cut the food into smaller pieces. Avoid very hard or frozen food.

How to store the blades?

Use the storage container (part no. 12) provided. Make sure the blades are completely dry to prevent rust.

Can I slice food without the hand guard?

No, the hand guard is mandatory to avoid any contact with the sharp blades. Always use it.

Are the blades interchangeable with other brands?

No, the blades are specific to the KA-5046BK model. Use only the provided blades.

How to clean the mandoline after use?

Disassemble all parts, wash them in hot soapy water or dishwasher, dry thoroughly, and store in a dry place.

USER MANUAL KA-5046BK Brentwood

© 2025 Brentwood Appliances, Inc.

VEGETABLE SLICER & GRATER

CORTADORA Y RALLADORA DE VERDURAS

Black and white photo of a hand mixer with sliced vegetables in a clear container (no text or symbols visible)

Operating and Safety Instructions

FOR INDOOR HOUSEHOLD USE ONLY

When using this or any other product, always follow these basic safety precautions, especially when children are present.

READ ALL INSTRUCTIONS BEFORE USE.

WARNING: To reduce the risk of serious personal injury, please note the following:

• Before use, ensure that all parts, especially the blades and safety guard, are properly assembled and securely in place.
• Ensure you are using the appropriate blade for the type of cut you want.
• Place the product on a flat, stable surface to prevent slipping or tipping while slicing/grating.
• Always use the product on a flat, even surface to avoid instability while slicing/grating.
• Consider wearing cut-resistant gloves to protect your hands from accidental slips when using the product.
• Always use the provided safety guard to hold the food while slicing/grating to avoid direct contact with the blades.
• Stay focused while using the product to ensure you don't accidentally injure yourself or misuse the tool.
• Always keep your hands and fingers away from the blade when using the product to avoid cuts.
• Allow the food to pass through the product at its own pace. Forcing food through could result in uneven cuts or injury.
• Avoid trying to slice/grate too much food at once. This could cause uneven slicing/grating or damage to the product.
• Avoid slicing/grating very hard items, such as bones or frozen food, which could damage the blades or cause injury.
• The blades are very sharp. Always handle them with care and avoid touching them directly to prevent cuts.
• Clean the product immediately after use to prevent food buildup, which could affect its performance and safety.
• Ensure all parts are completely dry before reassembling or storing the product to prevent rusting or slipping.
• Store the product with the blade protected or locked away to prevent accidental injury during storage.
• Store the product and its blades out of reach of children to prevent accidents.

PARTS

1	Hand Guard	7	Mandoline Blade
2	Blade Holder	8	Julienne Blade
3	Lid	9	Fine Grating Blade
4	Lid Spout	10	Medium Grating Blade
5	Food Container	11	Coarse Grating Blade
6	Waved Slicing Blade	12	Blade Storage Container

BEFORE USING THE VEGETABLE SLICER & GRATER

1. Check that all parts are intact and undamaged. Verify that the blades are sharp and free from rust or chips.

2. Detach the lid from the food container and carefully remove the blade attachment from the blade holder.

3. Wash all removable parts with warm, soapy water using a soft sponge or cloth. Handle the sharp blades with care to avoid damage and injury.

NOTE: The product and the blade attachments are dishwasher safe.

1. Dry all parts thoroughly with a clean towel or allow them to air dry. Ensure the blades are completely dry to prevent rust or moisture buildup.

2. Once all parts are clean and dry, carefully reassemble the product by attaching the lid to the food container and placing the selected blade attachment into the blade holder. Ensure the blade and all parts are securely in place to prevent accidents during use.

USING THE VEGETABLE SLICER & GRATER

1. Secure the vegetable onto the pins under the hand guard, ensuring it is firmly held in place to protect your hands from the sharp blade.
2. Slide the vegetable down the product toward the blade in a repetitive motion, applying steady, even pressure to create consistent slices/grates. Repeat until the entire vegetable is sliced/grated.
3. After the vegetable is sliced/grated, the pieces will fall into the food container.
4. Tilt the product without opening the lid and use the lid spout to pour the sliced/grated vegetables into a container. Be careful to avoid spilling or losing any slices/grates.
5. Your sliced/grated vegetables are now ready for use or further preparation!

CLEANING AND MAINTENANCE

1. Open the lid, remove any remaining sliced/grated vegetables from the product and dispose of or store any leftover pieces as needed.
2. Carefully remove the lid from the food container and the blade attachment from the blade holder.
3. Wash all removable parts with warm, soapy water using a soft sponge or cloth to prevent damage. Handle the sharp blade with caution to avoid cuts. NOTE: The product and the blade attachments are dishwasher safe.
4. Thoroughly dry all parts with a clean towel or allow them to air dry, ensuring the blade and other parts are completely dry to prevent rust.
5. Once all parts are clean and dry, carefully reassemble the product by attaching the lid to the food container and placing the selected blade attachment into the blade holder.
6. Store the product in a safe, dry place, ensuring the blade is protected or locked away to prevent injury.

PRECAUCIONES IMPORTANTES
