USER MANUAL Senza 86836 UNOLD

Exterior view of a tall, modern air conditioner unit with ventilation grilles and cooling fins (no visible text or symbols)

STANDVENTILATOR SENZA

Bedienungsanleitung

Instructions for use | Notice d'utilisation Gebruiksaanwijzing | Istruzioni per l'uso Instrucciones de uso | Instrukcja obsługi

Modell 86836

Impressum:

Modern kitchen appliance with digital display and bucket, no visible text or symbols

Product photo of a modern wheat bread machine with a metal basket and small kitchen utensils (no visible text or symbols)

UNOLD®

Care + Style

Product photo of a red and black electric toothbrush with a small hair clip, next to a black conical tool (no text or symbols visible)

Pink hair dryer with black handle and cord, no visible text or symbols

UNOLD®

Fan + Heat

Close-up of a desktop electric fan with mesh grille and stand (no visible text or symbols)

Red electric fan with visible blades and control panel (no text or symbols)

INHALTSVERZEICHNIS

Instructions for use Model 86836

Technical Specifications.... 14

Explanation of the symbols 14

For your safety.... 14

Explanation of the buttons.... 16

Remote control/battery replacement ..... 17

Operation....17

Cleaning and care....19

Guarantee Conditions....20

Waste Disposal /

Environmental Protection 20

Service 13

Hand inserting a keyboard into a white server tower (no text or symbols visible)

Simple line drawing of a trash bin with crossed x and y axes, no text or symbols present

Dimensions: approx. 22.0 x 30.0 x 91.0 cm (L/W/H)

Weight: approx. 5.9 kg

Degree of

protection: 11

Power cord length: approx. 180 cm

Colour: silver

Features: 4 speed levels, time preselect (1 to 8 hours), oscillation to 45^ , with remote control

Accessories: Operating instructions, remote control

Equipment features, technology, colours and design are subject to change without notice.

EXPLANATION OF THE SYMBOLS

This symbol indicates potential hazards that may result in injury or damage to the appliance.

FOR YOUR SAFETY

Please read the following instructions and keep them on hand for later reference.

Instructions for persons in the household

1. This appliance can be used by children 8 years and older, as well as by persons with reduced physical, sensory or mental abilities or with lack of experience and/or knowledge, if they are supervised or if they have been instructed with regard to safe use of the appliance and have understood the dangers that can result from use of the appliance.
2. Children must not play with the appliance.
3. Children are not allowed to perform cleaning and user maintenance, unless they are 8 years of age or older and are supervised.
4. Keep the appliance and the power cord out of the reach of children under 8 years of age.

Safety instructions for set-up and operation of the appliance

1. Only switch the appliance on when it has been properly assembled.
2. Ensure that there is sufficient space where the appliance is located. A minimum distance of 50 ~cm must be maintained between the appliance and other objects.
3. Do not use the appliance in rooms that are extremely dusty or in the vicinity of flammable substances.
4. Only connect the appliance to an AC power supply with voltage corresponding to the voltage specified on the rating plate.
5. This appliance must not be operated with an external timer or a remote control system (included remote control is not affected).
6. Never immerse the appliance or the power cord in water or other liquids - life-threatening danger!
7. Do not open the motor housing under any circumstances, there is danger of electric shock!
8. The appliance is intended for household use only, or for similar areas of use, such as in kitchenettes in businesses, offices or other workplaces, for use by guests in hotels, motels or other lodgings, in private guest houses or holiday homes.
9. Ensure that the power cord is laid out in such a manner that there is no possibility of stumbling over it.
10. To avoid damage to the cord, never wrap the power cord around the appliance.
11. To avoid damage to the cord, always unplug the mains plug from the electrical outlet by grasping the plug, never pull the power cord to unplug the appliance.
12. Ensure that the electrical outlet used is easily accessible, in order to unplug the appliance in an emergency.
13. To avoid damage to the power cord, ensure that it is not pinched or pulled over corners.
14. If possible, do not use an extension cord. If you must use an extension cord, completely unwind the extension cord and comply with the power limits of the respective extension cord.
15. Never place the appliance directly under an electrical outlet.

16. The appliance must never be used in wet/wet and cold or damp rooms - danger of electric shock!

17. Keep the appliance out of direct sunlight.

18. Never stick objects such as fingers, needles, pins, etc. through the openings into the interior of the appliance – danger of injury!
19. Check the appliance, the plug and the power cord regularly for wear or damage. If there is damage, please send the appliance for inspection and repair to our customer service organization. Unauthorised repairs can result in serious hazards for the user and void the guarantee.
20. If the power cord is damaged, it must only be repaired by the manufacturer, the manufacturer's customer service organization, or some other person with the appropriate technical qualifications to avoid hazards.
21. To avoid damage, do not use the appliance with accessories from other manufacturers or of other brands.
22. Unplug the mains plug from the electrical outlet after use and before cleaning. Never leave the appliance unattended when the mains plug is plugged in.

Never stick objects such as fingers, needles, pins, etc. through the openings into the interior of the appliance – danger of injury! Only operate the appliance on a level, stable substrate, so that it does not tip over.

The manufacturer will not be liable in the event of incorrect assembly, improper or incorrect use or if repairs are carried out by unauthorized third parties.

EXPLANATION OF THE BUTTONS

1	SpeedFor adjusting the four different speed levels
2	TimerFor selecting the time after which the appliance switches off, adjustable between 1 and 8 hours
3	ON/OFFFor switching the appliance on and off
4	OscillationFor switching the Swing Function/Oscillation On and Off
5	AnionsFor switching the ion function On and Off

REMOTE CONTROL/BATTERY REPLACEMENT

1. Carefully pull the cover of the battery compartment off of the remote control unit.
2. Insert the battery, in this process, strictly ensure that the polarity is correct; for orientation there are appropriate marks in the battery compartment.
3. If you want to insert a battery, ensure that you use type AAA batteries.
4. Close the cover.
5. If you adjust the appliance with the remote control unit, ensure that you hold it in the direction of the fan heater while you are making the settings.
6. The designations of the buttons on the remote control unit are identical to those of the buttons on the appliance.

OPERATION

1. Remove all packaging materials and any transport safeguards. Keep packaging materials away from children – danger of suffocation!
2. Ensure that the appliance is standing on a suitable, level substrate, and has been set up so that it is safe and stable.

3. Plug the power cord into an electrical outlet.

4. A short signal tone will sound, and the current temperature will be shown in the display. The „ON/OFF“ indicator light is illuminated.

5. Press the „ON/OFF“ button once. A signal tone sounds again and the appliance starts. In the basic setting the appliance runs at medium speed in Normal mode.

Setting the speed

1. Press the „Speed“ button until the appliance is working at the desired speed. The setting is shown by the respective indicator light.

Swing function/oscillation

1. Press the „Oscillation (Swing)“ button to switch on the swing function. Press the button again to stop the appliance in the current position, the fan however continues to run.

Timer

1. Via the Timer button you can select the desired runtime of the appliance. This is possible in the range from 1 hour to 8 hours. Press the „Timer“ button until the desired number of hours appears in the display. After this time elapses the appliance switches off automatically (a signal tone sounds beforehand). If you do not make a time setting, the appliance will run continuously.

Anion function

1. The anion function refreshes the ventilated air. With the anion function activated, the symbol is flashing. The anion function is always deactivated in the factory. If you want to use the anion function, you must switch it on by pressing the „ANION“ button. The negatively-charged ions that are now generated, clean the room air, dust particles are reduced. To switch off the function, press the button again.

Switching off

1. Press the „ON/OFF“ button again or the „ON/OFF“ button on the remote control unit to switch off the appliance. When you are no longer using the appliance, unplug the plug from the electrical outlet.

CLEANING AND CARE

Switch off the appliance, by pressing the "ON/OFF" button, and unplug it from the electrical outlet.

Never immerse the appliance in water. The motor or electrical components of the appliance must not get wet.

1. Never use any abrasive scouring agents, steel wool, metal objects, hot cleaning agents or disinfectants.

Hand inserting a keyboard into a white server tower (no text or symbols visible)

1. To clean the filter, open the filter cover. You can remove dust in the filter if you carefully hold a vacuum cleaner against the filter.
2. You can remove dust in the appliance if you carefully hold a vacuum cleaner against the air outlet grille or air inlet grille.
3. Wipe off the housing and grille of the fan with a slightly damp cloth.
4. Store the fan in a dry, safe place so that it is protected from dust, impact, heat and moisture.

GUARANTEE CONDITIONS

We grant a 24 months guarantee, and in case of commercial use a 12 months guarantee, starting from the date of purchase for any damage demonstrably due to manufacturing defects and when the appliance has been used according to its intended use. Within the warranty period we will remedy defective materials or workmanship through repair or replacement, at our option. Our warranty terms apply only to appliances sold in Germany and Austria. For other countries, please contact the responsible importer. In the event of a claim for remedy of defects, please send the appliance to our after sales service, properly packaged and postage paid, together with a copy of the automatically generated sales receipt, which must show the date of purchase, and a description of the defect. If the defect is covered by the warranty, the customer will be reimbursed for the shipping costs only in Germany and Austria. The warranty does not cover damage from normal wear, improper handling and failure to comply with the maintenance and care instructions. The warranty is void if repairs or modifications are made to the appliance by third parties. Any claims of the end consumer vis-à-vis the retailer are not limited by this warranty.

WASTE DISPOSAL / ENVIRONMENTAL PROTECTION

Our appliances are produced on a high quality level for a long lifetime. Regular maintenance and expert repairs by our after-sales service can extend the useful life of the appliance. If an appliance is defective and repair is not possible we ask you to follow the following instructions for disposal. Do not dispose this appliance together with your standard household waste. Please bring this product to an approved collection point for recycling of electric and electronic products. By separate collection and disposal of waste products you help to protect natural resources and ensure, that the product is disposed in an adequate way to protect health and environment.

Do not dispose of used batteries as household waste. Dispose of this product via your appliance dealer or take it to the municipal collection point.

Symbol of a trash bin with crossed lines indicating no waste or restriction, and a solid black rectangle below (no text or labels)

NOTICE D'UTILISATION MODÈLE 86836

SPÉCIFICATION TECHNIQUE

Puissance : 65-80 watts, 220-240 V\~, 50/60 Hz

Dimensions : env. 22,0 x 30,0 x 91,0 cm (L / l / h)

Poids : env. 5,9 kg

Hand inserting a keyboard into a server rack (no text or symbols visible)

CONDITIONS DE GARANTIE

Symbol of a trash bin with crossed lines indicating no waste or restriction, and a solid black rectangle below (no text or labels)

Hand inserting a keyboard into a white server tower (no text or symbols visible)

Symbol of a trash bin with crossed lines indicating no waste or discharge, and a solid black rectangle below (no text or labels)

Misure: circa 22,0 x 30,0 x 91,0 cm (lungh./largh./alt.)

Peso: circa 5,9 kg

Hand inserting a keyboard into a white computer tower (no text or symbols visible)

Symbol of a trash bin with crossed lines indicating no waste, and a solid black rectangle below (no text or labels)

Medidas: aprox. 22,0 x 30,0 x 91,0 cm (L/An/Al)

Peso: aprox. 5,9 kg

Hand inserting a keyboard into a server tower (no text or symbols visible)

Symbol of a trash bin with crossed lines indicating no waste, and a solid black rectangle below (no text or labels)

INSTRUKCJA OBSŁUGI MODEL 86836

DANE TECHNICZNE

Moc: 80 W, 220-240 V\~, 50/60 Hz

Hand inserting a card into a white server rack (no text or symbols visible)

Symbol of a trash bin crossed with a diagonal line and a horizontal bar below (no text or labels)
