USER MANUAL Breezy Swing 86634 UNOLD

Five colorful handheld fans with different colors and designs, displayed against a white background (no text or symbols visible)

HANDVENTILATOR BREEZY SWING

Bedienungsanleitung

Instructions for use | Notice d'utilisation Gebruiksaanwijzing | Istruzioni per l'uso Instrucciones de uso | Instrukcja obsługi

Modell 86630/34/36/38/39

Impressum:

Modern kitchen appliance with digital display and bucket containing food items (no visible text or symbols)

Illustration of a modern wheat bread machine with a bucket containing grain, accompanied by small kitchen utensils and a glass of milk (no text or symbols visible)

UNOLD®

Care + Style

Product photo of a red and black electric toothbrush with a curling tool, accompanied by a small gear clip (no text or symbols visible)

Close-up of a metallic mechanical device with wires and a small component (no visible text or symbols)

UNOLD®

Fan + Heat

Close-up of a desktop electric fan with visible blades and base (no text or symbols)

Red electric fan with cooling fan and control panel (no visible text or symbols)

INHALTSVERZEICHNIS

Technical Specifications....14

Explanation of the symbols.... 14

For your safety.... 14

Placing in service and charging.... 17

Operation.... 18

Cleaning and care....19

Guarantee Conditions....20

Waste Disposal/Environmental Protection ... 20

Service 13

Black and white photo of a modern office air conditioner with blue blades and red circular motion indicator (no text or symbols visible)

Dimensions: approx. 10.5 x 4.8 x 21.2 cm (W/D/H, without base)

Weight: approx. 0.17 kg (without base), 0.27 kg (with base)

Impeller: Diameter approx. 8.5 cm

Cable length: USB cable, approx. 99 cm

Rechargeable

battery: 3.7 V, 2000 mAh, DC 5/1000 mA, power 4 Watt

Housing: Plastic

Colour: 86630 white/yellow, 86634 rose/pink, 86636 green/anthracite, 86638 dark blue/medium blue, 86639 anthracite/purple

Features: OFF switch, diameter 8.5 cm, 5 speed settings, indicator light, base with oscillation 120°, running time depending on speed setting, max. 8 hours, approx. 3 hour charging time, 2 USB ports (device and base for separate charging)

Accessories: Instructions, USB charging cable without plug-in power supply

Equipment features, technology, colours and design are subject to change without notice. Errors and omissions excepted.

EXPLANATION OF THE SYMBOLS

This symbol indicates potential hazards that may result in injury or damage to the appliance.

FOR YOUR SAFETY

Please read the following instructions and keep them on hand for later reference.

Instructions for persons in the household

1. This appliance can be used by children 8 years and older, as well as by persons with reduced physical, sensory or mental abilities or with lack of experience and/or knowledge, if they are supervised or if they have been instructed with regard to safe use of the appliance and have understood the dangers that can result from use of the appliance.

2. Children must not play with the appliance.

3. Children are not allowed to perform cleaning and user maintenance, unless they are 8 years of age or older and are supervised.

4. Keep the appliance and the power cord out of the reach of children under 8 years of age.
5. Keep the appliance out of the reach of children.

Note: The appliance is delivered without plug-in power supply/USB charger. However, to charge the appliance it must be connected to the mains supply via a USB charger. In this regard the following instructions for dealing with electricity apply:

1. Strictly comply with the safety operating instructions for the respective USB charger.
2. When connecting the USB charger, ensure that the mains voltage meets the specified requirements of the charger.
3. The USB charger must not be operated with an external timer or a remote control system.

4. Only charge the appliance with the USB charger indoors.

5. Protect USB charger from wetness, heat and direct sunlight.

6. Always ensure that the charging cable is laid out its entire length to prevent damage due to overheating.

7. Unplug the charging cable from the electrical outlet only by grasping and unplugging the plug-in power supply. Do not, under any circumstances, pull directly on the charging cable.
8. Unplug the USB charger from the mains supply, when it is not required.
9. When you put the appliance away for storage purposes, do not, under any circumstances wrap the charging cable around the appliance. Wrapping the power cord around the appliance can damage the power cord. Disconnect the charging cable from the appliance when the appliance is completely charged.
10. As long as the plug-in power supply of the USB charger is in the electrical outlet, even if the appliance is switched off, the appliance poses a hazard in the vicinity of water.
11. Do not, under any circumstance, touch the plug-in power supplies with wet hands.

12. Do not insert any objects into the appliance. There is danger of electric shock due to appliance damage.

13. Ensure that you do not damage the rechargeable battery in the appliance, e.g. through falling, impact or vibration. Do not continue to use a damaged rechargeable battery. If in doubt, contact our customer service organisation.

14. Recharge the battery on a regular basis to avoid deep discharge, and thus a possible appliance defect.
15. Attention: The provided charging cable is not suitable for data transmission!
16. If liquid should escape from the rechargeable battery, put on protective gloves immediately before handling the appliance. Do not continue to use the appliance. Avoid contact with skin and eyes. Should skin or eye contact nevertheless occur, seek medical attention immediately. The appliance is intended for personal use only; it is not designed for commercial requirements.

Safety instructions for safe operation of the appliance

1. Do not use the appliance in rooms that are extremely dusty or in the vicinity of flammable substances.
2. Do not, under any circumstances, operate or charge the appliance if it has been brought from a cold environment into a warmer environment. In such a situation condensation can occur that can damage the appliance. Wait until the appliance has reached room temperature before using it.
3. Never open the housing of the appliance. This could damage the rechargeable battery.
4. The appliance is intended for household use only, or for similar areas of use, such as,

■ in kitchenettes in businesses, offices or other workplaces,
■ for use by guests in hotels, motels or other lodgings,
■ in private guest houses or holiday homes.

1. To avoid damage to the charging cable, ensure that it is not pinched or pulled over corners.

2. Do not, under any circumstances, stick fingers or objects, such as needles, pins, etc. through the basket grille into the interior of the appliance – danger of injury!

3. Ensure that long hair cannot be caught by the impeller.
4. Check the appliance, the plug and the charging regularly for wear or damage. If the charging cable or other parts are dama-

ged, please send the appliance for inspection and repair to our customer service organisation. Unauthorised repairs can result in serious hazards for the user and void the warranty.

1. To avoid damage, do not use the appliance with accessories of other manufacturers or brands.

2. Unplug the mains plug of the charger after use and before cleaning. Do not, under any circumstances, leave the appliance unattended when the mains plug is plugged in.

Do not, under any circumstances, stick fingers or objects, such as needles, pins, etc. through the openings into the interior of the appliance – danger of injury!

The manufacturer will not be liable in the event of incorrect assembly, improper or incorrect use or if repairs are carried out by unauthorized third parties.

PLACING IN SERVICE AND CHARGING

1. Remove all packaging materials and transport safeguards. Keep the packaging material, such as plastic bags or Styrofoam away from small children – danger of suffocation!
2. Ensure that the applanc e is switched off.
3. Place the fan on the base. Connect the charging cable to the charging connector of the appliance or to the charging connector of the base. Connect the other end of the charging cable to a USB charger.
4. Plug the plug of the USB charging cable into an electrical outlet (220-240 V\~50 Hz).
5. Ensure that all cables are correctly connected, otherwise the appliance cannot be correctly charged.
6. The indicator light on the appliance illuminates red; it indicates that the appliance is being charged. As soon as the charging process is concluded (duration approx. 3 h) the indicator light will go out.

7. To prevent damage of the rechargeable battery, the appliance should not be charged longer than 12 hours.

8. You can use the appliance on level 1 for approx. 8 ~h , level 2 for approx. 4 ~h and level 5 for approx. 2 ~h , before it must be recharged. The maximum capacity of the rechargeable battery is only achieved after multiple charging processes.

9. Only recharge the appliance when the rechargeable battery is completely discharged. Thus the full capacity of the rechargeable battery remains intact for a longer period of time.

10. Tips: The appliance can also be charged with a different USB charging cable, as long as the USB charging cable meets the technical specifications. If in doubt, contact our technical customer service organisation.

11. It is also possible to connect the supplied charging cable to a USB port of a computer or power bank and charge the appliance in this manner. However, for technical reasons this charging process can take a very long time; consequently we recommend charging with a USB charger. When using a power bank, follow all instructions of the manufacturer of the power bank.

OPERATION

1. Ensure that the app liance is charged.

2. Without the base the appliance can be used as a hand-held fan; with the base it can be used as a table fan.

3. The appliance can also be used while it is being charged.

4. Switch on the appliance via the ON/OFF switch on the right side of appliance.
5. Now select the desired speed level on the ON/OFF switch. Five speed levels are available (low, medium, high).
6. The respective indicator light illuminates blue and indicates that the appliance is in operation.
7. Note: If the indicator light is flashing blue, it means that the battery must be recharged. Recharge the battery as soon as possible.

Black and white photo of a modern office air conditioner with a circular fan and red motion rings (no text or symbols visible)

1. Oscillation can be used when the appliance with base is used as a table fan. Place the fan in the base.
2. Press the oscillation button on the base. The device begins to swing back and forth. Press the button again to switch off the oscillation.
3. Switch off the appliance via the ON/OFF switch, when you are not using it.

CLEANING AND CARE

Switch off the appliance.

Wait until the appliance has come to a complete standstill.

Do not, under any circumstances, immerse the appliance in water. The motor or electrical components of the appliance must not get wet.

1. Never use any abrasive scouring agents, steel wool, metal objects, hot cleaning agents or disinfectants.
2. Wipe off the housing and grille of the fan with a slightly damp cloth.
3. Store the fan in a dry, safe place so that it is protected from dust, impact, heat and moisture. We recommend that you store the original packaging and stow the appliance in the original packaging when the appliance is not needed.

GUARANTEE CONDITIONS

We grant a 24 months guarantee, and in case of commercial use a 12 months guarantee, starting from the date of purchase for any damage demonstrably due to manufacturing defects and when the appliance has been used according to its intended use. Within the warranty period we will remedy defective materials or workmanship through repair or replacement, at our option. Our warranty terms apply only to appliances sold in Germany and Austria. For other countries, please contact the responsible importer. In the event of a claim for remedy of defects, please send the appliance to our after sales service, properly packaged, together with a copy of the automatically generated sales receipt, which must show the date of purchase, and a description of the defect. You can print out a return receipt on our website www.unold.de/ruecksendung. (only for entries from Germany and Austria). The warranty does not cover damage from normal wear, improper handling and failure to comply with the maintenance and care instructions. The warranty is void if repairs or modifications are made to the appliance by third parties. Any claims of the end consumer vis-à-vis the retailer are not limited by this warranty.

WASTE DISPOSAL / ENVIRONMENTAL PROTECTION

Our appliances are produced on a high quality level for a long lifetime. Regular maintenance and expert repairs by our after-sales service can extend the useful life of the appliance. If an appliance is defective and repair is not possible we ask you to follow the following instructions for disposal. Do not dispose this appliance together with your standard household waste. Please bring this product to an approved collection point for recycling of electric and electronic products. By separate collection and disposal of waste products you help to protect natural resources and ensure, that the product is disposed in an adequate way to protect health and environment.

Do not dispose of used batteries as household waste. Dispose of this product via your appliance dealer or take it to the municipal collection point.

NOTICE D'UTILISATION MODÈLE 86630/34/36/38/39

SPÉCIFICATION TECHNIQUE

Black and white photo of a modern office air conditioner with a spool, mounted on a stand (no visible text or symbols)

CONDITIONS DE GARANTIE

Black and white photo of a modern office fan with a black body and blue blades, mounted on a stand with red circular motion indicators (no text or symbols visible)

Black and white photo of a modern office fan with a black body and blue blades, mounted on a black base (no visible text or symbols)

Black and white photo of a UNO OVO air conditioner fan with a red circular base (no text or symbols visible)

Black and white photo of a modern office air conditioner with a blue fan and black base (no visible text or symbols)
