USER MANUAL DOM507 LIVOO

Black portable grill with open doors and a grating on top (no visible text or symbols)

Livoo

-ÜrsÈoë : v.1.1

A

1P A UPp B 3P APp cPppNP p âP 8P

Figure 1

Attention surface chaude!

Symbol of a trash bin crossed with no text or labels, accompanied by a black rectangular block below (no readable text or symbols)

Thank you for choosing a Livoo product!

EN

Your blender, your barbecue, and your headphones are not just objects, they are extensions of yourself, allowing you to get closer to your friends and family, to bring them together, to laugh and to share experiences. Livoo's aim is to help you live your life to the fullest, whatever wishes you have throughout the year. Winter raclette, summer barbecue. Or the other way around. It's up to you. Take advantage of this freedom for feel good moments every day.

That's why we're constantly innovating and creating clever products full of zest, but most of all, accessible.

Find our entire collection on our website www.livoo.en.

Livoo, your daily companion till social networks

@Livoo

@livoo_officiel

@Livoo

Safety Instructions

Please, take time to read well the instruction sheet before the first use and keep them for a future use.

A misuse of the appliance can damage it or hurt the user. Assure that you use the appliance for the use for which it is designed. We refuse any responsibilities as for the damages by an incorrect use or a bad manipulation.

1. ChÜßã that your õαÈë voÉtaùÜ ßorrÜspoëds to that statÜd oë thÜ appÉÈaëßÜ.
2. ThÜ saòÜty ÈëstrußtÈoës do ëot üy thÜösÜÉvÜs ÜÉÈõÈëatÜ aëy daëùÜr ßoõpÉÜtÜÉy aëd propÜr αßßÈdÜët prÜvÜëtÈoë õÜasurÜs õust αÉways üÜ usÜd.
3. ÎÜvÜr ÉÜavÜ thÜ appÉÈaëßÜ uësupÜrvÈsÜd whÜë Èë usÜ.
4. KÜÜp thÜ appÉÈaëßÜ aëd Èts ßord out oò rÜaßh oò ßhÈÉdrÜë ÉÜss thaë 8 yÜars.
   ç. ChÈÉdrÜë shaÉÉ ëot pÉay wÈth thÜ appÉÈaëßÜ.
5. CÉÜaëÈëù aëd usÜ õaÈëtÜëaëßÜ shaÉÉ ëot üÜ õadÜ üy ƒhÈÉdrÜë uëÉÜss thÜy arÜ oÉdÜr thaë 8 yÜar aëd supÜrvÈsÜd.
   â. ThÈs appÉÈaëßÜ ßaë üÜ usÜd üy ßhÈÉdrÜë aùÜd òroõ 8 yÜars aëd aüovÜ aëd pÜRsoës wÈth rÜdußÜd physÈßaÉ, sÜësory or õÜëtaÉ ßapaüÈÉÈtÈÜs or Éaßã oò ÜxpÜrÈÜëßÜ aëd ãëowÉÜdùÜ Èò thÜy hav üÜÜë ùÈvÜë supÜrvÈsÈoë or ÈëstrußtÈoë ßoëßÜrëÈëù usÜ oò thÜ appÉÈaëßÜ Èe a saòÜ way aëd uëdÜRstaëd thÜ hazards ÈëvoÉvÜd
6. "ò thÜ suppÉy ßord Ès daõaùÜd, Èt õust üÜ rÜpÉaßÜd üy thÜ õaëuòaßturÜr, Èts sÜrvÈßÜ aùÜët

or sÈõÈÉarÉy quaÉÈòÈÜd pÜRsoës Èë ordÜR to avoÈd a hazard (*à.

ê. Do ëot pass thÜ ßord ovÜR oü-Üßts wÈth sharp ÜdùÜs aëd äÜÜp Èt at a dÈstaëßÜ òroõ, hot oü-Üßts aëd üarÜ òÉaõÜs. AÉways puÉÉ oë thÜ pÉuù to dÈsßoëëÜßt Èt òroõ thÜ òÜÜd sourßÜ

1. MaãÜ surÜ that thÜ ßord or thÜ ÜxtÜësÈoë ßaüÉÜ Ès ëot at rÈsã oò üÜÈëù puÉÉÜd ÈëadvÜrtÜëtÉy ëor oò üÜÈëù toppÜd ovÜr üy aëyoëÜ at thÜ tÈõÜ oò usÜ

2. \~hÜë you usÜ aë ÜxtÜësÈoë ßaüÉÜ. õaãÜ surÜ that Èt Ès adaptÜd to thÜ appÉÈaëßÜ ÜssÜëtÈaÉ BoësuõptÈoë. Coëtrary to thÈs, thÜ ÜxtÜësÈoë ßaüÉÜ aëd/ or thÜ pÉuù rÈsãs ovÜrhÜatÈëù.

3. OëÉy usÜ thÜ appÉÈaëßÜ òor doõÜstÈß purposÜs aëd Èë thÜ way ÈëdÈßatÜd Èë thÜ ÈëstrußtÈoës.

4. ÎÜvÜr ÈõõÜrsÜ thÜ üasÜ oò your appÉÈaëßÜ Èë watÜr or aëy othÜr ÉÈquÈd òor aëy rÜasoë whatsoÜvÜr. ÎÜvÜr pÉaßÜ Èt Èëto thÜ dÈshwashÜr.

5. "ë BasÜ thÜ appÉÈaëßÜ aßßÈdÜëtaÉÉy òaÉÉs Èëto watÜr dÈsßoëëÜßt Èt ÈõõÜdÈatÜÉy. "avÜ Èt RßhÜßãÜd üy aë ÜxpÜrt üÜðorÜ rÜ-usÈëù, Èò you do ëot do thÈs you ruë thÜ rÈsã oò ÜÉÜßtroßutÈoë.

1ç. ÎÜvÜr try to opÜë thÜ βasÈëù yoursÜÉò

1. Do ëot usÜ thÜ appÉÈaëßÜ Èò your haëds arÜ daõp Èò thÜ oÈÉ Ès wÜt, or Èò thÜ appÉÈaëßÜ ÈtsÜÉò i daõp

là. Do ëot toußh thÜ pÉuù Èò your haëds arÜ daõp or wÜt

1. ÎÜvÜr usÜ thÜ appÉÈaëßÜ ëÜar hot suròaßÜs.

1ê. ÎÜvÜR usÜ aßßÜssorÈÜs that arÜ ëot rÜßoõõÜëdÜd üy thÜ produßÜR. ThÜy βouÉd BoëstÈtutÜ a daëùÜR to thÜ usÜr aëd rÈsã to daõaùÜ thÜ appÉÈaëßÜ.

1. Do ëot puÉÉ thÜ ßord to õovÜ thÜ dÜvÈßÜ. Do ëot wrap thÜ ßord arouëd thÜ dÜvÈßÜ aëd do ëot üÜëd Èt.

2. PÉaßÜ thÜ dÜvÈßÜ oë a òÉat, staüÉÜ, hÜatzrÜsÈstaët suròaßÜ.

3. 'ëpÉuù thÜ appÉÈaëßÜ whÜë ëot Èe usÜ.

4. "t Ès aüsoÉutÜÉy ëÜßÜssary to äÜÜp thÈs appÉÈaëßÜ BÉÜaë at aÉÉ tÈõÜs as Èt BoõÜs Èëto dÈrÜßt Boëtaßt wÈth òood.

5. MaãÜ surÜ thÜ appÉÈaëßÜ Ès uëpÉuùùÜd üÜðorÜ ÈësÜrtÈëù, rÜõovÈëù or ßÉÜaëÈëù oëÜ oò thÜ aßßÜssorÈÜs. "t Ès aüsoÉutÜÉy ëÜßÜssary to rÜõovÜ thÜ aßßÜssorÈÜs üÜðorÜ ßÉÜaëÈëù thÜõ.

2ç. LÜt BooÉ aëd ãÜÜp out thÜ aßßÜssorÈÜs üÜðorÜ ßÉÜaëÈëù thÜõ
26. ThÜ appÉÈaëßÜ Ès ëot ÈëtÜëdÜd to üÜ opÜratÜd üy õÜaës oò ÜxtÜrëaÉ tÈõÜr or sÜparatÜ rÜõotÜ ßoëtroÉ systÜõ.A
2â. KÜÜp thÈs õaëuaÉ wÈth thÜ appÉÈaëßÜ. "ò thÜ appÉÈaëßÜ Ès to üÜ usÜd üy a thÈrd party, thÈs ÈëstrußtÈoë õaëuaÉ õust üÜ suppÉÈÜd wÈth Èt.
28. ÎÜvÜR βarry thÜ appÉÈaëßÜ whÈÉÜ stÈÉÉ hot
2ê. ThÈs appÉÈaëßÜ Ès ÈëtÜëdÜd to üÜ usÜd Èë housÜhoÉd aëd sÈõÈÉar appÉÈßatÈoës sußh as:

• staòò ãÈtßhÜë arÜas Èë shops, oòòÈßÜs aëd othÜr worâÈëù ÜëvÈroëõÜëts
• òarõ housÜs
• üy ßÉÈÜëts Èë hotÜÉs, öotÜÉs aëd othÜr rÜsÈdÜëtÈaÉ typÜ ÜëvÈroëõÜëts

• üÜd aëd ürÜaãòast typÜ ÜëvÈroëõÜëts

• \~arëÈëù: CharßoaÉ or sÈõÈÉar ßoõüustÈüÉÜ òuÜÉs õust ëot üÜ usÜd wÈth thÈs appÉÈaëßÜ.

• ThÜ appÉÈaëßÜ shaÉÉ üÜ suppÉÈÜd throuùh a RCD ëot ÜxßÜÜdÈëù 30õA.

• CÉass " appÉÈaëßÜs shaÉÉ üÜ ßoëëÜßtÜd to soßãÜt: outÉÜt havÈëù aë ÜarthÈëù ßoëtaßt.

• The supply cord shall be regularly examined for signs of damage and the appliance is not to be used if the cord is damaged.

• Always fill the grill pan with water before you switch on the appliance. The water helps to cool down the grill pan, reduces the buildup of smoke, and also facilitates cleaning.

• Ensure that the water level is kept between the 'Min.' and 'Max.' markings at all times during use.

WATER MAX 0.9L MIN 0.4L

—Max. water level indicator

—Min. water level indicator

The water level indicator can be found inside the tank.

1. The appliance must not be used without water

2. Regarding the instructions for cleaning with food, thanks to refer to the below paragraph of the manual surfaces in contact.

3. The temperature of accessible surfaces may be high when the appliance operating.

(*) Competent qualified electrician: after sales department of the producer or importer or any person who is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. "n any case you should return the appliance to this electrician.

Caution hot surface!

Surfaces are liable to get hot during use.

Technical Specifications

Voltage: 230V\~50Hz

Power: 2200w

õefore using for the first time

Remove any packaging materials from the appliance. Clean the tank, tray salvage dealer of fat and the grill pan. The tank must be filled with water up between MIN and MAX marking, never fill water on the heating element, it will damage it. Plug the appliance. Let the grill heat up for a moment without any food, this will reduce the smell when first switching on a new grill.

cssembly: check picture 1

Use of the device

Caution: do not, under any circumstances, cover the grill rack with aluminous foil, barbecue dishes or other items, as the resulting build-up of heat could cause irreparable damage to the grill.

When grilling food with a high fat or moisture content, splashes are not always avoidable.

Iways ensure that the water level is kept above the 'Min.' mark so add water during the heating to keep right level and ensure that it does not come into contact with the heating element.

Before the grill is used, always check that the heating element is correctly fitted in the grill pan and safely locked. Do not connect the grill to mains power until the grill pan has been filled with water. The tray salvage dealer of fat must be immersed and take care of not pour water on the heating element.

Use only the supplied tray salvage dealer of fat.

Ensure that the grill is not stored outdoors. Or in any other location where it might be subjected to extremes of temperature or high humidity.

1. The tank must be filled with water up between MIN and MAX marking, never fill water on the heating element, it will damage it. Plug the appliance.
2. Set the thermostat control knob on the temperature MAX and after 5-10 minutes, heating element is ready. The indicator light turns on and off during the heating, the temperature is maintained.
3. The water in the tank will evaporate during use. So you must to fill up water from time to time. Be careful not to pour water on the heating element.
4. When you grilling the food stuffs, you have to return them sometimes with adapted accessories and you can choose the temperature you want.
5. The grill can also be used to keep the food warm: by turning the thermostat control knob back to a lower position or by using the keep warn grill of the windshield.
6. When grilling is finished, turn the thermostat to "0" (off position) and disconnect the grill from the mains supply socket.

ãleaning and maintenance

Caution: Do not use wire brush or any abrasive items or liquids to clean the appliance.

Always remove the plug from the socket before cleaning the barbecue. Ensure that the appliance has completely cooled down;

Then you should remove thermostat control knob and heating element from the tank, never immerse them in water. Never switch the heating element on when it is not placed onto the appliance. Clean the tank, tray salvage dealer of fat and the grill pan with warm soapy water and dry afterwards.

Use damp cloth to clean the heating element. Do not use dishwasher. After cleaning, the grill should be stored indoors in a dry location.

Symbol of a trash bin crossed with two crossed lines, no text or labels present

correct disposal of the unit 'electrical and electronic equipment).

(Applicable in the European Union and the rest of Europe that have adopted separate collection systems countries). The European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in the normal household waste stream. Old appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain and reduce the impact on human health and the environment. The symbol of the crossed out dustbin is marked on all products to remind the obligations of separate collection. Consumers should contact their local authority or retailer for information concerning the correct disposal of their product.

• Non contractual illustration
- Product information is suü-ect to change without prior notice.
