Product type	Smartphone
Brand	Motorola
Model	Edge 50 Neo
Model number	XT2409-1
Power supply	USB-C Power Delivery charging (68 W max), Qi wireless charging
Resistance	IP68 (immersion up to 1.5 m for 30 minutes)
Connectivity	5G, Wi-Fi, Bluetooth, NFC, GPS
Sensors	Fingerprint, proximity, accelerometer, gyroscope
Rear camera	Main + ultra-wide/macro + telephoto
Front camera	Yes
Operating system	Android
Safety	Military standard MIL-STD-810H, SAR information via *#07#
Operating temperature	-20°C to 45°C
Storage temperature	-20°C to 60°C
Care	Avoid immersion in liquids other than fresh water, do not charge when wet
Repairability	Non-removable battery, authorized service required for replacement
SIM compatibility	Nano SIM + eSIM
Support	Settings > Help, www.motorola.com/mymotoedge

Frequently Asked Questions - Edge 50 Neo MOTOROLA

How to insert the SIM card?

Use the provided tool to eject the SIM tray. Insert the Nano SIM card with gold contacts facing up, then close the tray. The device also supports eSIM.

Is the phone water resistant?

Yes, it is IP68 certified, resistant to immersion up to 1.5 meters of fresh water for 30 minutes. Avoid pressurized water and other liquids.

How to charge wirelessly?

Place the phone on a Qi-certified wireless charger (sold separately). The charging area is on the back of the device.

How to check the SAR?

Dial *#07# on the keypad or go to Settings > Search 'Regulatory labels'.

What is the maximum charging power?

The maximum wired charging is 68 W with a compatible USB-C Power Delivery charger (sold separately). Qi wireless charging is also supported.

Can I use a 3.5 mm headset?

Yes, with a USB-C to 3.5 mm jack adapter (sold separately). The USB-C port is used for both charging and audio.

How to turn off the phone?

Press and hold the Power and Volume Up buttons simultaneously until the phone turns off.

What to do if the screen is unresponsive?

Press and hold the Power button until the screen turns off and the phone restarts. This forces a restart.

Where to find help?

Swipe up on the home screen, then tap Settings > Help. You can also visit www.motorola.com/mymotoedge.

Is the phone 5G compatible?

Yes, it supports 5G. A 5G plan and network coverage are required. It is not compatible with all 5G networks.

USER MANUAL Edge 50 Neo MOTOROLA

motorola edge 50 neo

English 3

Deutsch 8

Français....13

Español....18

Português.... 23

Italiano 28

Nederlands 33

Suomi....38

Polski 43

Scan with your Camera app for how-to videos.

Let's get started

Before using your phone, please read the legal, safety and regulatory information provided with your product.

Caution: screen protectors may reduce your phone's touchscreen sensitivity. Do not use screen protectors thicker than 0.5mm.

^1 Use a headset: to use a headset, you'll need one with a USB-C connector. If you're using a 3.5mm headset, you'll need an adapter to connect a 3.5mm connector to USB-C. Headset and adapter may be sold separately.

Water, splash and dust resistance. Water, splash and dust resistance were tested to IP68 standards under controlled laboratory conditions. Withstands immersion in up to 1.5 metres of fresh water for up to 30 minutes. Resistance will decrease as a result of normal wear. Not designed to work while submerged underwater. Do not expose to pressurised water or liquids other than fresh water. Do not attempt to charge a wet phone. Not waterproof. For more about your phone's water-resistant design and care, swipe up and tap Settings > Help.

^2 Wireless charging: charge your phone using a Qi-certified wireless charger (sold separately).

Put in the card and power on

1 Insert the SIM tool into the hole next to the SIM card tray to pop out the tray.

Make sure you use the correct size of SIM card and don't cut the SIM card.

2 Insert the SIM card with the gold contacts up, then gently push the tray into the slot.

eSIM option: your phone may support an eSIM (embedded SIM card) in addition to the physical SIM card. Contact your service provider for details if you want to activate and use it.

Connect with 5G: 5G service plan and 5G network coverage required; available only in selected areas; device not compatible with all 5G networks. Contact your service provider for details.

3 Press and hold the power button ⏻ to turn on your phone, then follow the prompts to get started.

To turn off your phone, press the power and volume up buttons ⏻ + ⏻+ at the same time.

Help and more

Get answers, updates and info:

• Help is here: from the Home screen, swipe up and tap Settings > Help to learn how to use your phone and get support.
  • Get more: get software, user guides and more at www.motorola.com/mymotoedge.
  • Get apps: tap Play Store to browse and download apps.

Legal information. This guide provides important legal, safety and regulatory information that you should read before using your product. For the complete legal information, from the Home screen

swipe up and tap Settings > Q then type Legal information or visit www.motorola.com/device-legal.

Reliability. This device passed testing against the US Department of Defense's MIL-STD-810H standard, which establishes a methodology for testing products against environmental stresses under controlled laboratory conditions. Such testing is not a guarantee of future performance under these test conditions. Abuse, like that contained in MIL-STD-810H testing, is not covered under Motorola's standard warranty.

Charging and battery safety. To prevent possible burning and injury, the battery in your phone should only be removed by a Motorola-approved service centre or similar skilled personnel. If your phone becomes unresponsive, press and hold the power button until the screen goes dark and your phone restarts.

The phone is PD (Power Delivery) capable. For the fastest charging speeds, charge your phone using a Motorola 68W or higher USB-C PD charger (may be sold separately) with the included PD cable. Use of other chargers is not recommended and may impair the charging performance. The power delivered by the charger must be between the min 5 Watts required by the radio equipment and the max 68 Watts to achieve the fastest charging speed. Chargers that do not comply with applicable national standards may be unsafe, with risk of death or injury, and may cause slow charging or product damage. Don't charge your phone in temperatures below -20°C or above 45°C. To view applicable standards and to learn more, see the "Legal information" section of this guide or visit www.motorola.com/device-legal.

Warning about high volume usage. To prevent possible hearing damage, do not listen at high volume levels for long periods. When your headset volume reaches the high volume threshold, a warning will be shown. Tap OK to dismiss it, or wait one to five seconds, then press the volume up button to dismiss the alert and enable the volume to continue to be adjusted.

Disposal and recycling. For help recycling products and packaging responsibly, visit www.motorola.com/recycling.

Extreme heat or cold. Don't use your phone in temperatures below -20°C or above 45°C. Don't store/transport your phone in temperatures below -20°C or above 60°C.

Legal disclaimers. Features, services and applications are network dependent and may not be available in all areas; additional terms/charges may apply. Product specifications and other information contained in this guide are believed to be accurate at the time of printing or release. Motorola reserves the right to correct or change any information without notice.

Arbitration. Your purchase is governed by a binding arbitration clause. For more information and how to opt out, see the legal guide that came with your phone.

SAR information (on e-label). To view specific absorption rate (SAR) values for this phone, from the Home screen swipe up and tap Settings > Q, then type Regulatory labels, from your phone's dial pad, type *#07#, or visit www.motorola.com/sar.

Supported frequencies and power (Model XT2409-1). This phone is capable of operation on the following frequencies, subject to location and network availability.

Operating mode	Frequency range MHz/band	Maximum nominal transmit power dBm
Bluetooth	2400 - 2483.5	20 dBm EIRP
Wi-Fi	2400 - 2483.5	20 dBm EIRP
Wi-Fi	5150 - 5250/5925 - 6425	23 dBm EIRP
Wi-Fi	5250 - 5350/5470 - 5725	20 dBm EIRP
Wi-Fi	5725 - 5850	14 dBm EIRP
GPS	1164 - 1215/1559 - 1610	N/A
NFC	13.56	-17.23 dBuA/m @ 10m
WPT	110 - 148 KHz	N/A
GSM	2*/3*/5/8	33/30*
UMTS	1/2/4/5/8	24
LTE	1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28/32/38/39/40/41*/42/43/66	23/26*
5G	n1/2/3/5/7/8/20/26/28/38/40/41/66/75/77*/78*	23/26*

Copyright and trademarks. MOTOROLA, the stylised M logo, MOTO and the MOTO family of marks are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. Google, Android, Google Play and other related marks and logos are trademarks of Google LLC. USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum. All other product or service names are the property of their respective owners.

© 2024 Motorola Mobility LLC. All rights reserved.

Product ID: motorola edge 50 neo (Model XT2409-1)

Manual number: 711608084211-A
